Bristan Naxos NAX BSM C (D2) Installation Instructions & User Manual

Dynamic Water Pressure
Max: 5.0 bar
Min: 0.3 bar
2.0 3.0
1.0
4.0
0 5.0
Pressure
BAR
Maximum Static Pressure: 10.0 bar
Pack Contents Pack Contents
x1
Naxos Tap
x2
x2
Plinth
Washer
x1
Outlet Key
Tools Required for Installation/ Maintenance Tools Required for Installation/ Maintenance
ø6mm
Drill Safety Glasses
All products manufactured and supplied by Bristan are safe to use provided that they are installed,
operated and receive regular maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water
Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
For full Installation Requirements & Notes (IRN) please visit www.wrasapprovals.co.uk/approvals-directory
Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance. Before installing this
product the water supply must be thoroughly flushed in order to remove any swarf, solder etc. Full access must be
made available for future maintenance/servicing purposes.
If power tools are used do not forget to:
This product must not be modified in any way as this will invalidate the guarantee.
Specifications
Inlet Water Temperature
Maximum Hot 60°C
x1
Hose
Washer
x1
Backnut
Handset
x1
Bracket
Pencil Adjustable Spanner Hexagonal Key
Prior to Installation
- Wear eye protection
Installation Instructions
Please leave these instructions
Naxos Bath Shower Mixer | NAX BSM C (D2)
Inlet Connections
60°C
3/4" BSP
Operation Operation
Pull up and twist diverter
clockwise to divert to handset
On
Hot
12mm
2mm
Hexagonal Key
(Grub Screws) (Diverter)
- Unplug equipment after use
& User Guide
with the end user
M24 Recessed
Flow Straightener
Continue to twist diverter clockwise
to divert back to bath fill
32mm
17mm
Box Spanner Box Spanner
(Inlets) (Cartridge)
Spare Parts
To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your
Outlet
On
Cold
Size 1
Philips Head
Screwdriver
product.
