- Page 1 FILLING CHECK VERSION WITH LEVEL SENSOR + RPM DISPLAY Software rel. 2.3.x...
-
Page 2: Table Of Contents
CONTENTS ● Legend of symbols ..................... 3 INTRODUCTION ......................4 Product description ....................4 INTENDED USE ......................4 CONTENT OF THE PACKAGE ..................4 PRECAUTIONS ......................4 RISKS AND PROTECTIONS BEFORE ASSEMBLY ............ 5 Positioning ........................5 Power supply and sensor connection ................ 5 ASSEMBLY DIAGRAMS ....................6 CONTROLS IN THE MENU ................... 7 First switching on ....................... -
Page 3: Legend Of Symbols
● Legend of symbols = Generic danger = Warning This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for any future reference; ARAG reserves the right to modify product specifications and instructions at any moment and without notice. -
Page 4: Introduction
INTRODUCTION Product description VISIO is a very compact and accurate top-notch multifunction display, able to display any kind of information concerning agricultural treatments. Operator can select the required function via software. It can display several types of values, which change according to set operating mode and type of connected sensors. INTENDED USE This device is designed to work on agricultural machinery for spraying and crop spraying applications. The machine is designed and built in compliance with EN ISO 14982 standard (Electromagnetic compatibility - Forestry and farming machines), harmonized with 2014/30/UE Directive. CONTENT OF THE PACKAGE The table below indicates the components that you will find in the VISIO package: Legend: VISIO Fixing kit P o w e r c a b l e , s e n s o r s a n d Instruction manual connection cables... -
Page 5: Risks And Protections Before Assembly
RISKS AND PROTECTIONS BEFORE ASSEMBLY All installation works must be done with battery disconnected, using suitable tools and any individual protection equipment deemed necessary. Positioning 1) Set mounting rail in cabin and fasten it with the relevant screws (1), in a position where VISIO can be easily seen and at hands' reach, but away from any moving organs. -
Page 6: Assembly Diagrams
ASSEMBLY DIAGRAMS +12Vdc Counting abort Connection +12VDC (yellow wire) Counting abort Ground connection (green wire) Legend: 1) Power cable 2) Connection cable for double sensors 3) Level sensor 4) Rpm sensor... -
Page 7: Controls In The Menu
CONTROLS IN THE MENU First switching on At first switching on, VISIO will run a guided procedure allowing user to set the device's basic settings. Press to scroll through items, to save and move on to next setting, or to go back to previous setting. WARNING: Before changing operating mode, make sure that all sensors / flowmeters are DISCONNECTED from the device. -
Page 8: Controls In The Menu
Controls in the menu In the following pages, according to the set operating mode, some menu items could slightly differ from the shown ones. SWITCHING ON A Press for 1 second B Press the key a few times to view the various values in extended mode (on display central part) Every time the device is switched on, it will shortly show a page with the name of device and software version SWITCHING OFF A Press for 2 seconds ACCESS TO SETUP MENU From the main page, press keys at the same time for 2 seconds to open the Setup Menu SELECTION AND ACCESS TO MENU ITEMS A Press a few times to scroll through items (selected item is indicated by a black line) B Press to open the selected menu item The three dots under an item indicate presence of another setup menu... -
Page 9: Editing A Value
EDITING A VALUE A Press to move through digits B Press a few times to edit the highlighted digit C Press to confirm. The display goes back to previous page D Press to exit page without confirming modification Edited value must fall within the range shown Work parameters From the main page, press key for two 100% seconds to open Work Parameters menu, and set values for Level correction. 0.0 rpm... -
Page 10: Menu Structure
MENU STRUCTURE Alarms Tank reserve Max level Sens. 1 min rpm Sens. 1 max rpm 100% Sensors 0 rpm Calib. flowmeter Man. calibration Rpm 1 Man. calibration Tank Capacity Tank zero value Calibration Man. calibration Auto calibration Load/Save Tank Save tank profile Load tank profile Options Language... -
Page 11: Preliminary Setup For Use
PRELIMINARY SETUP FOR USE Alarms Set the desired alarm display thresholds. Tank reserve alarm Set the value of the minimum fluid quantity left in the tank. 1) Open tank reserve alarm menu (Setup menu > Alarms > Tank reserve). The display will show the current setting below the selected item Press to edit the selected menu item 2) To deactivate the alarm, press and at the same time until the set value disappears and the message OFF is displayed instead. Carry out the same procedure to enable alarm again. 3) Set alarm value: A) Press to move through digits B) Press a few times to edit the highlighted digit C) Press to save changes, or D) Press to quit the page without confirming changes... - Page 12 Max tank level Set the maximum tank capacity percentage value for the desired alarm activation threshold. 1) Open tank max level menu (Setup menu > Alarms > Max level). The display will show the current setting below the selected item. Press to edit the selected menu item. and 2) To activate the alarm, press at the same time until the message OFF goes off and the alarm value is displayed instead. Carry out the same procedure to disable alarm again. 3) Set alarm value: A) Press to move through digits B) Press a few times to edit the highlighted digit C) Press to save changes, or D) Press to quit the page without confirming changes...
