ADLINK Technology MVP-6010 Series User Manual

6th generation intel core i7 / i5 / i3 fanless computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MVP-6010 Series
MVP-6020 Series
6th Generation Intel
Fanless Computer
MVP-6011/MVP-6012/MVP-6013/MVP-6015
MVP-6021/MVP-6022/MVP-6023/MVP-6025
Manual Rev.:
Revision Date:
Part No:
Leading EDGE COMPUTING
®
Core™ i7/i5/i3
User's Manual
1.0
June 23, 2017
50-1Z214-1000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVP-6010 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology MVP-6010 Series

Summary of Contents for ADLINK Technology MVP-6010 Series

  • Page 1 MVP-6010 Series MVP-6020 Series ® 6th Generation Intel Core™ i7/i5/i3 Fanless Computer MVP-6011/MVP-6012/MVP-6013/MVP-6015 MVP-6021/MVP-6022/MVP-6023/MVP-6025 User’s Manual Manual Rev.: June 23, 2017 Revision Date: 50-1Z214-1000 Part No: Leading EDGE COMPUTING...
  • Page 2 Leading EDGE COMPUTING Revision History Revision Release Date Description of Change(s) June 23, 2017 Initial Release...

  • Page 3: Mvp-6010/Mvp

    MVP-6010/MVP-6020 Preface Copyright 2017 ADLINK Technology, Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Leading EDGE COMPUTING Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.

  • Page 5: Table Of Contents

    MVP-6010/MVP-6020 Table of Contents Preface ..................iv List of Tables................. xii List of Figures ..............xiv 1 Introduction ................ 1 Overview................1 Features................1 Specifications............... 2 1.3.1 MVP-6011/6021, MVP-6012/6022, MVP-6013/6023.. 2 1.3.2 MVP-6015/6025............4 1.3.3 Power Consumption ........... 5 Schematics and Dimensions ..........8 Front Panel I/O Connectors ..........
  • Page 6 Leading EDGE COMPUTING 1.5.14 COM Port Connectors ..........22 Rear-Mounted CFast Host Connector ....... 23 Internal I/O Connectors............24 1.7.1 MVP-6010 Series Backplane Connectors ....25 1.7.2 MVP-6020 Series Backplane Connectors ....26 1.7.3 GPS Module Power Headers........27 1.7.4 USB 2.0 Connector...........
  • Page 7 MVP-6010/MVP-6020 B Appendix: BIOS Setup ............51 Main ................... 51 BIOS Information ............52 Platform Information ............. 52 FW Information ............. 52 System Time/System Date ........... 53 Advanced................53 B.2.1 CPU Configuration............ 54 Hyper-Threading ............55 Active Processor Cores ..........55 Intel Virtualization Technology ........
  • Page 8 Leading EDGE COMPUTING LAN #3(I211AT) Launch PXE OpROM ......60 Serial Port Console Redirection ........60 B.2.6 Advanced Power Management......... 61 State After G3 ............... 61 State After G3 ............... 62 RTC Wake system from S5 .......... 62 BIOS POST Watchdog ..........62 B.2.7 USB Configuration ............
  • Page 9 MVP-6010/MVP-6020 Setup Prompt Timeout ..........68 Bootup Num-Lock State ..........68 Quiet Boot ..............69 Fast Boot ..............69 Boot Option Priorities ............ 69 Save & Exit ................ 71 Discard Changes and Exit ..........71 Save Changes and Reset ..........71 Discard Changes ............
  • Page 10 Leading EDGE COMPUTING This page intentionally left blank. Table of Contents...

  • Page 11: List Of Tables

    MVP-6010/MVP-6020 List of Tables Table 1-1: MVP-6010 Series Front Panel I/O Connector Legend12 Table 1-2: MVP-6020 Series Front Panel I/O Connector Legend12 Table 1-3: LED Indicators ............13 Table 1-4: DisplayPort Pin Assignments ........14 Table 1-5: Applicable Cable Types..........14...
  • Page 12 Leading EDGE COMPUTING This page intentionally left blank. xiii List of Tables...

