SPLIT-TYPE, AIR CONDITIONERS January 2025 No. OCD886-T TECHNICAL & SERVICE MANUAL Outdoor unit R454B Note: Models • This manual describes service SUZ-AA09NLHZ-U1 data of the outdoor units only. SUZ-AA12NLHZ-U1 SUZ-AA15NLHZ-U1 SUZ-AA18NLHZ-U1 SUZ-AA09/12/15/18NLHZ Contents Service manual Technical data 1. COMBINATION OF INDOOR AND T1.
SAFETY PRECAUTION MEANING OF SYMBOLS DISPLAYED ON THE UNIT Refrigerant WARNING This unit uses a flammable refrigerant. safety Group If the refrigerant leaks and comes in contact with fire or heating part, it will create harmful gas and there is risk of fire. Read the OPERATING MANUAL carefully before operation.
[1] Warning for service (1) Do not alter the unit. (2) For installation and relocation work, follow the instructions in the Installation Manual and use tools and pipe components specifically made for use with refrigerant specified in the outdoor unit installation manual. (3) Ask a dealer or an authorized technician to install, relocate and repair the unit.
Page 5
[4] Cautions for unit using R454B refrigerant Basic work procedures are the same as those for conventional units using refrigerant R410A. However, pay careful attention to the following points. (1) Information on servicing (1-1) Checks to the area Prior to beginning work on systems containing FLAMMABLE REFRIGERANTS, safety checks are necessary to ensure that the risk of ignition is minimized.
Page 6
(3) Repair to intrinsically safe components Intrinsically safe components must be replaced. (4) Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans.
Page 7
a) Become familiar with the equipment and its operation. b) Isolate system electrically. c) Before attempting the procedure, ensure that: • mechanical handling equipment is available, if required, for handling refrigerant cylinders. • all personal protective equipment is available and being used correctly. •...
Unit Electronic weighing scale [5] Service tools Use the below service tools as exclusive tools for R454B refrigerant. Tool name Specifications · Only for R454B · Use the existing fitting specifications . (UNF1/2) Gauge manifold · Use high-tension side pressure of 768.7 PSIG [5.3 MPa.G] or over. ·...
PART NAMES AND FUNCTIONS SUZ-AA18NL(H)-U1 SUZ-AA24NL(H)-U1 SUZ-AA30NL(H)-U1 SUZ-AA36NL(H)-U1 SUZ-AA09NLHZ-U1 SUZ-AA12NLHZ-U1 SUZ-AA15NLHZ-U1 SUZ-AA18NLHZ-U1 OUTDOOR UNIT Air inlet (back and side) Piping Air outlet Drain hose Drain outlet TCH142...
SPECIFICATION Outdoor unit model SUZ-AA18NL(H) SUZ-AA24NL(H) SUZ-AA30NL(H) SUZ-AA36NL(H) Power supply V , phase , Hz 208/230 , 1 , 60 Max. fuse size (time delay) Min. circuit ampacity Fan motor Model SRB172FQHMT SRB220FQYMT Compressor fl oz. (L) 14.5 (0.43)/ 15.6 (0.46)/ Refrigeration oil (Model) (RM68EH)
Page 11
Outdoor unit model SUZ-AA09NLHZ SUZ-AA12NLHZ SUZ-AA15NLHZ SUZ-AA18NLHZ Power supply V , phase , Hz 208/230 , 1 , 60 Max. fuse size (time delay) Min. circuit ampacity Fan motor Model SRB172FQHMT Compressor fl oz. (L) 14.5 (0.43)/ Refrigeration oil (Model) (RM68EH) Refrigerant control Linear expansion valve...
OUTLINES AND DIMENSIONS SUZ-AA18NL(H)-U1 SUZ-AA24NL(H)-U1 SUZ-AA30NL(H)-U1 SUZ-AA36NL(H)-U1 SUZ-AA09NLHZ-U1 SUZ-AA12NLHZ-U1 SUZ-AA15NLHZ-U1 SUZ-AA18NLHZ-U1 Unit: inch REQUIRED SPACE 4 in OR MORE. 14 in OR MORE. 16-7/16 AIR IN DRAIN HOLE ø1-21/32 20 in OR MORE. AIR IN OPEN TWO SIDES OF RIGHT 4 in OR MORE.
ACTUATOR CONTROL 9-1. OUTDOOR FAN MOTOR CONTROL The fan motor turns ON/OFF, interlocking with the compressor. [ON] The fan motor turns ON 5 seconds before the compressor starts up. [OFF] The fan motor turns OFF 15 seconds after the compressor has stopped running. 5 seconds 15 seconds Compressor...
