ADLINK Technology MLB-3000 Series User Manual

Embedded system supporting mxm graphics module with 8th/9th generation intel core i7/i5/i3 in lga1151 socket
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Embedded System supporting MXM Graphics Module with
8th/9th Generation Intel® Core™ i7/i5/i3 in LGA1151 Socket
MLB-3000 Series
User's Manual
Manual Rev.:
Revision Date:
Part No:
1.0
May 13, 2022
50M-00074-1000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLB-3000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADLINK Technology MLB-3000 Series

Summary of Contents for ADLINK Technology MLB-3000 Series

  • Page 1 MLB-3000 Series Embedded System supporting MXM Graphics Module with 8th/9th Generation Intel® Core™ i7/i5/i3 in LGA1151 Socket User’s Manual Manual Rev.: Revision Date: May 13, 2022 Part No: 50M-00074-1000...

  • Page 2: Revision History

    Revision History Revision Release Date Description of Change(s) 2022-05-13 Initial release...

  • Page 3: Environmental Responsibility

    MLB-3000 Preface Copyright © 2022 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.

  • Page 4: California Proposition 65 Warning

    California Proposition 65 Warning WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-propyl) phosphate (TDCPP), 1,4- Dioxane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause...

  • Page 5: Table Of Contents

    MLB-3000 Table of Contents Preface ..................iii List of Tables................. vii List of Figures ................ ix 1 Introduction ................ 1 Overview................1 Features................1 Packing List ................. 2 Optional Accessories ............3 2 Specifications ..............5 MLB-3000 ................5 MLB-3000 Functional Block Diagrams ........ 7 Display Options..............
  • Page 6 Power Consumption Reference ......... 71 B Appendix: Resource Mapping ..........73 BIOS Mapping in SPI ROM..........73 PCI/PCIe Devices .............. 74 IRQ Lines (APIC Mode) ............. 75 IRQ Lines (PIC Mode)............76 System Memory Mapping ..........77 System I/O Mapping ............78 PCI/PCIe Interrupt Routing Mapping .........

  • Page 7: List Of Tables

    MLB-3000 List of Tables Table 2-1: Maximum Display Resolution ........8 Table 3-1: I/O Legend..............14 Table 3-2: Digital Input/Output Connector Pin Definition ... 17 Table 3-3: Active/Link LED Indicators........19 Table 3-4: Speed LED Indicators..........19 Table 3-5: D-Sub 9-pin Signal Function of COM Ports....20 Table 3-6: Mainboard Connector Legend ........
  • Page 8 This page intentionally left blank. viii List of Tables...

  • Page 9: List Of Figures

    MLB-3000 List of Figures Figure 2-1: MLB-3000 Functional Block Diagram ......7 Figure 2-2: MLB-3000 Front View ............9 Figure 2-3: MLB-3000 Left Side View ..........10 Figure 2-4: MLB-3000 Right Side View..........10 Figure 2-5: MLB-3000 Rear View............. 11 Figure 2-6: MLB-3000 Top View ............
  • Page 10 This page intentionally left blank. List of Figures...

  • Page 11: Introduction

    MLB-3000 Introduction 1.1 Overview The MLB-3000 series is an optimized computing platform support- ing performance-hungry workloads, such as deep learning, with expandability options and active cooling for applications requiring very high levels of computing in a limited space. The MLB-3000 series is one of the smallest embedded GPU platforms (3.2 liters)

  • Page 12: Packing List

    1.3 Packing List Before unpacking, check the shipping carton for any damage. If the shipping carton and/or contents are damaged, inform your dealer immediately. Retain the shipping carton and packing mate- rials for inspection. Obtain authorization from your dealer before returning any product to ADLINK.

  • Page 13: Optional Accessories

    MLB-3000 1.4 Optional Accessories CPU cooler (P/N: 32-20378-0000-A0)  CPU cooler bracket (P/N: 32-50015-0100-A0)  MXM cooler for P1000/P2000 (P/N: 32-20797-0200-A0)  MXM cooler for T1000 (P/N: 32-20830-0200-A0)  MXM cooler for RTX3000 (P/N: 32-20823-1100-A0)  MXM cooler for RTX5000 (P/N: 32-20839-1000-A0) ...
  • Page 14 This page intentionally left blank. Introduction...

  • Page 15: Specifications

    MLB-3000 Specifications 2.1 MLB-3000 Model MLB-3000 EGX-MXM- EGX-MXM- EGX-MXM- EGX-MXM- EGX-MXM- Support P1000 P2000 T1000 RTX3000 RTX5000  Intel® Core™ i7-9700E, 2.6GHz, 12M Cache, 65W TDP, LGA1151, DDR4 2666MHz support (8C/8T)  Intel® Core™ i7-9700TE, 1.8GHz, 12M Cache, 35W TDP, LGA1151, DDR4 2666MHz support (8C/8T) ...
  • Page 16 Model MLB-3000  Default: w/o Audio  Option 1: Mic-in, Line-out, Line-in Audio  Option 2: Mic-in, L/R speaker-out (6W + 6W)  Option 3: Line-in, L/R speaker-out (6W + 6W)  1x M.2 E key for 1630 or 2230 WiFi/BT module ...

  • Page 17: Mlb-3000 Functional Block Diagrams

    MLB-3000 2.2 MLB-3000 Functional Block Diagrams 2.2.1 MLB-3000 Functional Block Diagram SODIMM 1 DDI 1 (PORT B) : DP DP CN Channel A DDR4 non-ECC Socket DP CN DDI 2 (PORT C) : DP 8th/9th Gen Intel® DDI 3 (PORT D) : HDMI HDMI CN SODIMM 2 Core™...

