Generac Power Systems S2502 Installation Manual page 11

Section 2: General Information
PV Link Specifications
Description
Rated power
Peak efficiency
MPPT input voltage
Rated power input voltage
Maximum input voltage
Maximum input current (operating)
Maximum input current (short circuit)
Maximum output voltage
Nominal output
Maximum output current (continuous)
Standby power
Shutdown time
Topology
Protections
Operating temperature range
Enclosure
Weight
Certifications
Specifications are subject to change without notice. Refer to the product specification sheet for complete list.
SnapRS Specifications
Description
PV Module maximum VOC
Maximum number of PV modules per substring
Range of input operating voltage, DC
Typical power loss at maximum input current
Maximum input current
Max STC ISC of string
Shutdown time
Enclosure rating
Operating temperature range
Certifications
Weight
* 1 SnapRS per PV Module.
Installation Manual for PV Link and SnapRS Installation Manual
Units
W
%
VDC
VDC
VDC
13 A @ 122 °F (50 °C) 10 A @ 158 °F (70 °C)
A
A
VDC
—
A
W
Sec
—
Ground-fault protection, arc-fault protection (type 1), PVRSE
—
ºF (ºC)
—
lb (kg)
UL 1741, UL 1699B, CSA 22.2 No. 107.1
—
Units RS801
VDC
—
V
W
A
A
Sec
—
ºF (ºC)
—
oz (g)
S2502
2,500 (continuous)
99
60 — 360
200 — 360
420 (absolute maximum)
18
420 (open circuit)
REbus DC nanogrid (380 VDC + data)
8
<1
< 30
Boost converter
-40 to 158 (-40 to 70)
UL Type 4X
7.3 (3.3)
RS801A
75 80
10*
0 - 80
1.3 1.3
13 13
10.4 10.4
< 10
NEMA Type 6P
-40 to 158 (-40 to 70)
UL 1741, CSA 22.2 No.107.1
3.6 (103)
General Information
RS802,
RS802–clip
80
1.33
14
11.2
11
