INSTALLATION INSTRUCTIONS
Product
7160-1431
GETAC B360 LAPTOP DOCKING STATION
This instruction sheet is for the Getac B360 Laptop Docking Station only. For instructions on
features, set-up, and operation of the computer, please refer to the manual provided by
Getac with the computer.
This docking station is designed to be used with a variety of Gamber-Johnson mounting
systems. Installation instructions for other Gamber-Johnson products are provided with each
individual product.
This instruction sheet is for the following products:
Item No. 7160-1431-00 Non-RF (External Power Supply sold separately)
Item No. 7160-1431-03 Tri-RF (External Power Supply sold separately)
Getac recommends using the following Power Adapters to power the docking station. They
can be ordered from Gamber-Johnson seperately.
7300-0471 - Auto
7300-0413 - Isolated (12-32 Vdc input)
7300-0412 - Isolated (20-60 Vdc input)
7300-0416 - Isolated (72-110 Vdc input)
Product Mounting Disclaimer
Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage
of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson
products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is
required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications
and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
(12-32 Vdc input) - Available with the docking station as KIT 7170-0789
Revision
Rev. D
Printing Spec: PS-001
Form
INST-971
1 / 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GETAC B360 and is the answer not in the manual?

Questions and answers

Related Manuals for Gamber Johnson GETAC B360

Summary of Contents for Gamber Johnson GETAC B360

  • Page 1 GETAC B360 LAPTOP DOCKING STATION Printing Spec: PS-001 This instruction sheet is for the Getac B360 Laptop Docking Station only. For instructions on features, set-up, and operation of the computer, please refer to the manual provided by Getac with the computer.

  • Page 2: Pre-Installation Recommendations

    PRE-INSTALLATION RECOMMENDATIONS Conduct a "Bench Test" Gamber-Johnson strongly advises a "bench test" be conducted to verify all electronic and software issues are resolved prior to installation: Make sure the computer is operational by itself. Insert computer into the docking station and verify that the computer is operating in the dock.

  • Page 3: Feature Identification

    FEATURE IDENTIFICATION Rear Hooks Docking Mechanism Activators Rear Walls Provides docking guidance and prevents mis-docking Docking Connector External Antenna Tri RF (Optional) Release Button Shock Absorbers Front Hooks (2) USB 2.0 Barrel Key Lock Contact Friendly Edges 500 mA Release Button Cover VESA 75mm Hole Pattern Part#/Serial# Label 1/4-20 x 0.500"...

  • Page 4: Port Identification

    PORT IDENTIFICATION Ethernet (2) USB 3.0 (2) HDMI Power Input: 19 Vdc (RJ45) 900 mA USB 3.0 USB 2.0 Serial 900 mA 500 mA CABLE MANAGEMENT FEATURES AND PROPER INSTALLATION 1.) Use Zip ties (provided) to secure each port cable to the specific strain relief feature on the dock 2.) Use Zip ties (provided) to secure bundled cables for improved routing - OPTIONAL 1.) Cable Tie Slots 2.) Cable Tie Slot (Bundles)

  • Page 5: Operation - Docking

    DOCKING AND UNDOCKING THE COMPUTER OPERATION - DOCKING 1. Insert the front of the laptop into the front hooks of the dock. The walls on the dock will help guide the computer into place. 2. Rotate the back of the laptop onto the dock and push down in the center or both top corners, Push Down...
  • Page 6 Screen Support Installation Screen supports are recommended on all laptop dock/cradles in high-vibration environments. (1) screen support is included with each Getac B360 assembly, another may be purchased from www.GamberJohnson.com. Part Number: 7110-1332 Screen Support Mounting Locations Use supplied #6-32 screws to attach included screen support to the left or right mounting location, do not over-torque screws.
  • Page 7 Regulatory Certification Information Regulatory Model #: 7160-1431 GJ Model #'s & Description: 7160-1431-00 Dock-Getac B360 Laptop-No RF 7160-1431-03 Dock-Getac B360 Laptop-Tri RF Certifications: • EN 55032: 2012/AC: 2013 Class A • EN 50498: 2010 • E-Mark This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions.