-
Page 13: Rpm Alarms
RPM Alarms Set the desired alarm display thresholds for minimum and maximum Rpm values. 1) Open Alarm menu (Setup menu > Alarms). Minimum and maximum Rpm alarms are set in the same way. The display will show the current setting below the selected item. Press to edit the selected menu item. This menu allows setting two different sensors (if available). In case only one sensor is used, use items related to sensor 1 to perform the correct settings. 2) To activate the alarm, press and Sens. 1 min rpm at the same time until message OFF goes off and the Rpm alarm value is Min Value displayed instead. Max Value 9999 Carry out the same procedure to disable alarm again. 3) Set alarm value: A) Press to move through digits B) Press a few times to edit the highlighted Sens. 1 min rpm digit Min Value C) Press to save changes, or Max Value 9999... -
Page 14: Sensors
Sensors 1) Open Sensors menu (Setup menu > Sensors) The menu items displayed below change according to the set operation mode: when more items are available, select the desired one and press to edit it. -
Page 15: Flowmeter Calibration (To Be Used For Automatic Tank Calibration Only)
Flowmeter calibration (TO BE USED FOR AUTOMATIC TANK CALIBRATION ONLY) Due to the different system configurations (tubes, valves, etc.) rate reading could not be correct. It is therefore recommended to perform a spraying test. If measured value is different from actual value, change the rate constant through an automatic calibration procedure or manually calculate the constant. Manual calibration In order to manually set rate constant, calculate and set suitable constant using the following formula: [quantity measured by equipment] x [constant indicated on flowmeter body] [actually sprayed quantity] 1) Open manual calibration menu (Setup menu (Setup menu > Sensors > Calib. flowmeter > Man. calibration). Under Calibration, menu, select Man. Calibration, to view currently set constant value below the item. Press to edit the value. For flowmeter constant value, refer to the corresponding manual. 2) Set flowmeter constant value: A) Press to move through digits B) Press a few times to edit the highlighted digit C) Press to save changes, or D) Press to quit the page without confirming changes... -
Page 16: Sensors > Manual Calibration
Sensors > Manual calibration VISIO processes the rotation speed information related to a specific part through the pulses from the Rpm sensor. The manual calibration allows entering the Rpm constant value. 1) Open Sensors menu (Setup menu > Sensors). 2) Press to open manual calibration mode. This menu allows setting two different sensors (if available). In case only one sensor is used, use items related to Rpm 1 to perform the settings. 3) Set the Rpm constant value, i.e. the number of detection points, such as magnets or bolts fitted on the rotating shaft whose rotation speed shall be detected: A) Press to move through digits B) Press a few times to edit the highlighted digit C) Press to save changes, or D) Press to quit the page without confirming changes... -
Page 17: Tank
Tank From this menu it is possible to view and set a number of tank values. - Capacity: the display shows the maximum tank capacity value, as previously calculated through calibration. This value is read-only. Tank zero value Set level sensor zero value. The level sensor must be reset in the following cases: 1) If there are discrepancies between the quantity of fluid in the tank and the value measured by the level sensor (e.g., fluid presence detected but empty tank). 2) EVERY TIME a calibration curve is uploaded via USB. The tank zero value must ALWAYS be saved WITH AN EMPTY TANK. 1) Open tank zero value menu (Setup menu > Tank > Tank zero value). The display will show the current setting below the selected item Press to edit the selected menu item 2) Press : VISIO will save the level sensor zero value, which will be shown in the bottom part of the display (e.g., 3.964 mA in the image on the side). If a sensor malfunction occurs, the message Check sensor! will be shown in the top part of the display. -
