SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS

Technical & Service Manual

[Model Name]

PUZ-AK36NL

PUZ-AK42NL

PUZ-AK48NL

PUZ-AK60NL

PUY-AK36NL

PUY-AK42NL

PUY-AK48NL

PUY-AK60NL

SUZ-AK48NL

SUZ-AK60NL

SUZ-CK48NLH

SUZ-CK60NLH

Contents

Service manual

1. REFERENCE MANUAL ······················· 2

2. SAFETY PRECAUTION ······················· 2

3. FEATURES ····································· 13

4. SPECIFICATIONS ···························· 14

5. DATA ·············································· 15

6. OUTLINES AND DIMENSIONS ··········· 19

7. WIRING DIAGRAM ··························· 21

8. WIRING SPECIFICATIONS ················ 23

9. REFRIGERANT SYSTEM DIAGRAM ··· 26

10. TROUBLESHOOTING ······················· 29

11. EASY MAINTENANCE FUNCTION ······ 82

12. FUNCTION SETTING ························ 83

13. MONITORING THE OPERATION DATA

BY THE REMOTE CONTROLLER ······· 84

14. DISASSEMBLY PROCEDURE ············ 91

15. REMOTE CONTROLLER ··················106

[Service Ref.]

PUZ-AK36NL-U1

PUZ-AK42NL-U1

PUZ-AK48NL-U1

PUZ-AK60NL-U1

PUY-AK36NL-U1

PUY-AK42NL-U1

PUY-AK48NL-U1

PUY-AK60NL-U1

SUZ-AK48NL-U1

SUZ-AK60NL-U1

SUZ-CK48NLH-U1

SUZ-CK60NLH-U1

R454B

Technical data

T1. SPECIFICATIONS CONNECTED TO

INDOOR UNIT ································129

T2. PERFOMANCE CHART ···················143

T3. PERFORMANCE CURVES ···············150

T4. CORRECTION FACTORS ·················153

T5. PART LOAD CAPACITY CHART ·······155

T6. POSITION OF THE CENTER OF

GRAVITY ·······································177

T7. OPTIONAL PARTS ··························178

T8. SYSTEM CONTROL ························335

February 2025

No. OCD869

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the PUZ-AK36NL and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitsubishi Electric PUZ-AK36NL

