NEVO+600 Series
USER MANUAL
______________________________________________________________________________________________________
The NEVO+600 series user manual has been prepared by the Vox Power design team to assist qualified
engineers in correctly implementing the product and to achieve the best reliability and performance possible.
All specifications are believed to be correct at time of publishing. Vox Power Ltd reserves the right to make changes to any of its products and to change or improve any part of the
specification, electrical or mechanical design or manufacturing process without notice. Vox Power Ltd does not assume any liability arising out of the use or application of any of its products
and of any information to the maximum extent permitted by law. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document or
by any products of Vox Power Ltd. VOX POWER LTD DISCLAIMS ALL WARRANTIES AND REPRESENTATIONS OF ANY KIND WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF SUITABILITY, FITNESS FOR PURPOSE, MERCHANTABILITY AND NONINFRINGEMENT.
Please consult your local distributor or Vox Power directly to ensure that you have the latest revision before using the product and refer to the latest relevant user manual for further information
relating to the use of the product. Vox Power Ltd products are not intended for use in connection with life support systems, human implantations, nuclear facilities or systems, aircraft,
spacecraft, military or naval missile, ground support or control equipment used for the purpose of guidance navigation or direction of any aircraft, spacecraft or military or naval missile or any
other application where product failure could lead to loss of life or catastrophic property damage. The user will hold Vox Power Ltd harmless from any loss, cost or damage resulting from its
breach of these provisions.

NEVO+600 series overview

The NEVO+600 switch mode power supply series offers truly unrivalled power density, providing 600 W at 25 W/in
ultimate power solution for system designers as they address the pressing demands for more power within less space. Providing multiple isolated
outputs, the series carry full IEC60601 (NEVO+600M/ML only) and IEC60950 & IEC62368 (NEVO+600S/SL) safety approvals.The basic system consists
of an input module together with up to four fully isolated output modules. Single output modules have advanced remote voltage and current
programming functionality as standard. While dual output modules allow for up to eight fully isolated outputs. The input module delivers up to 600
W of output power and has 4 slots, each capable of separately delivering up to 150 W. A 5 V, 1A medically isolated bias supply together with an
AC_OK signal and a global inhibit signal that can disable all outputs simultaneously, comes as standard on all models. Output modules are available
in a range of output voltages and currents to suit all applications. Single output modules with voltage ranges from 1.5V to 60V, currents up to 25A
and paralleling and series capability can result in a voltage range up to 240V and a maximum current of up to 100 Amps from a single NEVO+600
configuration. Dual output modules have a voltage ranges from 1.5V to 15V and currents up to 5A with series capability. By selecting the correct
output modules, a custom power solution can be configured in a few minutes. This instantly available custom solution offers industry leading power
density, total system efficiencies of up to 89% and suits all types of applications including industrial, medical, aerospace, military and telecoms.
Page 1 of 31 Vox Power
Limited | Unit 2, Red Cow Interchange Estate, Ballymount, Dublin 22, D22 Y8H2, Ireland | T +353 1 4591161 |
600 Watts
in the palm of your hand
600W
Powerful
5" x 3" x 1.61"
Small
600g
Light
3
in a 5" x 3"x 1U package. It is the
www.vox-power.com
DOC-MN-005-07, NEVO+600 User Manual
