THE HEATER OUTLET GRILLE BECOMES VERY HOT WHILST IN OPERATION. DO NOT COVER THE OUTLET GRILLE OR
ANY PART OF THE APPLIANCE. FOR USE WITH 230V - 240V 50HZ ELECTRICITY SUPPLY ONLY. PLEASE READ THESE
INSTRUCTIONS CAREFULLY BEFORE INSTALLATION KEEP THE INSTRUCTIONS IN A SAFE PLACE.THEY WILL BE
NEEDED WHEN MAINTENANCE OR SERVICING IS REQUIRED. THIS APPLIANCE MUST BE EARTHED.
Version 2 03/04/25
Contents of manual may be updated without notice.
For the latest version of this manual please refer to our
website: www.mendipstoves.co.uk
WOODLAND ELECTRIC STOVE
U S E R I N S T R U C T I O N S A N D
I N ST A L LA T I O N
IMPORTANT NOTE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ilektro WOODLAND and is the answer not in the manual?

Questions and answers

Related Manuals for Mendip Stoves Ilektro WOODLAND

Summary of Contents for Mendip Stoves Ilektro WOODLAND

  • Page 1 WOODLAND ELECTRIC STOVE U S E R I N S T R U C T I O N S A N D I N ST A L LA T I O N IMPORTANT NOTE THE HEATER OUTLET GRILLE BECOMES VERY HOT WHILST IN OPERATION. DO NOT COVER THE OUTLET GRILLE OR ANY PART OF THE APPLIANCE.
  • Page 2 USER MANUAL CONTENTS TERMS AND CONDITIONS WARRANTY BOX CONTENTS S HOW TO USE YOUR APPLIANCE EUROSTOVE LTD UNIT H1 IMPOTANT SAFETY INFORMATION APP CONNECTING INSTRUCTIONS MENDIP INDUSTRIAL ESTATE ROOKSBRIDGE REMOTE CONTROL INSTRUCTIONS SOMERSET BS26 2UG OPERATING INSTRUCTION MAINTENANCE AND CARE FULL TERMS AND CONDITIONS ARE DETAILED IN THE WARRANTY STATEMENT ON THE HOW TO INSTALL YOUR APPLIANCE...

  • Page 3: Box Contents

    BOX CONTENTS PLEASE CHECK THAT THE FOLLOWING COMPONENTS ARE INCLUDED WITHIN THE BOX. IF ANYTHING IS MISSING OR DAMAGED, PLEASE CONTACT THE RETAILER AND DO NOT USE THE APPLIANCE UNTIL YOU HAVE EVERYTHING. APPLIANCE WITH TRAILING LEAD WITH MOULDED 13AMP PLUG, REMOTE CONTROL HANDSET AND BATTERIES.
  • Page 4 • WHERE THE ELECTRICITY SUPPLY CABLE HOW TO USE YOUR APPLIANCE HAS TO PASS THROUGH A MASONRY WALL, 1. IMPORTANT SAFETY STONE SURROUND ETC. ENSURE SUITABLE INFORMATION RUBBER BUSHES ARE FITTED AT POSSIBLE WEAR POINTS. • READ INSTRUCTIONS CAREFULLY BEFORE USING THE APPLIANCE. •...
  • Page 5 IF YOU ARE INSTALLING YOUR HOW TO USE YOUR APPLIANCE APPLIANCE IN TO AN EXISTING 1. IMPORTANT SAFETY CHIMNEY CAVITY INFORMATION • ENSURE THE FLOOR AREA THE APPLIANCE WILL SIT ON IS FLAT AND FREE FROM • IF THE ELECTRICITY SUPPLY CABLE IS LOOSE MATERIAL DAMAGED DO NOT USE THE APPLIANCE UNTIL IT HAS BEEN REPLACED.

