- Page 1 P A G E WINTEX 1000 The future is in the soil - and in professional soil samples Instruction Manual Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110...
-
Page 2: Table Of Contents
Adjusting the oil pressure Tightening and adjusting the chain Adjusting the soil box Adjusting the ejector Changing oil and oil filter Maintenance schedule Replacement of sensors Problem solving Problem solving Diagnostic sheet Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110... -
Page 3: Safety
The soil sampler has moving, sliding and rotating parts. Keep your limbs away from the soil sampler unless it is turned off and stay away from the foot / the base of the soil sampler. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com... - Page 4 Never disconnect the ground at the following parts: connection to the control system! Moving parts, danger of harming hands Danger of cutting, probe has sharp edges. Moving parts, danger of harming hands Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110...
-
Page 5: Mounting Guidelines
There are four brackets enclosed in the Wintex package which you need for mounting the soil sampler onto the frame. Please note that it might be necessary to drill new holes for the brackets for mounting the WINTEX 1000 on different quads. - Page 6 Oil pump and Honda GX160 engine Mounting the start switch on the right handlebar To get the necessary space for the start switch for the WINTEX 1000, it might be necessary to rearrange/adjust other accessories to make space for the start switch on the handlebar.
- Page 7 White: foot switch signal Black: stop light + Connectors to up and down solenoids Blue: start switch signal Black: not in use Start switch Red: to start switch + Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110...
-
Page 8: Using The Wintex
12: Menu / ENTER Reset 13: Not in use Not in use 14: Enable manual functions Probe up / down 15: Rotation + STOP Not in use 16: START + HOME Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110... -
Page 9: Connection And Startup
3 white wire Pin no. 5: Extra start button cable no. 5 blue wire There is a jump wire between pin no. 1 and pin no. 2. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110... - Page 10 P A G E | 10 At the first startup of the Wintex 1000 after mounting the control system, take place on the driver’s seat. Press “MANUAL” key and flip the “PROBE” switch downwards until the probe reaches the ground.
-
Page 11: Start Screen
Go to the “Setup Menu”. Scroll down until the “Depth” appears on the display. Adjust the depth by using the arrow up and down keys. Once the correct depth is set, press “MENU”. The setting is now saved and will appear on the start screen. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com... -
Page 12: Settings: Sticks Per Sample
This setting will differ according to the soil sampler, the hydraulics and the soil conditions. Go to the “Setup Menu”. Scroll down to “Rotation stop height” and adjust the figure with the arrow keys. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com... -
Page 13: Rotation Mode
LED will blink slowly, and the probe will not rotate at all. 3.i. MANUAL USE OF THE WINTEX 1000 By pressing the “MANUAL” key with the green letters, you can access all functions in green letters at the flip switches (“probe up”, “probe down”... -
Page 14: Test Menu
In some cases, it seems like you only can see for example one of four (1/4) “pages” on the screen. To view the other “pages”, press the “MENU / ENTER” key. Current power supply and depth Monitor keys Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110... - Page 15 The next lines show the inputs and outputs. In the event of an issue, your local dealer might need this information to trouble shoot. Digital inputs Analog inputs Outputs Current outputs Software version Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110...
-
Page 16: Maintenance
4.. MAINTENANCE ______________________________________________________________________________________________________________ 4.a. START THE WINTEX 1000 Start the ATV and deactivate the emergency stop. The red button must be up. Activate the foot switch and the brake handle on the steering wheel, and shortly push the button at your right hand. Foot switch and brake lever must be activated during the entire process. -
Page 17: Replacing The Probe
The pressure for lowering the probe must not exceed 50 bar or the soil sampler will be damaged! Contact for activating valves 3-pole plug manually Downward pressure 50 bar Upward pressure 80 bar Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110... -
Page 18: Tightening And Adjusting The Chain
4.e. TIGHTENING AND ADJUSTING THE CHAIN Make sure that the probe is up. Loosen the four 8 mm bolts at the front of the WINTEX 1000 with a 6 mm Allen key. Push the two upper 8 mm bolts down until the upper half of the chain is taut. Then tighten the bolts. Now push the lower 8 mm bolts up until the lower half of the chain is taut. -
Page 19: Adjusting The Ejector
4.g. ADJUSTING THE EJECTOR When adjusting the ejector make sure to stop the probe approximately 10 cm from the start position. Turn off the WINTEX 1000 and activate the emergency stop. Loosen the six Allen screws (three at the top and three below). Then loosen the nut for the probe. Adjust the ejector so that it is placed in the middle of the hole of the probe. -
Page 20: Maintenance Schedule
- Check and tighten vital parts. - Check and if necessary change the ejector tip. - Check and if necessary change the probe. - Check the oil level of the hydraulics. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110... -
Page 21: Replacement Of Sensors
- If the nut is within part A which is 16 mm long, it must be tightened with 6 Nm. - If the nut is within part B, it must be tightened with 15 Nm. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com... -
Page 22: Problem Solving
| 22 5. a. PROBLEM SOLVING PROBLEM CAUSE POSSIBLE SOLUTIONS The WINTEX 1000 does not start. 1) The fuse is blown. 1) Put in a new fuse. 2) The emergency stop is activated. 2) Deactivate the emergency stop. 3) A switch is defect. - Page 23 For testing the brake contact, the start switch, and the foot switch just activate the ignition on the vehicle, but do not start the motor. If all switches work, the rotation will start. It the rotation does not start, there is an error in one of the switches. Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com...
-
Page 24: Diagnostic Sheet
2,7 V, 10 V cable is shorted. Height sensor 2 (upper) 2,7 V, 10 V Analog in Foot / brake pedal 0- 10 V Analog in Extra start 0- 10 V Wintex Agro, Vilhelmsborgvej 8C, DK-7700 Thisted +45 97990800, contact@wintexagro.com, www.wintexagro.com 202110...