Page 1 SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS February 2025 No. OCD869 Technical & Service Manual R454B [Model Name] [Service Ref.] PUZ-AK36NL-U1 PUZ-AK36NL PUZ-AK42NL-U1 PUZ-AK42NL PUZ-AK48NL-U1 PUZ-AK48NL PUZ-AK60NL-U1 PUZ-AK60NL PUY-AK36NL-U1 PUY-AK36NL PUY-AK42NL-U1 PUY-AK42NL PUY-AK48NL-U1 PUY-AK48NL PUY-AK60NL-U1 PUY-AK60NL SUZ-AK48NL-U1 SUZ-AK48NL SUZ-AK60NL-U1 SUZ-AK60NL SUZ-CK48NLH-U1 SUZ-CK48NLH...
Page 2: Indoor Unit
REFERENCE MANUAL INDOOR UNIT Service manual No. Model name Service Ref. Parts catalog No. OCH856 PLA-AE12/18/24/30/36/42/48NL PLA-AE12/18/24/30/36/42/48NL-U1 OCB856 OCH860 PCA-AK24/30/36/42NL PCA-AK24/30/36/42NL-U1 OCB860 OCH859 PKA-AK24/30/36NL PKA-AK24/30/36NL-U1 OCB859 HWE24030 PEAD-AA12/18/24/30/36/42NL PEAD-AA12/18/24/30/36/42NL-U1 BWE024030 PAA-AA/BA/CA18/24/30/36/42NL MD-2025-K010 PVA-AA12/18/24/30/36/42/48/60NL PVA-AA12/18/24/30/36/42/48/60NL-U1 SVZ-AP48/60NL SVZ-AP48/60NL-U1 SAFETY PRECAUTION MEANINGS OF SYMBOLS DISPLAYED ON THE UNIT Refrigerant This unit uses a ﬂ...
Page 3 2-1. ALWAYS OBSERVE FOR SAFETY Before obtaining access to terminal, all supply circuits must be disconnected. Preparation before the repair service. • Prepare the proper tools. • Prepare the proper protectors. • Provide adequate ventilation. • After stopping the operation of the air conditioner, turn oﬀ the power-supply breaker. •...
Page 4 2-2. CAUTIONS RELATED TO NEW REFRIGERANT Cautions for units utilizing refrigerant R454B Use a vacuum pump with a reverse ﬂ ow check valve. Use new refrigerant pipes. Vacuum pump oil may ﬂ ow back into refrigerant cycle and In the case of using the existing pipes for R22, R410A, be that can cause deterioration of refrigerant oil, etc.
Page 5 [1] Warning for service (1) Do not alter the unit. (2) For installation and relocation work, follow the instructions in the installation manual and use tools and pipe components speciﬁ cally made for use with refrigerant speciﬁ ed in the outdoor unit installation manual. (3) Ask a dealer or an authorized technician to install, relocate and repair the unit.
Page 6: Cautions For Service
[2] Cautions for service (1) Perform service after recovering the refrigerant left in unit completely. (2) Do not release refrigerant in the air. (3) After completing service, charge the cycle with specified amount of refrigerant. (4) If moisture or foreign matter might have entered the refrigerant piping during service, ensure to remove them. [3] Additional refrigerant charge When charging directly from cylinder (1) Check that cylinder for R454B on the market is a syphon type.
Page 7 [4] Cautions for unit using R454B refrigerant Basic work procedures are the same as those for conventional units using refrigerant R410A. However, pay careful attention to the following points. (1) Information on servicing (1-1) Checks on the Area Prior to beginning work on systems containing FLAMMABLE REFRIGERANTS, safety checks are necessary to ensure that the risk of ignition is minimized.
Page 8 (2) Repairs to Sealed Components Sealed electrical components shall be replaced. (3) Repair to intrinsically Safe Components Intrinsically safe components must be replaced. (4) Cabling Refer to 6.1 in the installation manual. (5) Detection of Flammable Refrigerants Refer to 4.4 in the installation manual. (6) Removal and Evacuation Refer to 1.2 in the installation manual.
Page 9: Service Tools
[5] Service tools Use the below service tools as exclusive tools for R454B refrigerant. Tool name Specifications Gauge manifold · Only for R454B · Use the existing fitting specifications . · Use high-tension side pressure of 768.7 psig [5.3 MPa.G] or over. Charge hose ·...
Page 10 Tools for R454B (The following table shows whether conventional tools can be used or not.) Tools and materials R454B tools Can R22 tools be used? Can R22 tools be used? Gauge manifold Air purge, refrigerant Tool exclusive for R454B charge and operation Charge hose check Tool exclusive for R454B...
Page 11: Low Ambient Cooling
2-4. LOW AMBIENT COOLING Precautions for low ambient cooling • If the outdoor temperature is 23°F or lower during cooling operation, install an optional air guide to prevent wind from blowing into the outdoor unit. • Install the outdoor unit in a location where wind will not blow onto the back of the unit or through the unit. •...
Page 12 2.5. Minimum installation area ■ Indoor units When the indoor unit is installed in a room with a ﬂ oor area of A min or more, charge an appropriate amount of refrigerant M (factory-charged refrigerant + locally added refrigerant) according to the table below. * For the factory-charged refrigerant amount, refer to the speciﬁ...
Page 13 FEATURES PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUZ-AK48NL-U1 PUZ-AK60NL-U1 PUY-AK36NL-U1 PUY-AK42NL-U1 PUY-AK48NL-U1 PUY-AK60NL-U1 SUZ-AK48NL-U1 SUZ-AK60NL-U1 SUZ-CK48NLH-U1 SUZ-CK60NLH-U1 CHARGELESS SYSTEM PRE-CHARGED REFRIGERANT IS SUPPLIED FOR PIPING LENGTH AT SHIPMENT. (Maximum 100 ft [30 m]) The refrigerant circuit with LEV (Linear Expansion Valve) and the accumulator always control the optimal refrigerant level regardless of the piping length.
Page 14 SPECIFICATIONS PUZ-AK48NL-U1 PUZ-AK60NL-U1 PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUY-AK48NL-U1 PUY-AK60NL-U1 Service Ref. PUY-AK36NL-U1 PUY-AK42NL-U1 SUZ-AK48NL-U1 SUZ-AK60NL-U1 SUZ-CK48NLH-U1 SUZ-CK60NLH-U1 Power Phase Single supply Frequency 60 Hz Voltage 208/230 V Inverter Input MOCP Breaker size External ﬁ nish Munsell 3Y 7.8/1.1 Heat exchanger Cross ﬁ n Plate ﬁ...
Page 15 158 oz 158 oz 158 oz 158 oz 158 oz 158 oz 164 oz 170 oz 176 oz 182 oz 188 oz 194 oz 197 oz 158 oz PUZ-AK36NL-U1 4.5 kg 4.5 kg 4.5 kg 4.5 kg 4.5 kg 4.5 kg 4.7 kg 4.8 kg 5.0 kg 5.2 kg 5.4 kg 5.5 kg 5.6 kg 4.5 kg...
Page 16: Noise Criterion Curves
5-3. NOISE CRITERION CURVES PUZ-AK36/42NL-U1 PUY-AK36/42NL-U1 MODE SPL (dB) LINE MODE SPL (dB) LINE SUZ-AK48/60NL-U1 PUZ-AK36/42NL-U1 COOLING COOLING SUZ-CK48/60NLH-U1 PUY-AK36/42NL-U1 HEATING HEATING NC-70 NC-70 NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 APPROXIMATE APPROXIMATE THRESHOLD OF THRESHOLD OF HEARING FOR HEARING FOR NC-20 NC-20...
Page 17: Standard Operation Data
60 Hz 60 Hz 60 Hz Voltage 208/230 V 208/230 V 208/230 V Current 0.98 A 1.05 A 1.05 A Outdoor unit model PUZ-AK36NL PUZ-AK42NL PUZ-AK48NL Phase Single Single Single Cycle 60 Hz 60 Hz 60 Hz Voltage 208/230 V...
Page 18: Cooling Only
5-4-2. Cooling only Representative matching PLA-AE36NL PLA-AE42NL PLA-AE48NL Mode COOLING COOLING COOLING Total Capacity Btu/h 36,000 42,000 48,000 Input 2,620 3,500 4,573 Indoor unit model PLA-AE36NL PLA-AE42NL PLA-AE48NL Phase Single Single Single Cycle 60 Hz 60 Hz 60 Hz Voltage 208/230 V 208/230 V 208/230 V...
Page 19: Outlines And Dimensions
OUTLINES AND DIMENSIONS PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUZ-AK48NL-U1 SUZ-AK48NL-U1 PUY-AK36NL-U1 PUY-AK42NL-U1 PUY-AK48NL-U1 SUZ-CK48NLH-U1 Unit: mm<in> OCH869A...
Page 20 PUZ-AK60NL-U1 SUZ-AK60NL-U1 PUY-AK60NL-U1 SUZ-CK60NLH-U1 OCH869A...
Page 21: Wiring Diagram
WIRING DIAGRAM PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUY-AK36NL-U1 PUY-AK42NL-U1 OCH869A...
Page 22 PUZ-AK48NL-U1 PUZ-AK60NL-U1 SUZ-AK48NL-U1 SUZ-AK60NL-U1 PUY-AK48NL-U1 PUY-AK60NL-U1 SUZ-CK48NLH-U1 SUZ-CK60NLH-U1 OCH869A...
Page 23: Wiring Specifications
WIRING SPECIFICATIONS 8-1. INDOOR UNIT POWER SUPPLIED FROM OUTDOOR UNIT (A-control application) The following connection patterns are available. The outdoor unit power supply patterns vary depending on models. 1:1 System 1:1 System (Separate indoor unit/outdoor unit power supplies) Outdoor unit power supply Outdoor unit power supply Wiring circuit breaker or isolating switch Wiring circuit breaker or isolating switch...
Page 24 8-2. M-NET WIRING METHOD Points to notice: (1) Outside the unit, transmission wires should stay away from electric wires in order to prevent electromagnetic noise from making an influence on the signal communication. Place them at intervals of 5 cm [2 in.] or more. Do not put them in the same conduit tube.
Page 25 8-2-1. M-NET address setting In A-control models, M-NET address and refrigerant address should be set only for the outdoor unit. Similar to City Multi series, there is no need to set the address of outdoor unit and remote controller. To construct a central control system, the setting of M-NET address should be conducted only upon the outdoor unit.
Page 26: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUY-AK36NL-U1 PUY-AK42NL-U1 Unit: inch [mm] Unit: inch [mm] <4-way valve solenoid coil> <4-way valve solenoid coil> Thermistor TH7 Heating: ON Heating: ON Heat exchanger (Outdoor) Cooling: OFF Cooling: OFF Thermistor TH6 (Outdoor 2-phase pipe) Stop valve...
Page 27 PUZ-AK48NL-U1 PUZ-AK60NL-U1 SUZ-AK48NL-U1 SUZ-AK60NL-U1 PUY-AK48NL-U1 PUY-AK60NL-U1 SUZ-CK48NLH-U1 SUZ-CK60NLH-U1 Unit: inch [mm] <4-way valve solenoid coil> Thermistor TH7 Heating: ON (Outdoor) Heat exchanger Cooling: OFF Thermistor TH6 (Outdoor 2-phase pipe) Stop valve 4-way valve Refrigerant GAS pipe AK48: ø5/8 [15.88 mm] Strainer AK60: ø3/4 [19.05 mm] Thermistor TH3...
Page 28 1. Refrigerant collecting (pump down) Perform the following procedures to collect the refrigerant when moving the indoor unit or the outdoor unit. Supply power (circuit breaker). • When power is supplied, make sure that [Centrally controlled] is not displayed on the remote controller. If [Centrally controlled] is dis- played, the refrigerant collecting (pump down) cannot be completed normally.
Page 29: Troubleshooting
TROUBLESHOOTING 10-1. TROUBLESHOOTING <Error code displayed by self-diagnosis and actions required for service (summary)> Present and past error codes are logged, and they can be displayed on the wired remote controller and control board of outdoor unit. Actions required for service, which depends on whether or not the trouble is reoccurring in the field, are summarized in the table below.
Page 30 • Refer to the following tables for details on the error codes. Output pattern A Beeper sounds Beep Beep Beep Beep Beep Beep Beep · · · Repeated Operation indicator lamp Oﬀ blink pattern Oﬀ Approx. 2.5 s 0.5 s 0.5 s 0.5 s 0.5 s...
Page 31 10-3. SELF-DIAGNOSIS ACTION TABLE <Abnormalities detected when the power is turned on> Note: Refer to the indoor unit section for the codes starting with P and E. Error code Abnormal points and detection method Cause judgment and action No voltage is supplied to terminal Check following items.
Page 32 Error code Abnormal points and detection method Cause judgment and action Miswiring of indoor/outdoor unit Contact failure or miswiring of Check disconnection or looseness or polarity indoor/outdoor unit connecting wire of indoor/outdoor unit connecting wire of connecting wire Diameter or length of indoor/ indoor and outdoor units.
Page 33 <Abnormalities detected while unit is operating> Error code Abnormal points and detection method Cause judgment and action (1)High discharge temperature Overheated compressor Check intake superheat. Abnormal if discharge temperature operation caused by shortage of Check leakage of refrigerant. thermistor (TH4) exceeds 239˚F [115°C] refrigerant Charge additional refrigerant.
Page 34 Error code Abnormal points and detection method Cause judgment and action Temperature of heat sink The outdoor fan motor is locked. Check outdoor fan. Abnormal if heat sink thermistor (TH8) Failure of outdoor fan motor detects temperature indicated below. Airflow path is clogged. Check airflow path for cooling.
Page 35 Error code Abnormal points and detection method Cause judgment and action To find out the detail history (latest) about U9 error, turn ON SW2-1, 2-2, and 2-6. Detailed Refer to "10-9. FUNCTION OF SWITCHES, CONNECTORS AND JUMPERS". codes Overvoltage error Abnormal increase in power Check the field facility for the power supply.
Page 36 Error code Abnormal points and detection method Cause judgment and action Compressor overcurrent interruption Stop valve is closed. Open stop valve. (When compressor locked) Decrease of power supply voltage Check facility of power supply. Abnormal if overcurrent of DC bus or Looseness, disconnection or Correct the wiring (U·V·W phase) to compressor is detected within 30 seconds...
Page 37 Error code Abnormal points and detection method Cause judgment and action Compressor overcurrent interruption Stop valve of outdoor unit is Open stop valve. Abnormal if overcurrent DC bus or com- closed. pressor is detected after compressor starts Decrease of power supply Check facility of power supply.
Page 38 Error code Abnormal points and detection method Cause judgment and action Indoor/outdoor unit communication error Contact failure, short circuit or Note: Check LED display on outdoor controller (Signal receiving error) miswiring (reversed wiring) of circuit board. (Connect A-Control service (1) Abnormal if indoor controller board could indoor/outdoor unit connecting tool (PAC-SK52ST)) not receive any signal normally for 6...
