Operating Instructions
Figure 6-2.
PV Link S2502
Enable
Mod. Settings
Test PVRSS
RCPn: 00010003XXXX
< EXIT
SCROLL > NEXT • SELECT
Figure 6-2. PVRSS Commissioning (1 of 8)
4. See
Figure
6-3. If installing parallel series sub-
strings for high voltage modules, select the "String
Count" setting and update the value to '2'.
Figure 6-3.
PLM Channel:
Vin Startup:
String Count:
Enable PVRSS:
Cancel
Figure 6-3. PVRSS Commissioning (2 of 8)
5. See
Figure
6-4. Select the "Enable PVRSS" set-
tings and update the value to 'on'.
Figure 6-4.
PLM Channel:
Vin Startup:
String Count:
Enable PVRSS:
Cancel
Figure 6-4. PVRSS Commissioning (3 of 8)
6. See
Figure
6-5. If installing a small number of PV
modules on a substring such that the input voltage
will not equal 135 VDC, select the "Vin Startup" set-
ting and lower the value as needed.
26
Menu
020070
1
135.0V
2
off
Save
016073
1
135.0V
2
on
Save
016074
Figure 6-5.
PLM Channel:
Vin Startup:
String Count:
Enable PVRSS:
Cancel
Figure 6-5. PVRSS Commissioning (4 of 8)
7. See
Figure
6-6. Select the "SnapRSInstalld" set-
ting and set the value to the number of SnapRS de-
vices installed in the PV substring for the PV Link
recorded in
Table 1 PV Link and SnapRS Impor-
tant
Information.
Figure 6-6.
SnapRSInstalld:
SnapRSDetected:
Cancel
Figure 6-6. PVRSS Commissioning (5 of 8)
8. See
Figure
6-7. Select "Save" to save Mod. Setting
values. Do not exit without saving.
Figure 6-7.
SnapRSInstalld:
SnapRSDetected:
Cancel
Figure 6-7. PVRSS Commissioning (6 of 8)
9. See
Figure
6-8. Press the center button and to se-
lect "Enable" to enable the PV Link.
Installation Manual for PV Link and SnapRS Installation Manual
1
135.0V
2
on
Save
016075
7
0
Save
016076
7
0
Save
016077
