Page 3
This transceiver correspond to the requirements of European directives RED 2014/53/EU and answers theEuropean standards of telecommunication EN 62368-EN 62311-EN 50665- EN 301 489-1/15- EN 301783. IMPORTANT : This receivingtransmitterworks on not free frequencies IMPORTANT : in the use. The user has to possess a radio licence amateur radio (certificate of radio operator HAM) to use it (in emission) and only on the frequenciesauthorized in radio amateurs.
Page 5
WELCOME TO USE Welcome to the world of new radios. The new SS 9900V radio providesyou with top performance and best visualenjoyment. With the use of SMT technology to guarantee the best stability, reliability and unprecedentedquality, your multi-functional SS 9900V 10-meter Radio is a new step in personal communication and issurely the best choise for professionalusers of radio.
CONTENTS 1.FUNCTIONS & FEATURES ................1 2.STANDARD ACCESSORIES ................2 3.INSTALLATION ....................3 4.GETTING ACQUAINTED .................6 5.HOW TO USE YOUR RADIO ................9 6.KEYPAD FUNCTION ..................10 7.CHANNEL FUNCTION MENU OPERATION ..........13 8.PUBLIC DATA FUNCTION MENU OPERATION ..........15 9.BACKGROUND FUNCTION MENU OPERATION ........16 10.SELF DEFINE PF KEY ................20 11.SPECIFICATIONS ..................22...
1. FUNCTIONS & FEATURES LCD display with 7 color options for RX and TX, with back light dimming FM, AM, USB, LSB, CW, PA modes Frequency Tuning Steps: 10Hz, 100Hz, 1KHz, 5KHz, 10KHz, 100KHz, 1MHz ± 500Hz, 5KHz Clarifier (R/T/R+T selectable) Flexible menu functions and PC programming software RX and TX NRC Noise Reduction SQ, ASQ Function (FM and AM mode)
3. INSTALLATION Choose the most appropriate location from a simple and practical point of view. If installed in a vehicle, care should be taken to ensure your radio does not obstruct the driver or passengers. 1. Use the Self-tapping Screws and Pads to fix the Bracket to a suitable location. 2.
Page 10
3. INSTALLATION 3. A mobile antenna can be mounted in various locations, for example: 3.2 Power Connection .................. This radio requires a 13.8V (12V) DC power supply. Never connect the radio directly to a 24V DC battery system, as can be found in some vehicles. Please refer to the radio Specifications to ensure your 13.8V DC power supply can provide enough current (amps), otherwise poor performance may occur.
Page 11
3. INSTALLATION 3.4 Install Microphone Hanger ..............Choose a location which will not interfere with the driver. Use the supplied self-tapping screws and pads to install the hanger. 3.5 Install External Speaker ................. If using an external speaker, please choose an 8 ohm speaker with a 3.5mm mono (double cable) TS type plug.
4. GETTING ACQUAINTED 4.1 Front Panel ....................9 10 11 12 Functions FUNC Function / Menu key MODE Switch Mode: FM, AM, USB, LSB, CW, PA BAND Switch Band: A-I / VFO mode SCAN Scan / Scan add / Scan delete Use, Store or Delete memory channels Activate / deactivate the CTCSS/DCS function Activate / deactivate the NRC function...
Page 13
4. GETTING ACQUAINTED 4.2 Rear Panel ....................EXT SP DATA No. Functions PC Cable Jack External Speaker Jack Antenna Jack 4.3 Microphone ..................... PF (User defined) DOWN 6-Pin Connector EXT.AF Microphone cable MIC.KEY 6. +DC...
Page 14
4. GETTING ACQUAINTED 4.4 LCD Display .................... 24 23 22 Appears during transmit (TX) Displays the working mode Appears when using Emergency channels Appears when using Memory channels Appears when Echo function is ON Appears when Repeater Offset function is ON Appears when Hi-Cut function is ON Displays the channel number Appears when Noise Blanker / ANL is ON...
5. HOW TO USE YOUR RADIO 5.1 OFF/ON Radio ..................1. Turn VOL clockwise to switch the radio ON, the radio may emit a beep (if the BEEP Prompt function is enabled). The LCD display will show a frequency or a channel number. 2.
6. KEYPAD FUNCTION 6.1 MEM or ANL/NB ..................6.1.1 Using memory channels: 1. Short press to enter memory channel, turn CH to choose memory channel. M1-M99, (total of 99 memory channels). 2. Short press again to exit memory channel mode. Note: Short press the key to copy the current Memory Channel into VFO.
Page 17
6. KEYPAD FUNCTION 6.5 FUNC......................for 2 seconds to enter the main Background Function Menu (See 1. Long press section "9. BACKGROUND FUNCTION MENU OPERATION"). 2. Short press , "FUN" will appear at the top left of LCD display. Press [PUSH] to enter the Function menu list.