  • Page 6: App Download

    • REGISTER WITH YOUR EMAIL ID OR MOBILE HOW TO USE YOUR APPLIANCE PHONE NUMBER AS THE USERNAME. 2. APP CONNECTING • PUT ANY 6 TO 20 DIGIT NUMBERS AS INSTRUCTIONS PASSWORD. • AGREE TO THE TERMS AND CONDITIONS. • DURING THE PROCESS YOU MAY BE ASKED APP DOWNLOAD TO ALLOW THE APP TO KNOW YOUR LOCATION.
  • Page 7 CONNECTING SUCCESSFULLY HOW TO USE YOUR APPLIANCE 2. APP CONNECTING THE FIREPLACE WILL DISPLAY “P4” AFTER INSTRUCTIONS YOUR FIREPLACE WELL CONNECTED. THE NAME OF THE FIREPLACE APPEARS ON THE CONNECTING PHONE. CLICK THE NAME OF THE ELECTRIC FIREPLACE TO ENTER THE OPERATION INTERFACE.

  • Page 8: Light Functions

    • YOU CAN CHANGE THE COLOUR OF FUEL HOW TO USE YOUR APPLIANCE BED. 2. APP CONNECTING INSTRUCTIONS CONNECTING FAILURE • PLEASE REPEAT FROM STEP 1 TO STEP 4 FUNCTIONS LIGHT FUNCTIONS • YOU CAN CHANGE THE COLOUR AND BRIGHTNESS OF THE FLAME.

  • Page 9: Heat Function

    HOW TO USE YOUR APPLIANCE TEMPERATURE FUNCTION 2. APP CONNECTING • YOU CAN SET THE TARGET TEMPERATURE; THE FIRE WILL AUTOMATICALLY CONTROL INSTRUCTIONS ITS HEATER TO WARM YOUR ROOM TO HEAT FUNCTION THAT TEMPERATURE AND MAINTAIN IT • CHOOSE FOR H1: 1KW OF HEAT OR H2: 2KW AROUND THAT TEMPERATURE.
  • Page 10 Setting Up the 7-Day Programme Your app will automatically use the date and time from your phone or tablet. Important: If you're setting up your fire in a different time zone than your device was originally configured in, follow these steps: 1.
  • Page 11 STEP: 01 STEP: 02 STEP: 03 STEP: 04 STEP: 05 STEP: 06...
  • Page 12 STEP: 07 STEP: 08 STEP: 09...
  • Page 13 WOODLAND ELECTRIC – QUICK REFERENCE GUIDE HOW TO USE YOUR APPLIANCE 1. Power Switch . Turns the unit ON/OFF. 3. REMOTE CONTROL BUTTONS 2. Flame Brightness. Settings: F5 (Brightest) → F4 AND DISPLAY → F3 → F2 → F1 (Dimmest) 3.

  • Page 14: How To Use Your Appliance

    HOW TO USE YOUR APPLIANCE HOW TO USE YOUR APPLIANCE 4. OPERATING INSTRUCTIONS 4. MAINTENANCE AND CARE To ensure optimal performance and longevity of Safety Cut-Out your appliance, it is important to maintain the air If the safety cut-out is triggered, the circulation and cleanliness of the appliance.

  • Page 15: Battery Replacement Remote Control

    HOW TO USE YOUR APPLIANCE BATTERY REPLACEMENT 5. MAINTENANCE AND CARE REMOTE CONTROL BATTERY INFORMATION - SEE FIG. 3 CLEANING THE OUTLETS SLIDE OPEN THE BATTERY COVER ON • ENSURE THE APPLIANCE IS SWITCHED THE BACK OF THE REMOTE CONTROL OFF AT THE ISOLATION SWITCH INSTALL AAA BATTERIES INTO THE •...

  • Page 16: This Appliance Must Be Earthed

    For product dimensions and installation THIS APPLIANCE MUST BE guides for building your appliance into a EARTHED location, please visit Mendip Stoves (https:// mendipstoves.co.uk) to download the specification sheet for your appliance. THIS APPLIANCE HAS BEEN CERTIFIED FOR USE IN COUNTRIES OTHER THAN THOSE STATED.

