Thank you for purchasing our 6x3 Oscar
Storage Shed. Please take the time to identify
all the parts prior to assembly.
Please use Safety Eyewear and Gloves while
Assembling. Be sure to read and follow all operating
instructions for any tools used during assembly.
Remember- NO SAW CUTTING IS REQUIRED!
Safety Points and Other Considerations
Our products are built for use based on proper
installation and normal residential use, on level ground.
Please follow the instruction manual when building your
Oscar and retain the manual for future maintenance
purposes.
-Some of the safety and usage measures you may wish
to consider include:
-In high or gusty wind conditions it is
advisable to keep the structure securely grounded.
-Have a regular maintenance plan to ensure screws,
doors, roof and parts are tight.
Assembly Video Instructions
To view the assembly video, click on the following link:
www.youtube.com/watch?v=1BapdJOpJoY
You can also view the assembly video via the QR Reader App on your smart phone.
If you don't have a QR Reader App on your smart phone, follow the steps below.
Go to your App Store and search for a QR Reader App and install.
Scan QR code to the right, it will direct you to YouTube where you can view the video.
Inside - 32" d x 66 3/4" w x 50" (front) 53" (back)
Outside with Lid Overhang
front between floor and underside of Front Top Plate = 50"
- Inside depth when Doors are closed to Rear Wall = 32"
Please check your garbage can height and depth to confirm they fit prior to purchasing and assembly.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Toll Free 1-888-658-1658
6X3 Oscar Shed
Assembly Manual
6x3 Oscar Dimensions:
-
37"d x 72 5/8" w x 55"(front) 58" (back)
www.outdoorlivingtoday.com
Page 1
Although not required, having a
helper to assist during a few
assembly steps will make the
completion of this project more
convenient for you.
Important
- Inside distance in
sales@outdoorlivingtoday.com
Revision #10.2
December 15, 2024
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for OLT 6X3 Oscar Shed
Summary of Contents for OLT 6X3 Oscar Shed
- Page 1 6X3 Oscar Shed Revision #10.2 December 15, 2024 Assembly Manual Thank you for purchasing our 6x3 Oscar Storage Shed. Please take the time to identify all the parts prior to assembly. Please use Safety Eyewear and Gloves while Assembling. Be sure to read and follow all operating instructions for any tools used during assembly.
- Page 2 What to do before my Shed • Become familiar with this assembly manual and determine i you can complete the project yourself or will require a p • One helper is recommended to assist in constructing your Oscar. It generally takes two people less than a day to assemble •...
- Page 3 Foundation Types for 6x3 Oscar 82 3/4” 70 3/4” 35” 47” Floor Concrete Foundation Completed Foundation Concrete Slab Foundation: - Slab must be at least the same size as assembled floor frame (35” x 70 3/4”) or larger. - 6” Deep foundation. - 0.6 Cubic Yards of concrete required.
- Page 4 Exploded View and Parts List for 6’x3’ Oscar Parts Lists: Hardware Packs (3 Clear Plastic Bags R, R1 & R2) (See Page 5 for illustrated Hardware Details) Floor and Walls 1 - Floor - 35” x 70 3/4” (45 degree angle cut on front edge) R includes: 1 - Right Side Wall - Arched Top - 35”...
-
Page 5: Hardware Kit
6x3 Oscar Storage Shed Hardware Kit (Provided) 3/4” Black Part G x 32 pcs 1 1/2” 3” Part K x 60 pcs Part C x 9 pcs 2 1/2” Part A x 46 pcs Part B Square Drive Bit x 1 pc 2”... - Page 6 Before assembling your Oscar, be sure to lay down a foundation for your unit to sit level on. There are many options such as patio paving stones, a concrete slab or fine crushed gravel. Make sure the area is level and not elevated with surrounding ground so garbage cans can move easily in and out of your Oscar.
- Page 7 Lift Side Wall (2) up and orientate so wall framing is flush at rear with floor, wall siding is flush on side with floor. In the front, wall framing will overhang the floor as shown below. Wall Siding flush with outside for Floor.
- Page 8 Position and attach 2nd Rear Wall (3A). Align rear wall frames together and attach with 3 - 2 1/2” screws (A). 3 - 2 1/2” screws along wall framing Wall Siding flush with outside for Floor 3 - 2 1/2” screws along wall framing Lift 2nd Side Wall (2A) up and orientate and attach wall to rear wall...
- Page 9 Check for wall/floor alignment (wall siding flush with outside of floor on sides and rear). When satisfied, secure wall framing to floor with 4 - 2 1/2” screws (A) per wall panel. Note: For the Rear Wall Top Cleat, 2” is the width and 1 1/2”...
- Page 10 Using 2 - 2 1/2” screws (A), attach 4 Triangular Top Cleats (7) to front top plate and side wall fram- ing. Align flush at top. Note- Top cleats are pre-drilled. With your helper, lift and position the Curved Lid (8) on top of wall framing. Center on walls from front to rear and evenly from side-to-side.
- Page 11 Locate both Rear Black Strap Hinges (D). Orientate hinge as shown to right so pre-drilled hole in lid and top hinge hole align. Slide in a 2” Machine screw with Washer and Nut (E) through hinge hole and lid. From the inside, slide Washer on and tighten Nut snug with 3/8”...
- Page 12 Important: Have your assistant hold Lid open to desired height while Gas Shocks are attached. Never close Lid with only 1 Gas Shock attached. This may cause damage to shock and Lid. Some adjustment to height and depth of bottom of shock may be necessary to achieve optimum Lid opening height. Gas Shock is shipped with piston extended.
- Page 13 Note: All Trim pieces are graded best face rough. Parts 10 & 10A & 11 &11A are unique to each side. The rough side of all the trim will be the exposed face when nailing the pieces to the shed. Trim flush with inside of wall framing Close lid and mark the highest...
- Page 14 Locate both Doors (13) and 4 Black T - Hinges (L). Lay Doors on flat ground with door trim recessed to center.1 - 2” Machine Screw with Nut and Washer. (E) Door Trim recessed to center Line hinge and door and slide bolt through. Tighten bolt using 3/8”...
- Page 15 Position and attach Black Barrel Bolt (M) with 6 - 3/4” Black Screws (G). Note how female part of barrel bolt is positioned higher than male. Do a dry run first to position barrel bolt correctly. Important - Drill shallow pilot holes with 1/8”...
- Page 16 Note; Our Sheds are shipped as an unfinished product. If exposed to the elements, the lumber will weather to a silvery-gray color. If you prefer to keep the lumber looking closer to the original color, we suggest that you treat the wood with a good oil base wood stain.
