VoxPower VCCR300 Series User Manual

VCCR300 Series
USER MANUAL
Single Output Conduction Cooled DC/DC
_______________________________________________________________________________________________
The VCCR300 series user manual has been prepared by our design team to assist qualified engineers in correctly
designing in the VCCR300 product into their application to achieve the best reliability and performance possible.
All specifications are believed to be correct at time of publishing. Vox Power Ltd reserves the right to make changes to any of its products and to change or improve any part of the
specification, electrical or mechanical design or manufacturing process without notice. Vox Power Ltd does not assume any liability arising out of the use or application of any of its products
and of any information to the maximum extent permitted by law. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or
by any products of Vox Power Ltd. VOX POWER LTD DISCLAIMS ALL WARRANTIES AND REPRESENTATIONS OF ANY KIND WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF SUITABILITY, FITNESS FOR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT.
Please consult your local distributor or Vox Power directly to ensure that you have the latest revision before using the product and refer to the latest relevant user manual for further information
relating to the use of the product. Unless specifically otherwise agreed in writing by Vox Power, products sold by Vox Power are not intended for use in connection with life support systems,
human implantations, nuclear facilities or systems, aircraft spacecraft, military or naval missile, ground support or control equipment used for the purpose of guidance navigation or direction
of any aircraft spacecraft or military or naval missile or any other application where product failure could lead to loss of life or catastrophic property damage. The user will indemnify and hold
Vox Power harmless from any loss, cost or damage resulting from its breach of the provisions.

VCCR300 Series Overview

The VCCR300 series of conduction cooled power supplies have been designed to provide a rugged and highly reliable DC/DC power source that
can deliver a silent 300 Watts of power in a 7.43 x 4.6 x 1-inch low profile package. The input voltage has a wide range of 33.6V to 160V which covers
the full requirements for the standard 48V, 72V, 96V and 110V railway battery voltages outlined in EN50155 and suitable for a variety of Battery
Electric Vehicle (BEV) and other demanding industrial applications. The high efficiency design minimises heating resulting in a wide operating
temperature range of -40°C to +70°C (+85°C 10 mins) with minimal cooling requirement. Output voltages of 12V, 24V, 36V and 48V are available
with a wide adjustment range of 90% to 125%. Protections including over-voltage, over-current and over-temperature are provided while DC_OK
and warning signals indicate the status of the PSU. An adjustable droop mode current share allows multiple units to be paralleled while sharing the
load equally. Internal fusing and 10ms full power holdup are included as standard. A remote shutdown signal can place the unit in a low power
standby mode and the input undervoltage level can be adjusted to meet application requirements. The series meets the requirements of the latest
railway standards (EN50155), MIL-STD-810G (Shock & Vibration) and is approved to the latest industrial safety standards (IEC/UL62368-1 3
EMC emissions and immunity exceed the requirements of EN50121-3-2, EN55035 and EN55032 class B. As with all Vox products, our world class
sales, applications and engineering teams are available to support design-in of the VCCR300 series.
Page 1 of 20 Vox Power Limited | Unit 2, Red Cow Interchange Estate, Ballymount, Dublin 22, D22 Y8H2, Ireland | T +353 1 4591161 |
Ruggedised for long term reliability
7.43" x 4.6" x 1"
Low Profile
300W | 600W | 900W
Scalable
33.6-160V
DC
Wide input voltage range
Fan-less
Reliable
DOC-MN-009-03, VCCR300 User Manual
RD Edition).
www.vox-power.com
