7-Person Arc Table
Instruction Sheet
100-00116
Rev A
22
PAP

Advertisement

loading
Need help?

Need help?

Do you have a question about the MIDDLE ATLANTIC Forum and is the answer not in the manual?

Questions and answers

Related Manuals for LEGRAND MIDDLE ATLANTIC Forum

Summary of Contents for LEGRAND MIDDLE ATLANTIC Forum

  • Page 1 7-Person Arc Table Instruction Sheet 100-00116 Rev A...
  • Page 2 All other brand names or marks are used for identification purposes and are trademarks of their respective owners. Legrand AV Inc. Brands: Chief | Da-Lite | Middle Atlantic | Projecta | Sanus | Vaddio Page 2...

  • Page 3: Setting Up Middle Woodtop Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS - EN • Read these instructions. • Heed all warnings. • Clean only with dry cloth. • Keep these instructions. • Follow all instructions. • Only use attachments/accessories specified by the manufacturer. DANGER HAZARDOUS VOLTAGE: The lightning flash with the arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 4 INSTRUCTIONS DE SÉCURITÉ IMPORTANTES - FR • Lire ces instructions. • Respectez tous les avertissements. • Nettoyer uniquement avec un chiffon sec. • Conservez ces instructions. • Suivez toutes les instructions. • N'utilisez que des accessoires spécifiés par le fabricant. DANGER TENSION DANGEREUSE: Le symbole de la pointe de flèche, dans un triangle équilatéral, est destiné...

  • Page 5: Table Of Contents

    SETTING UP MIDDLE WOODTOP Important Safety Instructions......................3 - 4 Supplied Components and Hardware ..................... 6 - 7 Required Tools............................7 Introduction............................8 Setting Up Middle Woodtop ........................9 Attaching Leg Assemblies and Gusset Bracket................10 - 11 Attaching Left and Right Leg Assemblies and Brackets .............. 12 - 13 Attaching Left and Right Table Assemblies ..................

  • Page 6: Supplied Components And Hardware

    SUPPLIED COMPONENTS AND HARDWARE If any pieces are missing or damaged, please report it immediately to Technical Support at av.support@legrand.com or (866) 977-3901. Middle TOP ASSEMBLY HARDWARE KIT Woodtop (14x) (60x) #8 x 5/16” 10 x 5/8” Sheet Metal Wood Screw...

  • Page 7: Required Tools

    (Model Number: MDSA10-WH) (Model Number: MDCA3-WH) (Model Number: MDEA3-WH) NOTE: • To order more hardware, contact support at av.support@legrand.com or (866) 977-3901. • Additional hardware is included that may not be required for your installation. REQUIRED TOOLS • Protective Eyewear WARNING: Use tools with caution and follow all necessary •...

  • Page 8: Introduction

    INTRODUCTION NOTE: • Please take the time to carefully unpack and inspect all of the products you ordered and save this instruction sheet for future use. • Maintenance and care information is provided in Care and Cleaning of Products (I-00788) and Unpacking and Handling Precautions (I-00787) for your convenience.

  • Page 9: Setting Up Middle Woodtop

    SETTING UP MIDDLE WOODTOP NOTE: Adjust torque on electric drill to lightest setting and only increase as necessary. 1. Carefully place woodtop (A) upside down on an appropriate worksurface. 2. Use an electric drill, Phillips bit, and (15x) woodscrews (E) to secure support bracket (J) to woodtop (A).

  • Page 10: Attaching Leg Assemblies And Gusset Bracket

    ATTACHING LEG ASSEMBLIES AND GUSSET BRACKET NOTE: Adjust torque on electric drill to lightest setting and only increase as necessary. 1. Use an electric drill, Phillips bit, and (3x) 10-32 trusshead screws (N) to secure each leg assembly (K). FIGURE D 2.
  • Page 11 ATTACHING LEG ASSEMBLIES AND GUSSET BRACKET (CONTINUED) WARNING: This procedure requires at least one additional person. PRECAUCION: Este procedimiento require mas de una persona. AVERTISSEMENT: Cette procédure nécessite au moins une personne supplémentaire. 6. Carefully, team lift and move middle table assembly to desired location prior to flipping table right-side up. 7.

  • Page 12: Attaching Left And Right Leg Assemblies And Brackets

    ATTACHING LEFT AND RIGHT LEG ASSEMBLIES AND BRACKETS NOTE: Adjust torque on electric drill to lightest setting and only increase as necessary. 1. Carefully place woodtop (B and C) upside down on an appropriate worksurface. 2. Use an electril drill, Phillips bit, and (11x) woodscrews (E) to secure support bracket (H) to each woodtop (B and C).

  • Page 13: Attaching Left And Right Table Assemblies

    ATTACHING LEFT AND RIGHT LEG ASSEMBLIES AND BRACKETS (CONTINUED) 6. Use an electric drill, Phillips bit, and (4x) woodscrews (M) to secure gusset (U) to woodtop. (FIGURE K) 7. Use a ratchet and (4x) threadforming screws (N) to secure gusset to inside of leg. FIGURE K ATTACHING LEFT AND RIGHT TABLE ASSEMBLIES WARNING:...
  • Page 14 ATTACHING LEFT AND RIGHT TABLE ASSEMBLIES (CONTINUED) Hand tighten (3x) 10-32 trusshead screws (N) to loosely secure the middle leg assembly to left table assembly. (FIGURE M) FIGURE M NOTE: Adjust torque on electric drill to lightest setting and only increase as necessary. 4.

  • Page 15: Cable Management

    CABLE MANAGEMENT NOTE: • This topic and the image shown is meant to provide an example of routing many cables toward the leg and towards your power distribution unit (if purchased), up through pre-installed grommets to devices on your table. •...

  • Page 16: Attaching Modesty Panels

    ATTACHING MODESTY PANELS 1. Bend middle modesty panel (R) with bevel facing outwards into slot. (FIGURE S) NOTE: Align edges of modesty panel with ends of woodtop. Align Bend into slot Side with Bevel FIGURE S 2. Attach remaining modesty panels to the left and right table assemblies. (FIGURE T) NOTE: •...

  • Page 17: Securing Modesty Panels (Optional)

    SECURING MODESTY PANELS (OPTIONAL) NOTE: Obround slot on the back of the cable management bracket provides space to adjust panel, if needed. 1. Use a #2 Phillips screwdriver and (5x) #8 x 5/16” sheet metal screws (D) to secure (5x) cable management brackets (V) to middle modesty panel (R).

  • Page 18: Installing Wiremold Modpower Options To Table

    INSTALLING WIREMOLD MODPOWER OPTIONS TO TABLE (IF PURCHASED) NOTE: • If purchased, a primary ModPower unit is required to run any additional middle and end units. • A single primary unit may run power to an additional 7 units (for a maximum of 8 total). 1.

  • Page 19: Installing The Power Strip (If Purchased)

    INSTALLING THE POWER STRIP (IF PURCHASED) NOTE: • If purchased, follow the instructions below to mount your power strip. Region specific power strip is not provided. • Consider power requirements and cable management for your specific installation when deciding which section of the table to install your power strip on. 1.

  • Page 20: Warranty

    Unit C, Island Rd. Eden Prairie, MN, 55344, USA DK, Weert, Netherlands Reading RG2, 0RP- UK At Legrand AV Inc. we are always listening. Your comments are welcome. Legrand AV is an ISO 9001 and ISO 14001 Registered Company. Page 20...