  • Page 13: List Of Figures

    MVP-6010/MVP-6020 List of Figures Figure 1-1: MVP-6010 Series Functional Block Diagram....6 Figure 1-2: MVP-6020 Series Functional Block Diagram....7 Figure 1-3: Front View................ 8 Figure 1-4: Left Side View..............9 Figure 1-5: Top View................9 Figure 1-6: Rear View ..............10 Figure 1-7: Underside View..............
  • Page 14 Leading EDGE COMPUTING This page intentionally left blank. List of Figures...

  • Page 15: Introduction

    MVP-6010/MVP-6020 Introduction 1.1 Overview ADLINK’s MVP-6010/MVP-6020 Series of value line fanless embedded computing platforms, incorporating the 6th Generation ® ™ Intel Core processor, provides one PCIex16 and three PCI or two PCIex16 and two PCI expansion slots, one mini-PCIe slot and single-side access for I/O ports, optimizing easy maintenance in industrial automation environments.

  • Page 16: Specifications

    Leading EDGE COMPUTING CFast socket, onboard SATA III port for 1x 2.5” HDD/SSD  installation, and SATA 6Gb/s Built-in wide-range 12V DC to 24V DC power input  Fanless operation from 0°C to 50°C (with 35W CPU), and  0°C to 40°C (with 65W CPU) This option guarantees cold boot of the system at 0°c and operation with 100% loading at 50°...
  • Page 17 MVP-6010/MVP-6020 MVP-6011/6021 MVP-6012/6022 MVP-6013/6023 6 external USB ports (4x 3.0 + 2x 2.0) (each supporting 1.6A w/ 1 internal USB 2.0 port for 40 mil/A trace design and 5V ± 5% voltage stability) DI/O 8CH DI and 8CH DO Mini PCIe 1 internal mini PCIe USIM 1 USIM...

  • Page 18: Mvp-6015/6025

    Leading EDGE COMPUTING 1.3.2 MVP-6015/6025 System Core Processor Intel® Core™ i7-6700 (65W) MVP-6015: H110 Chipset MVP-6025: Q170 Video 1 VGA + 2 DisplayPort + 1 DVI-D Memory 4 GB DDR4 2133 MHz (up to 32 GB) Win7 32/64-bit, Win 10 64-bit, Linux* I/O Interface MVP-6015: 1 PCIe Gen3 x16 + 3 PCI expansion slots Expansion slots...

  • Page 19: Power Consumption

    MVP-6010/MVP-6020 Dimensions 220(W) X 210(D) X 208.7(H)mm (8.67” x 8.27” x 8.21”) Weight 4.7 kg (10.36 lbs) Mounting Wall mount kit Environmental Operating 0°C to 40°C Temperature Storage -40°C to 85°C (-40°F to 185°F) (excl. HDD/SDD/CFast) Temperature Humidity Approx. 95% @ 40°C (non-condensing) Operating, 5 Grms, 5-500 Hz, 3 axes (w/ CFast or SSD) Vibration Operating, 0.5 Grms, 5-500 Hz, 3 axes (w/ HDD)

  • Page 20: Figure 1-1: Mvp-6010 Series Functional Block Diagram

    Connector GBE I/F GBE I/F GBE I/F PCIex1 PCI 1 GbEcontroller RJ45 & Intel WGI211AT 8DO connector USB2.0 USB2.0 USB2.0 x 2 Connector NCT6016D COM x 4 COM x 4 Dsub-9 x4 Figure 1-1: MVP-6010 Series Functional Block Diagram Introduction...

  • Page 21: Figure 1-2: Mvp-6020 Series Functional Block Diagram

    MVP-6010/MVP-6020 Intel Core DDR4 Channel A DDR4 PCIE x8 Gen3 PCIE x8 Gen3 PCIE x 16 I7-6700 3.4GHz 260 pin SODIMM 2133MHZ slot I7-6700TE 2.4GHz I5-6500TE 2.3GHz DDR4 Channel BDDR4 PCIE x8 Gen3 I3-6100TE 2.7GHz PCIE x 16 260 pin SODIMM 2133MHZ Processor slot...

  • Page 22: Schematics And Dimensions

    Leading EDGE COMPUTING 1.4 Schematics and Dimensions All dimensions shown are in mm (millimeters). NOTE: NOTE: 208.7 Figure 1-3: Front View Introduction...

  • Page 23: Figure 1-4: Left Side View

    MVP-6010/MVP-6020 Figure 1-4: Left Side View Figure 1-5: Top View Introduction...