  • Page 18: Display Options

    2.3 Display Options The MLB-3000 includes six DisplayPort connectors, two Display- Port signals from the CPU and four from MXM. All DisplayPorts support DP++. Use DisplayPort1 (DP 1) to connect a monitor when booting the system for the first time to properly access the display settings in the BIOS menu.

  • Page 19: Mechanical Dimensions

    MLB-3000 2.4 Mechanical Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: Figure 2-2: MLB-3000 Front View (including wall-mount brackets and footpads) Specifications...

  • Page 20: Figure 2-3: Mlb-3000 Left Side View

    Figure 2-3: MLB-3000 Left Side View Figure 2-4: MLB-3000 Right Side View Specifications...

  • Page 21: Figure 2-5: Mlb-3000 Rear View

    MLB-3000 Figure 2-5: MLB-3000 Rear View 6.50 Figure 2-6: MLB-3000 Top View Specifications...
  • Page 22 To prevent damage to the system, ensure there is a minimum 10 cm clearance around the air vents for unrestricted airflow. The air tempera- ture inside the enclosure could rise above the specified operating temper- WARNING: ature limits if the airflow through the vents is restricted. AVERTISSEMENT: Pour éviter d'endommager le système, assurez-vous qu'il y a un dégagement minimum de 10 cm autour des bouches d'aéra- tion pour une circulation d'air sans restriction.

  • Page 23: System Layout

    MLB-3000 System Layout 3.1 Front Panel The MLB-3000 Series provides the following I/O access features. Figure 3-1: MLB-3000 Front Panel I/O Figure 3-2: MLB-3000 Rear Panel I/O System Layout...

  • Page 24: Table 3-1: I/O Legend

    USB 2.0 Type-A x2 (U9, U14) USB 3.2 Gen1 x1 Type-A x2 (U5/U6) RS-232 for COM1, RS-232/422/485 for COM2 DisplayPort x2 (DP 1/DP 2) i210-AT (LAN 2/ LAN 3) i210-AT (LAN 4), USB 3.2 Gen1 x1 Type-A (U3/U4) i219-LM (LAN 1), USB 3.2 Gen1 x1 Type-A (U1/U2) DisplayPort from MXM for DP A/DP B DisplayPort from MXM for DP C/DP D 12V DC Power Input...

  • Page 25: Figure 3-3: Power-On Module

    MLB-3000 3.1.1 Power-on Module Figure 3-3: Power-on Module Alarm Reset Button: When the fan or GPU temperature alarm has been triggered, insert a small, thin object like a paper clip and press the reset button to turn off the alarm. This is to reset the alarm beeper only, not to reset the alarm LED.

  • Page 26: Audio Connectors

    3.1.2 Audio Connectors The MLB-3000 provides the following default audio connectors. 3.5 mm mono jack for left channel speaker-out (6W)  3.5 mm mono jack for right channel speaker-out (6W)  Microphone-in  MLB-3000 series audio connectors are (from top to bot- tom) speaker-out L channel (6W), speaker-out R channel (6W), and Mic-in.

  • Page 27: Table 3-2: Digital Input/Output Connector Pin Definition

    MLB-3000 3.1.3 Digital I/O Connector The MLB-3000 provides 4 channels of non-isolation digital input and 4 channels of non-isolation digital output circuits, with specifi- cations and circuits as follows. 4-channel Digital Input VIH: 1.5 to 5V  VIL: 0 to 0.5V ...

  • Page 28: Figure 3-5: Digital Input Circuit

    Figure 3-5: Digital Input Circuit 2.2K Figure 3-6: Digital Output Circuit System Layout...

  • Page 29: Gigabit Ethernet Ports

    MLB-3000 3.1.4 Gigabit Ethernet Ports LED Color Status Description Ethernet port is disconnected. Orange Ethernet port is connected with no activity. Flashing Ethernet port is connected and active. Table 3-3: Active/Link LED Indicators LED Color Status Description 10 Mbps Green/Orange Green 100 Mbps Orange...

  • Page 30: Com Port Connectors

    3.1.5 COM Port Connectors The MLB-3000 provides two COM ports through D-sub 9-pin con- nectors. The COM2 port supports RS-232/422/485 modes by BIOS setting, while COM1 supports only RS-232. Figure 3-7: COM Port Pin Definition Signal Name RS-232 RS-422 RS-485 DCD# TXD422- 485DATA-...

  • Page 31: Internal I/O Connectors

    MLB-3000 3.2 Internal I/O Connectors Installation of add-on devices must be carried out by ADLINK service personnel only. Users must not disassemble the device themselves. Failure to comply with this instruction will result in WARNING: loss of warranty. 3.2.1 Mainboard Connector Locations AG AH Figure 3-8: Mainboard Connectors (Top) System Layout...

  • Page 32: Figure 3-9: Mainboard Connectors (Bottom)

    Figure 3-9: Mainboard Connectors (Bottom) System Layout...

  • Page 33: Table 3-6: Mainboard Connector Legend

    MLB-3000 CPU socket DRAM socket for DIMM1 DRAM socket for DIMM2 CPU Fan connector System Fan connector 2x USB 2.0 Gen1 x1 pin header for U9/U14 RS-232 pin header for COM1 RS-232/422/485 pin header for COM2 2x USB 3.2 Gen1 x1 pin header for U5/U6 Multi I/O connector Audio pin header PCIe power connector...

  • Page 34: Status Led (Blue)

    3.2.2 BMC Status LED and WDT LED 3.2.2.1 Status LED (Blue) The Status LED is controlled by SEMA to signal system state changes and power-up failures. The system state changes can be HW-Reset, SW-Reset, Power-Up, Power-Down, Reset-Button and Power-Button activity. The Status LED will light for short time. Power-Up failures can indicate a corrupted BIOS or failure of the onboard power supply.