Page 39 Error code Abnormal points and detection method Cause judgment and action Serial communication error Breaking of wire or contact Check connection of each connector CN2 Abnormal if serial communication failure of connector CN2 and CN4 between the outdoor controller between outdoor controller circuit board between the outdoor controller circuit board and the outdoor power circuit and outdoor power circuit board is...
Page 40 Refrigerant leakage Refrigerant leaks from the • Turn off the power after FAN operation is piping or the heat exchanger in Abnormal if the refrigerant leakage detected finished. (FAN operation continues for 8 hours.) the indoor unit. by a refrigerant sensor. •...
Page 41 Error code Abnormal points and detection method Cause judgment and action NO ACK signal Common factors that have no Always try the following when the error relation with abnormality source. “A7” occurs. Transmitting side controller detects The unit of former address Turn off the power supply of outdoor unit, abnormal if a message was transmitted does not exist as address...
Page 42 From the previous page. Error code Abnormal points and detection method Cause judgment and action If displayed address or attribute is During group operation with indoor unit of multi- refrigerant remote controller, system, if indoor unit transmit to indoor unit detects abnormality when remote controller while outdoor indoor unit transmitted to remote control- unit power supply of one...
Page 43 Error code Abnormal points and detection method Cause judgment and action M-NET NO RESPONSE Transmitting condition is Check transmission waveform or noise on Abnormal if a message was transmitted repeated fault because of noise transmission wire. and there were reply (ACK) that message and the like.
Page 44 10-4. TROUBLESHOOTING OF PROBLEMS Phenomena Factor Countermeasure Remote controller display does not 12 VDC is not supplied to remote controller. Check LED2 on indoor controller board. work. (1) When LED2 is lit, check the remote (Power supply display is not indicated on LCD.) controller wiring for breaking or contact failure.
Page 45 Phenomena Factor Countermeasure When operating by the IR wireless No operation for 2 minutes at most after the power Normal operation remote controller, beep sound is supply ON. heard, however, unit does not start operating. Hand-held remote controller operation is prohibited. Normal operation •...
Page 46 Symptoms: [Please Wait] is kept being displayed on the remote controller. Inspection method and Diagnosis ﬂ ow Cause troubleshooting Check the display time of [Please Wait] after turning on the main power. 6 minutes 2 minutes How long is [Please Wait] or more or less kept being displayed on the...
Page 47 LED display of the indoor controller board Symptoms: Nothing is displayed on the remote controller. LED1: LED2: LED3: Inspection method and Diagnosis ﬂ ow Cause troubleshooting Check the voltage between S1 and S2 on the terminal block (TB4) of the indoor unit. 198 to 264 VAC? Check the voltage among L1 and L2 on the terminal block (TB1) of the...
Page 48 LED display of the indoor controller board Symptoms: Nothing is displayed on the remote controller. LED1: LED2: LED3: Inspection method and Diagnosis ﬂ ow Cause troubleshooting Check the voltage between S1 and S2 on the terminal block (TB4) of the indoor unit. 198 to 264 VAC? Check the status Not lighting...
Page 49 LED display of the indoor controller board Symptoms: Nothing is displayed on the remote controller. LED1: LED2: LED3: — Inspection method and Diagnosis ﬂ ow Cause troubleshooting Check the voltage of the terminal block (TB6) of the remote controller. • Defective remote •...
Page 50 • Before repair Frequently Asked Questions Questions from customers Answers Note Unit does 1 The operating display of remote 1 Check if power is supplied to air conditioner. not operate controller does not come on. Nothing appears on the display unless power is at all.
Page 51 Questions from customers Answers Note The room cannot be cooled or heated 1 Check the set temperature of remote controller. suﬃ ciently. The outdoor unit cannot be operated if the set temperature is not appropriate. The outdoor unit operates in the following modes. COOL: When the set temperature is lower than the room temperature.
Page 52 Questions from customers Answers Note Something 3 Air blows out for a while after 3 This is not a malfunction. However, this control is is wrong HEAT operation is stopped. The blower is operating just for cooling down the also applied to the models with the heated-up air conditioner.
Page 53 Questions from customers Answers Note A white mist is expelled from the indoor unit. This is not a malfunction. This may occur when the operation is started in the room with high humidity. Water or moisture is expelled from the outdoor COOL: when pipes or piping joints are cooled, they unit.
Page 54: How To Check The Parts
10-5. HOW TO CHECK THE PARTS Parts name Checkpoints Disconnect the connector then measure the resistance with a multimeter. Thermistor (TH3) (At the ambient temperature 50 to 86°F [10 to 30°C]) <Liquid> Thermistor (TH4) <Discharge> Normal Abnormal Thermistor (TH6) 160 to 410 kΩ <...
Page 55 10-5-1. Check methods of outdoor controller circuit board Outdoor controller circuit board check Fuse check Check the fuse on outdoor controller circuit board. Yes (blow) Did the fuse (F1 and F2) blow? Check the indoor controller board wiring. Yes (blow) Did the fuse (F3 and F4) blow? Check the wiring for SV2 and 21S4*.
Page 56 10-5-2. Check methods of power circuit board Power board check Note: To check the voltage of the parts on this board with a multimeter is diﬃ cult due to its location. Test points are limited. Is the voltage of main incoming •...
Page 57 10-5-3. Check methods of DC fan motor (fan motor/outdoor controller circuit board) Notes · High voltage is applied to the connector (CNF1, 2) for the fan motor. Pay attention to the service. · Do not pull out the connector (CNF1, 2) for the motor with the power supply on. (It causes trouble of the outdoor multi controller circuit board and fan motor.) Self check Symptom: The outdoor fan cannot rotate.
Page 58 10-6. HOW TO CHECK THE COMPONENTS <Thermistor feature chart> Low temperature thermistors • Thermistor <Liquid> (TH3) • Thermistor <2-phase pipe> (TH6) • Thermistor <Ambient> (TH7) • Thermistor <Suction> (TH32) Thermistor R0 = 15 kΩ ± 3% B constant = 3480 ± 1% =15exp{3480( 273+t –...
Page 59: Linear Expansion Valve
Linear expansion valve (1) Operation summary of the linear expansion valve • The linear expansion valve opens/closes through stepping motor after receiving the pulse signal from the outdoor controller board. • The valve position can be changed in proportion to the number of the pulse signal. <Connection between the outdoor controller board and the linear expansion valve>...
Page 60 <Output pulse signal and the valve operation> Output Output The output pulse shifts in the following order. (Phase) Opening a valve: 8 → 7 → 6 → 5 → 4 → 3 → 2 → 1 → 8 ø1 ON ON OFF OFF OFF OFF OFF ON Closing a valve: 1 →...
Page 61 (3) How to attach and detach the coil of linear expansion valve PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUY-AK36NL-U1 PUY-AK42NL-U1 <Composition> The linear expansion valve is separable into the main body and the coil as shown in the diagram below. Main body Linear expansion valve...
Page 62 PUZ-AK48NL-U1 PUZ-AK60NL-U1 PUY-AK48NL-U1 PUY-AK60NL-U1 SUZ-AK48NL-U1 SUZ-AK60NL-U1 SUZ-CK48NLH-U1 SUZ-CK60NLH-U1 <Composition> Linear expansion valve is separable into the main body and the coil as shown in the diagram below. Main body Stopper Coil Lead wire <How to detach the coil> Hold the lower part of the main body (shown as A) firmly so that the main body does not move and detach the coil by pulling it upward.
Page 63: Emergency Operation
10-7. EMERGENCY OPERATION (1) When the error codes shown below are displayed on outdoor unit or microprocessor for wired remote controller or indoor unit has a failure, but no other problems are found, emergency operation will be available by setting the emergency operation switch (SWE) to ON at the indoor unit control board and short-circuiting the connector (CN31) on the outdoor controller board.
Page 64 (5) Operation data during emergency operation During emergency operation, no communication is performed with the indoor unit, so the data items needed for operation shall be set to the following values: Operation mode Operation data Remarks COOL HEAT Intake temperature (TH1) 81°F [27°C] 69°F [20.5°C] Indoor ﬂ...
Page 65 10-8. TEST POINT DIAGRAM Outdoor controller circuit board <CAUTION> TEST POINT CNF1 is high voltage. Test operation Pump down CNDM – : Input of low-level sound priority mode Demand control setting – : Input of external contact point Manual defrost, detect history record reset, reset, 21S4...
Page 66 Brief check for power module Outdoor power circuit board If they are short-circuited, they are broken. Measure the resistance at the following points (connectors, etc.). PUZ-AK36NL-U1 PUZ-AK42NL-U1 1. Check for power module PUY-AK36NL-U1 Check diode circuit PUY-AK42NL-U1 R – P1 S –...
Page 67 Brief check for power module Outdoor power circuit board If they are short-circuited, they are broken. Measure the resistance at the following points (connectors, etc.). PUZ-AK48NL-U1 PUZ-AK60NL-U1 1. Check for power module PUY-AK48NL-U1 Check diode circuit PUY-AK60NL-U1 R1 – P1 S1 – P1 R1 – N1 S1 – N1 SUZ-AK48NL-U1 R2 –...
Page 68 10-9. FUNCTIONS OF SWITCHES, CONNECTORS AND JUMPERS (1) Switch functions ■ The black square ( ) indicates a switch position. Type Action by switch operation Switch No. Function Eﬀ ective timing switch When compressor is operating Manual defrost *1 Start Normal in heating operation.
Page 69 Action by the switch operation Type of Switch No. Function Eﬀ ective timing Switch No function — — — Power failure When power supply is Auto recovery No auto recovery automatic recovery 3, 4 No function — — — No function —...
Page 70 <Display function of inspection for outdoor unit> The blinking patterns of both LED1 (green) and LED2 (red) indicate the types of abnormality when it occurs. Types of abnormality can be indicated in details by connecting an optional part ‘A-Control Service Tool (PAC-SK52ST)’ to the connector CNM on the outdoor controller board.
Page 71 Indication Error Outdoor controller board Detailed Error Contents Inspection method reference LED (Green) LED2 (Red) code* page 2 blinking 4 blinking Abnormality of refrigerant circuit Be sure to replace 4-way valve. p.39 Check refrigerant pipes for disconnection or leakage. After the recovery of refrigerant, vacuum dry the whole refrigerant circuit. Refer to “10-5.
Page 72 Indication Error Outdoor controller board Detailed Error Contents Inspection method reference LED (Green) LED2 (Red) code* page 4 blinking 1 blinking Abnormality of room temperature thermistor (TH1) Check if connectors (CN20, CN21, CN29, and CN44) on indoor controller board are not disconnected. Abnormality of pipe temperature Measure resistance value of indoor thermistors.
Page 73 <Outdoor unit operation monitor function> When optional part ‘A-Control Service Tool (PAC-SK52ST)’ is connected to outdoor controller board (CNM) By controlling SW2 on the 'A-Control Service Tool', a 2-digit number or code is displayed on the digital indicator LED1 to indicate the operating status and the meaning of the error code.
Page 74 ■ The black square ( ) indicates a switch position. SW2 setting Display detail Explanation for display Unit Pipe temperature/Liquid (TH3) −58 to 194˚F [−50 to 90˚C] −58 to 194 (When the coil thermistor detects 0˚F [-17°C] or below, “–” and temperature are displayed alternately.) ˚F (Example) When −10˚F [-23°C];...
Page 75 ■ The black square ( ) indicates a switch position. SW2 setting Display detail Explanation for display Unit Operation mode on error occurring Operation mode of when operation stops due to error is displayed by setting SW2 as below. (SW2) Code display 1 2 3 4 5 6...
Page 76 ■ The black square ( ) indicates a switch position. SW2 setting Display detail Explanation for display Unit The number of connected indoor 0 to 4 units (The number of connected indoor units are displayed.) Unit 1 2 3 4 5 6 Capacity setting display Displayed as an outdoor capacity code Capacity...
Page 77 ■ The black square ( ) indicates a switch position. SW2 setting Display detail Explanation for display Unit Indoor setting temperature 62 to 86˚F [17 to 30˚C] 62 to 86 ˚F [˚C] 1 2 3 4 5 6 Outdoor pipe temperature/2-phase −58 to 194˚F [−50 to 90˚C] pipe (TH6) (When the temperature is 0˚F [-17°C] or less, “–”...