  • Page 24: Figure 1-6: Rear View

    Leading EDGE COMPUTING Figure 1-6: Rear View Figure 1-7: Underside View Introduction...

  • Page 25: Front Panel I/O Connectors

    MVP-6010/MVP-6020 1.5 Front Panel I/O Connectors Figure 1-8: Front Panel I/O Connectors Power Button Digital Input LED Indicators Digital Output C Audio (Mic, Phones) DVI-D D PCI express X16 5V 32-Bit PCI USB 2.0 (Type A) x2 5V 32-Bit PCI Gigabit Ethernet x3 G 5V 32-Bit PCI USB3.0 (Type A) x4...

  • Page 26: Power Button

    Leading EDGE COMPUTING H Reset Button DC power supply DisplayPort x2 COM port x4 Table 1-1: MVP-6010 Series Front Panel I/O Connector Legend Power Button Digital Input LED Indicators Digital Output C Audio (Mic, Phones) DVI-D D PCI express X16 PCI express X16 USB 2.0 (Type A) x2...

  • Page 27: Led Indicators

    MVP-6010/MVP-6020 1.5.2 LED Indicators In addition to the LED of the power button, three LEDs on the front panel indicate the following. LED indicator Color Description Indicates watchdog timer status. When watchdog timer starts, the LED flashes. Watchdog (WD) Yellow When the timer is expired, the LED remains lit..

  • Page 28: Displayport Connectors

    Leading EDGE COMPUTING 1.5.6 DisplayPort Connectors Two DisplayPort connectors on the front panel can connect to VGA, DVI, HDMI and DisplayPort monitors via DisplayPort to VGA adapter cable, DisplayPort to DVI adapter cable, or DisplayPort to HDMI adapter cable and DisplayPort cable. Figure 1-9: DisplayPort Connector Signal Pin Signal...

  • Page 29: Display Options

    MVP-6010/MVP-6020 Display Options With computing and graphic performance enhancement from its 6th Generation Intel processor, the MVP-6010/MVP-6020 control- ler can support two independent displays, with configuration as fol- lows. Display Option 1 Display Option 2 DisplayPort1 DisplayPort2 4096x2304@60Hz 4096x2304@60Hz DisplayPort1 DVI-D 4096x2304@60Hz 1920x1200@60Hz...

  • Page 30: Table 1-7: Digital Input Connector Pin Legend

    Leading EDGE COMPUTING Figure 1-10: Digital I/O Connector Pin Assignment Signal DI_GND Table 1-7: Digital Input Connector Pin Legend Signal Introduction...

  • Page 31: Table 1-8: Digital Output Connector Pin Legend

    MVP-6010/MVP-6020 Signal DO_GND Table 1-8: Digital Output Connector Pin Legend Figure 1-11: Digital Input Circuit Figure 1-12: Digital Output Circuit Introduction...

  • Page 32: Dvi-D Connector

    Leading EDGE COMPUTING 1.5.8 DVI-D Connector The MVP-6010/MVP-6020 provides one DVI-D connector for con- nection to an external monitor. Figure 1-13: DVI-D Connector Pin Assignment Pin Signal Pin Signal Pin Signal DVIdata 2- DVIdata 1- DVIdata 0- DVIdata 2+ DVIdata 1+ DVIdata 0+ DVIDC clock DVIDC data...

  • Page 33: Usb 2.0 Ports

    MVP-6010/MVP-6020 Signal G_VGA_R G_VGA_G G_VGA_B CRT_DDAT_CN G_VGA_HSYNC G_VGA_VSYNC CRT_DCLK_CN Table 1-10: VGA Connector Pin Legend 1.5.10 USB 2.0 Ports The MVP-6010/MVP-6020 provides two USB 2.0 ports supporting Type A USB connection on the front panel. All USB ports are com- patible with high-speed, full-speed and low-speed USB devices.

  • Page 34: Figure 1-15: Ethernet Port And Led Legend

    Leading EDGE COMPUTING IEEE 802.3az Energy Efficient Ethernet  IEEE 1588/802.1AS precision time synchronization  IEEE 802.3Qav traffic shaper  Interrupt moderation, VLAN support, IP checksum offload  RSS and MSI-X to lower CPU utilization in multi-core sys-  tems ECC - error correcting memory in packet buffers ...

