Product End-of-Life Disassembly Instructions
Product Category: Workstation
Marketing Name / Model
[List multiple models if applicable.]
HP Z8 Fury G5 Workstation
FCLSA-2204A
FCLSA-2204B
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP Inc. products to remove components and materials requiring selective treatment, as defined by
EU directive 2012/19/EC, Waste Electrical and Electronic Equipment (WEEE).
NOTE: Recyclers should sort plastic materials into resin streams for recycling based on the ISO 11469 plastic marking
code on the plastic part. For any questions on plastic marking or identification of location of parts or components requiring
selective treatment, please contact
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment. An "X" in the list of components and parts indicates
the product contains the component or part requiring selective treatment
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA) with a surface greater than 10
sq cm
Batteries, excluding Li-Ion batteries. This includes
standard alkaline, coin or button style batteries
Li-Ion batteries. Includes all Li-Ion batteries if
more than one is provided with the product (such
as a detachable notebook keyboard battery, etc.)
EL-MF877-00
Template Revision D
last updated May-2022
HP's Sustainability
HP Inc. instructions for this template are available at
Contact.
Components and parts requiring selective
treatments
☒ Main board (MB) PCB*1
☒ Solid state drive (SSD) PCB*2
☐ Wireless WAN module (WWAN) PCB
☐ Touch module PCB
☒ Power supply PCB*1
☒ External Keyboard (KB)*1
☒ External Mouse*1
☒ Graphic card PCB *1,
☒Transfer card*1,
☒ Switch card*1
☒ PDB board PCB*1
☒ Memory PCB*4
☒ HDD PCB*1
☒ RTC/CMOS battery
☐ Others: _____________
Li-ion battery(ies) are attached to the product by:
☐ screws
☐ snaps
☐ adhesive
☐ other. Explain
EL-MF877-01
Quantity
of items
included
in product
15
1
0
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z8 Fury G5 and is the answer not in the manual?

Questions and answers

Summary of Contents for HP Z8 Fury G5

  • Page 1 Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the disassembly of HP Inc. products to remove components and materials requiring selective treatment, as defined by EU directive 2012/19/EC, Waste Electrical and Electronic Equipment (WEEE).
  • Page 2 Tool Description Tool Size (if applicable) Screwdriver Philip #0 Screwdriver Torx T8 Heat gun Suction cup 3.0 Product Disassembly Process EL-MF877-00 Page 2 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 3 51. Remove the CPU from the cooler 52. Remove the CPU from the carrier 53. Press the bottom and remove the 2 pcs PSU EL-MF877-00 Page 3 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 4 3.2 Location of components requiring selective treatment. The photos and/or graphics below identify the location of the parts or components requiring selective treatment within the main unit. For End-of-Life product disassembly instructions of EL-MF877-00 Page 4 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 5 Figure2 Remove the PCIe retainer from chassis. Figure3 Remove the CPU fan duct frame. Figure4 Press the latch and push the top PCI card duct out. EL-MF877-00 Page 5 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 6 Figure7 Remove the cooler fan from duct. Figure8 Disconnect the graphic card cable and remove the graphic card from motherboard. See below is Graphic card PCB. EL-MF877-00 Page 6 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 7 Figure10 Disconnect the ODD SATA/ Power cable from ODD. Below is 4pcs Memories PCB Figure11 Remove the ODD from chassis Figure12 Loosen the HDD bracket EL-MF877-00 Page 7 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 8 Figure17 Disconnect the front lower chassis fan cable Figure18 Press the guide and remove the PCIe fan guide from chassis. EL-MF877-00 Page 8 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 9 Figure22 Remove the rear system fan duct from hook. Figure23 Disconnect rear system fan cable from Figure24 Remove the fan guard from fan guard motherboard. EL-MF877-00 Page 9 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 10 Figure29 Disconnect the front upper chassis fan cable. Figure30 Press the guide and remove the front upper chassis fan and fan guard. EL-MF877-00 Page 10 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 11 Figure35 Loosen the screws(x2) of speaker and release Figure36 Disconnect the speaker cable from switch card. speaker. See below is Switch card PCB. EL-MF877-00 Page 11 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 12 Figure41 Loose the 4pcs switch card PCA screws and Figure42 Remove the SD card reader carrier. remove the switch card PCA. EL-MF877-00 Page 12 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 13 Figure46 Remove the 3pcs HDD brackets from chassis. Figure47 Remove ODD housing from chassis. Figure48 Disconnect the CPU cooler cable from Motherboard. EL-MF877-00 Page 13 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 14 Figure52 Remove the CPU from the carrier. Figure53 Press the bottom and remove the 2pcs PSU. Figure54 Cut off the cable ties on front upper in chassis EL-MF877-00 Page 14 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 15 Figure58 Remove the battery from MB Figure59 Release 2pcs screws of right side panel. Figure60 Cut off 5 pcs cable ties to fix power cable EL-MF877-00 Page 15 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 16 See below is PDB PCB. Figure63 Release the blind mating SATA connector from Figure64 Cut off cable tie and remove blind mating SATA chassis cable EL-MF877-00 Page 16 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 17 Figure69 Release clasp of front bezel on bottom side of Figure70 Remove the left side plastic parts of corner chassis and remove the bezel bracket pocket by release the clasp. EL-MF877-00 Page 17 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 18 Figure74 Remove the handle pocket and details of front pocket. side handle pocket Figure75 Unlock 2pcs screwsfront side handle. Figure76 Release 3pcs latches of rear handle pocket EL-MF877-00 Page 18 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 19 Figure80 Remove the bottom side spring of ODD bracket cover Figure81 Unlock top side screw of ODD bracket cover Figure82 Remove the ODD bracket cover EL-MF877-00 Page 19 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 20 Figure85 Push top cover on right hand side to make sure Figure86 Take top cover away. four snap in come off. EL-MF877-00 Page 20 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 21 Figure88 Remove the small Mylar. from top cover. Figure89 Unfasten GND screw. Figure90 Put AC socket cable outside to see PCBA screw. EL-MF877-00 Page 21 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 22 Figure92 Disconnect 3mm LED cable and fan cable from daughter board. Figure93 Take out PCBA with AC socket cable from Figure94 Unfasten two screws. bottom chassis. EL-MF877-00 Page 22 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 23 Figure97 Take out LED & S/W sub-assembly with cable Figure98 Remove bottom Mylar and two pads from bottom from bottom chassis. chassis. EL-MF877-00 Page 23 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 24 Figure101 Identity PCBA > 10 cm² for further treatment Figure102 Identity electrolyte capacitor > 2.5 cm for further (daughter board: 24.0 cm²). treatment (Length: 4.5 cm). EL-MF877-00 Page 24 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
  • Page 25 Figure103 Identity electrolyte capacitor > 2.5 cm for further treatment (Length: 4.5 cm). EL-MF877-00 Page 25 Template Revision D last updated May-2022 HP Inc. instructions for this template are available at EL-MF877-01...
