  • Page 1 ® E3 Series Classic ® Installation/Operation Manual Document 9000-0577 10/15/10 Rev: P/N 9000-0577:I ECN 10-116...

  • Page 2: Important Limitations

    Important Limitations Smoke detectors cannot be expected to provide adequate warning of fires caused by arson, children playing with While a fire alarm system may lower insurance rates, matches (especially in bedrooms), smoking in bed, and it is not a substitute for fire insurance! violent explosions (caused by escaping gas, improper storage of flammable materials, etc.).

  • Page 3: Installation Precautions

    Communications du Canada. Gamewell-FCI®, SmartScan®, and E3 Series® are registered trademarks of Honeywell International Inc. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation. ARCNET® is a registered trademark of Datapoint Corporation. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation.

  • Page 4: Software Downloads

    • Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services E3 Series Classic Installation/Operation Manual — P/N 9000-0577:I 10/15/10...

  • Page 5: Table Of Contents

    Table of Contents Table of Contents Section 1: General Description....................1 1.1: E3 Series Classic Equipment .........................2 1.1.1: Intelligent Network Command Center (INCC-C) ................2 1.2: E3 Series Classic Sub-Assemblies.........................2 1.2.1: Intelligent Network Interface-Voice Gateway, (INI-VGE)..............2 1.2.2: Addressable Switch Sub-Assembly (ASM-16) ...................2 1.2.3: Amplifier-100 Watt (AA-100)......................3 1.2.4: Amplifier-120 Watt (AA-120)......................3 1.2.5: PM-9/PM-9G Power Supply Sub-Assembly- 9 Amperes ..............3...
  • Page 6 Table of Contents 3.3.5: Selecting the Default Backup Tone ....................41 3.3.6: Backup Amplifier ..........................42 3.4: Speaker Circuit Connections........................43 3.4.1: Speaker Switching ..........................43 3.4.2: Speaker Wire .............................45 3.5: Dual-Channel Classic...........................46 Section 4: Transient Overvoltage Protection............... 47 4.1: Routing Of Power-Limited Field Wiring Circuits ..................47 Index ............................

  • Page 7: Section 1: General Description

    Section 1: General Description ® The E3 Series Classic Emergency Voice Evacuation System is a peer-to-peer, self-regenerating, token ring passing network consisting of two (2) to sixty-four (64) nodes. The System is of a modular design. This design allows a wide range of configurations from three basic assemblies to form an integrated, distributed fire alarm system with bulk audio evacuation and fire command capability.

  • Page 8: E3 Series Classic Equipment

    General Description E3 Series Classic Equipment 1.1 E3 Series Classic Equipment 1.1.1 Intelligent Network Command Center (INCC-C) The Command and Control Center is comprised of one INI-VGE, one or more ASM-16 programmable switch sub-assemblies, ANU-48 remote LED Driver sub-assemblies, or an NGA Network LCD annunciator.

  • Page 9: 3: Amplifier-100 Watt (Aa-100)

    E3 Series Classic Sub-Assemblies General Description 1.2.3 Amplifier-100 Watt (AA-100) The AA-100 is a 100-watt switching audio output amplifier, with two (2) standard outputs of or 70.7 V . Only one of the two outputs may be used in an installation. It has one (1) fully supervised speaker circuit wired Style Y (Class B) or Style Z (Class A) capable of supplying up to 100 watts of power maximum.

  • Page 10: 7100 Fire Alarm Control Panel Equipment

    General Description 7100 Fire Alarm Control Panel Equipment 1.3 7100 Fire Alarm Control Panel Equipment 1.3.1 7100 Fire Alarm Control Panel Features The 7100 Series is shipped unassembled. The shipping carton includes the 7100 Series Installation/Operating Manual, P/N: 9000-0447. The 7100 Series analog, addressable fire alarm control panel provides such standard features as: •...