  • Page 35: Usb 3.0 Ports

    MVP-6010/MVP-6020 LED Color Status Description Ethernet port is disconnected. Yellow Ethernet port is connected with no activity. Flashing Ethernet port is connected and active. Table 1-11: Active/Link LED Indicators LED Color Status Description 10 Mbps Green/Orange Green 100 Mbps Orange 1000 Mbps Table 1-12: Speed LED Indicators 1.5.12...

  • Page 36: Com Port Connectors

    Leading EDGE COMPUTING Figure 1-16: DC Power Connector Signal V+ (DC_IN) GND (CHGND) V- (DGND) Table 1-13: DC Power Supply Connector Signals 1.5.14 COM Port Connectors The MVP-6010/MVP-6020 provides four COM ports through D-sub 9 pin connectors. The COM1 & COM2 ports support RS-232/422/485 modes by BIOS setting, while COM3 and COM4 support only RS-232.

  • Page 37: Rear-Mounted Cfast Host Connector

    MVP-6010/MVP-6020 Signal Name RS-232 RS-422 RS-485 TXD422+ 485DATA+ RXD422+ DTR# RXD422- DSR# RTS# CTS# Table 1-14: D-Sub 9p Signal Function of COM Ports 1.6 Rear-Mounted CFast Host Connector The MVP-6010/MVP-6020 is equipped with a Type II Push Push CFlash host connector on the rear panel, by SATA interface. Data transfer rates up to 3.0Gb/s(300MB/s)/1.5Gb/s(150MB/s) are sup- ported.

  • Page 38: Internal I/O Connectors

    Leading EDGE COMPUTING 1.7 Internal I/O Connectors C D E Figure 1-19: Mainboard I/O Connectors GPS module 5V power header GPS module 3.3V power header USB2.0 connector Mini-PCIe connector SATA connector 9V fan connector Jumpers: Clear CMOS (upper)  N/C (lower) ...

  • Page 39: Mvp-6010 Series Backplane Connectors

    MVP-6010/MVP-6020 1.7.1 MVP-6010 Series Backplane Connectors Figure 1-20: MVP-6010 Series Backplane Board PCB PCIe x16 Backboard to mainboard PCB connector 12V fan connector Table 1-16: MVP-6010 Series Backplane Board Connector Legend Introduction...

  • Page 40: Mvp-6020 Series Backplane Connectors

    Leading EDGE COMPUTING 1.7.2 MVP-6020 Series Backplane Connectors Figure 1-21: MVP-6020 Series Backplane Board PCB PCIe x16 PCIe x16 Backboard to mainboard PCB connector 12V fan connector Table 1-17: MVP-6020 Series Backplane Board Connector Legend Introduction...

  • Page 41: Gps Module Power Headers

    MVP-6010/MVP-6020 1.7.3 GPS Module Power Headers Power supply via cable for mini PCIE GPS module cards is pro- vided in both 5V and 3.3V voltages. Pin #1 is on the right. 3.3V CN16 +V5_GPS CN17 +V3.3_GPS 3.3V +V3.3_GPS +V5_GPS 1.7.4 USB 2.0 Connector One onboard USB 2.0 Type-A connector is provided for the inter- nal USB dongle, with only the upper port functional.

  • Page 42: Fan Connector

    Leading EDGE COMPUTING 1.7.7 9V Fan Connector DC 9V fan module power supply is provided through the connec- tor, to which the optional fan module connects when installed in the chassis. Signal FAN_GND P_+9V0_FAN1 FAN_TACH_CN FAN_PWM_CN 1.7.8 Clear CMOS Jumper Upon encountering an abnormal condition preventing the MVP-6010/MVP-6020 from booting, the jumper can clear the BIOS content stored in CMOS and restore default settings.

  • Page 43: Extended Pwr/Reset Header

    MVP-6010/MVP-6020 1.7.9 Extended PWR/RESET header An internal header is provided for the Power and Reset buttons, with pin assignment as shown. Signal PWR_BTN-L RESET_BTN-L 1.7.10 USIM Slot The USIM slot connects to the Mini-PCIe slot. 1.7.11 Internal Reserved +5V and +12V Connector The MVP-6010/MVP-6020 provides one power pin header with +5V and +12V DC power, providing access for PCI and PCI express card external power supplies.