  • Page 35: Table 3-7: Usb 2.0 Connector Pin Definition

    MLB-3000 3.2.3 USB 2.0 Connector One USB 2.0 pin header is provided on the mainboard for an inter- nal USB dongle. 1  10  Figure 3-10: USB 2.0 Connector Pin Definition Signal Signal P5V_USB1 CN_U2_USB14_P P5V_USB1 CN_U2_USB9_N CN_U2_USB14_N CN_U2_USB9_P Table 3-7: USB 2.0 Connector Pin Definition System Layout...

  • Page 36: Table 3-8: Usb 3.2 Connector Pin Definition

    3.2.4 USB 3.2 Connector One USB 3.2 Gen1 x1pin header is provided on the mainboard for an internal USB dongle. Figure 3-11: USB 3.2 Connector Pin Definition Signal Signal P5V_USB56 CN_U3_USB6_T_P CN_U2_USB5_N CN_U3_USB6_T_N CN_U2_USB5_P CN_U3_USB6_R_P CN_U3_USB5_R_N CN_U3_USB6_R_N CN_U3_USB5_R_P CN_U2_USB6_P CN_U3_USB5_T_N CN_U2_USB6_N CN_U3_USB5_T_P P5V_USB56...

  • Page 37: Table 3-9: Pcie Power Connector Pin Definition

    MLB-3000 3.2.5 PCIe Power Connector Figure 3-12: PCIe Power Connector Pin Definition Signal P_+12V_S P_+12V_S P_+5V0_S P_+5V0_S Table 3-9: PCIe Power Connector Pin Definition System Layout...

  • Page 38: Sata Power Connector

    3.2.6 SATA Power Connector Figure 3-13: SATAConnector Pin Definition Signal P_+5V0_S P_+5V0_S P_+5V0_S Table 3-10: SATA Connector Pin Definition System Layout...

  • Page 39: Table 3-11: Com Connector Pin Definition

    MLB-3000 3.2.7 COM Connector Figure 3-14: COM Connector Pin Definition Signal Name RS-232 RS-422 RS-485 DCD# Tx/Rx- DSR# Tx/Rx+ RTS# CTS# DTR# Table 3-11: COM Connector Pin Definition System Layout...

  • Page 40: Cpu/System Fan Connectors

    3.2.8 CPU/System Fan Connectors Two connectors are provided for CPU and system fan power. Figure 3-15: CPU/System Fan Connector Pin Definition Signal FAN_GND P_+12V_FAN FAN_IN FAN_OUT Table 3-12: CPU/System Fan Connector Pin Definition System Layout...

  • Page 41: Table 3-13: Gpu Fan Connector Pin Definition

    MLB-3000 3.2.9 GPU Fan Connector Figure 3-16: GPU Fan Connector Pin Definition Signal FAN_OUT FAN_IN P_+12V_FAN FAN_GND Table 3-13: GPU Fan Connector Pin Definition System Layout...

  • Page 42: Table 3-14: Audio Connector Pin Definition

    3.2.10 Audio Connector Figure 3-17: Audio Connector Pin Definition Signal Signal AUDIO_Sense GND_AUD SPK_RP A_MIC_IN_L A_L_IN_L SPK_LP SPK_RN A_MIC_IN_R A_L_IN_R SPK_LN Table 3-14: Audio Connector Pin Definition System Layout...

  • Page 43: Table 3-15: Com1 Rs-232/Cctalk Selection Jumper

    MLB-3000 3.2.11 Multiple I/O Connector Figure 3-18: Multiple I/O Connector Pin Definition 3.2.11.1 COM1 RS-232/CCtalk Selection Jumper RS-232/CCtalk RS-232 (default) 8-10 CCtalk 9-11 10-12 Table 3-15: COM1 RS-232/CCtalk Selection Jumper 3.2.11.2 Case Open Jumper Case open 13-14 Function ON Undo (default) Table 3-16: Case Open Jumper System Layout...

  • Page 44: Table 3-17: Me Lock Jumper

    3.2.11.3 ME Lock Jumper ME Lock 15-16 Lock Undo (default) Table 3-17: ME Lock Jumper 3.2.11.4 Clear CMOS Jumper Clear CMOS 17-18 Clear CMOS Undo (default) Table 3-18: Clear CMOS Jumper 3.2.11.5 BIOS WP Jumper BIOS WP 17-18 BIOS WP Undo (default) Table 3-19: BIOS WP Jumper S3 and S4 not supported under operating system.

  • Page 45: Table 3-20: Power-On Module Connector Pin Definition

    MLB-3000 3.2.12 Power-on Module Connector Figure 3-19: Power-on Module Connector Pin Definition Signal Signal P_+5V0_A LED_TEMP_ALARM P_+3V3_A PWR_BTN LED_FAN_ALARM LED_STANDBY RST_BTN# P_+12V_A POWER_ON RESET_BUTTON_ALARM# BEEP_TEMP_ALARM PCH_SATS-L Table 3-20: Power-on Module Connector Pin Definition System Layout...

  • Page 46: Table 3-21: Dio Connector Pin Definition

    3.2.13 DIO Connector Figure 3-20: DIO Connector Pin Definition Signal 5V_12V_S Table 3-21: DIO Connector Pin Definition System Layout...

