Bradley S19-120BF Installation

Plastic showerhead stainless steel showerhead drench shower - horizontal supply

Download this manual

215-1259 Rev. D; ECN 08-512

Page 1 of 5

9/11/08

Installation

S19-120BF

Plastic Showerhead

S19-120ABF

Stainless Steel Showerhead

Drench Shower - Horizontal Supply

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . 2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

S19-120BF Components and Parts List . . . . . . . . . . . . 4

S19-120ABF Components and Parts List . . . . . . . . . . . 5

P.O. Box 309, Menomonee Falls, WI USA 53052-0309

PHONE 800.BRADLEY (800.272.3539) FAX 262.251 5817

bradleycorp.com

Need help?

Do you have a question about the S19-120BF and is the answer not in the manual?

Page 1 Installation ........3 S19-120BF Components and Parts List ... . 4 S19-120ABF Components and Parts List .
Page 2 For questions regarding the operation or installation of this product, visit www. bradleycorp.com or call 1-800-BRADLEY. Product warranties and service parts information may also be found under ”Products” on our web site at www.bradleycorp.com. 9/11/08 Bradley Corporation • 215-1259 Rev. D; ECN 08-512...
Page 3: Installation
2. Mount the safety sign to the wall using sign- mounting hardware supplied by installer. 8" (203mm) 24" (610mm) 6" 3-5/8" (152mm) (92mm) Ø 10-3/4" (273mm) 7'-0" (2134mm) to Floor 45" (1142mm) 9" (229mm) S19-120ABF Bradley Corporation • 215-1259 Rev. D; ECN 08-512 9/11/08...
Page 4: Parts List
Curtain Hook 1.31 110-214 Jam Nut Only S90-365D Pull Rod, 45" 140-720 Stop Bracket 161-026 Nut, 1/4"-20 128-129 Handle 204-421 Emergency Inspection Tag 113-006MT Pipe 1" NPT x 21" 114-050 Safety Sign 9/11/08 Bradley Corporation • 215-1259 Rev. D; ECN 08-512...
Page 5 Handle S90-365D Pull Rod, 45" 113-006MT Pipe 1" NPT x 21" 161-026 Nut, 1/4"-20 169-847 90° Elbow 1" NPT 204-421 Emergency Inspection Tag S24-189 Stainless Steel Showerhead Assembly 114-050 Safety Sign Bradley Corporation • 215-1259 Rev. D; ECN 08-512 9/11/08...