  • Page 11: E3 Series Fire Alarm Control Panel Equipment

    E3 Series Fire Alarm Control Panel Equipment General Description 1.4 E3 Series Fire Alarm Control Panel Equipment The E3 Series Fire Alarm Control Panel includes the following equipment: • ILI-MB-E3, ILI95-MB-E3 or ANX • PM-9 or PM-9G • LCD-E3 • RPT-E3-UTP or RPT-E3-FO 1.4.1 E3 Series Fire Alarm Control Panel Features •...

  • Page 12: Section 2: Installation

    Installation Installation Requirements Section 2: Installation 2.1 Installation Requirements ® All components of the E3 Series Classic System should be located per the following require- ments: • The INCC-C Command Center must be mounted close-nippled to the PM-9/PM-9G or to a UL Listed fire power supply that supplies it with its 24 VDC operating voltage, such as the ®...

  • Page 13: Incc-E Backbox (Single Back Box Application)

    INCC-E BackBox (Single Back Box Application) Installation 2.4 INCC-E BackBox (Single Back Box Application) Prepare the mounting site by pre-drilling for fasteners as needed using the dimensions shown in Figure 2.4.1. Mounting hardware should be #10 to ¼" in diameter. Fasteners must be anchored into solid materials unless backed by studs or equivalent support.

  • Page 14: Incc-E Back Box (Multiple Back Box Application)

    Installation INCC-E Back Box (Multiple Back Box Application) 2.5 INCC-E Back Box (Multiple Back Box Application) When two or more INCC-E enclosures are required, the first backbox is installed per the instructions described in Section 2.3. Additional backboxes require a separation of ¾" between adjacent enclosures to ensure clearance for the doors.

  • Page 15: E3 Series Classic Intelligent Network Command Center Assembly

    E3 Series Classic Intelligent Network Command Center Assembly Installation 2.6 E3 Series Classic Intelligent Network Command Center Assembly (INCC) General The INCC-C Intelligent Network Command Center uses a modular approach. Consequently, the contents of an INCC-C assembly will vary depending on the project's specific requirements. It occupies one (1) node on the E3 Series Classic network without an NGA installed, and occupies two (2) nodes with an NGA installed.

  • Page 16: 1: Intelligent Network Interface (Ini-Vge Series)

    Installation E3 Series Classic Intelligent Network Command Center Assembly 2.6.1 Intelligent Network Interface (INI-VGE Series) CAUTION: STATIC SENSITIVE EQUIPMENT THIS SUB-ASSEMBLY IS A STATIC SENSITIVE ELECTRONIC DEVICE. TO MINIMIZE THE POSSIBILITY OF DAMAGE, ALWAYS USE A GROUNDED WRIST STRAP OR MAINTAIN CONTACT WITH GROUND WHILE HANDLING THIS EQUIPMENT.

  • Page 17: 4: Asm-16 Or Anu-48 Wiring Connections

    E3 Series Classic Intelligent Network Command Center Assembly Installation 2.6.4 ASM-16 or ANU-48 Wiring Connections For the ASM-16, ANU-48, INI-VG Series, ILI-MB-E3/ILI95-MB-E3, LCD-E3 or remote enclo- sure installations, use the wiring connections in Table 2.6.4.1, and refer to Notes A-F in Figure 2.6.4.1 for the ribbon cable and hardwire locations.
  • Page 18 Installation E3 Series Classic Intelligent Network Command Center Assembly INI-VGC, INI-VGX or INI-VGE Wiring Designation Description Designation From INI-VGC, INI-VGX or INI-VGE To ASM-16 or ANU-48 J3 RS-485 Local Ribbon Cable J1, J2 or J3 Note: See Note C in Figure 2.6.4.1 for the ribbon cable connection. From INI-VGC, INI-VGX or INI-VGE To ASM-16 or ANU-48 TB6 RS-485 Remote...
  • Page 19 E3 Series Classic Intelligent Network Command Center Assembly Installation 2.6.4 ASM-16 or ANU-48 Wiring Connections (Continued) Figure 2.6.4.1 illustrates the ASM-16 and ANU-48 wiring connections. NOTE A: ASM-16 or ANU-48 to ASM-16 or ANU-48 wiring ASM-16/ANU-48 to ASM-16/ANU-48 RS-485 connection NOTE C and F: From local INI-VG or LCD-E3 J1 (RS-485 Local)

