- Page 1 MONITOR NINJA WITH INTEGRATED GPS NAVIGATOR 46709XX INSTALLATION...
-
Page 2: Table Of Contents
LEGENDA SIMBOLI • LEGEND OF SYMBOLS = Generic danger = Warning = remote control unit IBX100 CONTENTS Risks and protections before assembly ..............................3 Intended use ........................................3 Precautions ........................................3 Package content ......................................4 Position on farming machine ..................................4 Monitor positioning .................................... -
Page 3: Risks And Protections Before Assembly
INTRODUCTION • MANUAL USE MODES This manual contains information for installers. For this reason we have used technical terms without providing any explanations. THE INSTALLATION MUST BE CARRIED OUT BY AUTHORIZED AND SKILLED PERSONNEL ONLY. ARAG IS NOT RESPONSIBLE FOR ANY INSTALLATION CARRIED OUT BY UNAUTHORIZED OR UNSKILLED PERSONNEL. •... -
Page 4: Installation
INSTALLATION PACKAGE CONTENT The table below indicates the components that you will find in the NINJA monitor package: NINJA Legenda: 1 NINJA Visor kit 3 Fixing kit Fig. 1 POSITION ON FARMING MACHINE Monitor positioning • The monitor NINJA can be positioned outside the agricultural machinery. Observe the following precautions: - Do NOT install the monitor in areas where it would be subjected to excessive vibrations or shocks, to prevent any damage. -
Page 5: Visor Attachment
INSTALLATION Visor attachment The visor kit comes standard in the package. It must be fixed by fitting the supplied nuts in the seats indicated in the figure and tightening the supplied screws. Fig. 4 NINJA fixing outside of the machine - NINJA can be fitted outside the machine by observing the hole sizes indicated in Fig. -
Page 6: Wiring Connections
INSTALLATION WIRING CONNECTIONS • Use only the cables provided with the ARAG monitors. • Take care not to break, pull, tear or cut the cables. • Use of unsuitable cables not provided by ARAG automatically voids the warranty. • ARAG is not liable for damages to the equipment, persons or animals caused by failure to observe the above instructions. NAVIGATOR SYSTEM MODE: auxiliary function and power supply connection WARNING: To avoid short circuits, do not connect the power cables to battery before the installation is completed. -
Page 7: Power Supply Connection
6.1.2 POWER SUPPLY CONNECTION NINJA is supplied directly by the farming machine battery (12 VDC): ALWAYS switch on the system through the monitor, and then remember to switch it off using the specific key on the control panel. If NINJA remains on for a long time with machine off, the tractor battery could run flat: in case of prolonged breaks of the machine with engine off, make sure the monitor is off, too. -
Page 8: Accessories
INSTALLATION ACCESSORIES SD memory card The SD memory card may be used to exchange data with monitor NINJA. Before use, format the SD board in FAT 32 mode; make sure that the board is not protected and can be read by the system (Fig. -
Page 9: Maintenance / Diagnostics / Repairs
MAINTENANCE / DIAGNOSTICS / REPAIRS MAINTENANCE / DIAGNOSTICS / REPAIRS Troubleshooting FAULT CAUSE REMEDY No power supply • Check power supply connection The display does not switch on Monitor is OFF • Press the ON key Cleaning rules - Clean only with a soft wet cloth. - DO NOT use aggressive detergents or products. - Page 10 Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to the internet address www.aragnet.com 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com info@aragnet.com...
