- Page 1 User manual BOX 35-45-120 / BOX 40-45-110 BOX 35-45-150 / BOX 40-45-150 This product is not suitable for primary heating purposes Serial number: Production date:...
- Page 2 Barbas Bellfires BV. This document could contain technical inaccuracies or typographical errors. Barbas Bellfires BV reserves the right to revise this document from time to time in the contents thereof.
-
Page 3: Table Of Contents
Contents Contents Declaration of Performance..............5 BOX 35-45-120 ...........................5 BOX 40-45-110 ...........................6 BOX 35-45-150 ...........................7 BOX 40-45-150 ...........................8 About this document................9 How to work with this document....................9 Warnings and cautions used in this document................9 Related documentation........................ 9 Description..................... - Page 4 Contents Technical data ..................27 Product information according regulation (EU) 2015/1185....28 11.1 BOX 35-45-120 / BOX 40-45-110....................28 11.2 BOX 35-45-150 / BOX 40-45-150....................29 Warranty Terms..................30 BOX 35 45...
-
Page 5: Declaration Of Performance
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 6: Box 40-45-110
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 7: Box 35-45-150
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 8: Box 40-45-150
Name, registered trade name or registered trade mark Barbas Bellfires BV; Hallenstraat 17; 5531 AB Bladel; The Netherlands and contact address of the manufacturer as required pursuant to Article 11(5) -
Page 9: About This Document
About this document About this document This document shows the necessary information to operate the appliance and do basic maintenance on: • BOX 35-45-120 • BOX 40-45-110 • BOX 35-45-150 • BOX 40-45-150 in this document referred to as 'the appliance'. This document is an essential part of your appliance. -
Page 10: Description
Description Description Overview of the front of the appliance BOX 35-45-120 BOX 40-45-110 BOX 35-45-150 BOX 40-45-150 Door handle Glass Primary air inlet Grate Log guard Ash tray (under the grate) Combustion chamber panels Flue connection Control lever Wood log storage module... -
Page 11: Intended Use
Description Intended use The appliance is intended for indoor use to heat the room wherein it is installed. Do not use it for other purposes. It is not allowed to use the appliance as primary heating appliance. The appliance is intended for use with wood logs or wood briquettes as fuel. Do not use other fuels. -
Page 12: Safety
Note: • Do inspect and clean the appliance, the chimney and the external combustion air supply by a Barbas dealer minimum every year. • Do not use the appliance continuously. The intended use is as intermittent appliance. - Page 13 Safety • Dispose of ceramic heat-resistant glass as household waste. Do not dispose of ceramic heat-resistant glass in a glass recycling container. • Dispose of an obsolete appliance according to instructions of the authorities or the fitter. • Obey the local regulations. BOX 35 45...
-
Page 14: Fuel
Fuel Fuel Fuel types Warning: Do not use coal, anthracite, coal briquettes, liquid fuel or gel fuel. The appliance is not designed for these fuels. Use of these fuels is dangerous and can lead to bodily harm and to serious damage to the appliance. Suitable fuels are: •... - Page 15 Fuel The above listed amount burns for approximately 45 minutes. This time can be different, dependent on the chimney draught and the position of the combustion air valve. BOX 35 45...
-
Page 16: Operation
Operation Operation Preparation before first use Report any defects to your dealer immediately. Procedure Make sure that the appliance is not damaged. Make sure that the ceramic plate and the baffles are in the correct position. Make sure that the glass is not damaged. Make sure that the door opens and closes completely, by moving the door handle Remove document and components from the combustion chamber. - Page 17 Operation Put minimum 4 wood logs crosswise on the floor of the combustion chamber. Put some kindling wood and 1 or 2 firestarter cubes on top of the wood logs. Put some kindling wood above the firestarter cubes. Light the firestarter cubes with a lighter or a match. Close the door of the appliance.