  • Page 44: Backboard To System Pcb Connector

    Leading EDGE COMPUTING Signal +12V 1.7.12 Backboard to System PCB Connector This connector connects the backboard to a golden fin- ger-equipped mainboard PCB. 1.7.13 12V DC Fan Connector Signal FAN_GND P_+12V0_FAN1 FAN_TACH_CN FAN_PWM_CN Introduction...
  • Page 45 MVP-6010/MVP-6020 The MVP-6010/MVP-6020 provides a DC 12V to USB connector for fan module power. The optional fan module connects to the connector when assembled to the chassis. Introduction...
  • Page 46 Leading EDGE COMPUTING This page intentionally left blank. Introduction...

  • Page 47: Getting Started

    MVP-6010/MVP-6020 Getting Started 2.1 Unpacking Checklist Before unpacking, check the shipping carton for any damage. If the shipping carton and/or contents are damaged, inform your dealer immediately. Retain the shipping carton and packing materials for inspection. Obtain authorization from your dealer before returning any product to ADLINK.

  • Page 48: Deployment

    Leading EDGE COMPUTING 2.2 Deployment The MVP-6010/6020 can be deployed either upright, with the underside on a stable surface, or on its left side, as shown. Figure 2-1: Upright Deployment Getting Started...

  • Page 49: Figure 2-2: Left Side Deployment

    MVP-6010/MVP-6020 Figure 2-2: Left Side Deployment Getting Started...

  • Page 50: Installing Hard Disk Drives

    Leading EDGE COMPUTING 2.3 Installing Hard Disk Drives 1. Remove the 16 bottom and side cover screws by screw- driver Getting Started...
  • Page 51 MVP-6010/MVP-6020 2. Remove the bottom/side cover by lifting. 3. Use 4 of the included M3 screws to fix a 2.5" HDD or SSD unit to the bracket.. 4. Gently depress the drive into the SATA connector on the PCB. Getting Started...
  • Page 52 Leading EDGE COMPUTING 5. Use 4 of the included M3 screws to mount the drive.. 6. Replace the bottom cover and refasten screws. Getting Started...

  • Page 53: Installing A Pci/Pcie Card

    MVP-6010/MVP-6020 2.4 Installing a PCI/PCIe Card Remove the bottom cover as detailed previously. 1. Insert thePCI/PCIe card into the PCI/PCIe slot. True the lower edge of the card with the alignment guide. Getting Started...

  • Page 54: Installing Cfast Cards

    Leading EDGE COMPUTING 2.5 Installing CFast Cards 1. Remove the screws fixing the CFast socket cover. 2. True the CFast card with the alignment guide. Getting Started...

  • Page 55: Wall-Mounting The Mvp-6010/Mvp-6020

    MVP-6010/MVP-6020 3. Gently insert the CFast card until it is firmly seated in the socket. 4. Replace the socket cover and screws. 2.6 Wall-mounting the MVP-6010/MVP-6020 All dimensions shown are in mm (millimeters). NOTE: NOTE: The MVP-6010/MVP-6020 is shipped with wall-mount brackets and accessory screws.

  • Page 56: Underside Wall-Mounting

    Leading EDGE COMPUTING 2.6.1 Underside Wall-mounting While configuration shown may indicate otherwise, due to the presence of ventilation holes, for safety, the device should ONLY be wall-mounted with the front and rear panels on the CAUTION: sides, NEVER on the top or underside. 1.
  • Page 57 MVP-6010/MVP-6020 2. Use the 6 M4 screws shipped with the controller to fix the 2 wall-mount brackets, also included, to the chassis, according to the spacing dimensions of the screw holes and brackets, as shown. 5.20 25.20 7.20 Getting Started...
  • Page 58 Leading EDGE COMPUTING 3. Once final assembly as shown is complete, mount the MVP-6010/MVP-6020 on the wall via screw holes. Getting Started...

  • Page 59: Left Side Wall-Mounting

    MVP-6010/MVP-6020 2.6.2 Left Side Wall-mounting 1. Remove the 6 plastic pads from the left side panel. Getting Started...
  • Page 60 Leading EDGE COMPUTING 2. Use the 6 M4 screws shipped with the controller to fix the 2 wall-mount brackets, also included, to the chassis, according to the spacing dimensions of the screw holes and brackets, as shown. Getting Started...
  • Page 61 MVP-6010/MVP-6020 5.20 25.20 233.85 7.20 Getting Started...

