3. Connect the PV substring positive lead to PV Link
at the location marked PV Substring Input + (F).
See
Component Locations
4. Connect the PV substring negative lead with its
connected SnapRS device to PV Link at the loca-
tion marked PV Substring Input - (E). See
nent Locations
5. Mount the SnapRS devices to the module frame
using the built-in SnapRS mounting clips. The
SnapRS can be mounted to the module frame in
one of two configurations:
a. See
Figure 5-6
between the module and the module frame lip.
b. See
Figure 5-7
low the module frame lip.
Figure 5-6.
Figure 5-6. Mounting RS802-clip model SnapRS Between the Module and Module Frame Lip
Figure 5-7.
Figure 5-7. Mounting RS802-clip model SnapRS Below the Module Frame Lip
NOTE: Solar module frame thickness must be be-
tween 1-2 mm for the SnapRS-clip to mount prop-
erly.
Ensure
connection with module cable leads in a manner
which complies with minimum bend radii specified
by module manufacturer.
6. Record site details in
SnapRS Important Information
ray map using
Installation Manual for PV Link and SnapRS Installation Manual
for more information.
for more information.
for mounting the SnapRS in
for mounting the SnapRS be-
mounting
location
Table 1 PV Link and
and make an ar-
Table 2 : PV Array
Map.
Compo-
allows
for
Mounting and Connecting
016044
016045
23