-
Page 18: Reload For Nominal Heat Output
Operation 6.3.2 Reload for nominal heat output Caution: If there is insufficient burning material in the firebed to light a new fuel charge, excessive smoke emission can occur. Refueling must be done onto a sufficient quantity of glowing embers and ash to make sure that the new fuel charge will ignite in a reasonable period. -
Page 19: Control The Burn Process
Operation Wait until the last flames have almost disappeared. Set the control lever in the far right position. Open the door. Reload the appliance with 1 wood log or 1 wood briquette. Refer to section for the weight and the length of the wood log. -
Page 20: Increase The Flue Draught
Operation Control lever in the far right position: primary air inlet maximum open secondary air inlet maximum open airwash inlet maximum open Control lever in the center position: primary air inlet is closed secondary air inlet maximum open airwash inlet maximum open Control lever in the far left position: primary air inlet is closed secondary air inlet is closed... - Page 21 Operation Open the door. Loosen the nut above the heat shield with a 3 mm hexagonal key and a 10 mm fork spanner. Turn the nut down with the fork spanner and turn the screw up with the hexagonal key until the screw is loose from the heat shield.
-
Page 22: General Firing Tips
Operation Turn the screw down with a 3 mm hexagonal key until it is in the screw hole in the heat shield. Turn the nut up with a 10 mm fork spanner and tighten it. 6.3.6 General firing tips 6.3.1 •... -
Page 23: Maintenance
Maintenance Maintenance Maintenance schedule Caution: Clean the glass when it is dirty. If the glass is not cleaned when it is dirty the glass can become permanently dull. Task Frequency Procedure Remove the ashes When necessary Refer to section Clean the glass When necessary Refer to section Maintenance by your fitter... -
Page 24: Troubleshooting
Troubleshooting Troubleshooting Problem Possible cause Possible solution • Set the control lever in the far left position. • Call the emergency services. (112) • Put out the fire in the appliance with sand. Warning: Chimney fire (recognized by a Ignition of soot and tar de- Never use water roaring sound in the chimney) posits in the chimney. - Page 25 Troubleshooting Problem Possible cause Possible solution • Use the recommended amount of fuel. Refer to section • Increase the amount of com- The combustion chamber is bustion air with the control lev- 6.3.4 not hot enough er. Refer to section •...
-
Page 26: Information On Disposal Of The Appliance
Information on disposal of the appliance Information on disposal of the appliance • Dispose of an obsolete appliance according to instructions of the authorities or the installer. • The information in this section is informative. Always obey the national and local regulations on recycling and disposal of the appliance or parts of the appliance. -
Page 27: Technical Data
Technical data Technical data Name Barbas Model 35-45-120 40-45-110 35-45-150 40-45-150 EPREL registration number 2046154 2122295 2109579 2109585 Tested in accordance with EN 13240:2001-A2:2004 EN 16510-1 annex D, E, F BS 3841-2:1994 Energy efficiency index (according EU 2015/1186) Energy efficiency class Fuel •... -
Page 28: Product Information According Regulation (Eu) 2015/1185
Product information according regulation (EU) 2015/1185 Product information according regulation (EU) 2015/1185 11.1 BOX 35-45-120 / BOX 40-45-110 Model identifier BOX 35-45-120 Equivalent models BOX 40-45-110 Indirect heating function Direct heat output 7.1 kW Indirect heat output - kW Emissions at nominal heat... -
Page 29: Box 35-45-150 / Box 40-45-150
With electronic room temperature control plus week timer applicable) Other control options (multiple selection possible) Room temperature control, with presence detection Room temperature control, with open window detection With distance control option Barbas Bellfires BV Hallenstraat 17 Contact details www.barbas.com 5531 AB BLADEL The Netherlands (*) PM = particulate matter, OGC = organic gaseous compounds, CO = carbon monoxide, NOx = nitrogen oxides (**) Only required if correction factors F(2) or F(3) are applied. -
Page 30: Warranty Terms
Warranty Terms Warranty Terms To make a claim under the warranty, it is important to register the Barbas appliance after pur- chase via www.barbasbellfires.com. Barbas Bellfires Warranty Terms Barbas Bellfires B.V. guarantees the quality of the supplied Barbas appliance and the quality of the materials used. - Page 31 Article 5: Warranty period This warranty will only be granted during the warranty period. The body of the Barbas appliance is guaranteed for a period of 10 years against construction and/or material faults, starting from the moment of purchase. For other parts of the Barbas appliance, a similar warranty applies from the moment of purchase for a period of two years.
- Page 32 Your Barbas dealer 23.09.2024 - 355553 - 409-002...