Changing defrost finish temperature <JS> To change the defrost finish temperature, cut/solder the JS wire of the outdoor inverter P.C. board. (Refer to "11-6. TEST POINT DIAGRAM AND VOLTAGE".) Defrost fi nish temperature SUZ-AA18NL(H)-U1 SUZ-AA09NLHZ-U1 Jumper SUZ-AA24NL(H)-U1 SUZ-AA12NLHZ-U1 SUZ-AA30NL(H)-U1 SUZ-AA15NLHZ-U1...
Page 28
11-2. TROUBLE SHOOTING CHECK TABLE check No. Symptoms Condition Remedy code Abnormal point/ Condition indication Outdoor power system Overcurrent protection cut-out operates 3 consecutive times within 1 • Reconnect connector of compressor. minute after the compressor gets started. • Refer to “11-5. A How to check inverter/compressor".
11-3. HOW TO PROCEED "SELF-DIAGNOSIS" 11-3-1. Self-diagnosis <PAR-4xMAA ("x" represents 0 or later)> Select "Service" from the Main menu, Diagnosis and press the [ ] button. Self check Remote controller check Select "Check" from the Service menu, and press the [ ] button.
11-3-2. Remote controller check <PAR-4xMAA ("x" represents 0 or later)> If operations cannot be completed with the remote controller, diagnose the remote controller with this function. Diagnosis Select "Service" from the Main menu, and press the Self check ] button. Remote controller check Select "Check"...
Page 31
11-3-3. Self-diagnosis <PAR-21MAA> When a problem occurs to the air conditioner, the indoor and outdoor units will stop, and the problem is shown in the remote controller display. [CHECK] and the refrigerant address are displayed on the temperature display, and the check code and unit number are displayed alternately as shown below.
Page 32
When the error history is reset, the display will look like the one shown below. Press the ON/OFF button ( in the picture in the previous page) twice However, if you fail to reset the error history, the error content will be displayed again. within 3 seconds.
Page 33
11-3-6. Self-diagnosis <Wireless remote controller> <In case of trouble during operation> When a malfunction occurs to air conditioner, both indoor unit and outdoor unit will stop and operation lamp blinks to inform unusual stop. < Malfunction-diagnosis method at maintenance service> [Procedure] Refrigerant 1.
Page 34
• Refer to the following tables for details on the check codes. [Output pattern A] Beeper sounds Beep Beep Beep Beep Beep Beep Beep OPERATION · · · Repeated INDICATOR lamp blink pattern Approx. 2.5 sec. 0.5 sec. 0.5 sec. 0.5 sec.
11-4. TROUBLE CRITERION OF MAIN PARTS Part name Check method and criterion Figure Defrost thermistor Measure the resistance with a tester. (RT61) Refer to “Inverter P.C. board” in "11-6. TEST POINT DIAGRAM AND Fin temperature VOLTAGE”, for the chart of thermistor. thermistor (RT64) Ambient temperature thermistor (RT65)
11-5. TROUBLESHOOTING FLOW A How to check inverter/compressor Disconnect the connector (CN61) between compressor and the intelligent power module (IPM). Check the voltage between terminals. See 11-5. “Check of open phase”. Replace the inverter P.C. board. Are the voltages balanced? Check the compressor.
Page 37
D Check of compressor winding ● Disconnect the connector between the compressor and intelligent power module, and measure the resistance between the compressor terminals. <Measurement point> Measure the resistance between the lead wires at 3 points. BK - WH BK - RD WH - RD <Judgement>...
Page 38
G Check of outdoor thermistors Disconnect the connector of thermistor in the outdoor P.C. board (see below table), and measure the resistance of thermistor. Is the resistance of thermistor normal? Replace the thermistor except RT64. When RT64 is (Refer to "11-6.TEST POINT DIAGRAM AND VOLTAGE".) abnormal, replace the inverter P.C.
Page 39
I Check of outdoor fan motor Check the connection between the connector CN931 and CN932. Is the resistance between each termi- nal of outdoor fan motor normal? (Refer to"11-4. TROUBLE CRITERION OF MAIN PARTS".) Disconnect CN932 from the inverter P.C. board, and turn on the power supply.
Page 40
K Check of LEV Start Turn on power supply to the outdoor unit after checking Normal LEV coil is fi xed to the LEV body securely. Is "click - click" sound heard? Or, do you feel vibration of the LEV coil with a hand? Disconnect the connector CN724 is there nor- Replace the inverter P.C.
Page 41
M How to check miswiring and serial signal error Turn OFF the power supply. Is there rated voltage AC in Check the power supply. the power supply? Turn ON the power supply. Is there rated voltage between outdoor terminal block S1 and Check the wiring.
Page 42
N Check the defrost heater SUZ-AA18/24/30/36NLH-U1 SUZ-AA09/12/15/18NLHZ-U1 Check the following points before checking electric continuity. 1. Does the resistance of ambient temperature thermistor have the characteristics? Refer to 11-6.1. 2. Is the resistance of defrost heater normal? Refer to 11-4. 3.