Page 18: Tank Calibration
Tank calibration The tank profile calibration can be carried out in manual or automatic mode. During calibration, VISIO will save up to 200 calibration points to create the tank profile curve. If necessary, the tank profile can be saved and reimported into VISIO or compatible ARAG Computers (Bravo 180S/300S/400S/Delta80/Ninja) at a later time (e.g., when reusing the same tank). Before starting the procedure carry out the following operations: 1) Fill the tank with clean water WITHOUT ADDING CHEMICAL SUBSTANCES. The tank must be full. 2) Visually check the reached level. Automatic tank calibration 1) Open automatic calibration menu (Setup menu > Tank > Auto calibration). Press to edit the selected menu item. 2) Set the tank maximum capacity value, i.e., the theoretical quantity of fluid that was previously introduced: A) Press to move through digits... - Page 19 3) Start tank draining. The display will start showing the increasing measured fluid quantity value (central area of the display), the instant flowrate value (bottom right), and the progressive number of measured calibration points (bottom left). If a sensor malfunction occurs, the message Check sensor! will be shown in the top part of the display. 4) Once the tank has been completely drained, the value in the central area of the display will stop changing, and the message Compl. calibr.? will appear in the display top part Press for 1 second to complete calibration. 5) The display will go back to the previous menu and will show the acquired value. In case of measurement errors, or if it is necessary to stop the calibration, press for 2 seconds to quit the calibration procedure without saving. In this case, the curve will be the one previously measured, or the default curve.
- Page 20 Manual tank calibration To perform manual calibration, proceed as follows: 1) Calculate the suitable calibration interval with respect to tank maximum capacity, bearing in mind that: - it is possible to save up to 200 calibration points; - a high number of calibration points makes for more accurate measurements. 2) Adopt a reliable method for measuring the fluid quantity that was previously calculated. Example: [2000 liters] = [10 liters] [200 points] [2000 liters] = maximum tank capacity; [200 points] = set calibration points; [10 liters] * = measurement value in liters.
- Page 21 The message Stabilization will appear in the display top part for a few seconds, then it will switch back to Rec. cal. point. The value of calibration points will increase by one unit, and the value of the progressively drained partial volume will show the quantity of fluid measured up to that moment. VISIO is ready for a new measurement. It is possible to save calibration points obtained with different quantities of drained fluid. 4) Once the tank has been emptied completely, press key for 1 second to complete the calibration process and save the relevant curve. 5) The display will go back to the previous menu and will show the acquired value. In case of measurement errors, or if it is necessary to stop the calibration, press key for 1 second to quit the calibration procedure without saving. In this case, the curve will be the one previously measured, or the default curve.
