Summary of Contents for Toshiba ML2-EC09SAIT(BS)
- Page 1 INSTRUCTION MANUAL MICROWAVE OVEN ML2-EC09SAIT(BS) Please review this instruction manual before operating.
-
Page 2: Table Of Contents
CONTENTS PRODUCT SAFETY Precautions to avoid possible exposure to excessive microwave energy ........EN-01 Important safety instructions ........................EN-03 Grounding instructions ........................... EN-07 Radio interference ............................EN-09 Utensils .................................. EN-10 Materials you can use in microwave oven ....................EN-11 Materials can not be used in microwave oven ..................EN-13 PRODUCT SETTING Setting up your oven ............................ - Page 3 7. Combination cooking ..........................EN-23 8. Speedy cooking ............................EN-24 9. Convection without preheat ........................EN-24 10. Convection with preheat ........................EN-25 11. Auto menu ..............................EN-26 12. Air fry................................EN-28 13. Pro defrost ..............................EN-28 Mute mode ..............................EN-30 CLEANING ..............................
-
Page 4: Product Safety
PRODUCT SAFETY PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a). Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 5: Specifications
SPECIFICATIONS MODEL ML2-EC09SAIT(BS) 120VAC RATED VOLTAGE RATED FREQUENCY 60Hz RATED INPUT(Microwave) 1400W RATED OUTPUT(Microwave) 900W RATED INPUT(Grill) 1000W RATED INPUT(Convection) 1800W All pictures in this manual are for illustrative purposes only; these may be slightly different from the purchased equipment, please refer to the NOTE actual product. -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances basic safety precautions should be followed, including the following. To reduce the risk of burns, electric shock, WARNING fire, injury to persons or exposure to excessive microwave energy. HOT CONTENTS CAN Read all instructions before CAUSE SEVERE BURNS. - Page 7 IMPORTANT SAFETY INSTRUCTIONS Liquids, such as water, removing the container. coffee, or tea are able 5. Use extreme care when to overheat beyond the inserting a spoon or boiling point without other utensil into the appearing to be boiling. container. Visible bubbling or boiling when the container is removed from the...
- Page 8 IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of fire in Some products such as the oven cavity: whole eggs and sealed 1. Do not overcook containers, for example, food. Carefully attend closed glass jars are able to appliance when explode and should not be paper, plastic, or other heated in this oven.
- Page 9 IMPORTANT SAFETY INSTRUCTIONS Do not let cord hang over Use this appliance only edge of table or counter. for its intended use as described in the manual. Do not use corrosive Do not use paper products chemicals or vapors in when appliance is operated this appliance.
-
Page 10: Grounding Instructions
GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. - Page 11 GROUNDING INSTRUCTIONS Electric Shock Hazard: Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded. 1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
-
Page 12: Radio Interference
RADIO INTERFERENCE 1. Operation of the microwave oven may cause interference to your radio, TV or similar equipment. 2. When there is interference, it may be reduced or eliminated by taking the following measures: (1). Clean door and sealing surface of the oven. (2). -
Page 13: Utensils
UTENSILS Personal Injury Hazard: Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave CAUTION oven." There may be certain non-metallic utensils that are not safe to use for microwaving. -
Page 14: Materials You Can Use In Microwave Oven
MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause Browning dish the turntable to break. Microwave-safe only. Follow manufacturer’s instructions. - Page 15 MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food. Plastic wrap Microwave-safe only (meat and candy thermometers). Thermometers Use as a cover to prevent splattering and retain moisture.
-
Page 16: Materials Can Not Be Used In Microwave Oven
MATERIALS CAN NOT BE USED IN MICROWAVE OVEN UTENSILS REMARKS May cause arcing. Transfer food into microwave-safe dish. Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle Metal shields the food from microwave energy. Metal trim may cause arcing. -
Page 17: Product Setting
PRODUCT SETTING SETTING UP YOUR OVEN NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES Remove the oven and all materials from the carton and oven cavity. Cookbook Glass Turntable Turntable Ring Assembly Air Fry Tray Lower Wire Rack Higher Wire Rack ( Can not be used in (Cannot be used in ( Can not be used in... - Page 18 SETTING UP YOUR OVEN NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES Oven cavity Observation window The button of Control panel opening the door (Note: In any mode, you should press upwards the button rst, then pull the handle to open the door.) Safety interlock system Door assembly...
