- Page 1 INSTRUCTION MANUAL Cordless Impact Wrench TW011G Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: TW011G Fastening capacities Standard bolt M12 - M36 High tensile bolt M10 - M27 Square drive 19.0 mm No load speed (RPM) Max impact mode (4) 0 - 1,800 min Hard impact mode (3) 0 - 1,100 min... -
Page 3: Safety Warnings
Only for EU countries NOTE: The declared vibration total value(s) has been Ni-MH Due to the presence of hazardous com- Li-ion measured in accordance with a standard test method ponents in the equipment, waste electrical and may be used for comparing one tool with another. and electronic equipment, accumulators NOTE: The declared vibration total value(s) may also and batteries may have a negative impact... - Page 4 Do not expose power tools to rain or wet con- Zealand, it is legally required to wear a face ditions. Water entering a power tool will increase shield to protect your face, too. the risk of electric shock. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
- Page 5 result in personal injury. Make sure there are no electrical cables, water pipes, gas pipes etc. that could cause a hazard Battery tool use and care if damaged by use of the tool. Recharge only with the charger specified by Do not carry the tool by holding the impact the manufacturer.
-
Page 6: Functional Description
Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. Tips for maintaining maximum battery life Charge the battery cartridge before completely discharged. -
Page 7: Overload Protection
Release the switch trigger to stop. Let the tool and battery(ies) cool down. If no improvement can be found by restoring protection system, then contact your local Makita Service Center. Indicating the remaining battery capacity Press the check button on the battery cartridge to indi- cate the remaining battery capacity. -
Page 8: Forward/Reverse Switch
This tool is equipped with an electric brake. If the tool has been lost if not. consistently fails to quickly stop after the switch trigger is released, have the tool serviced at a Makita service NOTE: When the tool is overheated, the front lamps center. -
Page 9: Changing Operation Mode
Changing operation mode The tool features multiple application modes for efficient bolt/nut fastening and torque control. Select an appropriate mode according to your preferences and needs. Application modes can be switched for approximately 1 minute(s) after you release the switch trigger. You can extend the hold time for 1 more minute(s) by pressing the button NOTE: The LED display on the control panel goes off to save the battery power while the tool is switched off. - Page 10 Indication Mode Max. Max. rota- Target torque Features Application blows tion speed (N·m) (min (RPM) (min 2 (Medium) Auto-stop 1,400 50 - 150 Secures the initial fixing to Primary fastening. prevent loss of clamping (Secondary retention) force or displacement of fastening components. Stops automatically Allows to fasten bolts/nuts approximately 0.5 second with the required torque in...
- Page 11 Fig.8 Indication Mode Max. Max. rota- Target torque Features Application blows tion speed (N·m) (min (RPM) (min Impact 2,600 1,800 1,900 Maximum speed, blows Unfastening operation that (Free- and torque can be requires a dynamic pow- range) obtained. er-speed range control. 1/2/3 Auto-stop 2,600...
-
Page 12: Installing Hook
Installing hook ASSEMBLY WARNING: Use the hanging/mounting parts CAUTION: Always be sure that the tool is for their intended purposes only, e.g., hanging the switched off and the battery cartridge is removed tool on a tool belt between jobs or work intervals. before carrying out any work on the tool. -
Page 13: Operation
The ring is convenient for hanging the tool with hoist. Proper fastening torque for high tensile bolt with First, place the rope through the ring. Then hang the max impact mode (4) tool up to the air with hoist. N•m (kgf•cm) 1200 (12236) -
Page 14: Maintenance
Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. - Page 16 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885B14-226 20250123...