  • Page 47: Table 3-22: 12V Dc-In Connector Pin Definition

    MLB-3000 3.2.14 12V DC-in Connector Figure 3-21: 12V DC-in Connector Pin Definition Signal Signal DCIN DCIN DCIN DCIN Table 3-22: 12V DC-in Connector Pin Definition Before providing DC power, ensure the voltage and polarity provided are compatible with the DC input. Improper input volt- age and/or polarity could result in system damage.

  • Page 48: Table 3-23: Pcb Edge Connector Pin Definition

    3.2.15 PCB Edge Connector Figure 3-22: PCB Edge Connector Pin Definition Signal A1 (Pin 1 on bottom) P_+12V_S P_+12V_S JTAGE_CLK(NC) JTAGE_DI(NC) JTAGE_DO(NC) JTAGE_MS(NC) P_+3V3_S P_+3V3_S PCH_PLTRST-L_BUF CLKOUT_PCIE_P7 CLKOUT_PCIE_N7 GF_PCIEX21_RX_P GF_PCIEX21_RX_N Table 3-23: PCB Edge Connector Pin Definition System Layout...
  • Page 49 MLB-3000 Signal GF_PCIEX22_RX_P GF_PCIEX22_RX_N GF_PCIEX23_RX_P GF_PCIEX23_RX_N GF_PCIEX24_RX_P GF_PCIEX24_RX_N GF_PCIEX1_RX_P GF_PCIEX1_RX_N GF_PCIEX2_RX_P GF_PCIEX2_RX_N GF_PCIEX3_RX_P GF_PCIEX3_RX_N GF_PCIEX4_RX_P GF_PCIEX4_RX_N B1 (Pin 1 on top) P_+12V_S P_+12V_S Table 3-23: PCB Edge Connector Pin Definition System Layout...
  • Page 50 Signal P_+12V_S PCH_SMB_CLK_A PCH_SMB_DAT_A P_+3V3_S JTAGE_RST(NC) P_+3V3_S X_PCIE_WAKE-L GF_PCIEX5_21_TX_P GF_PCIEX5_21_TX_N PCH_CLK_REQ7-L GF_PCIEX22_TX_P GF_PCIEX22_TX_N GF_PCIEX23_TX_P GF_PCIEX23_TX_N GF_PCIEX24_TX_P GF_PCIEX24_TX_N PCH_CLK_REQ7-L GF_PCIEX1_TX_P GF_PCIEX1_TX_N Table 3-23: PCB Edge Connector Pin Definition System Layout...
  • Page 51 MLB-3000 Signal GF_PCIEX2_TX_P GF_PCIEX2_TX_N GF_PCIEX3_TX_P GF_PCIEX3_TX_N GF_PCIEX4_TX_P GF_PCIEX4_TX_N PCH_CLK_REQ7-L Table 3-23: PCB Edge Connector Pin Definition System Layout...

  • Page 52: Table 3-24: Db40 Connector Pin Definition

    3.2.16 DB40 Connecto Figure 3-23: DB40 Connector Pin Definition Signal VCC_SPI_IN SPI_BIOS_CS0# SPI_BIOS_CS1# SPI_BIOS_MISO SPI_BIOS_MOSI SPI_BIOS_CLK 3V3_LPC BIOS_DIS0 RST# CLK33_LPC LPC_FRAME# LPC_AD3 LPC_AD2 LPC_AD1 LPC_AD0 3.3V_SMC 3.3V_A TXD6 Table 3-24: DB40 Connector Pin Definition System Layout...
  • Page 53 MLB-3000 Signal RXD6 FUMD0 RESET_IN# DATA OCD0A OCD0B PWRBTN# SYS_RESET# CB_RESET# CB_PWROK SUS_S3# SUS_S4# SUS_S5# POSTWDT_DIS# SEL_BIOS BIOS_MODE SMC_STATUS RESVD Table 3-24: DB40 Connector Pin Definition System Layout...
  • Page 54 This page intentionally left blank. System Layout...

  • Page 55: Getting Started

    MLB-3000 Getting Started This chapter outlines the procedures for 2.5" storage, M.2 module, MXM module, wall-mount brackets, and driver installation. Installation of an add-on device must be carried out by ADLINK service personnel only. Users must not disassemble the device themselves.

  • Page 56: Installing 2.5" Storage

    4.1 Installing 2.5” Storage Before installing a disk drive, the drive bracket must be removed. 1. Remove the thumbscrews and take out the 2.5” drive bay. Getting Started...
  • Page 57 MLB-3000 2. Place a 2.5” SSD up to 9mm thick into the bracket and use the 4 provided M3 screws at 4kgf/cm torque to attach the drive to the bracket. 3. Gently slide the bracket back into the drive bay until the SATA connector on the PCB is engaged, and then refas- ten the thumbscrews.

  • Page 58: Installing An M.2 Module

    4.2 Installing an M.2 Module Remove the bottom panel before installing an M.2 Module. 1. Remove 8 screws total to release the bottom panel from the chassis, 4 on the bottom, and 2 each on the left and right sides. Bottom screws Getting Started...
  • Page 59 MLB-3000 Left side screws Right side screws Getting Started...
  • Page 60 2. Open the chassis to expose the contents and then remove the 4 screws attaching the left drive bay to the chassis. Getting Started...
  • Page 61 MLB-3000 3. Move the drive bay to reveal the M.2 socket underneath and install an M.2 module with an M3 screw at 4kgf/cm torque. P/N: 33-03013-0040. Getting Started...
  • Page 62 The following figure shows B, E, and M-key modules installed. M.2 B-key module example: 4G Module EM06-A Kit (M.2  B Key) with Antenna (P/N: 91-95284-000E). 4G module must be used with an MLB-3000 with the eSIM option. Contact your local ADLINK sales representative for more information.
  • Page 63 MLB-3000 4. The antenna cables of the M.2 B-key and E-key modules are installed as shown in the figures below. For improved cable management, route the M.2 B-key cables under the drive bay support plate before making the antenna connections.  ...
  • Page 64 E-key line out B-key line out   Make sure the antenna wires are properly soldered to the M.2 B- key and E-key modules. Getting Started...
  • Page 65 MLB-3000 5. The figure below shows the locations of the M.2 B-key and E-key module antenna cable connections. B-key E-key E-key B-key Getting Started...
  • Page 66 6. Attach the antenna cable connectors and the drive bay screws at 6kgf/cm torque. B-key B-key E-key E-key 7. Reattach the drive bay, and then screw the bottom panel back on at 6kgf/cm torque to complete the installation. Getting Started...
  • Page 67 MLB-3000 8. Install and lock the antennas as shown.   B-key E-key B-key E-key B-key E-key Getting Started...

