Heavy-Duty Gooseneck Microphone
Thank you for purchasing this quality Australian Monitor product.
The AMHEAVYG is a heavy-duty gooseneck microphone design specifically for continuous
high usage in commercial environments. The heavy-duty goose neck and dynamic
capsule provide dependable reliability which ensures years of reliable operation.
Featuring a momentary switch the AMHEAVYG is also capable of providing dry
contact closure to trigger pre-announce tone generators.
The AMHEAVYG is the ideal solution for PA paging scenarios such
supermarkets, service stations, fast food outlets and many other
demanding commercial environments.
What's in the box?
1 x AMHEAVYG Gooseneck Microphone
The instruction manual you are now reading
AMHEAVYG
INSTRUCTION MANUAL
Features
Tailored for PA paging announcements
Momentary including dry contact switch
Heavy Duty Gooseneck
Heavy duty dynamic capsule
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AUSTRALIAN MONITOR AMHEAVYG
Summary of Contents for AUSTRALIAN MONITOR AMHEAVYG
- Page 1 The heavy-duty goose neck and dynamic capsule provide dependable reliability which ensures years of reliable operation. Featuring a momentary switch the AMHEAVYG is also capable of providing dry contact closure to trigger pre-announce tone generators.
- Page 2 Using suitable fasteners secure the microphone in place. Wiring your microphone The AMHEAVYG is shipped with an unterminated 5 wire cable. This allows the installer to customise the connection type between the AMHEAVYG and device input. The AM HEAVY provides a balanced microphone output signal. It also provides a normally open (N/O) dry contact closure output from the momentary switch allowing connection to third party devices such as a pre-announce tone generator.
-
Page 3: Specifications
TYPICAL POLAR PATTERNS TYPICAL FREQUENCY RESPONSE Ø15.0mm Specifications Transducer Type Dynamic Polar Pattern Supercardioid Frequency Response 100Hz–15Khz Sensitivity 1.3 mV/Pa -58 dBV Electrical Impedance 500 Ω Min. Load Impedance 2000 Ω Max. SPL 135dB @ 1% THD Finish Silver Cable Unterminated 4.0 mm shielded 1.5m 5 core Audio Connection Red = Audio +... -
Page 4: Important Safety Information
PERSONNEL. Rating plate and caution marking are marked on the back enclosure of the apparatus ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde St, Silverwater NSW 2128 Australia. Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 35 007 573 417...
