Thyro-PX

Guide

ANYBUS PROFINET MODULE

The Anybus PROFINET module is an optional accessory for the Thyro-PX power controller. The

module allows the power controller to be integrated into complex installations via the field network.

Need help?

Do you have a question about the Thyro-PX Anybus PROFINET and is the answer not in the manual?

Questions and answers

Summary of Contents for Advanced Energy Thyro-PX Anybus PROFINET

Page 1: Table Of Contents
• “Installing Optional Modules” on page 8 • “PROFINET Parameter List” on page 9 • “AE Global Services” on page 29 This document and the information contained herein are the proprietary property of Advanced Energy Industries, Inc. Copyright© 2016 Advanced Energy Industries, Inc. All Rights Reserved.
Page 2: Hardware Description
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET HARDWARE DESCRIPTION This module is compliant with the PROFINET standard. Network status Link/activity port 1 Link/activity port 2 Module status RJ-45 connectors Figure 1. Hardware Table 1. Network status LED ...
Page 3: Configuring Process Control Software
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 3. Link/activity LED (Continued) LED State Description Green Ethernet link established Green, flickering Ethernet link established, communication present Table 4. RJ-45 Ethernet pinout Description 1,2,4,5 Connected to chassis ground over serial RC circuit...
Page 4 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET • Configure the flexible link parameters Adapting Thyro-PX Hardware Configuration Open parameter file with the unit online in the Port Explorer tab of the Thyro-Tool Pro PC software, or use the Thyro‑Touch display.
Page 5: Selecting Configuration
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Figure 4. PROFINET module MAC address Selecting Configuration Figure 5. Select configuration Each configuration name, status, and selection is described in the following table: Table 5. Configuration Name Status/Selection Description Control of validity...
Page 6: Configuring Diagnostics
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 5. Configuration (Continued) Name Status/Selection Description Motorpotentiometer = Motorpotentiometer = When enabled, the value of the motorpotentiometer Master Master continuously follows the master setpoint while in remote operation, so that no setpoint leap occurs during the switch-over to the local setpoint.
Page 7 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET The default read links are shown in the Thyro-Tool Pro PC software. These are not needed for PROFINET, because the preconfigured values are already available in the parameter list. Once the respective data point has been selected in the flexible link parameter configuration, it can be...
Page 8: Installing Optional Modules
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET INSTALLING OPTIONAL MODULES DANGER: RISK OF DEATH OR BODILY INJURY. Disconnect and lockout/tagout all sources of input power before working on this unit or anything connected to it. ...
Page 9: Profinet Parameter List
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET PROFINET PARAMETER LIST Table 7. Parameter list Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read Flexible link 01 r UINT32 Flexible link number 01 - read...
Page 10 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read Flexible link 17 r UINT32 Flexible link number 17 - read FLOAT Cyclic...
Page 11 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Write 36 Flexible link 16 w UINT32 Flexible link number 16 - write FLOAT...
Page 12 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read Device error r UINT32 Error - read Bit 0: Aux. supply error Bit 1: Parameter error...
Page 13 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read Device error UINT32 Error extension - read extension r Bit 1: Extension card X53 error...
Page 14 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read #1 Status PC r UINT32 Power controller #1: Status PC - read Bit 0: Output (pulses) on...
Page 15 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read #1 Monitoring PC r UINT32 Power controller #1: Monitoring PC - read Bit 4: U <...
Page 16 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index Cyclic Read #1 L1 Resistance r FLOAT Power controller #1: L1 Resistance - read Cyclic...
Page 17 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 100 Cyclic Read #2 Motor pot. FLOAT Power controller #2: Motor potentiometer setpoint r setpoint - read...
Page 18 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 111 Cyclic Read #2 Status PC r UINT32 Power controller #2: Status PC - read...
Page 19 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 112 Cyclic Read #2 Monitoring PC r UINT32 Power controller #2: Monitoring PC - read Bit 4: U <...
Page 20 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 122 Cyclic Read #2 L1 Resistance r FLOAT Power controller #2: L1 Resistance - read...
Page 21 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 138 Cyclic Read #3 Status PC r UINT32 Power controller #3: Status PC - read...
Page 22 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 139 Cyclic Read #3 Monitoring PC r UINT32 Power controller #3: Monitoring PC - read Bit 4: U <...
Page 23 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 149 Cyclic Read #3 L1 Resistance r FLOAT Power controller #3: L1 Resistance - read...
Page 24 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 155 Cyclic Write 155 I/O Int Relay 1-3 w UINT16 Internal I/O: Relay 1-3 - write...
Page 25 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 173 Cyclic Write 173 I/O Ext1 Relay w UINT16 I/O Extension 1: Relay - write...
Page 26 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 193 Cyclic Write 193 I/O Ext2 Relay w UINT16 I/O Extension 2: Relay - write...
Page 27 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 211 Cyclic Read dASM Count r UINT8 dASM Count - read 213 Cyclic Write 213...
Page 28 ® ™ ® Advanced Energy Thyro-PX Anybus PROFINET Table 7. Parameter list (Continued) Com- Read Slot Parameter Name Type Parameter Description muni- cation Write Index 224 Cyclic Write 224 #2 Control mode w UINT8 Power controller #2: Control mode - write...
Page 29: Ae Global Services
® ™ ® Advanced Energy Thyro-PX Anybus PROFINET AE GLOBAL SERVICES Please contact AE Global Services if you have questions or problems that cannot be resolved by working through the provided troubleshooting. When you call Global Services, make sure to have the unit serial number and part number.
