- Page 1 Installation manual Exigo E1500 Trailer Refrigeration Unit Installation manual EZESHP20AUAW1B English Exigo E1500 Trailer Refrigeration Unit EZLSHP20AUAW1B...
-
Page 2: Table Of Contents
▪ A subset of the latest technical data is available on the regional Battery ..................17 Daikin website (publicly accessible). Fuel supply ................18 ▪ The full set of the latest technical data is available on the Daikin 6.6.1 To install the fuel tank ..........18 Business Portal (authentication required). -
Page 3: General Safety Precautions
(thyme, liver, bone marrow). H411 Toxic to aquatic life with long lasting effects. Risk of poisoning The unit contains poisonous substances: ▪ Diesel fuel ▪ Engine oil EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 4: In Case Of Emergency
▪ Operating materials can endanger the environment. Leaking fluid should never seep into the ground, because of the risk of contaminating groundwater. ▪ Always use a suitable collecting recipient when checking for leaks. Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 5: For The Installer
WARNING equipment. Make sure installation, testing and applied materials comply with applicable legislation (on top of the WARNING instructions described in the Daikin documentation). WARNING Rotating components, electrical hazards and hot surfaces can cause severe injury or death. - Page 6 Make sure that the forklift, or any other lifting device used, can bear the weight of the unit. Daikin is not responsible for cold room safety. WARNING Make sure that no people are left in the cold room before you close the doors: ▪...
-
Page 7: Refrigerant
Refrigerant under pressure can escape due to breaks in ▪ Do NOT leave the unit unattended when the service the cooling system, or during maintenance on the cooling cover is removed. system. EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 8: Engine
About the box Overview: About the box This chapter describes what you have to do after the unit is delivered on-site. Keep the following in mind: Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 9: To Unpack The Installation Kit
(see "6.2.3 To install the unit on the cold room" [ 4 14]). 1 Bring out the unit that is mounted on the special transport pallet. Use a forklift or a lifting device. EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 10: About The Unit And Options
3 Lift the unit with a lifting device (e.g. overhead crane). Electrical plug User interface 4 Remove the plastic film from around the unit. Electrical box Engine ON/OFF switch Evaporator Radiator Exhaust Fuel pump Fuel pre-filter Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 11: About The System
Rear door switch used. Metallic IP grade switch to be connected with Exigo unit and ▪ A programmable microcontroller developed by Daikin. telematics to detect the opening of trailer doors. ▪ Electronic Expansion Valves (EEV). The micro switch signal interrupts the thermoregulation mode as ▪... - Page 12 See "10 Technical data" [ 4 25] for dimensions and weight. The structural integrity of the trailer/cold room is a responsibility of the user. Daikin accepts no liability for the trailer's or cold room's structural integrity. The surfaces of the cold room that contact the unit's mounting pads must be uni-planar to within 3 ...
-
Page 13: To Prepare The Unit
Always use a safety harness when working at height. instructions of the cold room/trailer manufacturer must always be followed. EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 14: Tools Needed For Installation
4 25] for the weight of the unit. 1 Position the unit (a) in front of the cold room (b) by hanging it from a lifting device (e.g. fork lift or overhead crane). Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... - Page 15 9 Open unit's service doors. 10 Loosen the lock nuts (k). The screws (l) and nuts (k) do not have to be removed. EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04...
- Page 16 13 Place a washer (e) and lock-nut (f) on the bolt (c), and hand tighten the lock nut (f). Exigo frame bolt Control panel Flat washer (Ø13×30×6, A2-70 INOX) Lock nut Lock nut (M12, 8.8 ZN) Screw Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04...
-
Page 17: To Install The Top Plate Grids
1 Remove the nuts (c) and washers (d) from the threaded rods Earth wire Connection stud (e). 2 Position the bottom panel (c) on the unit. 2 Remove the brackets (a) together with the relay box (b). EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 18: Fuel Supply
Keep open sparks and flames away from the battery at all times. The fuel tank is not supplied by Daikin. 6 Install the brackets (a) together with the relay box (b). 7 Install the nuts (c) and washers (d) on the threaded rods (e), and tighten the nuts to 1 N•m. -
Page 19: To Install The Fuel Pre-Filter
ALWAYS use hydraulic thread sealant as delivered with the installation kit to seal the fuel connections. Fuel pre-filter Bolt (M8×30, A2-70 INOX) Flat washer (Ø8×24, A2-70 INOX) Lock nut (M8, A2-70 INOX) EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... - Page 20 20 Attach the fuel line along the trajectory along the undercarriage 10 Connect the fuel supply line (i) going to the fuel pump (j) to the of the trailer. adapter (h). Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04...
-
Page 21: To Make The Electrical Connections
The fuel pump cable coming out of the unit is labelled "Fuel pump". A typical installation is shown below. The fuel pump is connected to the X50Y connector. EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 22: To Install The Iot Module
6.8.1 To install the door micro switch INFORMATION When the cold room door is closed, the optional micro switch (NO contact) sends a signal to the unit. Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 23: To Install The Cold Chain Data Logger
2 Guide the electrical cable from the tank to the unit. The fuel level probe cable is connected to the X64Y connector. INFORMATION Full installation instructions are delivered with the option kit. EZESHP20AUAW1B + EZLSHP20AUAW1B Installation manual Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 24: To Install The Pre-Filter Heater
After installation the installer is obliged to verify the correct operation of the unit. Therefore a test run MUST be performed according to the procedures described below. Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 25: To Fill Up The Fuel Line With Engine Bleeding Function
▪ A subset of the latest technical data is available on the regional function Daikin website (publicly accessible). ▪ The full set of the latest technical data is available on the Daikin 1 Switch on the unit. The fuel tank suction pipe is still empty at Business Portal (authentication required). -
Page 26: Piping Diagram
TE_A_OUT1 Inside air temperature sensor (out S*NPH Pressure sensor (high) evaporator) S*NPL Pressure sensor (low) TE_A_OUT2 Inside air temperature sensor backup (out evaporator) Pressure switch (air diff.) Installation manual EZESHP20AUAW1B + EZLSHP20AUAW1B Exigo E1500 Trailer Refrigeration Unit 4P726857-1B – 2025.04... -
Page 27: Weight
Technical skilled person who is qualified to install the product on a cold room trailer. Dealer Sales distributor for the product. Field supply Equipment NOT made by Daikin that can be combined with product according instructions accompanying documentation. Human Machine Interface. Screen that communicates information, data and metrics using graphics or visual representations. - Page 28 4P726857-1 B 00000006 4P726857-1B 2025.04...
