  • Page 1 Bathtub Sliding Swivel Bench User Manual AX19...

  • Page 2: Table Of Contents

    CONTENTS Table of Contents I.Safety Instructions II.Product Introduction III.Installation Instructions IV.Operating Instructions V.Warranty Policy...

  • Page 3: I.safety Instructions

    AX19 Bathtub Sliding Swivel Bench, making installa- tion and use straightforward and manageable. 2. Intended Use Only: The AX19 Bathtub Sliding Swivel Bench is designed for its intended purpose only. Do not use it as a stand, ladder, support, or for any simi- lar purposes.
  • Page 4 Components a. Backrest: Cushioned with 1.6 inches PU foam for added comfort. b. Seat: Features a 1.6 inches PU foam cushion for comfortable sitting. c. Armrest: Can rotate and includes foam padding for en- hanced grip and comfort. d. Sliding Rail: Allows the seat to slide smoothly for easier access. e.
  • Page 5 Your Family Rehabilitation Partner Specifications Item Value Unit Seat Width Inches Seat Depth Inches Cushion Thickness Inches Armrest Inner Width Inches Armrest Height Inches Backrest Height Inches Overall Width 19.3 Inches Overall Length Inches Seat Height (Lowest) 22.4 Inches Seat Height (Highest) 28.3 Inches Sliding Rail Base Height (Lowest)

  • Page 6: Iii.installation Instructions

    VOCIC after-sales team for assistance. 1. Main Body, 1 piece: The AX19 main body with the seat, sliding and rotating mech- anisms, and sliding rail. 2. Backrest, 1 piece: Backrest cushioned with thick PU foam.
  • Page 7 Your Family Rehabilitation Partner Installation Steps Step 1: Attach the Backrest to the Seat Press the metal spring pins on the backrest support and connect the backrest to the bottom of the seat. When you hear a click, the back- rest is locked in place.
  • Page 8 Step 2: Attach the Two Bent Aluminum Tubes to the Sliding Rail of the Main Body Insert the bent aluminum tubes into the sliding rail, align the holes, and tighten them with 4 screws.
  • Page 9 When you hear a click, the metal spring pins are locked. Step 4: Adjust the Height Adjust the hole positions on the four height-adjustable legs to ensure the AX19 is stable and level. To disassemble, reverse the above steps.

  • Page 10: Iv.operating Instructions

    IV.Operating Instructions Rotatable Armrests Press the red button on the outside of the armrest to release the lock and allow the armrest to rotate. Push the armrest back into the locking mechanism to secure it in place. Pull-to-Move Handle Pull the “Pull-to-Move Handle” outward to unlock the sliding function. Once unlocked, apply slight pressure to one side to slide the seat until it locks into position.

  • Page 11: V.warranty Policy

    We provide a 3-month warranty for consumable parts, including the black non-slip foot-pads and gray non-slip suction cups. The expected lifespan of the AX19 is 5 years from the date of manu- facture. During this period, VOCIC offers paid repair services.
  • Page 12 Your Home Rehabilitation Partner @VOCiCMedical @VOCiCMedical @VOCiCMedical @VOCiCMedical Manufacturer: HEBEI HEALTHPLUS MEDICAL DEVICE CO.,LTD Address: NO.1，Chuangye Street ,Matou Industry Park， HanDan City，HeBei Province，China lf you have any questions, please contact us: support@vocic.com...