  • Page 20: 5: Remote Led Driver Sub-Assembly (Anu-48)

    Installation E3 Series Classic Intelligent Network Command Center Assembly 2.6.5 Remote LED Driver Sub-Assembly (ANU-48) CAUTION: STATIC SENSITIVE EQUIPMENT THIS SUB-ASSEMBLY IS A STATIC SENSITIVE ELECTRONIC DEVICE. TO MINIMIZE THE POSSIBILITY OF DAMAGE, ALWAYS USE A GROUNDED WRIST STRAP OR MAINTAIN CONTACT WITH GROUND WHILE HANDLING THIS EQUIPMENT.

  • Page 21: 6: Amplifiers (Aa-100, Aa-120)

    E3 Series Classic Intelligent Network Command Center Assembly Installation 2.6.6 Amplifiers (AA-100, AA-120) The AA-100 and AA-120 amplifiers mount in the cabinets DR-C4B and DR-D4B. Unpack the AA Amplifier from its shipping carton and remove it from its anti-static bag. It mounts directly in the DR cabinet.

  • Page 22: 8: Voice Paging Microphone Assembly (Optional)

    Installation E3 Series Classic Intelligent Network Command Center Assembly 2.6.8 Voice Paging Microphone Assembly (Optional) Unpack the pre-assembled Voice Paging Microphone assembly from its shipping carton. NOTE: For new installations, temporarily remove the INCC inner door from the INCC-E backbox and place it face down on a flat surface.

  • Page 23: 9: Fire Fighter's Intercom Handset Assembly (Optional)

    E3 Series Classic Intelligent Network Command Center Assembly Installation 2.6.9 Fire Fighter's Intercom Handset Assembly (Optional) Unpack the handset assembly from its shipping carton. NOTE: Be sure to use the INCC-T inner door to accommodate the assembly. For new installations, temporarily remove the inner door from the INCC-E backbox and place it face down on a flat surface.

  • Page 24: 10: Nga Lcd Annunciator Sub Assembly

    Installation E3 Series Classic Intelligent Network Command Center Assembly 2.6.10 NGA LCD Annunciator Sub Assembly CAUTION: STATIC SENSITIVE EQUIPMENT THIS SUB-ASSEMBLY IS A STATIC SENSITIVE ELECTRONIC DEVICE. TO MINIMIZE THE POSSIBILITY OF DAMAGE, ALWAYS USE A GROUNDED WRIST STRAP OR MAINTAIN CONTACT WITH GROUND WHILE HANDLING THIS EQUIPMENT.

  • Page 25: Section 3: Wiring

    Power Connections Wiring Section 3: Wiring 3.1 Power Connections Connection of the power supply to the 120 @ 60 Hz or 240 VAC @ 50/60 Hz power source must be made in compliance with the National Electrical Code, NFPA 70, Article 760, the applicable NFPA Standards, and according to the requirements of the Authority Having Jurisdiction.

  • Page 26: Intelligent Network Interface, Voice Gateway (Ini-Vge)

    Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) 3.2 Intelligent Network Interface, Voice Gateway (INI-VGE) ® The INI-VGE is the network interface sub-assembly for the INCC-C, E3 Series Classic Voice Command Center. In the INCC enclosure, the INI-VGE sub-assembly connects to the E3 Series Classic System microphone and fire fighter telephone handset, and supervises and controls up to six (6), ANU-48 or ASM-16 sub-assemblies.
  • Page 27 Intelligent Network Interface, Voice Gateway (INI-VGE) Wiring 3.2 Intelligent Network Interface, Voice Gateway (INI-VGE) (Continued) Table 3.2.1 lists the E3 Series Classic INI-VGE Power Consumption Calculation Chart. Total Supv. Alarm Total Alarm Sub-Assembly Description Current Current Supv. Current Current INI-VGE Intelligent Network Voice 0.150 A 0.150 A...
  • Page 28 Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) 3.2 Intelligent Network Interface, Voice Gateway (INI-VGE) (Continued) Table 3.2.2 lists the E3 Series Classic INI-VGE Series field wiring connections. Terminal Block 1- E3 Series Classic Network connection- using unshielded, twisted-pair TB1-1 COM 1A connection TB1-2 COM 1B connection TB1-3...
  • Page 29 Intelligent Network Interface, Voice Gateway (INI-VGE) Wiring 3.2 Intelligent Network Interface, Voice Gateway (INI-VGE) (Continued) Table 3.2.3 lists the E3 Series Classic INI-VGE jumpers and cable connections. Table 3.2.4 lists the E3 Series Classic INI-VGE indicating and diagnostic LEDs. Designation Description Comments "E"...
  • Page 30 Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) Designation Description Comments LED 1- A network reconfiguration is in progress. LED 3- This node is attempting to perform a network reconfiguration. LED 4- Duplicate or invalid network address. LED 5- The sub-assembly is transmitting network data. LED 6- This sub-assembly is receiving network data on Channel 1.