Page 78 ■ The black square ( ) indicates a switch position. SW2 setting Display detail Explanation for display Unit DC bus voltage 180 to 500 180 to 500 (When it is 100V or more, hundreds digit, tens digit, and ones digit are displayed alternately.) 1 2 3 4 5 6 Capacity save 0 to 100...
Page 79 ■ The black square ( ) indicates a switch position. SW2 setting Display detail Explanation for display Unit Indoor room temperature (TH1) on 46 to 102˚F [8 to 39°C] error occurring 46 to 102 ˚F [˚C] 1 2 3 4 5 6 Indoor pipe temperature/Liquid −38 to 190˚F [−39 to 88°C] (TH2) on error occurring...
Page 80 SW2 setting Display detail Explanation for display Unit Discharge superheat on error 32 to 491˚F [0 to 255˚C] occurring (When the temperature is 100˚F [37°C] or more, hundreds digit, tens digit, and ones digit are displayed alternately.) 32 to 491 (Example) When 150˚F [65°C];...
Page 81 SW2 setting Display detail Explanation for display Unit Controlling status of compressor The following code will be a help to know the operating operating frequency status of unit. • The tens digit Display Compressor operating frequency control Primary current control Secondary current control •...
Page 82: Easy Maintenance Function
EASY MAINTENANCE FUNCTION 11-1. SMOOTH MAINTENANCE Refer to "15-9. SMOOTH MAINTENANCE" for operation procedure. 11-2. GUIDE FOR OPERATION CONDITION Checkpoints Enter the temperature diﬀ erences between 5, 4, 7, and 8 into the graph given below. Operation state is determined according to the plotted areas on the graph. For data measurements, set the fan speed to "Hi"...
Page 83: Function Setting
FUNCTION SETTING 12-1. UNIT FUNCTION SETTING BY THE REMOTE CONTROLLER Each function can be set as necessary using the remote controller. The setting of function for each unit can only be done by the remote controller. Select function available from the table 1. (1) Functions available when setting the unit number to 00 (Select 00 referring to setting the indoor unit number.) <Table 1>...
Page 84: Monitoring The Operation Data By The Remote Controller
13 MONITORING THE OPERATION DATA BY THE REMOTE CONTROLLER 13-1. HOW TO "MONITOR THE OPERATION DATA" Refer to "15-10. REQUEST CODE" when monitoring the operation data. 13-2. REQUEST CODE LIST Description Request content Unit Remarks (Display range) Operation state Refer to 13-2-1. Detail Contents in Request Code. Compressor-Operating current (rms) 0-50 Compressor-Accumulated operating time...
Page 85 Description Request content Unit Remarks (Display range) 50 Indoor unit-Control state Refer to 13-2-1. Detail Contents in Request Code. 51 Outdoor unit-Control state Refer to 13-2-1. Detail Contents in Request Code. 52 Compressor-Frequency control state Refer to 13-2-1. Detail Contents in Request Code. 53 Outdoor unit-Fan control state Refer to 13-2-1.
Page 86 Description Request content Unit Remarks (Display range) Displays error history. (" - - " is displayed if no 103 Error history 1 (latest) Code history is present.) Displays error history. (" - - " is displayed if no 104 Error history 2 (second to last) Code history is present.) Displays error history.
Page 87 Description Request content Unit Remarks (Display range) Indoor-Fan operating time 0–9999 1 hour (After ﬁ lter is reset) Indoor-Total operating time 0–9999 10 hours (Fan motor ON time) 157 Indoor fan output value (Sj value) 0–255 Fan control data For indoor fan phase control Indoor fan output value "00 **"...
Page 88 13-2-1. Detail Content in Request Code Request code Example) Request code "004" Ref.address Request code Discharge temperature 156°F Refrigerant address "00" Request: SELECT Cursor Operation state (Request code: "0") Data display Relay output state Power currently supplied Display Compressor 4-way valve Solenoid valve to compressor Relay output state...
Page 89 Fan control state (Request code: "53") Data display Fan step correction value by heatsink temperature overheat prevention control Fan step correction value by cool condensation temperature overheat prevention control Display Correction valve - (minus) Actuator output state (Request code: "54") Data display Actuator output state 1 Actuator output state 2...
Page 90 Contact demand capacity (Request code: "61") Data display Setting content Setting Display Setting value SW7-1 SW7-2 Setting content 100% External input state (Request code: "62") Data display Input state ●: Input position Contact demand Silent mode Display Spare 1 input Spare 2 input input input...
Page 91: Disassembly Procedure
See the table on the right. No. 2 J42 disconnected No. 3 J41, J42 disconnected DISASSEMBLY PROCEDURE 14-1. PUZ-AK36NL-U1 PUZ-AK42NL-U1 PUY-AK36NL-U1 PUY-AK42NL-U1 : Indicates the visible parts in the photos/ﬁ gures. : Indicates the invisible parts in the photos/ﬁ gures.
Page 92 OPERATING PROCEDURE PHOTOS/FIGURES 2. Removing the fan motor (MF1, MF2) Photo 2 Photo 3 (1) Remove the service panel. (See Photo 1) Propeller Fan motor fixing screws (2) Remove the top panel. (See Photo 1) (3) Remove the fan grille. (See Photo 1) (4) Remove a nut (for right handed screw of M6) to detach the propeller.
Page 93 OPERATING PROCEDURE PHOTOS/FIGURES 4. Removing the thermistor <2-phase pipe> (TH6) Photo 5 (1) Remove the service panel. (See Photo 1) (2) Remove the top panel. (See Photo 1) Clamp Electrical (3) Disconnect the connectors TH6 (red), on the controller parts box circuit board in the electrical parts box.
Page 94 OPERATING PROCEDURE PHOTOS/FIGURES 7. Removing the 4-way valve coil (21S4) and linear expan- Photo 8 sion valve coil (LEV-A, B) (1) Remove the service panel. (See Photo 1) (2) Remove the top panel. (See Photo 1) 4-way valve 4-wa 4-way valve coil Removing the 4-way valve coil fixing screw (3) Remove 4-way valve coil fixing screw (M5 ×...
Page 95 OPERATING PROCEDURE PHOTOS/FIGURES 9. Removing linear expansion valve Photo 9 (1) Remove the service panel. (See Photo 1) (2) Remove the top panel. (See Photo 1) (3)Remove the electrical parts box. (See Photo 4) (4)Remove the cover panel front. (Refer to procedure 8) (5)Remove the cover panel rear.
Page 96 OPERATING PROCEDURE PHOTOS/FIGURES 10. Removing the high pressure switch (63H) Photo 10 (1) Remove the service panel. (See photo 1) (2) Remove the top panel. (See photo 1) (3) Remove the electrical parts box. (See Photo 4) (4) Remove the cover panel front. (Refer to procedure 8) (5) Remove the cover panel rear.
Page 97 OPERATING PROCEDURE PHOTOS/FIGURES 12. Removing the compressor (MC) Photo 12 (1) Remove the service panel. (See Photo 1) (2) Remove the top panel. (See Photo 1) (3) Remove the screws on the front panel (2 screws on the top, 3 screws on the bottom, and 2 screws on the right). Then slide the front panel upward for removal.
Page 98 OPERATING PROCEDURE PHOTOS/FIGURES 13. Removing the power receiver Photo 15 (1) Remove the service panel. (See Photo 1) (2) Remove the top panel. (See Photo 1) (3) Remove the 2 front cover panel fixing screws (5 × 12) and remove the front cover panel. (See Photo 4) (4) Remove the 2 back cover panel fixing screws (5 ×...
Page 99 14-2. PUZ-AK48NL-U1 PUZ-AK60NL-U1 PUY-AK48NL-U1 PUY-AK60NL-U1 SUZ-AK48NL-U1 SUZ-AK60NL-U1 SUZ-CK48NLH-U1 SUZ-CK60NLH-U1 : Indicates the visible parts in the photos/ﬁ gures. : Indicates the invisible parts in the photos/ﬁ gures. Note: The red markings indicate that ﬂ ammable refrigerant is charged. If you remove the markings, put them back to the original position after the work is completed.
Page 100 OPERATING PROCEDURE PHOTOS/FIGURES 4. Removing the thermistor <2-phase pipe> (TH6) Photo 20 (1) Remove the service panel. (See Photo 16) (2) Remove the top panel. (See Photo 16) Electrical Clamp parts box (3) Disconnect the connectors TH6 and TH7 (red) on the controller circuit board in the electrical parts box.
Page 101 OPERATING PROCEDURE PHOTOS/FIGURES 7. Removing the 4-way valve coil (21S4) and linear expan- Photo 23 Linear expansion sion valve coil (LEV-A, B) valve coil (LEV-A) (1) Remove the service panel. (See Photo 16) (2) Remove the top panel. (See Photo 16) Removing the 4-way valve coil 4-way valve (3) Remove the 4-way valve coil fixing screw (M5 ×...
Page 102 OPERATING PROCEDURE PHOTOS/FIGURES 9. Removing linear expansion valve Photo 24 (1) Remove the service panel. (See Photo 16) (2) Remove the top panel. (See Photo 16) (3) Remove the electrical parts box. (See Photo 19) (4) Remove the cover panel front. (Refer to procedure 8) (5) Remove the cover panel rear.
Page 103 OPERATING PROCEDURE PHOTOS/FIGURES 10. Removing the high pressure switch (63H) Photo 25 (1) Remove the service panel. (See photo 16) (2) Remove the top panel. (See photo 16) (3) Remove the electrical parts box. (See Photo 19) High pressure (4) Remove the cover panel front. (Refer to procedure 8) switch (63H) (5) Remove the cover panel rear.
Page 104 OPERATING PROCEDURE PHOTOS/FIGURES 12. Removing the compressor (MC) Photo 27 (1) Remove the service panel. (See Photo 16) (2) Remove the top panel. (See Photo 16) (3) Remove the screws on the front panel (2 screws on the top, 3 screws on the bottom, and 2 screws on the right). Then slide the front panel upward for removal.
Page 105 OPERATING PROCEDURE PHOTOS/FIGURES 13. Removing the power receiver Photo 30 (1) Remove the service panel. (See Photo 16) (2) Remove the top panel. (See Photo 16) (3) Remove the 2 front cover panel fixing screws (5 × 12) and remove the front cover panel. (See Photo 19) (4) Remove the 2 back cover panel fixing screws (5 ×...
Page 106: Remote Controller Functions
REMOTE CONTROLLER 15-1. Remote controller functions 15-1-1. PAR-42MAAUB Controller interface Main display Main menu Main Main menu Room Energy saving Cool Set temp. Auto Mode Temp. Menu screen Function guide RETURN SELECT Operation MENU Vane·Louver·Vent. (Lossnay) HOLD High power Comfort Main menu: RETURN Cursor Function buttons...
Page 107 Display The main display can be displayed in 2 diﬀ erent modes: [Full] and [Basic]. The initial setting is [Full]. To switch to [Basic] mode, change the setting on the [Main display] setting. (Refer to operation manual included with remote controller.) All icons are displayed for explanation.
Page 108: Menu Structure
Menu structure Press [MENU] button. Move the cursor to the desired item with the F1 and F2 buttons, and press [SELECT] button Note: • Not all functions are available on all models of indoor units. [Vane · Louver · Vent. (Lossnay)] [Operation] [High power] [Manual vane angle]...
Page 109: Main Menu List
Main menu list [Main menu] Setting and display items Setting details [Operation] [Vane · Louver · Vent. (Lossnay)] Use to set the vane angle. • Select a desired vane setting. Use to turn on/oﬀ the louver. • Select a desired setting from [On] and [Oﬀ ]. Use to set the amount of ventilation.
Page 110 [Main menu] Setting and display items Setting details [Service] [Test run] Select [Test run] from [Service menu] to bring up the [Test run menu]. • [Test run] • [Drain pump test run] [Input maintenance info.] Select [Input maintenance Info.] from [Service menu] to bring up [Maintenance information] screen.
Page 111 15-1-2. PAR-FL32MA Controller interface Transmission area Transmission indicator Remote controller display Timer indicator *For explanation purposes, all of the items that appear in the display are shown. *All items are displayed when the Reset button is pressed. Operation areas ON/OFF button Temperature setting buttons Timer Off button Fan Speed button (Changes fan speed)
Page 112: Error Information
15-1-3. PAR-SL101A-E Controller interface Transmission area Remote controller display Set Temperature buttons OFF/ON button Mode button (Changes operation mode) Fan Speed button (Changes fan speed) Airflow button (Changes up/down airflow direction) i-see button Timer ON button Menu button Timer OFF button SET/SEND button Weekly timer ON/OFF button CANCEL button...
Page 113: Service Menu
Error information Error information Error code Contact information Error unit Dealer Unit#1 Time Occurred 2/ 1 4:48 Model name Serial No. Reset error: Reset button Reset error: Reset button Page Reset Page Reset blinks SELECT MENU RETURN HOLD 2. Reset the error •...
Page 114 Main Main menu Service menu Enter maintenance password Service Select: SELECT Cursor SELECT MENU RETURN HOLD 3. Enter the current maintenance password (4 numerical digits). Move the cursor to the digit you want to change with F1 or F2 button and set each number (0 through 9) with F3 or F4 button.
Page 115: Test Run Operation
■ Test run operation 1. Press F1 button to go through the operation modes in the order of [Cool] and [Heat]. Cooling mode: Check the cold air blows out. Heating mode: Check the heat blows out. 2. Check the operation of the outdoor unit’s fan. 3.
Page 116 TEST RUN TEMP ON/OFF AUTO STOP AUTO START MODE VANE CHECK LOUVER TEST RUN RESET CLOCK 15-4-3. PAR-SL101A-E Operating instructions 1. Stop the air conditioner • Press button to stop the air conditioner. • If the weekly timer is enabled ( is shown on the display), press button to disable it ( is oﬀ...
