Summary of Contents for CRT SS 6900V
- Page 3 RESTRICTIONS...
- Page 4 directive RED 2014/53/EU and answers the European standards of télécommunication EN 62368-1, EN 62311, EN 301 489-1/-15, EN 301 783. in radio amateurs 28.000-29.700 MHz. This model is approved for use in these countries : AT-BE-BG-CH-CY-CZ-DK-EE-ES-FI-FR-DE-UK-EL -HR-HU-IE-IS-IT-LI-LU-LT-LV-MT-NL-NO-PL-PT-RO-SK-SI-SE and in CEPT countries and those no CEPT countries that implement the CEPT regulation TR 61/01.
- Page 7 CTCSS-DCS CODES...
- Page 8 26. VOX function (in vox function, the squelch must always be engaged) 27. CTCSS/DCS code 28. RX compander 29. Noise gate setting 30. RX Noise Reduction (Included) 31. Mic type selection...
- Page 11 10K: Appears when +10KHZ function is started. EMG: Appears when EMG channel is used. SWR: Appears when SWR is used. SRF: Appears when S/RF is used. SC: Appears when SCAN is used. TSQ: Appears when CTCSS/DCS code is used. NR: Appears when RX noise reduction is turn on. VOX: Appears when VOX function is started.
- Page 15 27. Plug for programming cable CRT SS 6900 V MICROPHONE WIRING Cablage micro du CRT SS 6900 V 1 : masse/shield 2 : audio /module 3 : TX/ UP(montée)/DW(descente)/AQ(squelch auto) 4 : NC...
-
Page 16: Function Menu Setup
(07) NG (07) NG FUNCTION MENU SETUP This menu refers to TX noise gate setting. Default: OFF The initial functions and parameter can be changed via the following settings and operations. Please read the following instruction before making any desired amendments. (08) NR To enter Function Menu: under ON state, press and hold FUNC key for This menu refers RX noise reduction setting Default: OFF... - Page 17 (16) ASQ (16) ASQ (14) CLA (14) CLA ASQ control setting. It is same function This menu is to set functions turned by as the AQ button on the microphone. CLARIFIER knob. Options are as follows: Default: OFF FIN: Fine regulation. When this option is selected, users can fine tuning the receiving frequency by rotating the CLARIFIER (17)TOT (17)TOT...
- Page 18 OFF: When OFF is selected, SWR Protection function is disabled. (23) RBT (23) RBT (23) RBT NOTE: To protect the radio from long transmission under high SWR, This menu is to select Roger Beep Holding the radio would automatically start SWR Protection once the Time from 50ms—1000ms.
- Page 19 CTCSS code No. Freq. (Hz) Freq. (Hz) Freq. (Hz) Freq. (Hz) 67.0 97.4 136.5 192.8 71.9 100.0 141.3 203.5 74.4 103.5 146.2 210.7 77.0 107.2 151.4 218.1 79.7 110.9 156.7 225.7 82.5 114.8 162.2 233.6 85.4 118.8 167.9 241.8 88.5 123.0 173.8 250.3...
- Page 20 Software cable (reference TX 000991) - the cable connection is at the rear of the unit. INCLUDED : RX NOISE REDUCTION BOARD(NRC)
- Page 21 N° 200201 N° 200201 Description : Mobile Transceiver HF Amateur Radio Description : Mobile Transceiver HF Amateur Radio RED 2014/53/EU EN 62368-1:2014/A11:2017 EN 62368-1:2014/A11:2017 EN 62311:2008 EN 62311:2008 Draft EN 301 489-1 V2.2.0 Draft EN 301 489-1 V2.2.0 Draft EN 301 489-15 2.2.0 Draft EN 301 489-15 2.2.0 EN 301 783 V2.1.1 EN 301 783 V2.1.1...