  • Page 31: 1: Ini-Vge Power Connections

    Intelligent Network Interface, Voice Gateway (INI-VGE) Wiring 3.2.1 INI-VGE Power Connections The INI-VGE-FO or INI-VGE-UTP serving as the network interface and control unit of an INCC-C Command Center connects to its operating power via Terminal Block TB2. Figure 3.2.1.1 illustrates the INI-VGE power connections. ( C L E A R ) (B L A C K ) P H O N E...

  • Page 32: 2: E3 Series Classic Network Connections

    Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) 3.2.2 E3 Series Classic Network Connections The INI-VGE can be connected to the E3 Series Classic using an unshielded, twisted-pair of wires, fiber-optic cable, or a combination of the two. Figure 3.2.2.1 illustrates the INI-VGE connections. NOTE: Connectors J2, J5, J6 and J8 are omitted on the INI-VGE-UTP.
  • Page 33 Intelligent Network Interface, Voice Gateway (INI-VGE) Wiring 3.2.2 E3 Series Classic Network Connections (Continued) Designation Description Comments TB1-1 COM 1A To next node's TB1-3 (COM 2A) TB1-2 COM 1B To next node's TB1-4 (COM 2B) TB1-3 COM 2A From previous node's TB1-1 (COM 1A) TB1-4 COM 2B From previous node's TB1-2 (COM 1B)
  • Page 34 Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) ® 3.2.2 E3 Series Classic Network Connections (Continued) Figure 3.2.2.1 illustrates multiple network connections. REPEATER RS485 REMOTE RS485 LOCAL TO NEXT NODE RX2 CONNECTOR TO NEXT NODE TX2 CONNECTOR FROM PREVIOUS NODE RX1 CONNECTOR FROM PREVIOUS NODE TX1 CONNECTOR SIGNALS IN/OUT CONNECTIONS using FIBER-OPTIC CABLE...

  • Page 35: 3: Ini-Vge Signaling Line Circuit

    Intelligent Network Interface, Voice Gateway (INI-VGE) Wiring 3.2.3 INI-VGE Signaling Line Circuit This sub-assembly provides one (1), Style 4 (Class B) Signaling Line Circuit (SLC). Up to sixteen (16), AOM-TELF Fire Fighter Intercom circuits and up to thirty-two (32), AOM-2SF Single- Channel speaker circuits can be connected to this SLC.

  • Page 36: 4: Ini-Vge Fire Fighter Intercom Riser Connections

    Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) 3.2.4 INI-VGE Fire Fighter Intercom Riser Connections This sub-assembly provides a phone riser circuit on Terminal Block TB5, Terminals 3 and 4 that connects to the AOM-TELF/AOM-2SF Fire Fighter Phone circuit Terminals 3 and 4. Up to sixteen (16), AOM-TELF/AOM-2SF can be connected to each INI-VGE phone riser.

  • Page 37: 5: Ini-Vge Connections To Remote Asm-16 Sub-Assemblies

    Intelligent Network Interface, Voice Gateway (INI-VGE) Wiring 3.2.5 INI-VGE Connections to Remote ASM-16 Sub-Assemblies An INI-VGE installed in an INCC-C Command Center assembly can support up to sixteen (16), ASM-16 programmable switch sub-assemblies. The INCC-C cabinet has space for up to six (6), ASM-16 sub-assemblies (there are three (3) spaces available, if a microphone and fire fighter handset are included).

