800W BRIDGE SAW
Safety and Operating Manual
103620
Safety First
Read manual before use. Keep hands, arms and face clear
of blade whilst in use. Always have safety guard in place
when machine is switched on at mains. Always wear Vitrex
Protective Equipment when using hand or power tools.
A QUALITY BRAND OF
Advertisement
Table of Contents
Related Manuals for QEP Vitrex 103620
Summary of Contents for QEP Vitrex 103620
- Page 1 800W BRIDGE SAW Safety and Operating Manual 103620 Safety First Read manual before use. Keep hands, arms and face clear of blade whilst in use. Always have safety guard in place when machine is switched on at mains. Always wear Vitrex Protective Equipment when using hand or power tools.
- Page 2 800W BRIDGE SAW Safety and Operating Manual Contents Safety Instructions ....................................Machine Specifications ..................................Assembly, Operating Instructions and Maintenance ..................... Care, Customer Advice and Warranty ............................. Tel: +44 (0) 1283 245 430 • www.vitrex.co.uk...
-
Page 3: Safety Instructions
800W BRIDGE SAW Safety Instructions This manual must be kept in a safe place so that the information • Before use, check the pump for damage. Should the pump that it contains is always available. This operating manual must be damaged, it must not be used. accompany the equipment if it is transferred to somebody else. -
Page 4: Machine Specifications
Machine Specifications 103620 230V 50Hz Power Supply Motor 800W RPM (no load) 2950 rpm Maximum Sound Level 84.2 dB (A) Blade Size 22.2mm bore x 200mm Maximum Depth of Cut (new blade) 35mm Maximum Depth of Cut at 45° (new blade) 30mm Mitre Cutting Angle 0°... - Page 5 800W BRIDGE SAW Assembly Operating STRAIGHT CUTS Remove the saw from its carton, lay carefully on its side Unfasten blade carriage retaining bolt Always use the following procedure, in the order given, when assembling the water reservoir. Mount the first table leg in place. Mount the first cushion in the leg.
- Page 6 ANGULAR CUTS MITRE CUTS Place the tile in position on the cutting table so that it rests against the Loosen the two knobs at either end of the bridge measuring scale and the mitre guide Loosen the winged screw on the mitre guide and set the angle of cut Tilt the bridge to the desired angle (up to 45°) and re-tighten required Pull the blade carriage steadily towards you, cutting through the tile...
-
Page 7: Emptying Water
800W BRIDGE SAW Emptying Water Maintenance • The machine does not require any special maintenance • Regularly remove grindings from the housing and the covers • The unit must not be operated if the mains connection lead is not in perfect condition •... - Page 8 The above guarantee is only valid within the UK and does not affect your statutory rights. The guarantor is QEP Co. UK Ltd., The Maltsters, Wetmore Road, Burton upon Trent, DE14 1LS (Registered No. 04988177 England) QEP Co. UK Ltd., The Maltsters, Wetmore Road, Burton upon Trent, DE14 1LS PRCI SAS - Groupe QEP, Avenue du Moulin De La Jasse, BP 30, 34750 Villeneuve Les Maguelone, France Tel: +44 (0) 1283 245 430 •...
