Important installation information

This VCCM600 series of configurable power supplies are intended for use within end customer applications which restrict access to un-authorized personnel. The instructions in this manual
and all warning labels on the product must be adhered to carefully.
The VCCM600S and VCCM600M series are designed in accordance with the relevant safety requirements of IEC/EN/UL/CSA 62368-1, IEC/EN/UL/CSA 60950-
SAFETY 1, IEC/EN/UL/CSA 60601-1, Low voltage Directive LVD 2014/35/EU and EMC directive EMC 2014/30/EU. All VCCM600 series power supplies must be
installed correctly in a controlled environment which restricts access to any un-authorised personnel. Equipment and system manufacturers must protect
service personnel against unintentional contact with the output terminals.
Dangerous voltages are present within the power supply.
It should only be handled by qualified personnel when the power supply has been disconnected from the mains supply voltage for more than 3 minutes.
HAZZARDS
External surfaces of the power supply may become extremely hot during and after operation. Appropriate care should be taken. If series and/or parallel
combinations of outputs exceed safe voltage and/or energy levels, the final equipment manufacturer must provide the appropriate protection for both
users and service personnel.
Ambient
Temperature
Baseplate
Temperature
DE-RATINGS
Input Voltage
Remember to take the appropriate de-rating into consideration before specifying any VCCM600 power supply for an application.
If in any doubt, please contact Vox Power directly or your local Vox Power representative.
HEALTH AND To comply with section 6 of the health and safety at work act, a label that is clearly visible to service personnel must be placed on the final equipment.
SAFETY These labels warn that surfaces of the power supply may be hot and should not be touched when the product is operating.
The power supply has internal dual pole fusing. One fuse in each line.
FUSING Fuses are not replaceable. Damaged units should be returned to Vox Power for analysis and repair.
DC operation is not covered by safety approvals. Contact Vox Power for details.
SERVICING The power supply contains no user serviceable parts. Repairs must be carried out by authorised personnel only. Contact Vox Power for further information.
APPROVAL NORTH AMERICA - When this product is used with 180V
LIMITATIONS on the input connector.
For proper operation of the power supply, the user must ensure sufficient cooling to maintain all component temperatures within specifications. A
COOLING
thorough review of the user manual should be carried out for details of thermal performance.
To comply with the requirements of IEC/EN/UL/CSA 62368-1, IEC/EN/UL/CSA 60950-1 & IEC/EN/UL/CSA 60601-1, where the incoming wiring earth is
EARTH TERMINAL intended for connection as the main protective earth conductor and where the terminals for such a connection is not supplied on a component or
MARKING subassembly, the user shall add an appropriate label displaying a protective earth symbol in accordance with IEC60417-5019 (2006-08) directly adjacent to
the terminal. The label should be durable and legible and should withstand the 15 second rub test as per UL60950-1 section 1.7.15.
WARRANTY Contact your sales agent or Vox Power for product repairs. See Vox Power standard terms and conditions for warranty conditions.
The external product label contains information relevant to the power system. The label contains input voltage, maximum input current, input frequency,
PRODUCT LABELS
maximum output power, fuse rating and type, serial number, approvals and product part number in form VCCM600x-yyyy-zzz.
VCCM OUTPUT Each output module label contains information relevant to that output. The label contains voltage adjustment range, maximum output current, serial
MODULES number, approvals and the part number in format OPx.
•
A label warning that external surfaces are hot during operation and that the unit should be allowed to cool down properly should be placed on
the unit where such a label is clearly visible.
•
The VCCM600 series is designed to comply with EMC standards but it does not imply that the end system will comply.
•
To prolong the life of the unit, use in dust free environment.
OTHER
•
Units can sometimes be damaged during transit. In the event of transit damage, DO NOT connect power to the unit. Contact your sales agent or
Vox Power.
•
Always use adequately sized cables and ensure good crimp connections. Use cable supports to minimise stress on connectors.
•
Avoid excessive shock or vibration.
Page 1 of 4 Vox Power Limited | Unit 2, Red Cow Interchange Estate, Ballymount, Dublin 22, D22 Y8H2, Ireland | T +353 1 4591161 |
AC/DC Conduction Cooled Configurable Power Supply
•
The input module power must be de-rated by 2.5%/°C above 50°C ambient up to a maximum ambient temperature of 70°C.
•
The output module power and current must be de-rated by 2.5%/°C above 85°C baseplate up to a maximum baseplate
temperature of 105°C.
•
The input module power must be de-rated by 5W/V
Note that the mains supply voltage tolerance must be included when calculating the derating. E.g. 100V nominal mains
with -15% tolerance must be derated to 85V rating.
–253V
AC
VCCM600 Series
INSTALLATION MANUAL
below120 V (600W @ 120 V
RMS RMS
mains where no neutral is present, connect the two live wires to L (Live) and N (Neutral)
AC
, 450W @ 90 V )
RMS RMS
