Bradley S19-125BF Installation Manual

Barrier free recess-mounted drench shower
Hide thumbs
1
2
3
4
5
6
7
Table of Contents

Advertisement

Quick Links

Download this manual
S19-125BF
For questions regarding the operation, installation or maintenance of this product, visit bradleycorp .com
or call 800 .BRADLEY (800 .272 .3539) .
Product warranties and parts information may also be found under "Products" on our web site at bradleycorp .com .
215-1567 Rev. F: ECO 21-05-023
© 2021 Bradley
Page 1 of 7
9/15/2021
Installation
S19-125BF
S19-125FMBF
S19-125FMBF
Barrier Free Recess-Mounted Drench
Shower

Table of Contents

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Supplies Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly of Components . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cabinet Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Read the instructions in this manual before
beginning installation. Save these instructions
and refer to them for inspection, maintenance
and troubleshooting information.
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
+1 262 251 6000
bradleycorp.com
P.O. Box 309

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S19-125BF and is the answer not in the manual?

Questions and answers

Related Manuals for Bradley S19-125BF

Summary of Contents for Bradley S19-125BF

  • Page 1: Table Of Contents

    For questions regarding the operation, installation or maintenance of this product, visit bradleycorp .com or call 800 .BRADLEY (800 .272 .3539) . Product warranties and parts information may also be found under “Products” on our web site at bradleycorp .com .

  • Page 2: Safety Information

    ANSI/ISEA Z358 .1 . ANSI/ISEA Z358 .1 requires this unit to be used with a clean, potable, uninterrupted supply of tepid water . Bradley plumbed emergency fixtures require a minimum of 30 psi flowing pressure in order to function as designed and meet the ANSI/ISEA Z358 .1 standard .

  • Page 3: Supplies Required

    Service Prepacks Valve Mounting Hardware Prepack (includes Valve Mounting Bracket, U-Bolt, Nuts and Washers) S45-2236 Screw Prepack (includes six screws and Torx Power Bit) S45-2235 Valve/Handle Prepack (includes Handle and Valve Assembly) S45-2981 Bradley • 215-1567 Rev. F: ECO 21-05-023 9/15/2021...

  • Page 4: Cabinet Dimensions

    Side View Front View 3-3/4" (95mm) 1/4" (2mm) 15-13/16" (402mm) 14" 6-1/8" (357mm) (156mm) 8-5/16" (237mm) 3-3/4" (95mm) 3-9/16" 1/4" (2mm) (90mm) DIA. 2" 1-3/4" (51mm) (34mm) 10" 1-3/4" (254mm) (34mm) 12" (305mm) Bradley • 215-1567 Rev. F: ECO 21-05-023 9/15/2021...

  • Page 5: Rough-Ins

    30" (762mm) min. 30" (762mm) min. to 35" (889mm) max. to 35" (889mm) max. bottom of cabinet bottom of cabinet to floor to floor Wall opening 10-1/4" (260mm) wide 14-1/4" (362mm) high Bradley • 215-1567 Rev. F: ECO 21-05-023 9/15/2021...

  • Page 6: Installation

    . Spacer tabs come flat & will need to be bent (as shown) for ceilings less than 1" thick. NOTE: Use teflon tape only . Secure cabinet to wall, four places. Bradley • 215-1567 Rev. F: ECO 21-05-023 9/15/2021...

  • Page 7: Connect Water Supply

    Connect Water Supply c o rp .c ra d le y w w w .b 11 4-0 90 To Showerhead Connect supply piping. 1" NPT Supply Line Exploded view of valve and handle assembly Bradley • 215-1567 Rev. F: ECO 21-05-023 9/15/2021...

This manual is also suitable for:

S19-125fmbf
