JUM-2079VXL
Milling Machine
Servo DRO
Original:
GB
Operating Instructions
JPW Tool Group Hong Kong Limited
98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC
www.jettools.com
Импортёр в РФ: ООО «ИТА Технолоджи»
105082, Москва, Переведеновский пер., д. 17
www.jettools.ru
Made in PRC / Сделано в KHP
M/P– 50000863T
2022-09
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jet JUM-2079VXL Servo DRO
Summary of Contents for Jet JUM-2079VXL Servo DRO
- Page 1 JUM-2079VXL Milling Machine Servo DRO Original: Operating Instructions JPW Tool Group Hong Kong Limited 98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC www.jettools.com Импортёр в РФ: ООО «ИТА Технолоджи» 105082, Москва, Переведеновский пер., д. 17 www.jettools.ru Made in PRC / Сделано в KHP M/P–...
- Page 2 Dear Customer, Many thanks for the confidence you have shown in us with the purchase of your new JET-machine. This manual has been prepared for the owner and operators of a JET JUM-2079VXL Servo DRO Milling Machine to promote safety during installation, operation and maintenance procedures.
- Page 3 Always close the chuck guard and pulley cover before you start the machine. 4. Machine Safety for JUM-2079VXL Servo DRO Remove the chuck key and wrenches before machine The JUM-2079 VXL Servo DRO series milling machines are operation.
- Page 4 7: Complete of Machining and Power-Off ▲WARNING: Clean inside of the machine. 3. Idle Running ▲WARNING: Run the machine idly to warm it up before ▲WARNING: Keep machine bodies in specific position (like machining. X, Y, Z, spindle, etc.). ▲WARNING: During idle running, check for proper ▲WARNING: Turn off main power switch and get it functioning of each component: Check whether all the interlocked when machining is completed.
-
Page 5: Machine Structure
★ High Versatility: Universal milling head with 2 x 45° ISO 50, 7:24 taper and is compatible for end-mill or horizontal mill arbor. swivel shells that swivels 360° left to right and 0-90° up to down for high versatile vertical, horizontal and universal Universal milling head is mounted on the front side of the machining in a semi-sphere scope. -
Page 6: Unpacking And Installation
Torque of feed motor, X axis 18 Nm, servo motor Torque of feed motor, Y axis 18 Nm, servo motor 27 Nm, servo motor Torque of feed motor, Z axis with brake Power of universal milling head 7.5 kW motor Machine dimension 2625 x 2460 x 2080 (approximate) - Page 7 company, the insurance company and us promptly if any 5. Alignment of Machine damages occur. Align the machine with a precision leveling gauge longitudinally and cross on the table. The allowance is 0.04 / 3. Cleaning 1000mm. After the alignment, move down knee. Clean the machine thoroughly and remove the anti-rust oil and grease with proper solvent.
- Page 8 Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Gear Helix gear Helix gear Helix gear Helix gear Gear Gear Diagram – Transmission System Gear Gear X axis ballscrew Z axis ballscrew Conical gear Conical gear Gear...
- Page 9 Double row NN3018K/P5 90x140x37 cylindrical roller bearing Angular 7207AC 35x72x17 contact ball bearing Round head 2.5x16 GB309 needle Thrust 81117/P5 85x110x19 cylindrical roller bearing Deep groove 16009 45x75x10 ball bearing Angular 7009AC 45x75x16 contact ball bearing Deep groove 6207 35x72x17 ball bearing Deep groove 6205...
-
Page 10: Coolant System
level of oil is necessary for a smooth running. An oil level 11.COOLANT SYSTEM indicator is provided on the knee. The oil should be changed in the first 3 months and once every 6 months afterwards. General emulsified coolant mixture can be used for cooling of the cutting tools. - Page 11 low speed in the first 100 hours. Do NOT run the spindle at 1080rpm or above in the first 100 hours. 6). X / Y / Z axes can be locked with lock bolts. When the axis is locked, do NOT run it in auto feed mode. 7).
- Page 12 θ – angle between spindle center line and table cross 43° 62°54’10” 23°11’52” movement 44° 63°58’50” 23°49’48” β – angle of front shell 45° 65°31’49” 24°28’11” α – angle of rear shell 46° 67°05’17” 25°07’03” 47° 68°39’15” 25°46’24” For example, ①...
-
Page 13: Maintenance
⚫ e). After connecting to the power, check the spindle rotate abnormal noise direction, table feed and knee lifting direction and find out Movable parts vibration ⚫ whether the directions are the same with signs marked. Check for smooth running ⚫... - Page 14 1. Gib strip is too tight 1. Replace the gib strip Abnormal feed of three 2. Clearance in the bolt and nut is not proper 2. Adjust the clearance axes 3. Lack of lubrication oil 3. Add more oil 1. Tighten the grouting bolts Vibration of the 1.
