No: IS-0000 – rev. A
•
The QzHub can handle up to 32 nodes (base) to 105 nodes (for full network size, if using Range Extenders). Nodes include
shades, remotes and extenders.
•
ZigBee 3.0 ready and scalable for future updates
•
USB expandability with two on-board USB expansion ports
•
Onboard battery backup utilizing four AA batteries allows for operations, control and communication during power interruptions
•
Receives updates for firmware, API additions, new devices drivers, technology driver, and feature updates
Description
Dimensions, HWL
Weight
Ambient Operating Temperature
Storage Temperature
Ambient Operating Humidity
Storage Humidity
Indicators
Processor, ARM Cortex A8
System Memory
Application Storage
LAN/WAN Interface
Ethernet
FCC Compliance
ZigBee
USB
Wireless Description
ZigBee
Software Description
iOS
Android
The QzHub hardware device allows you to easily control your QMotion Zigbee-
enabled, motorized shades from your phone in conjunction with the Qz App. The
Qz App's intuitive interface and simple navigation allows you to easily edit, add,
commission, and control local shades.
FEATURES AND OPERATION OVERVIEW
SPECIFICATIONS
1.55"H x 4.5" W x 5.87"L
0.85lbs (w/ batteries), 0.65lbs (w/o batteries)
0-40°C
-20 to 60°C
0-95% non-condensing
0-99% non-condensing
Visual: 3x LEDs, Audible: Piezoelectric sounder (up to 80dB@10cm)
TI Sitara AM3352 (1GHz)
512MB 800MHz
eMMC NAND Flash: 2 GB
Description
10/100 w/ Auto MDIX, IEEE 802.3-compliant, auto-negotiation and automatic polarity
detection
Complies with FCC Part 15 Class C
Silicon Labs EM3587 2.4 GHz (+18dBm)
Texas Instruments AM 335BZCZ100 (2x Type-A host ports)
Range: 100+ ft. (30+ m) L.O.S., TX Strength: +18 dBm
iOS 9+
Kitkat 4.4+
QMotion
®
QzHub/Qz App
User's Guide
OVERVIEW
Specification
Specification
Specification
1
Advertisement
Table of Contents
Related Manuals for LEGRAND QMotion
Summary of Contents for LEGRAND QMotion
-
Page 1: Specifications
No: IS-0000 – rev. A OVERVIEW The QzHub hardware device allows you to easily control your QMotion Zigbee- enabled, motorized shades from your phone in conjunction with the Qz App. The Qz App’s intuitive interface and simple navigation allows you to easily edit, add, commission, and control local shades. -
Page 2: Installation Overview
INSTALLATION OVERVIEW The QzHub can be placed on a desk, on the floor tucked behind 4.5” furniture, or even mounted to a wall. Built-in rubber feet provide a no-slip surface for stability, and mounting sloths can be used for wall or floor mounting. 4.5”... -
Page 3: Software Navigation
FIRMWARE When requested by Legrand, application of new firmware may be needed for the QzHub. Follow these instructions to update the firmware. Download the firmware and copy it to a USB flash drive formatted to FAT32 (recommended 4 GB size). -
Page 4: Installer Instructions
INSTALLER INSTRUCTIONS ADDING A NEW HUB Tap on the hub you wish to add To add a new hub to the network, If the hub is powered on and and you will be prompted to navigate to the Add Devices. connected to the same network as activate it by following the on- You will see available authorized... - Page 5 ADDING A RANGE EXTENDER OR REMOTE To add a range extender or remote to the network, follow these simple steps. Navigate to the Add Devices Tap the Join button to put the hub Once connected, a notification will page. Tap the hub you wish to add into join mode.
- Page 6 ADDING SHADES Once a hub has been activated, you can start adding shades to the network. Navigate to the Add Devices Use the arrows to cycle between Tap the Join button on the bottom page and select the hub you want groups, and the “+”...
-
Page 7: Setting Limits
SETTING LIMITS Setting Limits can be accessed either when first adding a shade, or in the Edit Devices page under each individual shade. NOTE: Due to the nature of wireless communication, you may need to refresh the page or it will appear slow to respond as it reconciles communication between the hub, app, and shade motor. -
Page 8: Edit Groups
EDIT GROUPS The Edit Groups page takes you to an overview of your device groups. These will typically be a room or location in your home. Tap on the Edit Group which To add a new group, tap Tap on a group to begin editing. takes you to the Edit Groups the “+”... -
Page 9: Edit Devices
EDIT DEVICES To configure your devices, open The details page displays device Set Upper/Lower Limit: Refer the navigation menu and select information. The Information section to Setting Limits Section for Edit Devices. Use the tabs to displays details about the device such as details. - Page 10 EDIT DEVICES - RANGE EXTENDERS AND REMOTES Tap on the Edit Misc to go to the Swipe or long press to access the To rename, tap Rename, edit list view of available extenders rename or delete options. Deleting name and save changes by and remotes.
- Page 11 USER INSTRUCTIONS GROUP CONTROL PAGE By default, the app launches to Group Control. This page contains a list of your device groups that can be raised and lowered using the arrow buttons. Tap a group to access individual group control. A list of various shade groups To access individual shade is displayed.
- Page 12 TUG COMMANDS Tug Command Mode will allow certain features to be performed manually without a learned remote. Read the following instructions completely before starting the procedure. Inputs from the user are time sensitive. If the shade times out before entering a tug command, reutrn the shade to the Upper Limit Position and begin the procedure over.
-
Page 13: Troubleshooting
TROUBLESHOOTING • Make sure QzHub and app are on the same network. • If you need to clear a shade manually, or the shade is not discoverable and you need to reset it, follow the manual tug commands on previous page. •... - Page 14 INFORMACIÓN DE LA GARANTÍA QMotion Incorporated, (the “Manufacturer”) warrants that this QMotion® window shade product will be free from defects in materials and workmanship for 5 years, beginning from the date first sold to the commercial or residential consumer who has, or intends to, use the product, as evidenced by such consumer’s proof of purchase:...
