Avantree Orbit Pro User Manual page 20

User Manual
Use as Wireless Audio Receiver
(Receiver Mode)
The Orbit Pro's receiver (RX) mode allows you to receive audio
from a Bluetooth enabled source (such as a phone) and output
it through a non-Bluetooth compatible speaker or similar.
STEP 1
TX
Switch to the "RX" position.
OFF
RX
STEP 2
Using the provided power cable, plug the Orbit Pro into a
wall outlet via 5V/500-mA-2A rated USB adapter (any phone
charger should work. Please contact support@avantree.com if
you'd like us to send you a free adapter).
STEP 3
Connect to your speaker / soundbar via the included AUX,
RCA, or OPT cables. Plug the other end into the Orbit Pro's
"OUTPUT" section.
STEP 4
Press the button on the Orbit Pro once to enter PAIRING
mode.
On your device, turn on Bluetooth. Keep the Orbit Pro & your
audio source device closed together, and select "Avantree
Orbit Pro" from the Bluetooth menu.
Once connected successfully, the
shown on the LCD screen.
and "Connected" will be
ORBIT PRO
17
