Summary of Contents for AUSTRALIAN MONITOR Z624PS
- Page 1 INSTALLATION AND OPERATION MANUAL Z624PS Z624 Paging Station...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION READ these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 3: Introduction & Contents
Controls Connecting the Z624PS The Z624PS is designed to be used with the Z624 system to provide paging to individual zones, combination of zones or all Specifications zones. Connection to the Z624 is via low cost CAT 5 cable. - Page 4 To accommodate different speech levels there is a microphone becomes active. gain control on rear of the Z624PS. Adjust the level to provide clear paging audio. ALL PAGE This button pages to all zones. It is momentary so ACCESSORY PORT must be held while talking into the microphone.
- Page 5 Remote Input 1 - Z624PS TERMINATION (DO NOT SKIP THIS STEP) If the Z624PS is the LAST device on an accessory port cable run it MUST be terminated using the rear panel "PORT TERM" DIP switches by turning them to the ON position.
- Page 6 Note: This step will only happen when using a new paging station or the system needs to update the firmware. 3. The Z624PS will then reboot and retrieve it's configuration from the Z624, this is indicated by a rotating clockwise LED pattern.
-
Page 7: Specifications
1.0kg SHIPPING WEIGHT 1.5kg OPERATING TEMPERATURE 0°C to 40°C FINISH Powder coated steel COLOUR Black (Satin) Label sticker sheet ACCESSORIES Microphone Windsock APPROVALS CE, IEC, RCM Microphone Frequency Response 1000 2000 5000 15000 20000 Hz Z624PS INSTALLATION AND OPERATION MANUAL... - Page 8 Z624PS DRAWINGS 132.0 mm Z624PS ZONE A ZONE B ZONE C ZONE D 132.0 mm ENGINEERED BY AUSTRALIAN MONITOR Address: Unit 1, 2 Daydream Street, Warriewood NSW 2102 Australia Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 86 003 231 187...