Page 117 15-5. [Function setting] 15-5-1. PAR-42MAAUB Operating instructions 1. Open the [Function setting] screen. • Select [Service] from [Main menu], and press [SELECT] button. • Select [Setting] from [Service menu], and press [SELECT] button. • Select [Function setting] and press [SELECT] button. [Function setting] screen will appear.
Page 118 Function setting Ref. address Grp. Mode 1 Mode 2 Mode 3 Mode 4 Request: SELECT Cursor Cursor SELECT MENU RETURN HOLD 5. Complete the function settings • When the settings are completed, press [SELECT] button to send the setting data from the remote controller to the indoor units.
Page 119 15-5-2. PAR-FL32MA Functions can be selected with the wireless remote controller. Function selection using wireless remote controller is available only for refrigerant system with wireless function. Refrigerant address cannot be speciﬁ ed by the wireless remote controller. An example of function selection ﬂ ow An example of a function selection ﬂ...
Page 120 Notes: • If a mode number that cannot be recognized by the unit is entered, 3 beeps of 0.4 seconds will be emitted. Reenter the mode number. • If the signal was not received by the sensor, no beep or a ˝double beep˝ will be emitted. Reenter the mode number. 4.
Page 121: Error History
4. Select the setting number. • Press button to change the setting number C. • Direct the wireless remote controller toward the receiver of the indoor unit and press button. 5. Select multiple functions continuously. • Repeat the steps 3 and 4 to change multiple function settings continuously. 6.
Page 122: Self-Diagnosis
3. 16 error history records will appear. 4 records are shown per page, and the top record on the ﬁ rst page indicates the latest error record. Error history Error Unt# dd/mm/yy Check menu: RETURN Delete Page 4. Delete the error history. •...
Page 123 3. Reset the error history. • Press F4 button [Reset]. A conﬁ rmation screen will appear to ask you if you want to delete the error history. • Press F4 button [OK] to delete the error history. [Request rejected] will appear if deletion fails. [Unit not exist] will appear if no indoor unit is assigned to the entered address.
Page 124 15-7-3. PAR-SL101A-E Operating instructions 1. Press button to stop the air conditioner. If the weekly timer is enabled ( is shown on the display), press button to disable it ( is oﬀ ). 2. Press button for 5 seconds. appears and the unit starts the self-check mode. CHECK 3.
Page 125 Notes: • To cancel the remote controller check and exit [Remote controller check] menu screen, press [MENU] or [RETURN] button. • The remote controller will not reboot itself. Remote controller check Start checking? Begin: SELECT SELECT MENU RETURN HOLD 3. Check the result of the remote controller check. See the following descriptions for each result: [OK]: •...
Page 126 15-9. [Smooth Maintenance] Operating instructions 1. Go to [Smooth maintenance] screen. • Select [Service] from [Main menu], and press [SELECT] button. • Select [Check] with F1 or F2 button, and press [SELECT] button. • Select [Smooth maintenance] with F1 or F2 button, and press [SELECT] button. Check menu Error history Diagnosis...
Page 127 Twin Refrigerant Refrigerant address = 00 address = 00 Outdoor unit Outdoor unit Indoor unit Indoor unit Indoor unit Remote Remote controller controller • Multi refrigerant system (group control) Up to 16 refrigerant systems (16 outdoor units) can be connected as a group by 1 remote controller. To check or set the refrigerant addresses.
Page 128 15-10. [Request code] Details on the operation data including each thermistor temperature and error history can be conﬁ rmed with the remote control- ler. 1. Go to [Request code] screen. • Select [Service] from [Main menu], and press [SELECT] button. •...
Page 129 T1 SPECIFICATIONS CONNECTED TO INDOOR UNIT Model name Indoor unit PLA-AE36NL PLA-AE42NL PLA-AE48NL Outdoor unit PUZ-AK36NL PUZ-AK42NL PUZ-AK48NL Cooling at 95°F Max. Capacity Btu/h 36,600 42,500 49,000 Rated Capacity Btu/h 36,000 42,000 48,000 Min. Capacity Btu/h 14,300 15,400 17,000 Total Input...
Page 130 Model name Indoor unit PLA-AE36NL PLA-AE42NL PLA-AE48NL Outdoor unit PUY-AK36NL PUY-AK42NL PUY-AK48NL Cooling at 95°F Max. Capacity Btu/h 36,600 42,500 49,000 Rated Capacity Btu/h 36,000 42,000 48,000 Min. Capacity Btu/h 14,300 15,400 17,000 Total Input 2,620 3,500 4,573 EER2 Btu/h/W 13.7 12.0 10.4...
Page 131 Model name Indoor unit PKA-AK36NL Outdoor unit PUZ-AK36NL Cooling at 95°F Max. Capacity Btu/h 36,000 Rated Capacity Btu/h 33,400 Min. Capacity Btu/h 13,200 Total Input 2,770 EER2 Btu/h/W 12.0 Moisture Removal Pints/h 12.0 0.61 Power factor SEER2 Btu/h/W 20.3 Heating at 47°F...
Page 132 Model name Indoor unit PKA-AK36NL Outdoor unit PUY-AK36NL Cooling at 95°F Max. Capacity Btu/h 36,000 Rated Capacity Btu/h 33,400 Min. Capacity Btu/h 13,200 Total Input 2,770 EER2 Btu/h/W 12.0 Moisture Removal Pints/h 12.0 0.61 Power factor SEER2 Btu/h/W 20.3 Heating at 47°F Max.
Page 133 Model name Indoor unit PCA-AK36NL PCA-AK42NL Outdoor unit PUZ-AK36NL PUZ-AK42NL Cooling at 95°F Max. Capacity Btu/h 37,000 42,500 Rated Capacity Btu/h 36,000 42,000 Min. Capacity Btu/h 13,500 13,600 Total Input 2,930 3,820 EER2 Btu/h/W 12.2 10.9 Moisture Removal Pints/h 12.7 15.4...
Page 134 Model name Indoor unit PCA-AK36NL PCA-AK42NL Outdoor unit PUY-AK36NL PUY-AK42NL Cooling at 95°F Max. Capacity Btu/h 37,000 42,500 Rated Capacity Btu/h 36,000 42,000 Min. Capacity Btu/h 13,500 13,600 Total Input 2,930 3,820 EER2 Btu/h/W 12.2 10.9 Moisture Removal Pints/h 12.7 15.4 0.62 0.60...
Page 135 Model name Indoor unit PEAD-AA36NL PEAD-AA42NL Outdoor unit PUZ-AK36NL PUZ-AK42NL Cooling at 95°F Max. Capacity Btu/h 37,000 44,000 Rated Capacity Btu/h 36,000 42,000 Min. Capacity Btu/h 13,500 14,200 Total Input 2,860 3,760 EER2 Btu/h/W 12.5 11.1 Moisture Removal Pints/h 11.8 10.8...
Page 136 Model name Indoor unit PEAD-AA36NL PEAD-AA42NL Outdoor unit PUY-AK36NL PUY-AK42NL Cooling at 95°F Max. Capacity Btu/h 37,000 44,000 Rated Capacity Btu/h 36,000 42,000 Min. Capacity Btu/h 13,500 14,200 Total Input 2,860 3,760 EER2 Btu/h/W 12.5 11.1 Moisture Removal Pints/h 11.8 10.8 0.65 0.72...
Page 137 Model name Indoor unit PVA-AA36NL PVA-AA42NL Outdoor unit PUZ-AK36NL PUZ-AK42NL Cooling at 95°F Max. Capacity Btu/h 37,000 44,000 Rated Capacity Btu/h 36,000 42,000 Min. Capacity Btu/h 13,400 14,100 Total Input 2,960 3,760 EER2 Btu/h/W 12.1 11.1 Moisture Removal Pints/h 12.1 12.5...
Page 138 Model name Indoor unit PVA-AA36NL PVA-AA42NL Outdoor unit PUY-AK36NL PUY-AK42NL Cooling at 95°F Max. Capacity Btu/h 37,000 44,000 Rated Capacity Btu/h 36,000 42,000 Min. Capacity Btu/h 13,400 14,100 Total Input 2,960 3,760 EER2 Btu/h/W 12.1 11.1 Moisture Removal Pints/h 12.1 12.5 0.64 0.68...
Page 139 Model name Indoor unit PAA-BA36NL PAA-BA42NL Outdoor unit PUZ-AK36NL PUZ-AK42NL Cooling at 95°F Max. Capacity Btu/h 36,000 43,000 Rated Capacity Btu/h 32,000 42,000 Min. Capacity Btu/h 16,200 15,400 Total Input 2720 4,040 EER2 Btu/h/W 11.7 10.3 Moisture Removal Pints/h 11.1 0.78...
Page 140 Model name Indoor unit PAA-BA36NL PAA-BA42NL Outdoor unit PUY-AK36NL PUY-AK42NL Cooling at 95°F Max. Capacity Btu/h 36,000 43,000 Rated Capacity Btu/h 32,000 42,000 Min. Capacity Btu/h 16,200 15,400 Total Input 2,720 4,040 EER2 Btu/h/W 11.7 10.3 Moisture Removal Pints/h 11.1 0.78 0.72 Power factor...
Page 141 Model name Indoor unit PAA-CA36NL PAA-CA42NL Outdoor unit PUZ-AK36NL PUZ-AK42NL Cooling at 95°F Max. Capacity Btu/h 36,000 43,000 Rated Capacity Btu/h 32,000 42,000 Min. Capacity Btu/h 16,200 15,400 Total Input 2,720 4,040 EER2 Btu/h/W 11.7 10.3 Moisture Removal Pints/h 11.1 0.78...
Page 142 Model name Indoor unit PAA-CA36NL PAA-CA42NL Outdoor unit PUY-AK36NL PUY-AK42NL Cooling at 95°F Max. Capacity Btu/h 36,000 43,000 Rated Capacity Btu/h 32,000 42,000 Min. Capacity Btu/h 16,200 15,400 Total Input 2,720 4,040 EER2 Btu/h/W 11.7 10.3 Moisture Removal Pints/h 11.1 0.78 0.72 Power factor...
Page 143 T2 PERFOMANCE CHART T2-1. INVERTER T2-1-1. COOLING CAPACITY PLA-AE36NL/PUZ-AK36NL/ PUY-AK36NL CAPACITY (Btu/h): 36,000 INPUT (kW): 2.62 SHF: 0.76 Indoor Indoor Indoor Indoor Outdoor intake air °C/°F D.B. intake air intake air intake air intake air 20/68 25/77 30/86 35/95 40/104 46/115 D.B.(°C) D.B.(°F) W.B.(°C) W.B.(°F)
Page 144 3.68 58,556 42,512 0.73 4.07 54,971 39,909 0.73 4.43 51,386 37,306 0.73 4.76 47,801 34,703 0.73 4.99 43,817 31,811 0.73 5.14 PKA-AK36NL/PUZ-AK36NL/ PUY-AK36NL CAPACITY (Btu/h): 33,400 INPUT (kW): 2.77 SHF: 0.61 Indoor Indoor Indoor Indoor Outdoor intake air °C/°F D.B.
Page 145 PCA-AK36NL/PUZ-AK36NL/ PUY-AK36NL CAPACITY (Btu/h): 36,000 INPUT (kW): 2.93 HF: 0.62 Indoor Indoor Indoor Indoor Outdoor intake air °C/°F D.B. intake air intake air intake air intake air 20/68 25/77 30/86 35/95 40/104 46/115 D.B.(°C) D.B.(°F) W.B.(°C) W.B.(°F) SHC SHF P.C.
Page 146 PEAD-AA36NL/PUZ-AK36NL/ PUY-AK36NL CAPACITY (Btu/h): 36,000 INPUT (kW): 2.86 SHF: 0.65 Indoor Indoor Indoor Indoor Outdoor intake air °C/°F D.B. intake air intake air intake air intake air 20/68 25/77 30/86 35/95 40/104 46/115 D.B.(°C) D.B.(°F) W.B.(°C) W.B.(°F) SHC SHF P.C.
Page 147 PVA-AA36NL/PUZ-AK36NL/ PUY-AK36NL CAPACITY (Btu/h): 36,000 INPUT (kW): 2.96 HF: 0.64 Indoor Indoor Indoor Indoor Outdoor intake air °C/°F D.B. intake air intake air intake air intake air 20/68 25/77 30/86 35/95 40/104 46/115 D.B.(°C) D.B.(°F) W.B.(°C) W.B.(°F) SHC SHF P.C.
Page 148 PAA-B/CA36NL/PUZ-AK36NL/ PUY-AK36NL CAPACITY (Btu/h): 32,000 INPUT (kW): 2.72 HF: 0.78 Indoor Indoor Indoor Indoor Outdoor intake air °C/°F D.B. intake air intake air intake air intake air 20/68 25/77 30/86 35/95 40/104 46/115 D.B.(°C) D.B.(°F) W.B.(°C) W.B.(°F) SHC SHF P.C.
Page 149 T2-1-2. HEATING CAPACITY PUZ-AK·NL Indoor Indoor Outdoor intake air °C/°F W.B. Capacity Input Model Name intake air intake air -10/14 -5/23 0/32 5/41 10/50 15/59 Btu/h D.B.(°C) D.B.(°F) P.C. P.C. P.C. P.C. P.C. P.C. 24,500 1.63 29,837 1.94 32,522 2.08 37,921 2.33 43,351...
Page 150: Cooling Performance Curve
T3 PERFORMANCE CURVES FOR THE COMBINATION OF OUTDOOR UNIT PUZ-AK36/42/48/60NL SUZ-AK48/60NL SUZ-CK48/60NLH Cooling performance curve INDOOR W.B. 22°C (72° F) 20°C (68° F) 18°C (64° F) 16°C (61° F) (0° F) (32° F) (50° F) (68° F) (86° F) (104° F) (115°...
Page 151 FOR THE COMBINATION OF OUTDOOR UNIT PUY-AK36/42/48/60NL Cooling performance curve INDOOR W.B. 22°C (72°F) 20°C (68°F) 18°C (64°F) 16°C (61°F) -28.9 -18* (-40°F) (-20°F) (0°F) (32°F) (50°F) (68°F) (86°F) (104°F) (115°F) OUT DOOR D.B. (°C) INDOOR W.B. 22°C (72°F) 20°C (68°F) 18°C (64°F) 16°C (61°F) -18*...
Page 152: Heating Performance Curve
Heating performance curve Correcting the capacity line influenced by frosting INDOOR Not correcting the capacity line influenced by frosting D.B.( C) In some cases, heating operation cannot be 15 (59 F) conducted with the maximum frequency in the 20 (68 F) area below the slanting line.
Page 153 T4 CORRECTION FACTORS T4-1. COOLING CAPACITY CORRECTION FACTORS Refrigerant piping length (one way) Outdoor unit 15ft (5m) 30ft (9m) 50ft (15m) 70ft (21m) 100ft (30m) 130ft (40m) 165ft (50m) 200ft (61m) 225ft (69m) 245ft (75m) PUZ-AK36/42NL 1.000 0.987 0.971 0.954 0.929 0.904 0.875...
Page 154 T4-4. ADDITION OF REFRIGERANT • Additional charging is not necessary if the pipe length does not exceed 30 m 100 ft. • Especially, additional charging is not necessary if the pipe length does not exceed 30 m 100 ft when connected to the A-COIL indoor unit (PAA).
Page 155 T5 PART LOAD CAPACITY CHART PLA-AE36NL Rated PUZ-AK36NL PUY-AK36NL Q(Btu/h): 36000 1) COOLING 2620 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 36,893 36,288 27,216 18,144 14,414 34,038...
Page 156 PLA-AE36NL Rated PUZ-AK36NL Q(Btu/h): 38000 2) HEATING 2470 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 51,052 48,499 36,375 24,250 16,592 52,532...
Page 157 PKA-AK36NL Rated PUZ-AK36NL PUY-AK36NL Q(Btu/h): 33400 1) COOLING 2770 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 36,288 33,667 25,250 16,834 13,306 33,480 31,062 23,297 15,531 12,276 31,428...
Page 158 PKA-AK36NL Rated PUZ-AK36NL Q(Btu/h): 38000 2) HEATING 2690 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 51,052 48,499 36,375 24,250 16,847 52,532...
Page 159 PEAD-AA36NL Rated PUZ-AK36NL PUY-AK36NL Q(Btu/h): 36000 1) COOLING 2860 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 37,296 36,288 27,216 18,144 13,608 34,410 33,480 25,110 16,740 12,555 32,301...
Page 160 PEAD-AA36NL PUZ-AK36NL Rated Q(Btu/h): 38000 2) HEATING 2610 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 51,052 48,499 36,375 24,250 16,847 52,532...
Page 161 PVA-AA36NL Rated PUZ-AK36NL PUY-AK36NL Q(Btu/h): 36000 2960 1) COOLING Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 37,296 36,288 27,216 18,144 13,507 34,410 33,480 25,110 16,740 12,462 32,301...