  • Page 62: Driver Installation

    Leading EDGE COMPUTING 3. Once final assembly as shown is complete, mount the MVP-6010/MVP-6020 on the wall via screw holes. 2.7 Driver Installation Download requisite drivers, as follows, for your system from http://www.adlinktech.com and install. The following drivers must be installed: Chipset driver ...

  • Page 63: A Appendix: Power Consumption

    MVP-6010/MVP-6020 Appendix A Power Consumption Information in this Appendix is for power budget planning and design purposes only. Actual power consumption may differ based on final application. NOTE: NOTE: A.1 Power Consumption Reference Power consumption as follows is based on lab data in which 24V DC is applied and current is measured by the DC power supply.

  • Page 64: Power Supply Reference

    Leading EDGE COMPUTING Sufficient power supply for the entire system is  required to meet these specifications. At least 100W at 24V input is recommended. NOTE: NOTE: Heat generated by add-on PCI/PCIe adapters  affects thermal stability. Additional heat dissipa- tion is required when the system operates at high temperatures or in harsh environments with add-on adapters.

  • Page 65: B Appendix: Bios Setup

    MVP-6010/MVP-6020 Appendix B BIOS Setup The Basic Input/Output System (BIOS) is a program that provides a basic level of communication between the processor and peripherals. In addition, the BIOS also contains codes for various advanced features applied to the MVP-6010/MVP-6020. The BIOS setup program includes menus for configuring settings and enabling features of the MVP-6010/MVP-6020.

  • Page 66: Bios Information

    Leading EDGE COMPUTING BIOS Information Shows current system BIOS Vendor, Core Version, BIOS Version, Board Version and Product Name. Platform Information Shows current system Platform Name, CPU Stepping, PCH SKU, PCH Stepping and GT information. FW Information Shows current system Memory RC version, Microcode Path, IGFX VBIOS version and ME FW version.

  • Page 67: System Time/System Date

    MVP-6010/MVP-6020 System Time/System Date Allows adjustment of system time and date, as follows. 1. Highlight System Time or System Date using the up and down <Arrow> keys 2. Enter new values using the keyboard and select <Enter> 3. Select < Tab > to move between fields. The date must be entered in MM/DD/YY format, ...

  • Page 68: B.2.1Cpu Configuration

    Leading EDGE COMPUTING B.2.1CPU Configuration BIOS Setup...

  • Page 69: Hyper-Threading

    MVP-6010/MVP-6020 Hyper-Threading Enabled for Windows XP and Linux (optimized for Hyper-Thread- ing Technology) and Disabled for other OS (not optimized for Hyper-Threading Technology). When Disabled only one thread per enabled core is enabled. Active Processor Cores Number of cores to enable in each processor package. Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabil- ities provided by Vanderpool Technology.

  • Page 70: Memory Configuration

    Leading EDGE COMPUTING B.2.2 Memory Configuration Shows current system Memory RC Version and values for mem- ory frequency, total memory, DIMM#0, and DIMM#1. BIOS Setup...

  • Page 71: System Agent (Sa) Configuration

    MVP-6010/MVP-6020 B.2.3 System Agent (SA) Configuration VT-d Enables/disables VT-d capability. BIOS Setup...

  • Page 72: Graphics Configuration

    Leading EDGE COMPUTING B.2.4 Graphics Configuration Primary Display Sets the IGFX/PEG/PCI graphics device to be primary display. GTT Size Sets GTT size. Aperture Size Sets aperture size, with MMIO BIOS assignment exceeding 4GB automatically enabled when 2048MB aperture is selected, avail- able when CSM Support is disabled.

  • Page 73: Dvmt Total Gfx Mem

    MVP-6010/MVP-6020 DVMT Total Gfx Mem Sets size of DVMT5.0 total graphic memory used by the internal graphics device. B.2.5 Onboard Device Configuration Serial Port 1 to 4 Configuration Sets port type (RS-232/422/485) for Serial Ports 1 and 2 only. LAN #1 (Intel I211AT) Enables/Disables onboard Intel I211AT LAN controller.