  • Page 68: Installing Mxm P1000/P2000/T1000 Module

    4.3 Installing MXM P1000/P2000/T1000 Module 1. Remove the protective film from the MXM cooler. Getting Started...
  • Page 69 MLB-3000 2. Attach the MXM cooler to the MXM module. Tighten the screws in the order indicated at 4kgf/cm torque. Getting Started...
  • Page 70 3. Remove 2 screws to detach the top panel from the chassis. Remove the top panel to reveal the internal components of the system. Getting Started...
  • Page 71 MLB-3000 4. Attach the MXM module with 2 M3 screws P/N: 33- 03306-0040 at 4kgf/cm torque and plug the MXM cooling fan connector into the GPU fan connector. 5. Screw the top panel back on to complete the installation. Getting Started...

  • Page 72: Installing Mxm Rtx3000/Rtx5000 Module

    4.4 Installing MXM RTX3000/RTX5000 Module 1. Remove 2 screws to detach the top panel from the chassis. Getting Started...
  • Page 73 MLB-3000 2. Remove the top panel to reveal the internal components of the system. Getting Started...
  • Page 74 3. Remove the protective film from the MXM cooler bracket and attach the bracket to the bottom side of the MXM module. Getting Started...
  • Page 75 MLB-3000 4. Attach the MXM module with 2 M3 screws P/N: 33- 03306-0040 at 4kgf/cm torque to the mainboard. Getting Started...
  • Page 76 5. Remove the protective film from the MXM cooler and lock the MXM cooler on the MXM module via the four spring screws. Then plug the MXM cooling fan connector into the GPU fan connector. Getting Started...
  • Page 77 MLB-3000 6. Place 4 washers PN: 33-90086-0000-A0 and 4 rubber spacers PN: 39-00039-0000 over the screw holes on the top of the fan. 7. Use 4 screws PN: 33-03320-0050 to secure the rubber spacers to the fan at 4kgf/cm torque. 8.

  • Page 78: Mounting

    4.5 Mounting 4.5.1 Installing the Wall-Mount Brackets / Installation des Supports de Montage-Mural Use the 4 footpad screws to attach the 2 wall-mount brackets to the chassis. Utilisez les 4 incluses dans la boîte d'accessoires pour fixer les 2 supports de montage mural inclus au châssis. Wall-Mount Bracket / Wall-Mount...
  • Page 79 MLB-3000 Mounting the Device / Montage de l'Appareil Mount the device to a wall using the 4 keyhole openings indicated with M4 6mm screws torqued to 6kgf/cm, or the 6 mounting holes circled, according to the spacing dimensions of the holes in the bracket as shown in Figure 2-6 MLB-3000 Top View.

  • Page 80: Driver Installation

    4.6 Driver Installation Download the Windows 10 drivers from the product page at https://www.adlinktech.com/Products/ Medical_Panel_Computer_Tablet/medical-box-pc/MLB-3000 The following drivers must be installed: Intel GPU  Chipset    Audio    RAID  Getting Started...

  • Page 81: A Appendix: Power Consumption

    MLB-3000 Appendix A Power Consumption Information in this Appendix is for power budget planning and design purposes only. Actual power consumption may differ based on final application. NOTE: NOTE: A.1 Power Consumption Reference Power consumption as follows is based on lab data in which 12V DC is applied and current is measured by the DC power supply.
  • Page 82 Sufficient power for the entire system is required to  meet these specifications. We recommend using a DC source instead of the optional 240W adapter when NOTE: NOTE: power consumption is over 240W in an environment where the temperature is 40°C. Heat generated by add-on PCIe adapters affects ther- ...

  • Page 83: B Appendix: Resource Mapping

    MLB-3000 Appendix B Resource Mapping B.1 BIOS Mapping in SPI ROM The chipset supports up to three SPI ROMs (SPI_CS0#, SPI_CS1# and SPI_CS2#). The motherboard uses SPI flash SPI_CS0# to select the SPI flash which stores ME firmware and the system BIOS. The size of the SPI ROM is 16MB for H310, and 32MB for Q370 chipsets.

  • Page 84: Pci/Pcie Devices

    B.2 PCI/PCIe Devices The following table lists all PCI/PCIe devices in the system. Device Function Routing Description Number Number Number 0x00 Intel HOST Bridge - 6 Cores/Desktop 0x02 Internal IGFX - GT2/6 Cores/Desktop 0x01 Internal PEG Root Port D1F0 0x12 Internal Thermal Subsystem 0x14...

  • Page 85: Irq Lines (Apic Mode)

    MLB-3000 B.3 IRQ Lines (APIC Mode) The following table lists the IRQ line mapping when APIC mode is enabled. Typical Interrupt IRQ # Connected to Pin Available Resource Counter 0 Keyboard Controller Cascade Interrupt from slave PIC Serial Port 2 (COM2) IRQ3 via SERIRQ/PIRQ Serial Port 1 (COM1) IRQ4 via SERIRQ/PIRQ IRQ5 via SERIRQ/PIRQ IRQ6 via SERIRQ/PIRQ...