- Page 15 Ring seal 16mm inner dia. x 1.8mm section 3 pieces 14. Environmental protection Protect the environment. Your appliance contains valuable materials which can be recovered or recycled. Please leave it at a specialized institution. 15. Available accessories Refer to the JET-Price-list...
- Page 16 16. Exploded View & Part List Exploded View for JUM-2079VXL Servo DRO Milling Machine –OVERVIEW...
- Page 17 JUM-2079VXL Servo DRO-OVERVIEW Index No. Part No. Description Size JUM2079VXL-01 Bed Part JUM2079VXL-02 Knee Part JUM2079VXL-03 Table Part JUM2079VXL-04 Head Part JUM2079VXL-05 Ram Part...
- Page 18 Exploded View for JUM-2079VXL Servo DRO Milling Machine –Bed Assembly 01...
- Page 19 Part List for JUM-2079VXL Servo DRO Milling Machine – Bed Assembly 01 Index No. Part No. Description Size JUM2063-01-01 base JUM2063-01-02 support JUM2063-01-03 cover JUM2063-01-04 JUM2063-01-05 Oil plate JUM2063-01-06 guard JUM2063-01-07 platen JUM2063-01-08 cover JUM2063-01-09 platen JUM2063-01-10 platen JUM2063-01-11 JUM2063-01-12...
- Page 20 Exploded View for JUM-2079VXL Servo DRO Milling Machine –Knee Assembly 02...
- Page 21 Part List for JUM-2079VXL Servo DRO Milling Machine – Knee Assembly 02 Index No. Part No. Description Size JUM2063-02-01 pillar JUM2063-02-02 support JUM2063-02-03 handle JUM2079-02-4 Bearing 6205GB/T276 JUM2079-02-5 Washer JUM2079-02-06 Gear JUM2079-02-07 Washer JUM2079-02-08 Gear JUM2079-02-09 Washer JUM2079-02-10 Bearing 6205 GB/T276...
- Page 22 Exploded View for JUM-2079VXL Servo DRO Milling Machine –Table Assembly 03...
- Page 23 Part List for JUM-2079VXL Servo DRO Milling Machine – Table Assembly 03 Index No. Part No. Description Size JUM2063-03-01 motor JUM2063-03-02 plate JUM2063-03-03 JUM2063-03-04 cover JUM2063-03-05 flange JUM2063-03-06 JUM2063-03-07 JUM2063-03-08 bracket JUM2063-03-09 cover JUM2063-03-10 bearing 7206 GB/T292 JUM2063-03-11 block JUM2079-03-12...
- Page 24 Exploded View for JUM-2079VXL Servo DRO Milling Machine –Head Assembly 04...
- Page 25 Part List for JUM-2079VXL Servo DRO Milling Machine – Head Assembly 04 Index No. Part No. Description Size JUM2063-04-01 shell JUM2063-04-02 plate JUM2063-04-03 cover JUM2063-04-04 drawbar JUM2063-04-05 bearing NN3018K/P5 JUM2063-04-06 spindle JUM2063-04-07 gear JUM2063-04-08 JUM2063-04-09 JUM2063-04-10 bearing JUM2063-04-11 JUM2063-04-12 bearing...
- Page 26 Exploded View for JUM-2079VXL Servo DRO Milling Machine –Ram Assembly 05...
- Page 27 Part List for JUM-2079 VXL Servo DRO Milling Machine – Ram Assembly 05 Index No. Part No. Description Size JUM2063-05-01 Gear JUM2063-05-02 Shaft JUM2063-05-03 Bearing 7212C JUM2063-05-04 Gear JUM2063-05-05 Bearing 51105 JUM2063-05-06 Gear JUM2063-05-07 Bearing 7007C JUM2063-05-08 Gear JUM2063-05-09 Bearing 6207 JUM2063-05-10 Gear...
- Page 28 Wiring Diagram for JUM-2079 VXL Servo DRO 50000852T 3~400V 50Hz...
- Page 37 INSPECTING...
- Page 41 Packing List --Main machine, Accessories and tools Name Detail JUM-2079 VXL Servo Milling Machine DRO Milling Machine Draw Bar End Face Milling Cutter Handle 7：24 ISO50 Ø40 Double-Ended Wrench 12x14 Double-Ended Wrench 22x24 Allen Wrench Allen Wrench Allen Wrench Operation Manual JUM-2079 VXL Servo Certificate Of Quality DRO Milling Machine...
