TriTeq MicroIQ Installation Instructions

General dimensions
1.00
.39
1
1
Installation
1
Align the bar on the MicroIQ spindle to be perpendicular with the bars of the
Timberline shell as shown below. ( Bars shown darkened in the picture below )
With the knob attached, insert the spindle into the shell and using the
knob, turn the spindle 90° CCW until you hear or feel a snap sound.
Verify that the spindle is engaged.
Example*:
MicroIQ spindle
with knob
Bars are perpendicular to each other
* NOTE: If the lock shell bars are vertical, insert the spindle with the bars in the horizontal position.
1 3 3
www.microiqlock.com
TriTeq Lock and Security
701 Gullo Ave
Elk Grove Village, IL 60007
061715 - Rev. 4 © Copyright 2014 TriTeq Lock and Security. All rights reserved
3.86
MicroIQ
Turn knob
CCW after
inserted
Lock shell
HORIZONTAL
VERTICAL
R
Phone: (847) 640-7002
Toll Free: (888) 603-5625
Email: marketing@triteqlock.com
4
5
6
1
Knob
2 Lock Housing with keypad and infrared receiver
3
Spindle
4 Hex tool (1.5 mm)
5
Temper proof battery holder screw
6
CR2032 - 3 Volt Lithium Battery and battery holder
7
Mounting screws ( select one )
2
Exercise the knob and verify that the spindle
is engaged and operates your locking
mechanism as intended.
90°
Remove the knob from the spindle with
3
the mechanism in the locked position.
Install Fastener
4
5
Select appropriate mounting screw.
If mounted on sheet metal :
#4 x.375 sheetmetal screw
If mounted to wood panel with threaded insert:
#4 -40 x.500 machine screw
6
Insert the knob and push until flush
inside housing at locked position and
rotate to verify that the cam stop was
positioned correctly.
Confirm that your mechanism is locked
when the knob points to the lock icon
7
Rotate your knob only 45°. Using the hex tool, fasten the knob
to the spindle from the indicated location.
Battery
The mounting screw for the lock housing must be installed before installing the
MicroIQ battery. Prior to installation and insertion of the battery, the knob of the lock
mechanism will be free moving.
After installing the lock to the mounting surface, the battery and holder can be
inserted into the lock. The cover for the battery holder also serves to lock the holder
into the lock housing. The battery cover must be in the fully open position before
inserting the holder. The battery holder screw cannot be protruding from the bottom of
the battery holder. It must be flush with the holder so the holder can be inserted.
#4 #4
M2
7
.
Fig. 1
1
2
3
4
5
45
6