  • Page 86: Irq Lines (Pic Mode)

    B.4 IRQ Lines (PIC Mode) The following table lists the IRQ line mapping when APIC mode is disabled. Typical Interrupt IRQ # Connected to Pin Available Resource Counter 0 Keyboard Controller Cascade Interrupt from slave PIC Serial Port 2 (COM2) IRQ3 via SERIRQ/PIRQ See note.

  • Page 87: System Memory Mapping

    MLB-3000 B.5 System Memory Mapping The following table lists the system memory mapping. Address Range Address Range (Hex) Size Description (Decimal) (4GB – 2MB) FFE00000 – FFFFFFFF 2 MB High BIOS Area (4GB – 18MB) – FEE00000 – FEEFFFFF 1 MB MSI Interrupt (4GB –17MB –...

  • Page 88: System I/O Mapping

    B.6 System I/O Mapping The following table lists the system I/O mapping. I/O Range (Hex) Device 020h – 02Dh & 030h – 03Dh Interrupt controller 1, 8259 equivalent 02Eh – 02Fh Motherboard resource 040h – 043h & 050h – 053h System Timer 04Eh –...

  • Page 89: Pci/Pcie Interrupt Routing Mapping

    MLB-3000 B.7 PCI/PCIe Interrupt Routing Mapping B.7.1 Internal Devices Audio xHCI SATA SMBus INT Line Controller Controller Controller #1 Controller Controller Controller Int0 INTA: 16 INTA: 16 INTA: 16 INTA: 16 INTA: 16 INTA: 16 Int1 INTB: 17 INTB: 17 INTB: 17 Int2 INTC: 18...

  • Page 90: Smbus Slave Address Mapping

    B.8 SMBus Slave Address Mapping The following table lists the SMBus slave address (8-bit address- ing) mapping. Device Address DIMM A 0A0h DIMM B 0A4h 050h 0C0h Resource Mapping...

  • Page 91: Appendix C Bios Setup

    MLB-3000 Appendix C BIOS Setup BIOS can be configured via the BIOS Setup Utility that is invoked during BIOS boot phase. The BIOS configuration is kept in NVRAM which is the same hardware part where the BIOS is stored. All settings will remain after the system is powered down. C.1 BIOS Setup Menu The BIOS Setup Utility is invoked by pressing <ESC>...

  • Page 92: Menu Conventions

    Menu Conventions The appearance of the setup menus and items listed in this chapter are based on a VT100 terminal connection via serial console with the following menu conventions. Using color  The default BIOS setup fields are in black. The BIOS setup fields currently not used are in grey.

  • Page 93: Menu Structure

    MLB-3000 C.2 Menu Structure This section presents the six primary menus of the BIOS Setup Utility. Use the following tables as a quick reference for the contents of the BIOS Setup Utility. The remainder of this chapter describe the submenus and options for each menu item. The default settings are presented in bold, and the function of each setting is described in the right hand column of the table.
  • Page 94 Boot Save & Exit - Boot Configuration - Save Changes and Exit - Setup Prompt Timeout - Discard Changes and Exit - Bootup NumLock State - Save Changes and Reset - Quiet Boot - Discard Changes and Reset - Fast Boot - Save Changes - Boot Order - Discard Changes...

  • Page 95: Main Menu

    MLB-3000 C.3 Main Menu This menu provides read-only information about your system and also allows you to set the System Date and Time. Refer to the tables below for details of the submenus and settings. C.3.1 Main > BIOS Information Feature Options Description...
  • Page 96 C.3.4 Main > Memory Information Feature Options Description Total Memory Info only Total Memory Memory Frequency Info only Memory Frequency C.3.5 Main > PCH Information Feature Options Description PCH SKU Info only PCH SKU Stepping Info only PCH Stepping C.3.6 Main >...
  • Page 97 MLB-3000 C.3.8 Main > System Date & Time Feature Options Description Requires the alpha-numeric entry of Weekday, the day of the week, day of the System Date MM/DD/ month, calendar month, and all 4 YYYY digits of the year, indicating the century and year (Fri XX/XX/20XX) Presented as a 24-hour clock setting System Time...