Page 162 PVA-AA36NL Rated PUZ-AK36NL Q(Btu/h): 38000 2) HEATING 2660 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 51,052 48,499 36,375 24,250 16,975 52,532...
Page 163 PAA-BA36NL PAA-CA36NL Rated PUZ-AK36NL PUY-AK36NL Q(Btu/h): 32000 1) COOLING 2720 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 36,288 32,256 24,192 16,330 33,480 29,760 22,320 15,066 31,428 27,936...
Page 164 PAA-BA36NL PAA-CA36NL Rated PUZ-AK36NL Q(Btu/h): 38000 2) HEATING 3030 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 53,605 48,499 36,375 24,505 55,159...
Page 165 PLA-AE42NL Rated PUZ-AK42NL PUY-AK42NL Q(Btu/h): 42000 1) COOLING 3500 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 42,840 42,336 31,752 21,168 15,523 39,525 39,060 29,295 19,530 14,322 37,103 36,666 27,500 18,333 13,444...
Page 166 PLA-AE42NL Rated PUZ-AK42NL Q(Btu/h): 45000 2) HEATING 3230 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 63,304 57,434 43,075 28,717 16,847 65,140 59,099 44,324 29,549 17,336...
Page 167 PCA-AK42NL Rated PUZ-AK42NL PUY-AK42NL Q(Btu/h): 42000 1) COOLING 3820 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 42,840 42,336 31,752 21,168 13,709 39,525 39,060 29,295 19,530 12,648 37,103 36,666 27,500 18,333 11,873...
Page 168 PCA-AK42NL Rated PUZ-AK42NL Q(Btu/h): 45000 2) HEATING 3460 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 63,049 57,434 43,075 28,717 16,975 64,877 59,099 44,324 29,549 17,467...
Page 169 PEAD-AA42NL Rated PUZ-AK42NL PUY-AK42NL Q(Btu/h): 44000 1) COOLING 3970 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 42,336 44,352 33,264 22,176 14,314 39,060 40,920 30,690 20,460 13,206 36,666 38,412 28,809 19,206 12,397...
Page 170 PEAD-AA42NL Rated PUZ-AK42NL Q(Btu/h): 45000 2) HEATING 3400 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 63,432 57,434 43,075 28,717 16,975 65,271 59,099 44,324 29,549 17,467...
Page 171 PVA-AA42NL Rated PUZ-AK42NL PUY-AK42NL Q(Btu/h): 42000 1) COOLING 3760 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 44,352 42,336 31,752 21,168 14,213 40,920 39,060 29,295 19,530 13,113 38,412 36,666 27,500 18,333 12,309...
Page 172 PVA-AA42NL Rated PUZ-AK42NL Q(Btu/h): 46000 2) HEATING 3420 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 63,432 58,710 44,032 29,355 16,975 65,271 60,412 45,309 30,206 17,467...
Page 173 PAA-BA42NL PAA-CA42NL Rated PUZ-AK42NL PUY-AK42NL Q(Btu/h): 42000 4040 1) COOLING Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 43,344 42,336 31,752 21,168 15,523 39,990 39,060 29,295 19,530 14,322 37,539 36,666 27,500 18,333...
Page 174 PAA-BA42NL PAA-CA42NL Rated PUZ-AK42NL Q(Btu/h): 46000 2) HEATING 4030 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 63,815 58,710 44,032 29,355 24,122 65,665 60,412 45,309 30,206...
Page 175 PLA-AE48NL Rated PUZ-AK48NL PUY-AK48NL Q(Btu/h): 48000 1) COOLING 4573 Indoor W.B. 71°F / 21.7°C 67°F / 19.4°C 63°F / 17.2°C Outdoor D.B. Rated Rated Rated (°F) (°C) 46.1 Q(Btu/h) 49,392 48,384 36,288 24,192 17,136 45,570 44,640 33,480 22,320 15,810 42,777 41,904 31,428 20,952 14,841...
Page 176 PLA-AE48NL Rated PUZ-AK48NL Q(Btu/h): 54000 2) HEATING 4510 Indoor D.B. 77°F / 25°C 68°F / 20°C 59°F / 15°C Outdoor W.B. Max Rated 75% Max Rated 75% Max Rated 75% (°F) (°C) 18.3 Q(Btu/h) 76578 68920 51690 34460 21187 78798 70918 53189 35459 21801...
Page 177 T6 POSITION OF THE CENTER OF GRAVITY Unit: inch (mm) Model name PUZ-AK36/42NL 17-1/3 (440) 7-1/2 (190) 23-2/5 (594) PUY-AK36/42NL PUZ-AK48/60NL PUY-AK48/60NL 16-2/9 (412) 6 (150) 23-1/2 (596) SUZ-AK48/60NL OCD869...
Page 178 OPTIONAL PARTS Optional Parts List for Indoor [P-series] P series Wall-mounted Ceiling-suspended Series Name PAC-SH59KF-E PAC-SH89KF-E ● ● High-efﬁ ciency Filter Element PAC-SH90KF-E ● ● PAC-KE92TB-E PAC-KE93TB-E Filter Box PAC-KE94TB-E Decoration panel with 3D I-see sensor PLP-41EAEU Air outlet shutter Plate PAC-SJ37SP-E Multi-functional Casement PAC-SJ41TM-E...
Page 179 Optional Parts List for Indoor [P-series] P series 4-way Cassette Ceiling-concealed Multi position A-Coil Series Name PEAD 12 18 24 30 36 42 48 9 12 18 24 30 36 18 24 30 36 42 PAC-SH59KF-E ● ● ● ● ●...
Page 180 Optional Parts List for Outdoor [S-series] Heat pump Hyper heating Series Name AK48NL AK60NL AK24NLHZ AK30NLHZ AK36NLHZ AK42NLHZ AK48NLHZ PAC-SJ07SG-E PAC-SG59SG-E Air Outlet Guide PAC-SH96SG-E ● ● ● ● ● ● ● PAC-SJ06AG-E PAC-SH63AG-E Air Protection Guide PAC-SH95AG-E ● ● ●...
Page 181: Table Of Contents
Optional Parts Optional parts for indoor units Optional parts for outdoor units 1. PAC-SH59KF-E ·······························229 1. PAC-SJ07SG-E ·······························345 2. PAC-SH89/90KF-E ···························231 2. PAC-SG59SG-E ······························348 3. PAC-KE92/93/94TB-E ······················232 3. PAC-SH96SG-E ······························350 4. PLP-41EAEU ··································236 4. PAC-SJ06AG-E ·······························352 5. PAC-SJ37SP-E ·······························240 5. PAC-SH63AG-E ······························354 6.
Page 182: High-Effi Ciency Filter Element
High-efﬁ ciency Filter Element PAC-SH59KF-E Descriptions Photo High-efﬁ ciency Filter is part that remove dust in air. PAC-SH53TM-E (Multi-function Casement) is required for in- stallation. Applicable Models PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations Dust collection efﬁ ciency Colorimetric method 65% (JIS 11 class) Filter element ,aterial Electrostatic polyoleﬁ...
Page 183: Replacement Period
High-efﬁ ciency Filter Element PAC-SH59KF-E How to Use / How to Install 1 Checking packed parts (The unit is provided with this manual and following parts in the box.) Part #, NOTICE High-efficiency filter element Name Q'ty In case that the High-efficiency filter element is installed, it should be installed on the Multi-functional casement which is option.
Page 184: Pac-Sh89/90Kf
High-efﬁ ciency Filter Element PAC-SH89/90KF-E Descriptions Photo • High-efficiency Filter is part that remove dust in air. Dust collection efﬁ ciency: 70% (Weighing method) • It is the best for the air-conditioning of the stove where a lot of going of the person in and out exists. Applicable Models and Speciﬁ...
Page 185: Filter Box
Filter Box PAC-KE92/93/94TB-E Photo Applicable Models Model PAC-KE92TB-E PAC-KE93TB-E PAC-KE94TB-E PEAD-AA12NL PEAD-AA24NL PEAD-AA36NL Applicable models PEAD-AA18NL PEAD-AA30NL PEAD-AA42NL OCD869...
Page 186 Filter Box PAC-KE92/93/94TB-E How to Use / How to Install 1 Confirming the Supplied Parts 1. Model names and applicable models Unit : inch [mm] Applicable filter Model name Applicable types Size Q'ty PEAD-AA12NL 35-7/16 × 9-1/2 PAC-KE92TB-E PEAD-AA18NL [900 240] PEAD-AA24NL 21-21/32 ×...
Page 187: Installing The Filter
Filter Box PAC-KE92/93/94TB-E 2. Install the filter box on the indoor unit with the supplied screws. (Fig. 2-2) PAC-KE92/93TB-E ········10 pcs. PAC-KE94TB-E ·············12 pcs. Note) Failure to firmly tightened the screws will cause air leak- age. Make sure the screws are firmly tightened. Filter box Indoor unit Fig.2-2...
Page 188: Final Check
Filter Box PAC-KE92/93/94TB-E Fig.3-1-3 CAUTION Never place your hand inside the filter box during maintenance. If the filter tabs become caught when the filter is removed for maintenance, use a long stick or similar item to remove the remaining filter. 2.
Page 189: Plp-41Eaeu
Decoration panel with 3D i-see sensor PLP-41EAEU Descriptions Figure This panel is only for ceiling cassette type indoor units with i-see sensor. Applicable Models PLA-AE12/18/24/30/36/42/48NL Dimensions Unit : inch Corner pocket Air intake hole Ceiling Vane motor Indoor unit Grille Air intake grille i-see sensor corner panel Air outlet hole...
Page 190: Installing The Grille
Decoration panel with 3D i-see sensor PLP-41EAEU How to Use / How to Install 1. Checking the contents (Fig. 1) • This kit contains this manual and the following parts. Accessory name Q’ty Remarks Grille 950 × 950 (mm), 37-3/8 × 37-3/8 (inch) Installation gauge (Divided into 4 parts) Screw (4 ×...
Page 191 Decoration panel with 3D i-see sensor PLP-41EAEU 4.2. Temporary installation of the grille (Fig. 6) Main unit • Join the corner of drain pipe on the main unit with the corner with hole on the Corner of drain pipe grille and put them together temporarily by hanging the hook of the grille to the Claw on the main unit claw of the main unit.
Page 192 Decoration panel with 3D i-see sensor PLP-41EAEU 5. Installing the intake grille (Fig. 11) Note: When reinstalling the corner panels (each with a safety strap attached), con- nect the other end of each safety strap to the grille as shown in the illustration. * If the corner panels are not attached surely, they may fall off while the main unit is operating.
Page 193: Air Outlet Shutter Plate
Air Outlet Shutter Plate PAC-SJ37SP-E Descriptions Figure Part to block the air outlet of a cassette-type indoor unit. Applicable Models PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations Number of shutter plates 4 directions → 3 directions 4 directions → 2 directions (Change to 1 direction is not possible.) Air outlet pattern Note 1: Selecting “2 directions”...
Page 194 Air Outlet Shutter Plate PAC-SJ37SP-E How to Use / How to Install Checking for provided parts Part #, 1 Shutter plate 2 Shutter plate Name Make sure that the parts shown on the Q'ty right are in this bag, along with the instruction sheet.
Page 195: Pac-Sj41Tm
Multi-functional Casement PAC-SJ41TM-E Descriptions Figure Part to block the air outlet of a cassette-type indoor unit. Applicable Models PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations Connected duct diameter (inch) Ø3-15/16 Fresh Number of intakes Any 2 corners or less (among four corners) intake Input volume 20% or less of indoor units air volume High-performance ﬁ...
Page 196: Parts Check
Multi-functional Casement PAC-SJ41TM-E How to Use / How to Install 1 Parts check (The unit is provided with this manual and following parts in the box.) MULTI-FUNCTIONAL CASEMENT Part No., Multi-functional Screw with Grille securing Screw Name casement washer (black) bracket Q'ty M5×0.8×25...
Page 197 Multi-functional Casement PAC-SJ41TM-E 3 Installation of Multi-functional casement Electrical work of main unit Refrigerant pipe installing casement 1: Note: Drain pipe Temporary installation Note: casement plates casement 1 Caution Note: installation position is Caution Attaching bracket for securing grille 3 to secure the 4 Grille securing brackets 4 to each corner of Multi-functional casement 1. (See the figure below.) Grille securing bracket 4 Screw 3...
Page 198 Multi-functional Casement PAC-SJ41TM-E 4 Installation of duct (in case of fresh air intake) Installation of duct flange Linkage of duct fan and air conditioner. In case that a duct fan is used, be sure to make it linked Caution with the air conditioner when outside air is taken. the installation manual provided with it.
Page 199: Electrical Work
Multi-functional Casement PAC-SJ41TM-E 5 Installation of grille Bush Bush Fixing the grille Pass through the lead wire Pass through the lead wire of of the Signal receiver here. the panel vane. Refer to the installation manual of the main unit for the installation. Clamp for lead wire Electrical work For lead wires of the grille the Signal receiver, and...
Page 200: Duct Flange For Fresh-Air Intake
Duct Flange for Fresh-air Intake PAC-SH65OF-E Descriptions Photo Part to attach a duct to take in fresh air from outdoors. Applicable Models PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations Connection duct ø7-7/8 diameter (inch) Material Hot-dip zinc-coated carbon steel sheet (t0.8) Accessory Insulator, Fixing screw (ST4x10)x3 Dimensions Unit : inch 19/32...
Page 201: Checking Parts
Duct Flange for Fresh-air Intake PAC-SH65OF-E How to Use / How to Install 1. Checking Parts (This box contains the installation manual and the following parts) Part 1Duct flange 2Insulator 3Screws(M4×10) Shape Duct flange 1 2. Attaching Duct Flange for External Air Input Insulator 2 1) Punch an opening for the duct flange.
Page 202: Space Panel
Space Panel PAC-SJ65AS-E Descriptions Figure Enables to install cassette-type indoor units even if the ceiling height is low. A part to the panel 40 mm lower than the ceiling surface. Applicable Models PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations Color (Mansell No.) Pure White (6.4Y 8.9/0.4) Exterior Coating Surface treatment...
Page 203 Space Panel PAC-SJ65AS-E How to Use / How to Install 1. Checking packed parts 2. Installing space panel OCD869...
Page 204: Drain Pump
Drain Pump PAC-SL48DM-E Descriptions Photo Raises drain generated during unit's operation to secure the appropriate angle of the drain pipe. Applicable Models PKA-AL12/18NL PKA-AK24/30/36NL Speciﬁ cations Rated voltage 220-240V 50Hz / 60Hz Power consumption 12 / 10.8W Operating current 0.114 / 0.092A Max.