  • Page 38: 7: Ini-Vge Programming Address Switch Settings

    Wiring Intelligent Network Interface, Voice Gateway (INI-VGE) 3.2.7 INI-VGE Programming Address Switch Settings Use INI-VGE DIP Switch SW-1 to set the address that the sub-assembly will occupy on the E3 Series Classic network. Do not duplicate addresses with other sub-assemblies on the network. For the fastest communication between nodes, set the addresses in consecutive order.

  • Page 39: Aa-100 And Aa-120 Power Amplifiers

    AA-100 and AA-120 Power Amplifiers Wiring 3.3 AA-100 and AA-120 Power Amplifiers Figure 3.3.1 illustrates the AA-100 and AA-120 Power amplifiers. Figure 3.3.1 AA-100 and AA-120 Power Amplifiers A) AA-100 Audio Amplifier The AA-100 audio amplifier provides up to 100 watts of power. Two outputs are provided, dual output provides 70.7V .

  • Page 40: 1: Primary/Secondary Power Requirements For The Aa-100/Aa-120 Audio Amplifiers

    Wiring AA-100 and AA-120 Power Amplifiers 3.3.1 Primary/Secondary Power Requirements for the AA-100/AA- 120 Audio Amplifiers Primary power required for the AA-100, and AA-120 amplifiers are 120VAC. Secondary power (24 VDC battery) connections must be made at the designated terminals shown in Figure 3.3.2.1. Secondary power may be obtained from any source of 24 VDC that is Listed for fire alarm signaling and it has sufficient alarm and standby capacity (etc.).
  • Page 41 AA-100 and AA-120 Power Amplifiers Wiring 3.3.1.1 ACT-1 Audio Coupling Transformer Overview The ACT-1 Audio Coupling Transformer couples a low-level audio to the audio amplifiers. The unit can be used to couple a low-level audio signal up to eight (8), devices. Multiple ACT-1s are required for amplifiers on multiple channels.
  • Page 42 Wiring AA-100 and AA-120 Power Amplifiers 3.3.1.2 ACT-1 Audio Coupling Transformer Installation To connect an ACT-1 to an AA-100 or AA-120 amplifier, follow these steps and refer to Figure 3.3.1.2.1: Connect the ACT-1 to the first amplifier in the chain by inserting P1 pins of the ACT-1 into Terminal Block P3 of the amplifier as shown in Figure 3.3.1.2.1.
  • Page 43 AA-100 and AA-120 Power Amplifiers Wiring 3.3.1.3 ACT-1 Wiring Amplifiers Figure 3.3.1.3.1 illustrates the wiring amplifiers. Figure 3.3.1.3.1 ACT-1 Wiring Diagram NOTE 1: Using the grounding wire supplied, connect the “EARTH” ground terminal of each ACT-1 to terminal P8-10 on the AA-100 or AA-120. The “COMM” terminal is intended for shielding of the ACT-1 output.

  • Page 44: 2: Amplifier Connections

    Wiring AA-100 and AA-120 Power Amplifiers 3.3.2 Amplifier Connections Figure 3.3.2.1 illustrates the amplifier connections for the upper and the lower boards. Figure 3.3.2.1 Amplifier Connections - Upper and Lower Boards NOTE 1:The low-level input and high-level output "P" connectors are primarily for in-cabinet applications where the wiring to or from the amplifier remains in the same cabinet.

  • Page 45: 3: Adjusting Audio Gain Level

    AA-100 and AA-120 Power Amplifiers Wiring 3.3.2 Amplifier Connections (Continued) Figure 3.3.2.2 illustrates the stand alone operation. Cut R100 to enable 4-wire output supervision Cut R107 to enable “Stand Alone” operation Figure 3.3.2.2 “Stand Alone” Operation 3.3.3 Adjusting Audio Gain Level A multi-position rotary switch allows the installer to adjust the gain of the audio output signal to compensate for audio line losses.