-
Page 22: Language
Language Set the desired language. Open language setting menu (Setup menu > Options > Language). Options The display will show the current Language English setting below the selected item. Units of measurem. Display contrast Press to edit language. 1) Select a language through Language Česk Deutsch 2) Press to save, or to quit English Español without saving. -
Page 23: Units Of Measurement
Units of measurement Set unit of measurement for the values detected by the device. Rate units of measurement Open instant rate unit of measurement setting menu (Setup menu > Options > Units of measurem. > Flowrate). The display will show the current setting below the selected item. Press to select flowrate unit of measurement. 1) Select a unit through 2) Press to save, or to quit without saving. Volume units of measurement Open volume unit of measurement setting menu (Setup menu > Options > Units of measurem. > Volume). The display will show the current setting below the selected item. Press to select volume unit of measurement. 1) Select a unit through 2) Press to save, or to quit without saving. -
Page 24: Display Contrast
Display contrast Set display contrast. Open display contrast menu (Setup menu > Options > Display contrast). The display will show the current setting below the selected item. Press to edit the selected menu item. 1) Set a value through . Every time you press it, value will increase by 5% up to 100%. Use key to decrease value by 5%. 2) Press to save, or to quit without saving. -
Page 25: Alarm Tones
Alarm tones Enable/disable the alarm tones. Open alarm tones menu (Setup menu > Options > Alarm tones). The display will show the current setting below the selected item. Press to edit the selected menu item. 1) Set status through 2) Press to save, or to quit without saving. Keytones Enable/disable keytones. 1) Open keytones menu (Setup menu > Options > Keytones). The display will show the current setting below the selected item. Press to edit the selected menu item. 1) Set status through 2) Press to save, or to quit without saving. -
Page 26: Operating Mode
Operating mode Set required operating mode. Open operating mode menu (Setup menu > Options > Operating mode). The display will show the current setting below the selected item. Press to change the operating mode. 1) Select the required operating mode through 2) Press to save, or to quit without saving. WARNING: Once is pressed, the page on twhe side will be displayed. Before changing operating mode, make sure that all sensors are DISCONNECTED from the device. Press to confirm changes. Connect the sensors REQUIRED FOR THE SET OPERATING MODE. -
Page 27: Setup Management
Setup management VISIO settings can be loaded from or saved on a USB pen drive in order to reconfigure it if required, fix problems or set another VISIO with no need to repeat all manual operations. Once installation is completed, and VISIO operation has been checked, we recommend to save all settings onto a USB pen drive. To be able to use the following functions it is necessary to insert a USB pen drive in the relevant port at the bottom of VISIO. 1) Open Setup management menu (Setup menu > Setup management). Press to edit the selected menu item. Load setup Allows to select a configuration file saved in the USB pen drive and to set VISIO again. WARNING: By loading the SETUP.BIN file contained in the USB pen drive onto the VISIO, all current settings will be lost. 1) Select the desired control through key. 2) Press to confirm loading, or to quit without saving. The SETUP.BIN file can be loaded only if it is saved in the USB pen drive root directory. If setup download involves changing operating mode and using different sensors than the ones in use, make sure that all sensors are DISCONNECTED from the device. Press to confirm loading. Reconnect sensors. - Page 28 Save setup Allows saving VISIO configuration file on the USB pen drive: it will be possible to load it again any time the same settings need to be retrieved. 1) Select the desired control through key. 2) Press to confirm saving, or to quit without saving. If a SETUP.BIN file is already present in the USB pen drive root directory, the file will be overwritten.
-
Page 29: Test Menu
Test menu This menu allows user to view some data and carry out an operation test of VISIO: - Firmware version: the display shows the firmware version installed. - Battery voltage: the display shows the power voltage of the device. Display test Display test checks the device display correct operation. 1) Open display test menu (Setup menu > Test > Display). Press to perform the test. All pixels on display are turned on. Press to go back to previous page. Keys test Keys test checks the device keys correct operation. Open keys test menu (Setup menu > Test > Keys). Press to perform the test. 1) Press any key and the corresponding display area will turn on. Press to quit: as soon as you acknowledge the switch-on on of the corresponding area on the display, device will go back to previous page. - Page 30 Sensors test Sensors test checks correct operation of the sensors connected to the device. Open sensors test menu (Setup menu > Test > Sensors). Press to perform the test. The display will show the current sensor reading below the selected item. 1) Several sensors could be displayed, depending on the set operating mode. In this case, select required sensor through 2) Press to quit.
