Scotchman SHEARMASTER 610 Instructions Manual

How to replace a kraus & neimer camswitch with a direct replacement cam switch
Hide thumbs Also See for SHEARMASTER 610:

Advertisement

Quick Links

Download this manual
COLOR PRINTING IS RECOMMENDED
FOR DIGITAL COPY CONTACT 1-800-843-8844
FEBRUARY 2022
SCOTCHMAN INDS. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-800-843-8844

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHEARMASTER 610 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Scotchman SHEARMASTER 610

Summary of Contents for Scotchman SHEARMASTER 610

  • Page 1 COLOR PRINTING IS RECOMMENDED FOR DIGITAL COPY CONTACT 1-800-843-8844 FEBRUARY 2022 SCOTCHMAN INDS. - 180 E US HWY 14 - PO BOX 850 - PHILIP, SD 57567 Call: 1-800-843-8844...
  • Page 2 The following instructions describe how to replace a Kraus & Neimer cam switch with a direct replacement cam switch on the machine(s) listed below. For machines built prior to February 2022 with Klockner Moeller cam switches, see Page 5. DISCONNECT POWER TO THE MACHINE BEFORE MODIFICATION. 011200 011200 Applies to Serial Numbers:...
  • Page 3 Turn the main power disconnect (A) to the OFF position. Open the panel door by turning the lock (B) counter-clockwise. Press the red release handle (C) of the switch and disconnect the switch from the legend holder assembly. Carefully pull the switch back to allow access to the legend holder (D) assembly from the rear. Remove the old legend holder from the panel by unscrewing the nut (E) from the backside.

  • Page 4: Right View

    #43 - 3 REMOVE ALL EXTERNAL JUMPERS (A) SUPPLIED WITH NEW #13 - 5 SWITCH. Press the red release handle (B) on the new switch to separate the #31 - 9 LEFT VIEW knob/legend holder from the switch. #23 - 11 Install the legend holder (C) into the panel and fasten with nut (D) from backside.
  • Page 5 Replacement Diagram 1DISC SEE MOTOR TAG INCOMING SUPPLY FOR DETAILS (BY CUSTOMER) PROVIDE MAXIMUM UPSTREAM PROTECTION PER N.E.C. CODE 430-52 AND TABLE 430-152. SEE TRANSFORMER FOR FUSE REPLACEMENT WIRING DATA 1FU & 2FU = FNQ-R-1 OPTIONAL WORK LIGHT 3FU = FNM-2 AVAILABLE (1T MUST BE 250VA) (BLK) (WHT)
  • Page 6 The following instructions describe how to replace a Klockner Moeller cam switch (left) with a Kraus & Neimer cam switch (right) on the machine(s) listed below. DISCONNECT POWER TO THE MACHINE BEFORE MODIFICATION. Klockner Moeller Kraus & Neimer Applies to Serial Numbers: 610 ShearMaster: 2093A0921 &...
  • Page 7 The key difference between the Klockner Moeller switches (011868) and the Kraus & Neimer switches (011200) are the contact numbers and internal jumpers. The charts below show the difference in contact closures and jumpers. KLOCKNER MOELLER KRAUS & NEIMER CONTACT CLOSURE CLOSURE CONTACT CLOSURES...

  • Page 8: Bottom View

    Turn the main power disconnect (A) to the OFF position. Open the BOTTOM VIEW panel door by turning the lock (B) counter-clockwise. Loosen the screw (C) retaining the knob. Remove knob (D). Unscrew the large nut (E) of the cam switch from the back side of the panel.
  • Page 9 #43 - 3 REMOVE ALL EXTERNAL JUMPERS (A) SUPPLIED WITH NEW #13 - 5 SWITCH. Press the red release handle (B) on the new switch to separate the #31 - 9 LEFT VIEW knob/legend holder from the switch. #23 - 11 Install the legend holder (C) into the panel and fasten with nut (D) from backside.
  • Page 10 Retrofit Diagram 1DISC SEE MOTOR TAG INCOMING SUPPLY FOR DETAILS (BY CUSTOMER) PROVIDE MAXIMUM UPSTREAM PROTECTION PER N.E.C. CODE 430-52 AND TABLE 430-152. SEE TRANSFORMER FOR FUSE REPLACEMENT WIRING DATA 1FU & 2FU = FNQ-R-1 OPTIONAL WORK LIGHT 3FU = FNM-2 AVAILABLE (1T MUST BE 250VA) (BLK) (WHT)
