- Page 1 DC-X SERIES DC50-X / DC65-X / DC85-X / DC130-X Owners Manual & Operating Instructions Please read carefully before use and installation...
- Page 2 We recommend installing an isolation switch for the fridge circuit as close to your battery bank as possible. Any switches must have Bushman DC-X fridge a breaking load not less than 20 A on 12 V or 10 A on 24 V. The power supply wiring must also be protected with a 15 A fuse.
- Page 3 Important steps for effective operation Mounting option 2 – Mounting kit You will receive a mounting kit (fascia) with your fridge. The Thermostat setting mounting kit is affixed to the sides and top of the fridge cabinet The thermostat should be set on the lowest number to keep your using the screws provided.
- Page 4 Leave the door closed in this stickers with every fridge in the owners manual pack. position for 10 minutes for the seal to cool down. g. Use the supplied DC-X Series sticker to cover the old screw holes.
- Page 5 Measurements MOUNTING KIT COOLING UNIT SCALE: (MM) Model DC50-X Model DC65-X Model DC85-X Model DC130-X...
- Page 6 Ventilation options Exterior ventilation Interior ventilation option 1 Interior ventilation option 2 Interior ventilation option 3 Interior ventilation option 4...
- Page 7 DP Refrigeration Pty Ltd trading as Bushman Fridges ABN 94 Connect the red and black power wires from the compressor 615 295 255 (Bushman) warrants, to the original owner, that this directly to a different 12V power source (for example a fully product is free from defects in workmanship and material for a charged deep cycle 12V battery).
- Page 8 Red LED error light From mid 2021 onwards all Bushman DC-X series are fitted with a red LED error light. – Mid 2021 – mid 2022 the red LED is located on the compressor module. – Mid 2022 onwards the red LED is located inside the interior light housing.
