Carrier CDI-30Q7 Owner's Manual

Hide thumbs

Table Of Contents

Quick Links

Download this manual

IMPORTANT NOTE:

Before using your appliance, please read

this manual carefully and keep it for future reference.

DEHUMIDIFIER

Owner's Manual

Installation & Operation

CDI-30Q7

CDI-30Q7B

Table of Contents

Need help?

Do you have a question about the CDI-30Q7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Carrier CDI-30Q7

Page 1 DEHUMIDIFIER Owner’s Manual Installation & Operation CDI-30Q7 CDI-30Q7B IMPORTANT NOTE: Before using your appliance, please read this manual carefully and keep it for future reference.
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS PRODUCT OVERVIEW CONFIRM IT BEFORE YOU GET START OPERATION INSTRUCTIONS REMOVING THE COLLECTED WATER CLEANING AND MAINTENANCE TROUBLESHOOTING DISPOSAL AND RECYCLING...
Page 4: Safety Precautions
SAFETY PRECAUTIONS It’s really important you read Safety Precautions Before Operation and Installation Incorrect installation due to ignoring instructions can cause serious damage or injury. The seriousness of potential damage or injuries is classiﬁed as either a WARNING or CAUTION. Explanation of Symbols WARNING The signal word indicates a hazard with a medium level of risk...
Page 5 CAUTION • This appliance can be used by children aged from 8 years and above and person with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 6 Note about Fluorinated Gasses(Not applicable to the unit using R290 Refrigerant) 1. Fluorinated greenhouse gases are contained in hermetically sealed equipment. For speciﬁc information on the type, the amount and the CO2 equivalent in tonnes of the ﬂuorinated greenhouse gas(on some models), please refer to the relevant label on the unit itself.
Page 7 WARNING for Using R32/R290 Refrigerant Do not use means to accelerate the defrosting process or to clean, other than those • recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition • sources (for example: open ﬂames, an operating gas appliance or an operating electric heater).
Page 8 6.Information on servicing 1)Checks to the area Prior to beginning work on systems containing ﬂammable refrigerants, safety checks are necessary to ensure that the risk of ignition is minimised. For repair to the refrigerating system, the following precautions shall be complied with prior to conducting work on the system.
Page 9 9)Checks to electrical devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with.
Page 10 Leak detection ﬂuids are suitable for use with most refrigerants but the use of detergents containing chlorine shall be avoided as the chlorine may react with the refrigerant and corrode the copper pipe-work. If a leak is suspected, all naked ﬂames shall be removed/extinguished.
Page 11 g) Start the recovery machine and operate in accordance with manufacturer's instructions. h)Do not overﬁll cylinders. (No more than 80 % volume liquid charge). i)Do not exceed the maximum working pressure of thecylinder, even temporarily. j)When the cylinders have been ﬁlled correctly and the process completed, make sure that the cylinders and the equipment are removed from site promptly and all isolation valves on the equipment are closed o .
Page 12: Product Overview
PRODUCT OVERVIEW NOTE ON ILLUSTRATIONS: All the illustrations in the manual are for explanation purpose only. Your machine may be slightly di erent. The actual shape shall prevail. The unit can be controlled by the unit control panel alone. Back View Front View control panel water tank...
Page 13: Optional Accessories
Casters(At four points on the bottom of unit) Casters can move freely. Do not force casters to move over carpet, nor move the unit with water in the bucket. (The unit may tip over and spill water.) A dehumidiﬁer operating in a basement will have little or no e ect in drying an adjacent enclosed storage area, such as a closet, unless there is adequate circulation of air in and out of the area.
Page 14: Operation Instructions
OPERATION INSTRUCTIONS Control Panel NOTE The following control panels are for explanation purpose only. The control panel of the unit you purchased may be slightly di erent according to the models. Your machine may not contain some indicators or buttons. The actual shape shall prevail.
Page 15 ECO MODE Press the Mode button and select ECO mode. In ECO dehumidiﬁcation mode, you can press the UP and DOWN buttons to adjust the humidity. The humidity range is 35% to 85%. The default value is 60%. NOTE: When in ECO mode, FAN speed can not be adjusted. SET MODE Press the Mode button and select Set mode.
Page 16 9.Self-clean- Function • Turn this function ON/OFF by press the PURIFY button for 3 seconds. 10.LED Function • In the startup state, press TIMER and MODE keys and continue for3 seconds to turn on/o the digital display function. 11.Child Lock Function •...
Page 17: Removing The Collected Water
REMOVING THE COLLECTED WATER There are two ways to remove collected water. Type 1: Type 2: Bucket drainage water hose drainage (continuous) Bucket drainage Type 1 NOTE · When you remove the bucket from the unit do not set the unit on any electrical components as the bottom may be wet.
Page 18 Water outlet Pour the water out. Pour the water out.(The bucket of the unit you purchased may be slightly di erent) water hose drainage (continuous) Type 2 NOTE · Make sure the hose is secure so there are no leaks. ·...
Page 19: Cleaning And Maintenance
CLEANING AND MAINTENANCE Turn the dehumidiﬁer o and disconnect the plug from the power source before cleaning. Clean the Grill and Case Use water and a mild detergent. Do not use bleach or abrasives. Do not splash water directly onto the main unit. Doing so may cause an electrical shock, cause the insulation to deteriorate, or cause the unit to rust.
Page 20 Clean the air ﬁlter The air ﬁlter behind the front grille should be checked and cleaned at least every two weeks or more often if necessary. NOTE: DO NOT RINSE OR PUT THE FILTER IN AN AUTOMATIC DISHWASHER. To remove: •...
Page 21 Install big HEPA ﬁlter with handle strap. Mount outwards for replacement. NOTE: Be sure to remove the plastic sealing ﬁlm before using big HEPA ﬁlter. CAUTION DO NOT operate the dehumidiﬁer without a ﬁlter because dirt and lint will clog it and reduce performance. NOTE: The cabinet and front may be dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mildliquid dishwashing detergent.
Page 22 When not using the unit for long time periods Step 2 Step 1 Step 3 After *Please refer to the actual plug, and the legend is for reference only. Step6 Step 4 Step 5 Step 1: Unplug the product, after turning o the unit. Step 2: Empty the bucket after 24 hours of unplugging.
Page 23: Troubleshooting 2
TROUBLESHOOTING Before calling for service, review the chart below ﬁrst yourself. Problem What to check Make sure the dehumidiﬁer s plug is pushed completely into the outlet. Check the house fuse/circuit breaker box. Unit does not start Dehumidiﬁer has reached its preset level or bucket is full. Water bucket is not in the proper position.
Page 25 说明书技术条件：（此页无需印刷）材质：80克双胶纸颜色：黑白尺寸：210*290 装订：骑马钉...