-
Page 31: Use
The main page shows the display divided into three horizontal parts: - top part: the progress bar shows the tank level in percentage; - central part: the value represents the volume of fluid inside the tank; - bottom part: The value represents the number of revolutions per minute of the rotating part. Press the key several times to view a value in extended mode until value is on display central part. -
Page 32: Maintenance / Diagnostics / Repairs
MAINTENANCE / DIAGNOSTICS / REPAIRS • Clean only with a soft wet cloth. • Do not use aggressive detergents or products. • Do not clean equipment with direct water jets. Troubleshooting FAULT CAUSE REMEDY Check power cable No power supply connections VISIO is off or does not switch on Device is OFF Press the ON key Check displayed data Wrong setup setup VISIO shows wrong data Sensor fault Contact the nearest Assistance Center VISIO fault Filling pump (if any) does Pump Stop Module not Check power supply not start powered connection END OF LIFE DISPOSAL Dispose of the system in compliance with the established legislation in the country of use. -
Page 33: Technical Data
TECHNICAL DATA Device technical data Description VISIO Display Graphic LCD, 128 x 64 pixels, back-lighting Power supply voltage 9 ÷ 16 Vdc Protection against short-circuit • Protection against polarity inversion • Max. frequency 1.2 KHz Analog inputs 4 ÷ 20 mA Digital output - Max current 100 mA Maximum power input (with no 160 mA sensors connected) -20 °C ÷ 70 °C Operating temperature -4 °F ÷ +158 °F -30 °C ÷ 80 °C Storage temperature -22 °F ÷ +176 °F Size 126 x 79 x 66 mm Weight 245 g... -
Page 34: Setup Menu
Setup menu Data Min. Max. Default UoM Notes Calib. Calibration 10000 pls/l flowmeter Calibration 9999 pls/rv Alarm can be disabled by setting Min. RPM 9999 value to "OFF" Alarm can be disabled by setting Max. RPM 9999 value to "OFF" Alarms Alarm can be disabled by setting Reserve tank 1000 value to "OFF" Alarm can be disabled by setting Max. level value to "OFF" Display Contrast Available languages: Italiano, English, Español, Português, Language English Français, Deutsch, Cesky, Polski, Русский, Magyar, Flowrate units of Available units of measurement: Options l/min. -
Page 35: Guarantee Terms
GUARANTEE TERMS ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery note). The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or production process, will be repaired or replaced free of charge at the nearest Assistance Center operating at the moment the request for intervention is made. The following costs are excluded: disassembly and reassembly of the apparatus from the original system; transport of the apparatus to the Assistance Center. The following are not covered by the guarantee: damage caused by transport (scratches, dents and similar); damage due to incorrect installation or to faults originating from insufficient or inadequate characteristics of the electrical system, or to alterations resulting from environmental, climatic or other conditions; damage due to the use of unsuitable chemical products, for spraying, watering, weedkilling or any other crop treatment, that may damage the apparatus; malfunctioning caused by negligence, mishandling, lack of know how, repairs or modifications carried out by unauthorized personnel; incorrect installation and regulation; damage or malfunction caused by the lack of ordinary maintenance, such as cleaning of filters, nozzles, etc.; anything that can be considered to be normal wear and tear. Repairing the apparatus will be carried out within time limits compatible with the organizational needs of the Assistance Center. No guarantee conditions will be recognized for those units or components that have not been previously washed and cleaned to remove residue of the products used; Repairs carried out under guarantee are guaranteed for one year (360 days) from the replacement or repair date. ARAG will not recognize any further expressed or intended guarantees, apart from those listed here. No representative or retailer is authorized to take on any other responsibility relative to ARAG products. The period of the guarantees recognized by law, including the commercial guarantees and allowances for special purposes are limited, in length of time, to the validities given here. In no case will ARAG recognize loss of profits, either direct, indirect, special or subsequent to any damage. The parts replaced under guarantee remain the property of ARAG. All safety information present in the sales documents regarding limits in use, performance and product characteristics must be transferred to the end user as a responsibility of the purchaser. - Page 36 GUARANTEE TERMS The declaration of conformity is available at www.aragnet.com, in the relevant section.
