- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S LWM4X1UM LWM3X1UM LWM5X1UM Wall-Mounted Modular Menu Boards Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description...
-
Page 2: Important Safety Instructions
The information contained in this document is subject LWM3X1UM 125 lbs 375 lbs to change without notice or obligation of any kind. Legrand (56.7 kg) (170.1 kg) (wood stud/ makes no representation of warranty, expressed or implied, concrete) regarding the information contained herein. - Page 3 Installation Instructions Modular LWM Series WARNING: Use this mounting system only for its intended use as described in these instructions. Do not use attachments not recommended by the manufacturer. WARNING: Never operate this mounting system if it is damaged. Return the mounting system to a service center for examination and repair.
- Page 4 Modular LWM Series Installation Instructions LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
-
Page 5: Tools Required For Installation
Installation Instructions Modular LWM Series TOOLS REQUIRED FOR INSTALLATION 7/32" 3/8" 1/8" 1/8" 3/8" 3/16" 3/16" 1/2" (all included) PARTS [Quantities listed in order for models: LWM3X1M/LWM4X1M/LWM5X1M] DISPLAY ATTACH HARDWARE BAG (3/4/5) Q (3 - 36"/3 - 36" + 1 - 48"/4 - 48") (Qty listed per hardware bag) [Horizontal mounting rail] (Example shown: 36") - Page 6 Modular LWM Series Installation Instructions WALL ATTACHMENT INFORMATION Attachment for LWM3X1M Rail Outside wall uprights (CC) Attachment for LWM4X1 and LWM5X1 (LWM4X1 shown as example) Rail Center wall upright (DD) Outside wall uprights (CC) Figure 1 Table 1: Wall Upright Specifications Model (Outside wall upright spacing) (End of rail to wall upright)
-
Page 7: Installation
Installation Instructions Modular LWM Series INSTALLATION IMPORTANT ! : Refer to Dimensions section at end of instructions to find specific Modular LWM wall-mounted Spring washer menu board dimension requirements BEFORE proceeding with installation. NOTE: The outside wall uprights (CC) ship assembled to allow height adjustment from the bottom. - Page 8 Modular LWM Series Installation Instructions Attach Wall Uprights Remove four button head screws and nuts, and one small metal plate from lower side within wall upright. (See Figure 5) IMPORTANT ! : Reference Wall Placement Reinstall metal plate at top of wall upright using same Information section (See Figure 1) and Table 1.
- Page 9 Installation Instructions Modular LWM Series Installing to Wood Stud Walls Installing to Concrete Walls Drill one 7/32" (5.5mm) pilot hole in stud at upper mounting Drill one 3/8" x 3-1/2" (9.5mm x 88.9mm) pilot hole at each slot. (See Figure 8) marking.
- Page 10 Modular LWM Series Installation Instructions Installing to Steel Stud Walls Installing BETWEEN steel studs into 3/4" plywood (covered in 1/2" or 5/8" drywall) : Use two 1/4-20 BB Snaptoggle anchors with two minimum 2-1/2" long, minimum Grade 5 screws through wall upright into plywood. (Hardware not included.) (See Figure Installing into plywood (covered in 1/2"...
- Page 11 Installation Instructions Modular LWM Series Steel Studs Snap off plastic straps on anchor at wall by pushing side to side, snapping off straps level with flange of plastic cap. IMPORTANT ! : See Site Requirements section before (See Figure 14) proceeding with Steel Studs installation to ensure installation site meets requirements! The drywall must have a minimum thickness of 1/2"!
- Page 12 Modular LWM Series Installation Instructions ATTACH MOUNTING RAIL Slide second section of mounting rail (Q) over tie bars (NN) and bring it flush to first section of mounting rail. (See Figure 18) NOTE: One height adjust plate (BB) will need to be slid into place prior to attaching mount rails for LWM4X1M and (FF) (KK)
- Page 13 Installation Instructions Modular LWM Series Attach one end cap (S) with two 1/4-20 x 1/2" Phillips head screws (T) to end of mounting rail (Q). (See Figure 20) (CC) 125 lbs 375 lbs (56.7 kg) (170.1) (BB) (T) x 2 (back view of rail) Figure 20 Slide height adjust plates (BB) into open end of mounting...
- Page 14 Modular LWM Series Installation Instructions Adjust and Level Mounting Rail Place displays face down on a soft, non-abrasive surface. Adjust the height of the mounting rail via the wall upright, as Align the center of the interface bracket (R) with center of necessary, to level the mounting rail on the wall.
- Page 15 Installation Instructions Modular LWM Series ATTACH DISPLAYS TO MOUNTING RAIL display onto mounting rail, hooking top of interface brackets onto front of mounting rail. (See Figure 28) Repeat Steps 3 through 5 for each additional display. WARNING: IMPROPER INSTALLATION CAN LEAD TO DISPLAY FALLING CAUSING SERIOUS PERSONAL Interface Bracket Adjustment INJURY OR DAMAGE TO EQUIPMENT! The displays must...
- Page 16 Modular LWM Series Installation Instructions OPTIONAL: Security OPTIONAL: Add padlock (not included) to each interface bracket to lock display to menu board. (See Figure 31) Padlock (Optional) (Displays not shown) Figure 31...
- Page 17 Installation Instructions Modular LWM Series DIMENSIONS LWM3X1UM...
- Page 18 Modular LWM Series Installation Instructions DIMENSIONS (continued) LWM3X1UM...
- Page 19 Installation Instructions Modular LWM Series DIMENSIONS (continued) LWM4X1UM...
- Page 20 Modular LWM Series Installation Instructions DIMENSIONS (continued) LWM4X1UM...
- Page 21 Installation Instructions Modular LWM Series DIMENSIONS (continued) LWM5X1UM...
- Page 22 Modular LWM Series Installation Instructions DIMENSIONS (continued) LWM5X1UM...
- Page 23 Installation Instructions Modular LWM Series DIMENSIONS (continued) LWM5X1UM...
-
Page 24: Installation Instructions