Page 205 Drain Pump PAC-SL48DM-E How to Use / How to Install 1. Before installation of the Drain Pump (* Position the indoor unit ﬁrst.) 1-1 Set up of the Drain Pump ● Remove the cover and the mounting plate which is ﬁxed on the back of the Drain Pump each. * The packaging material which is put between the cover and the main body of Drain Pump is only for cushion for transportation.
Page 206: Installation Of Refrigerant Piping
Drain Pump PAC-SL48DM-E Installation of the Drain Pump ● Fix the Drain Pump on the mounting plate (1) Install the screws to the 2 upper holes (indicated by the arrows shown in right figure) of the mounting plate by hand tightening them about halfway, and then hook the Drain Pump on the screws.
Page 207: Electric Wiring
Drain Pump PAC-SL48DM-E 5. Electric wiring 5-1 Set up of the indoor unit that the is off the installation the panel of unit and the (* See the unit installation section in the installation of the 5-2 Electric wiring Route the the left space of the space...
Page 208: Pac-Whs01Wf-1
Wi-Fi Adapter PAC-WHS01WF-1 Descriptions Photo Allows for a Mitsubishi Electric indoor unit to communicate with to the kumo cloud app and web. Applicable Models MSZ-FH06/09/12/15NA SLZ-KA09/12/15NA MSZ-FH18NA2 SEZ-KD09/12/15/18NA4 MSZ-EF09/12/15/18NAW(B)(S) MVZ-A09/12/15/18/24AA4 MSZ-GL06/09/12/15/18/24NA PKA-A12/18HA7 MSZ-D30/36NA PKA-A24/30/36KA7 PCA-A24/30/36/42KA7 MSY-GL09/12/15/18/24NA PLA-A12/18/24/30/36/42EA7 MSY-D30/36NA PEAD-A12/18/24/30/36/42AA7 MFZ-KJ09/12/15/18NA PVA-A12/18/24/30/36/42AA7 Speciﬁ...
Page 209: Pac-Us445Cn-1
T-STAT Interface PAC-US445CN-1 Photo Descriptions Allows a HVAC Thermostat or I/O Controller to control a MitsubishiElectric Cooling & Heating CITY MULTI® or M-Series or P-Series indoor unit. Applicable Models MSZ-FH06/09/12/15NA SLZ-KA09/12/15NA MSZ-FH18NA2 SEZ-KD09/12/15/18NA4 MSZ-EF09/12/15/18NAW(B)(S) MVZ-A12/18/24/30/36AA4 MSZ-GL06/09/12/15/18/24NA PKA-A12/18HA7 MSZ-HM09/12/15/18/24NA PKA-A24/30/36KA7 MSZ-D30/36NA PCA-A24/30/36/42KA7 MSY-GL09/12/15/18/24NA PLA-A12/18/24/30/36/42EA7...
Page 210: System Configuration
T-STAT Interface PAC-US445CN-1 System Conﬁ guration Warning: Thermostat should be for use with a conventional system (not heat pump). Note: When either Y2 or W2 is left unconnected, it is recommended to set SW2-6 to the OFF position. 1. All wiring shown should be performed with 18 AWG thermostat wire. 2.
Page 211 T-STAT Interface PAC-US445CN-1 Example 2: Single-stage Cooling and Heating Note: When either Y2 or W2 is left unconnected, it is recommended to set SW2-6 to the OFF position. Example 3: Single-stage Cooling and Heating with Dedicated Fan Speed Relays Note: When connecting only stage signals (Y1/W1), it is recommended to set SW2-6 to the OFF position.
Page 212 T-STAT Interface PAC-US445CN-1 Example 4: Single-stage Cooling with Alternate Primary Heating Source Note: For this it is recommended to set SW2-6 to the OFF position. Follow the wiring from example 2, with the following adjustments: 1. Connect thermostat W1 to the alternate heat source. 2.
Page 213: How To Install
T-STAT Interface PAC-US445CN-1 How to Install Choose a place where to install the PAC-US444CN-1. The device provides two mounting holes that can be used to mechanically affix the case to a solid surface. Double-sided tape may be used to affix the device. When using tape, ensure that the tape is approved for use within the anticipated operating temperature ranges.
Page 214 T-STAT Interface PAC-US445CN-1 SW1-3/4: The indoor unit fan speed can be adjusted via the following settings: SW1-3 SW1-4 Result Auto (Default) Medium High Custom Auto Note: Custom Auto provides more comfortable fan speed operation vs. the more Two-Stage Thermostat Operation SW2-6: Adjusts indoor unit operation during stage 1 heating and stage 1 cooling according to the following table: SW2-6...
Page 215: Temperature Sensing
T-STAT Interface PAC-US445CN-1 CN24 Operation During Defrost SW2-4: Adjusts Mode 23 function settings according to the following table: SW2-4 Result Fan and CN24 Setting 2 (Default) Setting 1 *Refer to the appropriate Indoor Unit Installation Manual for Mode 23 function setting Fan Speed During Heating Mode, Thermal Off SW2-5: Adjusts Mode 25 initial setting (fan speed in thermal off for heating) according to the following table:...
Page 216 T-STAT Interface PAC-US445CN-1 Usage Operate the third-party thermostat per the manufacturer’s instructions. During normal operation, the connection of Mitsubishi remote controllers (e.g. MA/ME) is not supported, as they will interfere with the correct operation of the PAC-US444CN-1. Notes: 1. The indoor unit will limit the internal temperature control set point based on the 2.
Page 217: Wired Remote Controller
Wired Remote Controller PAR-42MAAUB Figure Descriptions Photo Advanced MA remote controller with the large size dot liquid crystal display. Multi-language display and weekly timer func- tion are available. Applicable Models SLZ-AF09/12/15/18NL MSZ-FH06/09/12/15NA * MSZ-D30/36NA * SEZ-AD09/12/15/18NL MSZ-FH18NA2 * SLZ-KA09/12/15NA SVZ-AP12/18/24/30/36NL MSZ-FE09/12NA * SEZ-KA09/12/15/18NA4 PKA-AL12/18NL...
Page 218: System Requirements
Wired Remote Controller PAR-42MAAUB How to Use / How to Install 1. System Requirements The CD-ROM that is supplied with the unit can only be played on a CD-drive or a DVD-drive. Do not attempt to play WARNING this CD-ROM on an audio CD player as this may damage your ears and/or speakers. Your computer must meet the following requirements to run Manual Navigation Software.
Page 219: Selecting An Installation Site
Wired Remote Controller PAR-42MAAUB 4. Selecting an installation site This remote controller is for the wall installation. It can be installed either in the switch box or directly on the wall. When performing direct wall installation, wires can be thread through either back or top of the remote controller.
Page 220 Wired Remote Controller PAR-42MAAUB 5. How To Wire Transmission Line The wiring is different when the remote controller is connected to a CITY MULTI control system (“-A” type and later) and when it is connected to M-series and P-series air conditioners (A control type). The wiring also differs with the system configuration.
Page 221 Wired Remote Controller PAR-42MAAUB 2. Connecting to M-series and P-series air conditioners The remote controller wiring depends on the system configuration. Check the system configuration. Wire the remote controller as shown in the example below. The numbers (1) to (3) in the figure correspond to items (1) to (3) in the following description. [1] Connecting the remote controller for each refrigerant system (Standard 1:1, simultaneous twin, simultaneous triple, simultaneous four) Connect to TB5...
Page 222 Wired Remote Controller PAR-42MAAUB (4) Total length of remote controller wiring • The MA Remote Controller can be wired up to 450 m (1476 ft). CAUTION - The wiring cannot be connected to TB5 of the indoor unit of the same refrigerant system.
Page 223: Installation Space
Wired Remote Controller PAR-42MAAUB Do not install the controller in a place where To avoid deformation and malfunction, do the difference between the remote controller not install the remote controller in direct surface temperature and the actual room sunlight or where the ambient temperature temperature will be great.
Page 224 Wired Remote Controller PAR-42MAAUB Prepare the bottom case of the remote controller. Top case Bottom case Connect the remote controller cable to the terminal block on the bottom case. Peel off the remote controller cable sheath as shown below to connect to the terminal block properly. Secure the remote controller cable so that the peeled part of the cable will fit into the case.
Page 225 Wired Remote Controller PAR-42MAAUB Install the bottom case. ■ Installation using a switch box • Secure at least two corners of the switch box with screws. ■ Direct wall installation • Thread the cable through the groove. • Secure at least two corners of the remote controller with screws. •...
Page 226 Wired Remote Controller PAR-42MAAUB Insert the wires into the clamp. Clamp Important Hold the wires in place with the clamp to prevent undue force from being applied to the terminal block and causing cable breakage. Insert the wires. Install the top case on the bottom case. Two mounting tabs are at the top of the top case.
Page 227 Wired Remote Controller PAR-42MAAUB • Uninstalling the top case Uninstalling the top case Insert a flat-tip screwdriver with a blade width of 3-5 mm (1/8-7/32 inch) into the latches at the bottom of the remote controller and lift the latches. Then, pull up the top case. ■...
Page 228: Function Buttons
Wired Remote Controller PAR-42MAAUB 7. Remote controller button functions (7) Backlit LCD (2) Function buttons F1, F2, F3, and F4 from the left (6) Operation indicator (1) ON/OFF button (4) RETURN button (3) MENU button (5) SELECT/HOLD button (1) ON/OFF button Pressing the MENU button will bring up the Main Use to turn ON/OFF the indoor unit.
Page 229: Turning On The Power
Wired Remote Controller PAR-42MAAUB Button operations on the Main menu Cursor Move the cursor to the desired function with the F2 and F3 buttons, and press the SELECT button to go to the next page. Password may be required. Button function guide will appear at the bottom of the screens.
Page 230 Wired Remote Controller PAR-42MAAUB 9. Test run Note: Maintenance password is required. (1) Read the section about Test run in the indoor unit Installation Manual before performing a test run. (2) At the Main display, press the Setting button and select Service>Test run>Test run. (3) Press the ON/OFF button to cancel the test run if necessary.
Page 231: Daylight Saving Time
Wired Remote Controller PAR-42MAAUB (3) Daylight saving time The start/end time for daylight saving time can be set. The daylight saving time function will be activated based on the setting contents. • If a given system has a system controller, disable this setting to keep the correct time.
Page 232 Wired Remote Controller PAR-42MAAUB Display setting menu (1) Main display setting [Button operation] Move the cursor to “Full/Basic,” and use the F3 or F4 button to select the display mode “Full” or “Basic.” (The factory setting is “Full.”) Full mode (Example) Basic mode (Example) Note: This setting is only for the Main display.
Page 233 Wired Remote Controller PAR-42MAAUB [1] Clock display [Button operation] Select “Clock” from the display details setting screen, and press the F4 button (Change) to bring up the clock display setting screen. Use the F1 through F4 buttons to select “Yes” (display) or “No” (non- display) and its format for the Status display and the Main display.
Page 234 Wired Remote Controller PAR-42MAAUB [5] Backlight The backlight lighting-up time can be set. [Button operation] Move the cursor to “Backlight” from the display details setting screen, and select the desired time (5/10/20/30/60 seconds) with the F4 button. (The factory setting is “30” seconds.) Note: This setting is effective on the Status display and the Main display.
Page 235 Wired Remote Controller PAR-42MAAUB Operation setting menu (1) Auto mode setting [Button operation] Whether or not to use the Auto (single set point) or Auto (dual set points) mode can be selected by using the F3 or F4 button. This setting is valid only when indoor units with the Auto mode function are connected.
Page 236 Wired Remote Controller PAR-42MAAUB (1) Test run (CITY MULTI and M/P-series) Select “Test run” from the Service menu to bring up the Test run menu. • Test run: Select this option to perform a test run. • Drain pump test run: Select this option to perform a test run on the drain pump on the indoor unit.
Page 237 Wired Remote Controller PAR-42MAAUB Note: · Refer to the indoor unit Installation Manual for information about the factory settings of indoor units, function setting numbers, and setting values. · Be sure to write down the settings for all functions if any of the initial settings has been changed after the completion of installation work.
Page 238 Wired Remote Controller PAR-42MAAUB Table1. Function setting options Mode No. Mode Settings Setting No. Unit numbers Automatic recovery after Disable Set “Grp.” for the Unit number. power failure These settings apply to all the Enable (Four minutes of standby time connected indoor units.
Page 239 Wired Remote Controller PAR-42MAAUB When the search is completed, the smallest address of the indoor units that are connected to the remote controller and the address of the interlocked LOSSNAY unit will appear. “--” will appear if no LOSSNAY unit is interlocked with the indoor units. If no settings need to be made, press the RETURN button to go back to the Settings menu.
Page 240 Wired Remote Controller PAR-42MAAUB (6) Check Select “Check” on the Service menu to bring up <M/P-series> <CITY MULTI> the Check menu screen. The type of menu that appears depends on the type of indoor units that are connected (CITY MULTI or M/P-series). (When CITY MULTI is connected, only “Error history”...
