MA lighting grandMA3 onPC command wing XT Quick Manual page 81

Sorties grandMA3 onPC command wing XT
grandMA3 onPC command wing XT panneau arrière
Nombre Connecteur
4x DisplayPort 1.2 pour écrans externes
2x RJ 45
2x USB 3.0 (type A) max. 900 mA
2x USB 2.0 (type A) max. 500 mA
1x Audio In (mini jack 3.5mm)
1x Audio Out (mini jack 3.5mm)
2 x DMX512-A OUT (5pin XLR female)
1 x DMX512-A IN (5pin XLR male)
1 x MIDI IN (5pin DIN female)
1 x MIDI OUT (5pin DIN female)
1 x LTC – Linear Time Code (3pin XLR female)
1 x GPI – General Purpose Input (D-SUB DE9 female – DC remote control)
1x IEC connector
1 x LED desk light (4pin XLR female)
81