  • Page 74: Lan #2 (Intel I211At)

    Leading EDGE COMPUTING LAN #2 (Intel I211AT) Enables/Disables onboard Intel I211AT LAN controller. LAN #2(I211AT) Launch PXE OpROM Enables or disables execution of LAN boot-rom to add boot option for legacy network devices. LAN #3 (Intel I211AT) Enables/Disables onboard Intel I211AT LAN controller. LAN #3(I211AT) Launch PXE OpROM Enables or disables execution of LAN boot-rom to add boot option for legacy network devices.

  • Page 75: Advanced Power Management

    MVP-6010/MVP-6020 Console Redirection Enables console redirection on COM 1 to 4 and EMS COM. Console Redirection Settings Sets miscellaneous parameters for COM Ports 1 to 4 and EMS COM. B.2.6 Advanced Power Management State After G3 Determines the state the computer enters when power is restored after power loss, from among Last State, Power On, and Power Option Description...

  • Page 76: State After G3

    Leading EDGE COMPUTING Option Description When power is restored, returns the system to Last State the state in which power was interrupted State After G3 Sets the state entered when power is re-applied after a power fail- ure (G3 state). RTC Wake system from S5 Enable or disable system wake on alarm event, with FixedTime waking the system at the hr/min/sec specified, and DynamicTime...

  • Page 77: Usb Configuration

    MVP-6010/MVP-6020 B.2.7 USB Configuration Legacy USB Support With AUTO disabling legacy support if no USB devices are con- nected, and DISABLE keeping USB devices available only for EFI applications. XHCI Hand-off A workaround for OS without XHCI hand-off support, where XHCI ownership change should be claimed by the XHCI driver.

  • Page 78: Usb Transfer Time-Out

    Leading EDGE COMPUTING USB transfer time-out Timeout value for Control, Bulk, and Interrupt transfers. Device reset time-out USB mass storage device Start Unit command timeout. Device power-up delay Maximum time taken before the device reports itself to the Host Controller, with Auto using a default value of 100 ms for a Root port, and for Hub port the delay is taken from the Hub descriptor.

  • Page 79: Csm Configuration

    MVP-6010/MVP-6020 B.2.9 CSM Configuration CSM Support Enable or Disable CSM Support. GateA20 Active UPON REQUEST disables GA20 using BIOS services, and ALWAYS prevents GA20 from being disabled, useful when any RT code exceeding 1MB is executed. Option ROM Messages Sets display mode for Option ROM. Boot option filter Controls Legacy/UEFI ROM priority.

  • Page 80: Network

    Leading EDGE COMPUTING Network Controls execution of UEFI and Legacy PXE OpROM. Storage Controls execution of UEFI and Legacy Storage OpROM. Video Controls execution of UEFI and Legacy Video OpROM. Other PCI devices Determines OpROM execution policy for devices other than Net- work, Storage, and Video.

  • Page 81: Administrator Password

    MVP-6010/MVP-6020 power-on password and must be entered to boot or enter setup. In Setup the user receives Administrator Password Sets Administrator Password. User Password Sets User Password. RTC Lock Enable locks bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. BIOS Lock Enable/Disable the PCH BIOS Lock (BLE bit).

  • Page 82: Boot

    Leading EDGE COMPUTING B.4 Boot Setup Prompt Timeout Number of seconds before setup activation key is launched, with 65535(0xFFFF) setting indefinite waiting. Bootup Num-Lock State Sets keypad Number Lock status following boot. BIOS Setup...

  • Page 83: Quiet Boot

    MVP-6010/MVP-6020 Quiet Boot Option Description Disabled Directs BIOS to display POST messages Enabled Directs BIOS to display the OEM logo. Fast Boot Option Description Disabled Directs BIOS to perform all POST tests. Directs BIOS to skip certain POST tests to boot Enabled faster.
  • Page 84 Leading EDGE COMPUTING Hard Drive BBS Priorities Specifies the priority of boot devices. All installed boot devices are detected during POST and displayed. Target Boot Option # and click to select the desired device. BIOS Setup...

  • Page 85: Save & Exit

    MVP-6010/MVP-6020 B.5 Save & Exit Discard Changes and Exit Discards all changes and exits BIOS setup Save Changes and Reset Saves all changes and reboots the system, with new settings tak- ing effect Discard Changes Resets system setup without saving any changes Restore Defaults Sets all BIOS options to default settings, designed for maximum system stability but less than maximum performance.