  • Page 17: Fitting The Appliance

    HOW TO INSTALL YOUR APPLIANCE FITTING THE APPLIANCE 7. GENERAL INSTALLATION • Handle with care when lifting the appliance. If needed, seek assistance to prevent injury. IMPORTANT: Installation must be carried out by a trained installation technician. • Always follow safe manual handling Incorrect installation may void your techniques to avoid strain or damage.

  • Page 18: Electrical Connection & Safety

    HOW TO INSTALL YOUR APPLIANCE ELECTRICAL CONNECTION & SAFETY 8. INSTALLATION – POSITIONING YOUR • The appliance should be positioned **near a APPLIANCE suitable mains socket** to allow for easy connection. Your new appliance is freestanding and can be placed almost anywhere in your home, as long as •...
  • Page 19 9. SETTING THE FUEL BED CAUTION: ITEMS FOR THE FIRE CHAMBER Ceramic log sets are delicate. Handle with care.** • Ceramic Log Set (8-piece log set) • Amber Crystals Installation Steps: • Clear Crystals 1. Spread amber crystals evenly across the •...

  • Page 20: Electrical Connection

    HOW TO INSTALL Y OUR • CONNECT THE POWER CABLE TO AN EARTHED SOCKET APPLIANCE 10. ELECTRICAL CONNECTION • ONLY USE THE POWER CABLE PROVIDED WITH YOUR APPLIANCE AS IT WILL BE WARNING CORRECT FOR YOUR REGION ENSURE THE APPLIANCE IS FULLY ASSEMBLED AND THE FRONT GLASS WITH TRIM IS BACK IN THE APPLIANCE BEFORE THE APPLIANCE IS CONNECTED...
  • Page 21 IF THE HEATER STOPS OPERATING WHILST SERVICING INSTRUCTIONS THE FLAME EFFECT CONTINUES NORMALLY, 11. GENERAL INFORMATION THIS INDICATES THAT THE E.S. CONTROL IS IN OPERATION. THE E.S. CONTROL CAN ONLY BE RE-SET THIS APPLIANCE MUST ONLY BE SERVICED AFTER THE APPLIANCE HAS COOLED DOWN. BY A SUITABLY QUALIFIED PERSON.
  • Page 22 SERVICING INSTRUCTIONS 12. FAULT FINDING OPERATE APPLIANCE BEFORE COMMISSIONING 1. CLICK ON THE REMOTE HANDSET POWER BUTTON. IF THE APPLIANCE DOES NOT FUNCTION, THEN, FOLLOW POINTS 1, 2, 3, 4 AND 5 RESPECTIVELY. 2. CHECK THE POWER CONNECTION AT THE FIG:8 ISOLATION SWITCH ISOLATION SWITCH IS IN THE ON POSITION.

  • Page 23: Fan Motor

    ilektro REFERENCE INFORMATION 13. WIRING DIAGRAM FAN MOTOR HEATING ELEMENT FIG 9: WIRING DIAGRAM...
  • Page 24 REFERENCE INFORMATION 14. EXPLODED DIAGRAM FIG 10: EXPLODED DIAGRAM...
  • Page 25 REFERENCE INFORMATION 13. EXPLODED DIAGRAM Replaceable Parts Description Part Number REMOTE CONTROL WOODLAND STOVE REMOTE SYNCHRONOUS MOTOR 430000210000 MAIN PCB BOARD 440402830125 FUEL BED LED 440402810100 FLAME EFFECT ROTTISORRIE 510400300430 FLAME LED 440402820100 FAN AND HEATING ELEMENT 430400030150 IEC CABLE 470000070300 ISOLATION SWITCH 460000010400...
  • Page 28 Technical support UK Distributor Eurostove Ltd Unit H1 Mendip Industrial Estate Rooksbridge Somerset BS26 2UG Tel: +44(0)1934 750500 Fax: +44(0)1173 156207 technical@eurostove.co.uk www.eurostove.co.uk 148 Cochranes Road Moorabbin, Victoria 3189 www.paulagnewdesigns.com.au info@paulagnewdesigns.com.au...