-
Page 19: Turntable Installation
SETTING UP YOUR OVEN TURNTABLE INSTALLATION Cleaning the cooking compartment and putting the turntable in place. For new installations, make sure all packaging and shipping tape has been removed from the turntable shaft. Before using the appliance to prepare food for the first time, you will need to put the turntable in place correctly. -
Page 20: Countertop Installation
COUNTERTOP INSTALLATION Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective lm found on the microwave oven cabinet surface. Do not remove the waveguide cover that is attached to the oven cavity to protect the magnetron. -
Page 21: Instruction For Use
INSTRUCTION FOR USE BEFORE USING FOR THE FIRST TIME The appliance may produce unpleasant odors when it is used for the first time. This section tells you what you need to do before using your microwave to prepare food for the first time. -
Page 22: Operation
OPERATION CONTROL PANEL AND FEATURES Microwave Broil Convection Pro Defrost Auto Menu Child Lock Clock Temperature Strip EN-19... -
Page 23: Clock Setting
This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking. 1. CLOCK SETTING In waiting state, press " Kit.Timer/Clock " twice, The hour figures will flash. Turn the parameter knob to set the hour gures. Press "... -
Page 24: Kitchen Timer Setting
LEVEL POWER DISPLAY Press the " Microwave " key once, "P100" displays. Turn parameter knob or press "Microwave" key repeatedly to set the power level .The 10 power levels are available. Press " " to confirm . Turn parameter knob to set the cook time. Press "... -
Page 25: Lock Function
Press " " to confirm. The timer starts counting down. • The kitchen timer is a timer. • During kitchen timer, any program cannot be set. NOTE 4. LOCK FUNCTION In waiting state, You can use this function to prevent children from accidentally turning the oven To activate the lock: In waiting state, press and hold "... -
Page 26: Combination Cooking
Press " " to confirm. Turn the parameter knob to set the cooking time. The maximum time value is "95:00". Press " " to start cooking. • The buzzer will sound to remind you to turn over the food during grilling. If there is no operation, it will keep on working. -
Page 27: Speedy Cooking
• In the combination cooking state, each more press on “ ” can increase the cooking time by 30 seconds. NOTE 8. SPEEDY COOKING In waiting state, press " " to cook food with 100% power level for 30 seconds. Each press on the same key can increase 30 seconds and the maximum time value is "95 min". -
Page 28: Convection With Preheat
• In the convection cooking state, each more press on “ ” can increase the cooking time by 30 seconds. NOTE 10. CONVECTION WITH PREHEAT In waiting state, press " Convection " once, "350 F" will display. Turn parameter knob to set the temperature, " 100 F, 150 F, 250 F, 275 F, 300 F, 325 F, 350 F, 375 F, 400 F, 425 F "... -
Page 29: Auto Menu
11. AUTO MENU (A01-A07 and A10-A11) Turn parameter knob right and then “ A01” will display. Turn parameter knob repeatedly to select the menu. Press " " to confirm the menu. Turn parameter knob to set the weight of the food. Press "... - Page 30 Auto menu chart DISPLAY MENU WEIGHT POWER P100 P100 P100 P100 P100 P100+P30 Conv.400 F Conv.325 F Conv.375 F Chicken P100/Conv.400 F P100 EN-27...
-
Page 31: Air Fry
12. AIR FRY In waiting state, press " Air Fry ", "H01" will display Turn parameter knob to set the menu, "H01~H10" are available. Press " " to start cooking. The chart of the air fry: DISPLAY MENU PREHEAT TEMPERATURE Frozen French Fries 425 F Frozen onion Rings... - Page 32 Press " " to confirm. Turn parameter knob to set the weight. Press " " to start cooking. DEFROST BY TIME In waiting state, press " Pro Defrost ", "dEF1" will display. Turn parameter knob to select "dEF7". Press " "...
-
Page 33: Mute Mode
. MUTE MODE To activate the mute mode: In standby mode, press “ Sound On/Off/Lock 3s ” once. A beep will sound and “oFF” will display. When you press the key, it does not make a sound. To deactivate the mute mode: In mute mode, press “... -
Page 34: Cleaning
CLEANING With good care and cleaning, your appliance will retain its appearance and remain fully functioning for a long time to come. We will explain here how you should correctly care for and clean your appliance. • Scratched glass in the appliance door may develop into a crack. Do not use a glass scraper, sharp or abrasive cleaning aids or detergents. -
Page 35: Door Panel
APPLIANCE FRONT PLATE Hot soapy water: Clean using a dish cloth and then dry with a soft cloth. Remove splashes and patches of limescale, grease, starch and albumin immediately. Corrosion can form under these patches or splashes. Do not use glass cleaners or metal or glass scrapers for cleaning. -
Page 36: Maintenance
MAINTENANCE TROUBLE SHOOTING Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY a. Electrical cord for oven is not a. - Page 37 TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY a. Cover or lid over food must a. Cover or lid on food not contain vent hole for escaping vented. steam. Sensor cooked foods b. Door opened before sensor- b. Do not open door to stir or not properly cooked detect-ed cooking time appears turn food before sensor-...
-
Page 38: One Year Limited Warranty
If service is required during the warranty period, properly pack your unit. We recommend using the original carton and packing materials. If additional assistance is needed, please contact customer assistance at: customercare@us.toshiba-lifestyle.com 855-204-5313 Midea America Corp. expressly disclaims all responsibility for consequential damages or incidental losses caused by use of the appliance. - Page 40 Details Matter Customercare@us.toshiba-lifestyle.com 855-204-5313...