  • Page 86: Save As User Defaults

    Leading EDGE COMPUTING Restore Defaults if the computer encounters system configuration problems. Save as User Defaults Saves all changes to this point as user defaults Restore User Defaults Restores user defaults to all setup options Launch EFI Shell from filesystem device Attempts to launch EFI Shell application (Shell.efi) from one of the available filesystem devices BIOS Setup...

  • Page 87: C Appendix: Watchdog Timer (Wdt)

    MVP-6010/MVP-6020 Appendix C Watchdog Timer (WDT) Function Library This appendix describes use of the watchdog timer (WDT) func- tion library for the MVP-6010/MVP-6020 controller. The watchdog timer is a hardware mechanism provided to reset the system if the operating system or an application stalls. After starting, the watch- dog timer in the application must be periodically reset before the timer expires.
  • Page 88 Leading EDGE COMPUTING unit. ResetWDT or StopWDT should be called before the expi- ration of watchdog timer, or the system will reset. Syntax C/C++ BOOL SetWDT(BYTE tick, BYTE unit) Parameters tick Specify the number of ticks for watchdog timer. A valid value is 1 - 255.
  • Page 89 MVP-6010/MVP-6020 Return codes TRUE if watchdog timer is successfully started. FALSE if watchdog timer is failed to start. ResetWDT Reset the watchdog timer. The invocation of ResetWDT allows restoration of the watchdog timer to the initial timeout value specified in SetWDT function. ResetWDT or StopWDT should be called before the expiration of the watchdog timer, or the system will reset.

  • Page 90: Wdt With Dos/Linux

    Leading EDGE COMPUTING C.2 WDT with DOS/Linux Under Linux, please program WDT function using the same LPC IO registers according to the sample program as follows. #include <dos.h> #include <stddef.h> #include <stdio.h> /* Config LPC IO NCT6102D to enter config mode */ EnterConfig(void) outp(0x4E, 0x87);...
  • Page 91 MVP-6010/MVP-6020 printf("Init config GPIO ports<<<<<<<<<<<<<<<<<<<<<<<<<\n"); printf("---------------------------------------------- ----\n"); EnterConfig(); /* config WDT registers */ w_reg(0x07,0x08); /* enable keyboard interrupt to reset WDT timeout value */ w_reg(0xF2,r_reg(0xF2)|0x40); /* set unit as second */ w_reg(0xF0,r_reg(0xF0)&~0x04); /* start the Watchdog */ w_reg(0x30,0x01); /* set timeout value as 30 seconds */ /* WDT start automatically while timeout value is set w_reg(0xF1,0x1E);...
  • Page 92 Leading EDGE COMPUTING w_reg(0x30,0x00); printf("WDT disable. Program terminating."); ExitConfig(); return 0; Watchdog Timer (WDT) Function Library...

  • Page 93: D Appendix: Digital Input/Output

    MVP-6010/MVP-6020 Appendix D Digital Input/Output Function Library DI/O provides input/output to support inter-device communica- tions. Simple programming guides allow easy transmission of digi- tal signals between the system and attached peripherals. DI/O with API/Windows Matrix DI/O API library files and a demo program (incl. source code) can be downloaded from http://www.adlinktech.com.
  • Page 94 Leading EDGE COMPUTING Parameter(s) Index Indexes the digital logic state of MVP-6010/MVP-6020 digital input channels 1 to 8 (bit 0 to 7) Value Sets the digital logic state of MVP-6010/MVP-6020 digital out- put channels 1 to 8 (bit 0 to 7) to 0 or 1. Return codes 0: Operation Success -1: Operation Failed...

  • Page 95: Important Safety Instructions

    MVP-6010/MVP-6020 Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. S'il vous plaît prêter attention stricte à tous les avertissements et mises en garde figurant sur l'appareil , pour éviter des blessures ou des dommages.
  • Page 96 Leading EDGE COMPUTING Never attempt to repair the device, which should only be  serviced by qualified technical personnel using suitable tools A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type;...
  • Page 97 MVP-6010/MVP-6020 BURN HAZARD Touching this surface could result in bodily injury. To reduce risk, allow the surface to cool before touching. RISQUE DE BRÛLURES Ne touchez pas cette surface, cela pourrait entraîner des blessures. Pour éviter tout danger, laissez la surface refroidir avant de la toucher.
  • Page 98 Leading EDGE COMPUTING This page intentionally left blank. Important Safety Instructions...