Page 43
P Electromagnetic noise enters into TV sets or radios Is the unit grounded? Ground the unit. Is the distance between the antennas Extend the distance between the antennas and and the indoor unit within 9.91 ft., or is the indoor unit, and/or the antennas and the the distance between the antennas and outdoor unit.
Page 44
Q Check of compressor protector Disconnect the connector of compressor protector in the inverter P.C. board, and check the conduction of compressor protector Operate the unit Is the discharge temperature Is the compressor protector and re-confi rm if the thermistor normal? Refer to 11-5. conductive? abnormality occur.
11-6. TEST POINT DIAGRAM AND VOLTAGE 1. Inverter P.C. board SUZ-AA18NL(H)-U1 SUZ-AA24NL(H)-U1 SUZ-AA30NL(H)-U1 SUZ-AA36NL(H)-U1 SUZ-AA09NLHZ-U1 SUZ-AA12NLHZ-U1 SUZ-AA15NLHZ-U1 SUZ-AA18NLHZ-U1 Back side of unit Smoothing Smoothing Smoothing Fuse (F880) Output to drive Heater (CN601) Capacitor Capacitor Capacitor T3.15AL250V outdoor fan motor 230 V AC...
FUNCTION SETTING 12-1. UNIT FUNCTION SETTING BY THE REMOTE CONTROLLER Each function can be set according to necessity using the remote controller. The setting of function for each unit can only be done by the remote controller. Select function available from the table 1. <Table 1>...
Page 48
12-1-1. Selecting functions using the wired remote controller <PAR-41MAA> <Service menu> Maintenance password is required Main Main menu Select "Service" from the Main menu, and press the [ ] button. *At the main display, the menu button and select "Service" to make Service the maintenance setting.
Page 49
12-2. FUNCTION SETTING 12-2-1. PAR-41MAA Settings menu 1. Select ˝Service˝ from the Main menu, and press the [ ] button. Function setting Rotation setting Select ˝Function setting˝, and press the [ ] button. Service menu: Select ˝Setting˝ from the Service menu, and press the [ ] button.
Page 50
Pattern 2 4. Toggle through the pages with the F3 or F4 button. Function setting Ref. address Grp. (1/8) Mode 1 5. Select the mode number with the F1 or F2 button, and then press the [ Mode 2 button. Mode 3 Mode 4 Save:...
DISASSEMBLY INSTRUCTIONS <Detaching method of the terminal with locking mechanism> The terminal which has the locking mechanism can be detached as shown below. There are 2 types of the terminal with locking mechanism. The terminal without locking mechanism can be detached by pulling it out. Check the shape of the terminal before detaching.
Page 52
OPERATING PROCEDURE PHOTOS/FIGURES 2. Removing the inverter assembly, inverter P.C. board Screws of the conduit cover Photo 3 and fuse P.C. board 2-1. Removing the inverter assembly and inverter P.C. board (1) Remove the top panel, cabinet and service panel. (Refer to section 1.) (2) Disconnect the lead wire to the reactor and the following connectors:...
Page 53
OPERATING PROCEDURE PHOTOS/FIGURES * Connection procedure when attaching the inverter P.C. Photo 7 board (Photo 8, 9) 1. Attach the heat sink support to the P.C. board support. 2. Hook the lead wires of the compressor, the reactor and the P.C.
Page 54
OPERATING PROCEDURE PHOTOS/FIGURES 2-2. Removing the fuse P.C. board Photo 10 (1) Remove the top panel, cabinet and service panel. (Refer to Support section 1.) CN65 Fuse P.C. board (2) Disconnect the lead wire to the reactor and the inverter P.C. board connectors.
Page 55
OPERATING PROCEDURE PHOTOS/FIGURES 3. Removing the discharge temperature thermistor, Photo 12 Outdoor heat exchanger defrost temperature thermistor, outdoor heat exchanger temperature thermistor temperature thermistor and ambient temperature ther- mistor (1) Remove the cabinet and panels. (Refer to section 1.) (2) Disconnect the lead wire to the reactor and the following connectors: <Inverter P.C.
Page 56
OPERATING PROCEDURE PHOTOS/FIGURES 5. Removing the compressor and 4-way valve Photo 14 (1) Remove the cabinet and panels. (Refer to section 1.) Brazed part of (2) Remove the inverter assembly. (Refer to section 2) Discharge the discharge pipe (3) Remove the screws fixing the reactor. temperature thermistor (4) Remove the reactor.