  • Page 98: Advanced Menu

    C.4 Advanced Menu This menu contains the settings for most of the user interfaces in the system. C.4.1 Advanced > CPU Configuration Feature Options Description CPU Configuration Info only Type Info only Displays the Processor Type Package Info only Displays the Processor Package Stepping Info only Displays the Processor Stepping.
  • Page 99 MLB-3000 Feature Options Description Intel(R) Disabled Allows more than two frequency ranges to SpeedStep(tm) Enabled be supported. Intel(R) Speed Shift Disabled Enables/Disables Intel(R) Speed Shift Technology Enabled Technology support. Enabling will expose the CPPC v2 interface to allow for hardware controlled P-states.
  • Page 100 Feature Options Description Tcc Activation Offset 0-63 Offset from factory set Tcc activation Default: 1 temprature at which the Thermal Control Circuit must be activated. Tcc will be activated at: Tcc Activation Temp - Tcc Activation Offset. Tcc Activation Offset range is 0 to 63.
  • Page 101 MLB-3000 Feature Options Description VESA 24 bpp Data format and Color Data format and Color Depth Depth JEIDA 24 bpp select JEIDA/vesa 18 bpp LVDS Output Mode Dual LVDS bus Single/Dual mode select Single LVDS bus DE Polarity Active High DE Polarity select Active Low Vsync Polarity...
  • Page 102 Feature Options Description Lock Legacy Resources Disabled Enables/Disables Lock of Enabled Legacy Resources Restore AC Power Loss Power On Select AC power state when Power Off power is re-applied after a Last State power failure. Power Supply Unit Emulate AT Mode ATX: OS will turn off system ATX Mode power when shutdown.
  • Page 103 MLB-3000 C.4.5 Advanced > System Management Feature Options Description System Management Info only Version Info only SEMA Firmware Info only Version of SEMA Firmware Build Date Info only Build Date of SEMA Firmware SEMA Bootloader Info only Version of SEMA Bootloader Build Date Info only Build Date of SEMA Bootloader...
  • Page 104 Feature Options Description AT/ATX mode Info only AT/ATX mode ACPI Thermal Trigger Info only ACPI Thermal Trigger Backlight restore Info only Backlight restore DTS register available Info only DTS register available System Fan 2 Info only System Fan 2 TIVA BMC Info only TIVA BMC Board2 Temperature Info only Board2 Temperature...
  • Page 105 MLB-3000 C.4.10 Advanced > Thermal Management Feature Options Description Thermal Management Info only CPU Temperature Info only Current Info only Current CPU temperature Startup Info only Startup CPU temperature Info only Min. CPU temperature Info only Max. CPU temperature Board Temperatures Info only Current Info only...
  • Page 106 C.4.11 Advanced > Thermal Management > Smart Fan Feature Options Description Smart Fan Info only CPU Smart CPU Sensor CPU Smart FanTemperature FanTemperature Source Source CPU Fan Mode AUTO (Smart Fan) CPU Fan Mode Fan Off Fan On Trigger Point 1 Info only Trigger Temperature 0-100...
  • Page 107 MLB-3000 Feature Options Description Trigger Temperature 0-100 Trigger Temperature Default: 0 PWM Level 0-100 PWM Level Default: 30 Trigger Point 2 Info only Trigger Temperature 0-100 Trigger Temperature Default: 50 PWM Level 0-100 PWM Level Default: 45 Trigger Point 3 Info only Trigger Temperature 0-100...
  • Page 108 Feature Options Description Trigger Temperature 0-100 Trigger Temperature Default: 60 PWM Level 0-100 PWM Level Default: 75 Trigger Point 4 Info only Trigger Temperature 0-100 Trigger Temperature Default: 80 PWM Level 0-100 PWM Level Default: 100 C.4.12 Advanced > Watchdog Timer Feature Options Description...

  • Page 109: Options Description

    MLB-3000 C.4.13 Advanced > Super IO Configuration Feature Options Description Super IO Configuration Info only COM1 Device Settings Info only IO=3F8h; IRQ=4; COM1 Control RS232 Select COM1 mode. RS232 only Ring1 Wake Disabled Disable/Enable RI ping for Wake On Enabled Ring function(PCH PME# signal) COM2 Device Settings Info only...
  • Page 110 C.4.15 Advanced > Console Redirection Settings [COM1-2] Feature Options Description COM[1-2] Info only Console Redirection Settings Terminal Type VT100 Emulation: VT100+ ANSI: Extended ASCII char set. VT-UTF8 VT100: ASCII char set. ANSI VT100+: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
  • Page 111 MLB-3000 Feature Options Description None Flow Control Flow control can prevent data loss from Hardware buffer overflow. When sending data, if RTS/CTS the receiving buffers are full, a 'stop' signal can be sent to stop the data flow. Once the buffers are empty, a 'start' signal can be sent to re-start the flow.
  • Page 112 Feature Options Description Security Device Disabled Enables/Disables BIOS support for security Support Enabled device. OS will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Active PCR banks Info only Available PCR banks Info only SHA-1 PCR Bank Disabled Enables/Disables SHA-1 PCR Bank...
  • Page 113 MLB-3000 C.4.17 Advanced > RTC Wake Settings Feature Options Description RTC Wake system Disabled Enables/Disables System wake on alarm from S5 Fixed Time event. Dynamic FixedTime: system will wake on the Time hr::min::sec specified. DynamicTime: System will wake on the current time + Increase minute(s) Wake up hour 0-23...
  • Page 114 Feature Options Description Ipv6 PXE Support Disabled Enables/Disables IPv6 PXE boot support. If Enabled disabled, IPv6 PXE boot support will not be available. Disabled Ipv6 HTTP Support Enables/Disables IPv6 HTTP boot support. Enabled If disabled, IPv6 HTTP boot support will not be available.
  • Page 115 MLB-3000 C.4.22 Advanced > RAM Disk Configuration > Create raw Feature Options Description Size (Hex): Number The valid RAM disk size should be multiples of the RAM disk block size. Create & Exit Create a new RAM disk with the given starting and ending address.

