Summary of Contents for Sundstrom SR 100
- Page 1 Operation instructions SR 100 Half mask Revision: 03 OI01H-2018 SR 100 2020-03-06...
-
Page 2: General Information
SR 307 compressed air attachment which then serves as a breathing apparatus with continuous flow for connection to a compressed air supply. A wide range of accessories are available. When selecting equipment for SR 100 some of the factors that should be taken into account are as follows: •... - Page 3 Unpacking the SR 100 Packing list: • Half mask • Pre-filter holder • Cleaning tissue • ID-tag • Pre-filter • Storage bag • Instruction for use OI01H-2018 SR 100 2020-03-06...
- Page 4 Squeeze hard until you hear of the particle filter and the the particle filter snap onto small tab molded into the side the gas filter. of the gas filter. Push firmly and twist the coin until the filter pops off. OI01H-2018 SR 100 2020-03-06...
- Page 5 Carefully check that the edge of the filter is in the internal groove of the filter mounting all around. 1.6 Fit pre-filter SR 221 in the pre-filter holder. OI01H-2018 SR 100 2020-03-06...
- Page 6 2.2 Take out any twists or 2.4 Let the mask hang on tangles. your chest. OI01H-2018 SR 100 2020-03-06...
- Page 7 2.5 Grab the pad with one 2.7 Pull the pad over your hand and the filter with the head and place it on the other. crown of the head. 2.6 Hold the mask against your face. OI01H-2018 SR 100 2020-03-06...
-
Page 8: Adjusting The Harness
Use your thumb and forefinger to squeeze the buckle shut. 3.2 Pull the free end away 3.4 Wiggle the respirator until from the neck until buckle it seats comfortably. pops open. OI01H-2018 SR 100 2020-03-06... - Page 9 If any leakage is detected, check the inhalation and exhalation valves, adjust the straps of head harness or switch to alternative size of the respirator. Repeat the fit check until there is no leakage. OI01H-2018 SR 100 2020-03-06...
- Page 10 Gently not twisted and snap on the stretch the flap until it slips new harness by putting each over the stud. plastic swivel into the contoured slot and pulling it until it snaps in. OI01H-2018 SR 100 2020-03-06...
- Page 11 Carefully check that the membranes are in contact with the membrane seats all round. 7.2 Prise off the membranes. 7.4 Press the valve covers into place. A clicking sound indicates that the cover has snapped into place. OI01H-2018 SR 100 2020-03-06...
- Page 12 8.1 Remove the filter, the covers for the exhalation valves and the membranes, the inhalation membrane and the head harness. (Optional – The harness can be washed but takes extra time to dry.) OI01H-2018 SR 100 2020-03-06...
-
Page 13: Maintenance Schedule
9. Maintenance schedule Before use After use Annually Visual inspection Functional check Cleaning Membrane change Head harness change OI01H-2018 SR 100 2020-03-06... - Page 14 H01-2812 Product Description The SR 100 half mask is made of silicone in three sizes, i.e. S/M, M/L and L/XL. The mask is equipped with two exhalation valves, which ensures very low exhalation resistance. The valve covers with partitions effectively protect the exhalation membrane against dust and paint mist.
- Page 15 SR 100, SR 90-3 Spare parts / Accessories...
- Page 16 Description Ordering No. Head harness SR 363, single strap R01-2001 Head harness sr 362, cradle strap R01-2002 Gas filter (SR 217 A1, SR 218 A2, SR 315 ABE1, SR 294 A2B2E1, SR 297 ABEK1, SR 298 A2AX, SR 316 K1, SR 295 K2, SR 299-2 ABEK-Hg-P3R) Particle filter SR 510 P3 R H02-1312 Pre-filter SR 221...