Page 57
13-2. SUZ-AA24NL SUZ-AA30NL SUZ-AA36NL SUZ-AA24NLH SUZ-AA30NLH SUZ-AA36NLH : Indicates the visible parts in the photos/fi gures. NOTE: Turn OFF the power supply before disassembly. : Indicates the invisible parts in the photos/fi gures. OPERATING PROCEDURE PHOTOS/FIGURES 1. Removing the cabinet Photo 1 Screws of the top panel (1) Remove the screws of the service panel.
Page 58
OPERATING PROCEDURE PHOTOS/FIGURES 2. Removing the inverter assembly, inverter P.C. board Photo 5 and fuse P.C. board Screw of the heat sink Screw of the P.C. board support and the separator 2-1. Removing the inverter assembly and inverter P.C. board support and the motor (1) Remove the top panel, cabinet and service panel.
Page 59
OPERATING PROCEDURE PHOTOS/FIGURES * Connection procedure when attaching the inverter P.C. Photo 7 board (Photo 8, 9) 1. Attach the heat sink support to the P.C. board support. 2. Hook the lead wires of the compressor, the reactor and the P.C.
Page 60
OPERATING PROCEDURE PHOTOS/FIGURES 2-2. Removing the fuse P.C. board Photo 10 (1) Remove the top panel, cabinet and service panel. (Refer to Support CN65 Fuse P.C. board section 1.) (2) Disconnect the lead wire to the reactor and the inverter P.C. board connectors.
Page 61
OPERATING PROCEDURE PHOTOS/FIGURES 3. Removing the discharge temperature thermistor, Photo 12 Outdoor heat exchanger defrost temperature thermistor, outdoor heat exchanger temperature thermistor temperature thermistor and ambient temperature thermistor (1) Remove the cabinet and panels. (Refer to section 1.) (2) Disconnect the lead wire to the reactor and the following connectors: <Inverter P.C.
Page 62
OPERATING PROCEDURE PHOTOS/FIGURES 5. Removing the compressor and 4-way valve Photo 14 (1) Remove the cabinet and panels. (Refer to section 1.) Brazed part of (2) Remove the inverter assembly. (Refer to section 2) Discharge the discharge pipe (3) Remove the screws fixing the reactor. temperature thermistor (4) Remove the reactor.
POSITION OF THE CENTER OF GRAVITY T2-1. OUTDOOR UNIT Unit: inch(mm) Model SUZ-AA09NLHZ 12-19/32 6-57/64 14-61/64 33-1/16 34-10/16 SUZ-AA12NLHZ 13 (330) SUZ-AA15NLHZ (320) (175) (380) (840) (880) SUZ-AA18NLHZ OCD886-T...
CAPACITY CORRECTION RATIO CURVE FOR PIPING LENGTH T6-1. CAPACITY CORRECTION RATIO CURVE FOR PIPING LENGTH Correction ratio of capacity according to the length of piping (cooling) 100% Indoor unit 09/12/15 class Indoor unit 18 class 16.4 32.8 49.2 65.6 82.0 114.8 (ft) 98.4...
EARTHQUAKE-PROOF STRENGTH ANALYSIS Earthquake-proof strength analysis <Anchor bolt> 1.Type: 2.Model name: SUZ- A09N HZ 3.Specification (1) Unit mass (2) Anchor bolt 1.The total number of bolts. 2.The size and shape. "=M type 3.The axis section area per one bolt. 78 ×10 4.The total number of bolts in one side which be pulled stronger when the unit inverted.
Page 127
Earthquake-proof strength analysis <Anchor bolt> 1.Type: 2.Model name: SUZ- A12N HZ 3.Specification (1) Unit mass (2) Anchor bolt 1.The total number of bolts. 2.The size and shape. "=M type 3.The axis section area per one bolt. 78 ×10 4.The total number of bolts in one side which be pulled stronger when the unit inverted. (3) The height between the installing surface and the center of gravity of the unit (4) The bolt-span from the examination angle 0.360 m...
Page 128
Earthquake-proof strength analysis <Anchor bolt> 1.Type: 2.Model name: SUZ- A15N HZ 3.Specification (1) Unit mass (2) Anchor bolt 1.The total number of bolts. 2.The size and shape. "=M type 3.The axis section area per one bolt. 78 ×10 4.The total number of bolts in one side which be pulled stronger when the unit inverted. (3) The height between the installing surface and the center of gravity of the unit (4) The bolt-span from the examination angle 0.360 m...
Page 129
Earthquake-proof strength analysis <Anchor bolt> 1.Type: 2.Model name: SUZ- A18N HZ 3.Specification (1) Unit mass (2) Anchor bolt 1.The total number of bolts. 2.The size and shape. "=M type 3.The axis section area per one bolt. 78 ×10 4.The total number of bolts in one side which be pulled stronger when the unit inverted. (3) The height between the installing surface and the center of gravity of the unit (4) The bolt-span from the examination angle 0.360 m...