  • Page 116: Chipset

    C.5 Chipset C.5.1 Chipset > System Agent (SA) Configuration Feature Options Description System Agent (SA) Info only Configuration SA PCIe Code Version Info only SA PCIe Code Version VT-d Info only Supported or not Memory Configuration ► Sub-Menu Memory Configuration Parameters Graphics Configuration ►...
  • Page 117 MLB-3000 Feature Options Description Memory Remap Disabled Enables/Disables Memory Remap Enabled above 4GB Fast Boot Disabled Enables/Disables fast path through Enabled C.5.3 Chipset > System Agent (SA) Configuration > Graphics Configuration Feature Options Description Graphics Configuration Info only Graphics Turbo IMON 14-31 Graphics turbo IMON current values Default: 31...
  • Page 118 C.5.4 Chipset > System Agent (SA) Configuration > PEG Port Configuration Feature Options Description PEG Port Configuration Info only PEG [Bus, Dev, Fun] Info only PEG location and info Enable Root Port Disabled Enables/Disables the Root Port Enabled Auto Max Link Speed Auto Configure PEG [Bus, Dev, Fun] Max Gen1...
  • Page 119 MLB-3000 C.5.6 Chipset > PCH-IO Configuration > PCI Express Configuration Feature Options Description PCI Express Configuration Info only PCI Express Clock Gating Disabled Enables/Disables PCI Express Enabled Clock Gating for each root port. Pcie Pll SSC Auto Pcie Pll SSC percentage. 0.0% AUTO - Keep hw default, no BIOS 0.1%...
  • Page 120 C.5.7 Chipset > PCH-IO Configuration > SATA Configura- tion Feature Options Description SATA Configuration Info only AHCI SATA Mode Selection Determines how SATA Intel RST Premium With Intel controller(s) operate. Optane System Acceleration Serial ATA Port 0 Info only SATA device info Serial ATA Port 2 Info only SATA device info...
  • Page 121 MLB-3000 Feature Options Description U3_USB1_TX_P Disabled Enables/Disables this USB Physical (EXTERNAL USB) Enabled Connector (physical port). Once disabled, any USB devices plugged U3_USB2_TX_P Disabled into the connector will not be detected (EXTERNAL USB) Enabled by BIOS or OS. U3_USB3_TX_P Disabled (EXTERNAL USB) Enabled U3_USB4_TX_P...
  • Page 122 C.5.9 Chipset > PCH-IO Configuration > Security Config- uration Feature Options Description Security Configuration Info only Disabled BIOS Lock Enables/Disables the PCH BIOS Lock Enabled Enable feature. Required to be enabled to ensure SMM protection of flash. C.5.10 Chipset > PCH-IO Configuration > HD Audio Con- figuration Feature Options...

  • Page 123: Security

    MLB-3000 C.6 Security C.6.1 Security > Password Description Feature Options Description Password Description Info only Administrator Password Enter password Sets Administrator Password User Password Enter password Sets User Password Secure Boot menu ► Submenu Secure Boot configuration C.6.2 Security > Secure Boot menu Feature Options Description...

  • Page 124: Boot

    C.7 Boot C.7.1 Boot > Boot Configuration Feature Options Description Boot Configuration Info only Setup Prompt Timeout 1 Number of seconds to wait for setup activation key. 65535 (0xFFFF ) means indefinite waiting. Bootup NumLock State On Selects the keyboard NumLock state. Quiet Boot Disabled Enables/Disabless Quiet Boot option.

  • Page 125: Save & Exit

    MLB-3000 C.8 Save & Exit Feature Options Description Save Changes and Yes No Exits system setup after saving the Exit changes. Discard Changes Yes No Exits system setup without saving any and Exit changes. Save Changes and Yes No Resets the system after saving the Reset changes.
  • Page 126 This page intentionally left blank. BIOS Setup...

  • Page 127: Appendix D Displayport Bios Settings

    MLB-3000 Appendix D DisplayPort BIOS Settings This appendix describes use of the DisplayPort BIOS settings for MXM modules. D.1 MXM P1000/P2000/T1000/RTX3000/RTX5000 BIOS Setting DisplayPort POST Stage Windows 10 Primary Internal LVDS DP from DP from DP from DP from Display Graphics IGFX Enabled...
  • Page 128 This page intentionally left blank. DisplayPort BIOS Settings...

  • Page 129: Appendix E Digital Input/Output Function Library

    To use the DI/O function library for the MLB-3000 series, include the header file (GpioLib.h) and linkage library (GpioLib.lib) in the C++ project. DI/O functions are as follows. GPIO_Init This API checks if the GPIO driver handle is valid.
  • Page 130 GPO_Write This API is used to write the new state of a digital output (DO): char GPO_Write(UCHAR GpioNum,UCHAR GpioPortVal) Arguments: GpioNum: The number of a digital output pin (4-7). GpioPortVal: A new output state 0 or 1. Return values: GPIO_OK on success. GPIO_ERROR on failure. RegisterInterruptEvent The event passed will be signaled when there is a change in state on a digital input pin.

  • Page 131: Important Safety Instructions

    MLB-3000 Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. Read these safety instructions carefully. ...
  • Page 132 A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type; please dispose of used batteries appropriately. CAUTION: This equipment is not suitable for use in locations where ...

  • Page 133: Consignes De Sécurité Importante

    MLB-3000 Consignes de Sécurité Importante S'il vous plaît prêter attention stricte à tous les avertissements et mises en garde figurant sur l'appareil, pour éviter des blessures ou des dommages. Lisez attentivement ces consignes de sécurité.  Conservez le manuel de l'utilisateur pour pouvoir le con- ...
  • Page 134 N'essayez jamais de réparer l'appareil, qui ne doit être réparé  que par un personnel technique qualifié à l'aide d'outils appro- priés Une batterie de type Lithium peut être fournie pour une ali-  mentation de secours ininterrompue ou d'urgence. ATTENTION: Risque d’explosion si la pile est remplacée par une autre de type incorrect.
  • Page 135 MLB-3000 RISQUE DE BRÛLURES Partie chaude! Ne touchez pas cette surface, cela pourrait entraîner des blessures. Pour éviter tout danger, laissez la surface refroidir avant de la toucher. Consignes de Sécurité Importante...
  • Page 136 This page intentionally left blank. Consignes de Sécurité Importante...

  • Page 137: Getting Service

    San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com ADLINK Technology GmbH Hans-Thoma-Straße 11...

Table of Contents
