VoxPower EIRE300 Series User Manual

EIRE300 Series
USER MANUAL
Single Output Open Frame AC/DC Power Series
______________________________________________________________________________________________________
4" x 2" x 1"
Low profile
300W
Fan cooled
200W
Convection cooled (115V )
AC
BF Rated
Silent
Superior convection cooling, unlimited applications.
The EIRE300 series user manual has been prepared by our design team to assist qualified engineers in correctly
designing in the EIRE300 product into their application to achieve the best reliability and performance possible.
All specifications are believed to be correct at time of publishing. Vox Power Ltd reserves the right to make changes to any of its products and to change or improve any part of the
specification, electrical or mechanical design or manufacturing process without notice. Vox Power Ltd does not assume any liability arising out of the use or application of any of its products
and of any information to the maximum extent permitted by law. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or
by any products of Vox Power Ltd. VOX POWER LTD DISCLAIMS ALL WARRANTIES AND REPRESENTATIONS OF ANY KIND WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF SUITABILITY, FITNESS FOR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT.
Please consult your local distributor or Vox Power directly to ensure that you have the latest revision before using the product and refer to the latest relevant user manual for further information
relating to the use of the product. Unless specifically otherwise agreed in writing by Vox Power, products sold by Vox Power are not intended for use in connection with life support systems,
human implantations, nuclear facilities or systems, aircraft spacecraft, military or naval missile, ground support or control equipment used for the purpose of guidance navigation or direction
of any aircraft spacecraft or military or naval missile or any other application where product failure could lead to loss of life or catastrophic property damage. The user will indemnify and hold
Vox Power harmless from any loss, cost or damage resulting from its breach of the provisions.

EIRE300 Series Overview

The EIRE300 series of open frame power supplies deliver 300 Watts of power in a miniature 4x2x1 Inch package and is the ultimate power solution
for industrial automation, home healthcare and telecommunication applications where a high efficiency, ruggedized, affordable and BF rated
power solution with Class I or II installation capability is required. The EIRE300 product series offers power densities exceeding 37W per cubic
inch with efficiencies up to 95%. The EIRE300 is approved to the latest medical and industrial safety standards (IEC/UL60601-1 3 RD Edition,
IEC/UL62368-1 3 RD Edition). The EIRE300 has also been designed to meet UL60335-1, UL61558-1, UL61010-1, and is approved to the latest EMC
standards and feature market leading specifications and design-in application support.
