VCCM600 Series
AC/DC conduction cooled configurable power supplies
User Manual
_____________________________________________________________________________________________________
Cool it your way.
Conduction | Convection | Forced Air
4"x7"x1.61"
600W
SILENT
SMALL
POWERFUL
FAN-LESS
The VCCM600 series user manual has been prepared by our design team to assist qualified engineers in correctly
designing in the VCCM600 product into their application to achieve the best reliability and performance possible.
All specifications are believed to be correct at time of publishing. Vox Power Ltd reserves the right to make changes to any of its products and to change or improve any part of the
specification, electrical or mechanical design or manufacturing process without notice. Vox Power Ltd does not assume any liability arising out of the use or application of any of its
products and of any information to the maximum extent permitted by law. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this
document or by any products of Vox Power Ltd. VOX POWER LTD DISCLAIMS ALL WARRANTIES AND REPRESENTATIONS OF ANY KIND WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, IMPLIED WARRANTIES OF SUITABILITY, FITNESS FOR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT.
Please consult your local distributor or Vox Power directly to ensure that you have the latest revision before using the product and refer to the latest relevant user manual for further
information relating to the use of the product.
Vox Power Ltd products are not intended for use in connection with life support systems, human implantations, nuclear facilities or systems,
aircraft, spacecraft, military or naval missile, ground support or control equipment used for the purpose of guidance navigation or direction of any aircraft, spacecraft or military or naval
missile or any other application where product failure could lead to loss of life or catastrophic property damage. The user will hold Vox Power Ltd harmless from any loss, cost or damage
resulting from its breach of these provisions.

VCCM600 Series Overview

The VCCM600 series of conduction cooled configurable power platform delivers a silent 600 Watts and up to 750 Watts of peak power for 5
seconds in a rugged 4" x 7" package and is the ultimate power solution for applications where reliability or audible noise are of concern. The
product combines the advantages of a modular power supply with the high reliability of a fan-less architecture. Depending on your application,
the VCCM600 can be configured as a conduction, convection or forced air cooled solution and this versatility allows the unit to be seamlessly
integrated across a vast range of applications, which makes it perfect for standardising your power platform.
Designed with highest reliability and versatility in mind, the VCCM600 is suitable for applications ranging from the most controlled environments
to the harshest conditions. Each configured modular solution can accommodate up to 4 isolated DC output modules which utilize 100% SMT
components for increased reliability. Standard features include full output voltage adjust range, externally controllable voltage and current and
series & paralleling of outputs. The unique design approach and heat dissipation techniques allows the unit to be mounted in virtually any
orientation giving system designers even more flexibility. The series is approved to latest safety and EMC standards and features market leading
specifications and design in application support.
DOC-MN-007-03 VCCM600 User Manual
Vox Power Limited | Unit 2, Red Cow Interchange Estate, Ballymount, Dublin 22, D22 Y8H2, Ireland | T +353 1 4591161 | www.vox-power.com