Page 18
6. KEYPAD FUNCTION 6.8 NRC or SPLIT ..................6.8.1 NRC Short press key to start the RX noise reduction function. Repeat this operation to switch ON/OFF the function. Short press key to start the TX noise reduction function. Repeat this operation [PTT] to switch ON/OFF the function.
7. CHANNEL FUNCTION MENU OPERATION 1. Press , the top left of LCD displays "FUN", Press [PUSH] to enter the menu list. 2. Turn Channel switch to select menu No.1- No.7. 3. Press [PUSH] to choose the menu to modify. 4.
Page 20
7. CHANNEL FUNCTION MENU OPERATION OFF: Choose independent channel menu; ON: Choose public channel menu; Default: ON Public Data Note: When OFF is selected, additional hidden public channel menu items 8-13 will appear. These are the same as shown in 'Section 8'. Note: Public Data settings can be used to enable saving of individual settings (e.g.
8. PUBLIC DATA FUNCTION MENU OPERATION 1. Hold [PUSH] for 2 seconds to enter the Public Data menu list; 2. Turn the Channel switch to select menu 1-6; 3. Press [PUSH] to choose the menu to modify; 4. Turn the Channel switch to modify the menu options. 5.
9. BACKGROUND FUNCTION MENU OPERATION for 2 seconds to enter the Background Function Menu list; 1. Hold [FUNC] 2. Turn the Channel switch to select menu 1-42; 3. Press [PUSH] to choose the menu to modify; 4. Turn the Channel switch to modify the menu options; 5.
Page 23
9. BACKGROUND FUNCTION MENU OPERATION Monitor Gain 1-32, OFF, Total 33 levels available; (Talkback) Default: OFF (Disable NOG function) ECHO 1-32, Total 32 levels available; volume level Default: 28 setting 1-32, Total 32 levels available; ECHO delay time setting Default: 28 1-600s, OFF, Total of 10 minutes available;...
Page 24
9. BACKGROUND FUNCTION MENU OPERATION Set the Dual Watch channel, mode and band: DW Channel Turn channel knob to change channel, press MODE to choose the mode, press BAND to choose the band. Set Emergency Channel 1 and its mode. EMG1 Turn channel knob to choose the channel, press MODE Channel...
Page 25
9. BACKGROUND FUNCTION MENU OPERATION 01-63: Adjusts the CW Sidetone level (volume); CW Volume OFF: CW Sidetone disabled; (Sidetone) Default: 31 300Hz-3KHz: This menu is to select CW Sidetone; frequency. The frequency step is 10Hz; CW FREQ Default: 1050Hz CW-U: select USB for CW RX CW-L: select LSB for CW RX CW RX Default: CW-U...
10. SELF DEFINE PF KEY for 2 seconds and enter the Background Function Menu "PF.KEY"; Hold [FUNC] 2. Press to choose the menu to enter modify mode; [PUSH] 3. Turn the Channel switch to modify the PF.KEY menu options; 4. Press [PUSH] to return to the previous menu.
Page 27
10. SELF DEFINE PF KEY TXNR TXNR ON/OFF Enter TXNR setting menu FM.DEV Choose FM Deviation level TONE Choose SSB TX bandwidth When set to SWR, long press INDIC Choose LCD meter display enters SWR setting menu. CH.PUSH Choose frequency STEP size Enter Public Setting PD menu AGC.SET Choose AGC FAST/SLOW speed...
11. SPECIFICATIONS GENERAL Frequency Range 28.000-29.700MHz (Programmable) Frequency Band A/B/C/D/E/F/G/H/I + VFO Channel 40 channels (programmable) in each band Frequency Control Phase-Locked-Loop Synthesizer 10Hz,100Hz,1KHz,5KHz,10KHz,100KHz,1MHz Frequency Step Frequency Tolerance ±5.0 ppm Temperature Range -20℃~ +50℃ Microphone With Push-to-Talk / UP / DN / PF and coiled cord Input Voltage 13.8V DC Dimensions (in mm)
Page 29
N° 200245 N° 200245 SS9900V RED 2014/53/EU EN IEC 62368-1 :2020+A11 :2020 EN IEC 62311 :2020 EN 50665 :2017 ETSI EN 301 489-1 V.2.2.3 (2019-11) ETSI EN 301 489-15 V2.2.1 (2019-04) ETSI EN 301 783 V2.1.1 (2016-01) C.R.T. France INTERNATIONAL S.A.S. Route de Pagny - 21250 SEURRE - France Capital de 1 800 000 euros Tél.
