Thank you for purchasing this quality Australian Monitor product.
The IMGC450 is the finest gooseneck microphone Australian Monitor has released.
This premium electret condenser microphone is tailored specifically for voice
reproduction, providing a neutral tone and transparent response. The cardioid polar
pattern of the IMGC450 provides exceptional gain before feedback. Users will
enjoy fuss-free setup with minimal EQ manipulation, ensuring maximum
SPL for that all-important presentation.
This premium microphone is highly recommended for conference rooms,
board rooms, meeting rooms, houses of worship, school halls and
many other presentation applications.
What's in the box?
1 x IMGC450 Gooseneck Microphone
1 x Isolated shock mount
3 x Self tapping screws for
shock mount installation
1 x Windsock
The instruction manual
you are now reading
IMGC450
Gooseneck Microphone
INSTRUCTION MANUAL
Features
Tailored for Voice reproduction
High Sensitivity
Exceptional gain before feedback
Discreet unobtrusive slim design
RF Shielded
Low Frequency Filter
Phantom Power 9 – 52 V
Advertisement
Related Manuals for AUSTRALIAN MONITOR IMGC450
Summary of Contents for AUSTRALIAN MONITOR IMGC450
- Page 1 Gooseneck Microphone Thank you for purchasing this quality Australian Monitor product. The IMGC450 is the finest gooseneck microphone Australian Monitor has released. This premium electret condenser microphone is tailored specifically for voice reproduction, providing a neutral tone and transparent response. The cardioid polar pattern of the IMGC450 provides exceptional gain before feedback.
- Page 2 Insert the shock mount into the hole again and fasten down the shock mount with the 3 screws provided. Installing IMGC450 into the Shock Mount To install the IMGC450 into the Shock Mount unscrew the bottom plastic screw collar. Slide the IMGC450 body into the Shock Mount.
-
Page 3: Specifications
250Hz 2000Hz 500Hz 4000Hz 1000Hz 8000Hz TYPICAL POLAR PATTERNS TYPICAL FREQUENCY RESPONSE Specifications Transducer Type Electret condenser Ø 11.5mm Polar Pattern Cardioid Frequency Response 40Hz – 20Khz LF Filter 150Hz, 6 dB/Oct Sensitivity 7.0 mV/Pa -42 dBV Electrical Impedance 200 Ω Min. -
Page 4: Important Safety Information
PERSONNEL. Rating plate and caution marking are marked on the back enclosure of the apparatus ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde St, Silverwater NSW 2128 Australia. Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 35 007 573 417...
