  • Page 1 INSTALLATION AND OPERATION MANUAL ICON-3...

  • Page 2: Important Safety Information

    à la pluie ou à l’humidité. mains outlet with a protective earth connection. Un appareil avec la borne de terre de protection doit être connecté au secteur avec la connexiion de terre de protection. PAGE 2 ICON-3 MANUAL...

  • Page 3: Introduction And Contents

    INTRODUCTION AND CONTENTS ICON-3 INTRODUCTION The ICON-3 paging station is both elegant and ergonomic to suit FRONT PANEL today’s modern installations. CONNECTION ICON-3 is designed for use with the Australian Monitor Zone Revolution, allowing for paging to any single zone or combination...

  • Page 4: Front Panel

    Zone page is active but on a lower priority paging station A template for creating these labels is provided with your ICON-3 paging microphone, additional copies may be downloaded from the Australian Monitor web site (the URL is provided on the last page of this manual).
  • Page 5 This RJ45 connector provides power, data and audio signals to and from the ICON-3, for direct connection to the Zone Revolution Page ports. Each ICON-3 paging station is connected directly to the Zone Revolution in a point-to-point manner. Zone Revolution supports a maximum of 2 ICON-3 stations.
  • Page 6 SETTINGS The ICON-3 Paging Station under side provides a single bank of DIP switches for VR1: address selection and future options. The adjustable potentiometer VR1 provides The adjustable trim-pot provides a method to trim the microphone audio gain fi ne adjustment of the microphone audio level.
  • Page 7 DIMENSIONS 109.0 mm 80.0 mm SIDE FRONT BACK BOTTOM PAGE 7 ICON-3 MANUAL...
  • Page 8 ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde Street, Silverwater, Sydney NSW 2128 Australia. Private Bag 149, Silverwater NSW 1811 ABN 78 001 345 482 Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au DISTRIBUTED IN AUSTRALIA AND NEW ZEALAND BY HILLS SVL www.hillssvl.com.au...