  • Page 46: 4: Leds

    Wiring AA-100 and AA-120 Power Amplifiers 3.3.3. Adjusting Audio Gain Level (Continued) Figure 3.3.3.1 illustrates the audio gain switch. Audio Gain Figure 3.3.3.1 Audio Gain Switch 3.3.4 LEDs Figure 3.3.4.1 includes a description of the LEDs. SW1 (see detail below) Battery Trouble LED –...

  • Page 47: 5: Selecting The Default Backup Tone

    AA-100 and AA-120 Power Amplifiers Wiring 3.3.5 Selecting the Default Backup Tone Use SW1, located in the lower right corner of the amplifier circuit board, to select Hi/Lo or Slow Whoop as the default backup tone. The backup tone will start automatically if the low-level audio input to the amplifier is lost or when the amplifier has been configured for stand-alone operation.

  • Page 48: 6: Backup Amplifier

    Wiring AA-100 and AA-120 Power Amplifiers 3.3.6 Backup Amplifier An AA-120 amplifier can be used to backup one or more amplifiers. In the event of an amplifier failure, backup amplifier switching is automatic. Figure 3.3.6.1 illustrates the backup amplifier switching. Figure 3.3.6.1 Backup Amplifier E3 Series Classic Installation/Operation Manual —...

  • Page 49: Speaker Circuit Connections

    Speaker Circuit Connections Wiring 3.4 Speaker Circuit Connections 3.4.1 Speaker Switching The amplified signal from each audio amplifier must be connected to a control module, which will switch the signal to a speaker circuit when necessary. Figure 3.4.1.1 through Figure 3.4.1.4 illustrate the wiring configurations for the AA-100, and AA-120 audio amplifiers.
  • Page 50 Wiring Speaker Circuit Connections 3.4.1 Speaker Switching (Continued) Communication Line 28 VDC max. twisted-pair is recommended All wiring is supervised. From panel or To Next Previous device Device Control Module Speaker Switching Circuit-NFPA Style Y AOM-2SF Speakers must be Listed for fire protection Maximum Load 43.75 watts max.

  • Page 51: 2: Speaker Wire

    Speaker Circuit Connections Wiring 3.4.2 Speaker Wire Use twisted, SHIELDED pair, 18 AWG. minimum. Make sure the shield is run continuously through the speaker circuits with no segments of the shield left floating. Do not tie the shield to conduit or junction boxes in the field. Terminate the drain wire back at the panel's location to system negative.

  • Page 52: Dual-Channel Classic

    Wiring Dual-Channel Classic 3.5 Dual-Channel Classic The Dual-Channel Classic is a dual-channel configuration used in the bulk audio voice evacuation ® ® systems, such as the NetSOLO and E3 Series Classic Systems. This alternate design uses one AOM-2RF module and one AOM-2SF module. The AOM-2RF module provides the dual-channel for audio, and the AOM-2SF module provides the broadcast channel for zone paging/alarm tone.

  • Page 53: Section 4: Transient Overvoltage Protection

    Section 4: Transient Overvoltage Protection 4.1 Routing Of Power-Limited Field Wiring Circuits UL Standard 864, (Control Units for Fire Protective Signaling Systems), requires that a minimum of ¼ inch separation be maintained between power-limited circuits and non power-limited circuits. The control unit is designed so the required separation between these circuits (power-limited vs. non power-limited) is maintained at the field wiring terminals.

  • Page 54: Index

    Index Numerics 7100 Features 4 LEDs 40 AA 33 NGA 3 AA-100 3 AA-120 3 ACT-1 35 PM-9 3 Address Switch Settings PM-9G 3 INI-VGE 32 Power Amplifiers ANU-48 3 AA-100 and AA-120 33 ANX 5 Power Consumption ASM-16 2 ANU-48 21 AOM-2SF 21 AOM-TELF 21...

  • Page 55: Manufacturer Warranties And Limitation Of Liability

    Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
  • Page 56 Gamewell-FCI 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.gamewell-fci.com...