Page 241 Wired Remote Controller PAR-42MAAUB <M/P-series> <CITY MULTI> When there is no error history [Resetting the error history] Press the F4 button (Reset) on the screen that shows the error history. A confirmation screen will appear asking if you want to delete the error history.
Page 242: Remote Controller Check
Wired Remote Controller PAR-42MAAUB (9) Remote controller information The following information of the remote controller in use can be checked. • Model name • Software version • Serial number [Button operation] Select “Others” from the Service menu. Select “Remote controller information”. 12.
Page 243: Signal Receiver
Signal Receiver PAR-SR4LA-E Descriptions Figure • Integrate the Signal Receiver in the corner panel (the opposite side of refrigerant piping). • Applicable only for PLA models. Panel Applicable Models PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations Model name PAR-SR4LA-E During operation: LED (green) lights, Abnormal Operation indicator lamp condition: LED (green) blinks, Preparing for heating operation:LED.(orange) lights...
Page 244 Signal Receiver PAR-SR4LA-E How to Use / How to Install 1 Preparation for installing SIGNAL RECEIVER Make sure to turn off the main power before work. Note: When specifying the unit is not required, this setting is not necessary. 2 Installing SIGNAL RECEIVER 1.
Page 245 Signal Receiver PAR-SR4LA-E OCD869...
Page 246: Pac-Yt53Crau
Simple MA Remote Controller PAC-YT53CRAU Descriptions Photo New functions have been added to the CITY MULTI series that enable the setting of certain indoor unit functions (such as static pressure) from the remote controller. (For more detailed infor- mation, please contact your nearest sales ofﬁ ce or distributor.) Applicable Models PKA-A12/18HA7 PKA-A24/30/36KA7...
Page 247 Simple MA Remote Controller PAC-YT53CRAU How to Use / How to Install Component names and supplied parts The following parts are included in the box. Top case *1 Bottom case *2 Parts name Qty. Appearance Remote controller (top case) Right figure *1 Remote controller (bottom case) Right figure *2 Roundhead cross slot screws M4×30...
Page 248 Simple MA Remote Controller PAC-YT53CRAU How To Wire Transmission Line The wiring is different when the remote controller is connected to a CITY MULTI control system (“-A” type and later) and when it is connected to a M-Series and P-Series air conditioner (A control type). The wiring also differs with the system configuration.
Page 249 Simple MA Remote Controller PAC-YT53CRAU (4) To interlock to a LOSSNAY or OA processing unit, make the following settings using the remote controller. (For a description of how to set an interlock, see section Ventilation Setting Set the LOSSNAY or OA processing unit address and the address of all the indoor units you want to interlock.
Page 250 Simple MA Remote Controller PAC-YT53CRAU (3) Up to two remote controllers can be connected to one group When two remote controllers are connected to one group, always set the Main remote controller and Sub remote controller. When only one remote controller is connected to one group, set it as the Main controller. When two remote controllers are connected to one group, set the Main remote controller and Sub remote controller.
Page 251 Simple MA Remote Controller PAC-YT53CRAU To monitor the accurate indoor temperature, install the remote controller away from direct sunlight, heat sources, and the supply air outlet of the air conditioner. Install the remote controller in a location that allows the sensor to measure the representative room temperature.
Page 252 Simple MA Remote Controller PAC-YT53CRAU 3 Prepare the bottom case of the remote controller. Top case Bottom case 4 Connect the remote controller cable to the terminal block on the bottom case. Peel off the remote controller cable sheath as shown below to connect to the terminal block properly. Secure the remote controller cable so that the peeled part of the cable will fit into the case.
Page 253 Simple MA Remote Controller PAC-YT53CRAU 5 Install the bottom case. Be sure to secure two places of the bottom case. Installation using a switch box Direct wall installation Seal the cable Remote access hole controller cable Single switch box with putty. Wood Refer to 4.
Page 254 Simple MA Remote Controller PAC-YT53CRAU 1 2 3 4 8 Connect the connector to the top case. Connect the connector on the bottom case to the socket on the top case. Connect the connector. Important To prevent malfunctions, do not remove the To prevent cable breakage and protective sheet or the circuit board from the malfunctions, do not hang the top controller...
Page 255 Simple MA Remote Controller PAC-YT53CRAU Direct wall installation (when running the cable along the wall) Thread the cable through the access hole at the top of the remote controller. Seal the cut-out part of the cover with putty. Use a cable cover. Use a cable cover.
Page 256: Ventilation Setting
Simple MA Remote Controller PAC-YT53CRAU Test Run 1. Before making a test run, refer to the “Test Run” section of the indoor unit installation manual. 2. When the [ON/OFF] button and [TEMP. ] button are pressed simultaneously for 2 seconds or longer, test run is performed.
Page 257 Simple MA Remote Controller PAC-YT53CRAU - When LOSSNAY or OA processing unit are not registered 4 If registration is unnecessary, end registration by pressing and holding down the [ FAN] and [TEMP. ] buttons at the same time for two seconds. If a new LOSSNAY or OA processing unit must be registered, go to step 1.
Page 258 Simple MA Remote Controller PAC-YT53CRAU <2. Confirmation procedure> 8 Set the address of the indoor unit connected by the remote controller whose LOSSNAY or OA processing unit you want to confirm using the [TEMP. ] and [TEMP. ] buttons. (01 to 50) 9 Press the [ON/OFF] button and [ FAN] button simultaneously for 2 seconds, and check the LOSSNAY address registered at the set indoor unit address.
Page 259 Simple MA Remote Controller PAC-YT53CRAU Function Selection for M-Series and P-Series Make the following settings for M-Series and P-Series if necessary. (This setting cannot be made with CITY MULTI Control System. To make CITY MULTI indoor l l o 9 Function Selection for CITY MULTI Set the functions of each indoor unit from the remote controller, as required.
Page 260 Simple MA Remote Controller PAC-YT53CRAU [Function selection flow] First grasp the function selection flow. The following describes setting of “Thermistor selection” of Table 1 as an example. (For the actual setting procedure, see [Setting procedure] 1 to 0.) 1 Check the function selection set contents. 2 Switch to the FUNCTION SELECTION mode.
Page 261 Simple MA Remote Controller PAC-YT53CRAU * If the remote controller enters the OFF state after the “ (FUNCTION)” and room temperature displays “ ” have flashes for two seconds, communication is probably abnormal. Make sure there are no noise sources near the transmission line. NOTE: If you make a mistake during operation, end function selection by step and repeat selection from step...
Page 262 Simple MA Remote Controller PAC-YT53CRAU Mode No. selection Select the mode No. you want to set with the [TEMP. ] and [TEMP. ] buttons. (Only the settable mode numbers can be selected.) Mode No. display Mode No. 02 = Thermistor selection Select the setting contents of the selected mode.
Page 263 Simple MA Remote Controller PAC-YT53CRAU Function Selection for CITY MULTI Make this setting only when the function settings need to be changed on CITY MULTI. (This setting cannot be made with M-Series and P-Series Control System. To make settings Function Selection for M-Series and P-Series Set the functions of each indoor unit from the remote controller, as required.
Page 264 Simple MA Remote Controller PAC-YT53CRAU 8If the set settings need to be changed, repeat steps 4 to 7. To complete the settings, press the [MODE] and the [ FAN] buttons at the same time for two seconds or longer. Response has been received. [TEMP.
Page 265 Simple MA Remote Controller PAC-YT53CRAU 5To check the settings, repeat steps 2 to 4. To complete the checking process, press the [MODE] and the [ FAN] buttons at the same time for two seconds or longer. Response has been received. [TEMP.
Page 266 Simple MA Remote Controller PAC-YT53CRAU 3 Self-diagnosis result display <Error history> (For the contents of the error code, refer to the indoor unit installation manual or service handbook.) Error detection attribute Error code 4 digits or (Alternate error code 2 digits display) Address 3 digits or unit address No.
Page 267 Simple MA Remote Controller PAC-YT53CRAU 3 Remote controller check result <When remote controller is normal> Since there is no problem at the remote controller, check for other causes. <When remote controller is faulty> (Error display 1) “NG” flashes Remote controller send/receive circuit abnormal Remote controller switching is necessary.
Page 268: Wireless Remote Controller
Wireless Remote Controller PAR-FL32MA-E Photo Descriptions Wireless remote controller for P series and SEZ models. (The receiver is necessary.) Applicable Models PLA-A12/18/24/30/36/42EA7 SEZ-KD09/12/15/18NA4 PKA-A12/18HA7 PEAD-A12/18/24/30/36/42AA7 PKA-A24/30/36KA7 PVA-A12/18/24/30/36/42AA7 PCA-A24/30/36/42KA7 Speciﬁ cations Accessory “AAA” LR03 alkaline batteries: 2pcs 4.1×16 tapping screws: 2 Dimensions Unit: inch [mm] 2-9/32 [58]...
Page 269: Applicable Models
Wireless Remote Controller PAR-SL101A-E Descriptions Photo Wireless remote controller for P-series and S-series. Applicable Models SLZ-M • FA2 series PEA-M • LA series SEZ-M • DAL2 series PKA-M • LAL2 series SFZ-M·VA series PKA-M • KAL2 series PLA-ZM • EA2 series PCA-M •...
Page 270 Wireless Remote Controller PAR-SL101A-E How to Use / How to Install Check that the box includes the following parts in addition to this installation manual: Parts Name Quantity Wireless remote controller Remote controller holder LR6 AA alkaline battery Tapping screws 3.5 Only use LR6 AA batteries.
Page 271 Wireless Remote Controller PAR-SL101A-E The following settings can be made in the initial setting mode. Item Setting Fig. 5-3 Temperature unit ºC/ºF Time display 12-hour format/24-hour format AUTO mode Single set point/Dual set point Pair No. 0–3 Backlight On/Off i t i (Fig.
Page 272 Wireless Remote Controller PAR-SL101A-E 5. Changing the pair No. (Fig. -1, Fig. -3 Press the button • Set the pair number to "0"–"3". (The factory setting is “0”.) Indoor unit setting Mr. Slim CITY MULTI Indoor PC board Pair No. of wireless remote SW22 settings Indoor PC board jumper wire (J41 and J42 settings) controller...
Page 273 Wireless Remote Controller PAR-SL101A-E you want to set, refer to the operation manual and techni- cal materials for the unit. mode (Fig. -1) 1. Press the button to stop the air conditioner. • If the weekly timer is enabled, press the button to disable the timer.
Page 274 Wireless Remote Controller PAR-SL101A-E (Fig. -1) 1. Press the button to stop the air conditioner. • is on), press the button to disable it ( is off). 2. Press the button for 5 seconds. • comes on and the unit enters the service mode.
Page 275 Wireless Remote Controller PAR-SL101A-E Mr. Slim output contents [Output pattern A] Errors detected by indoor unit Wired remote Wireless remote controller controller Symptom Remark Beeper sounds/OPERATION INDICATOR lamp blinks Check code (Number of times) Intake sensor error P2, P9 Pipe (liquid or 2-phase pipe) sensor error E6, E7 Indoor/outdoor unit communication error Drain sensor error/Float switch connector open...
Page 276 Wireless Remote Controller PAR-SL101A-E CITY MULTI output contents [Output pattern A] The abnormal unit (attribute) is an indoor unit, LOSSNAY unit, or outdoor air processing unit. [Output pattern B] The abnormal unit (attribute) is an outdoor unit or other unit (a unit other than an indoor unit, LOSS- NAY unit, or outdoor air processing unit).
Page 277 Wireless Remote Controller PAR-SL101A-E Function selection procedure (Fig. -3, -4) First, it is important to understand the procedure for the function selection. The following procedure explains how to set "LOSSNAY connectivity" in table 1 to "Supported (indoor unit is not equipped with outdoor-air intake)" as an example. For the actual operations, refer to the following procedure.
Page 278: How To Install
2 Removing the existing brand label case Remove the brand label case (name plate with MITSUBISHI ELECTRIC) from the bottom right of the unit. If it is difficult to remove the case, use a flat-blade screwdriver, etc., taking care not to damage the panel.
Page 279 PAC-SH91MK-E/PAR-SA92MW-E/PAR-SL93B-E Clips on the ceiling side Pass the lead wire through the retaining clips. with the clips on the ceiling side of the unit. Retaining clip 5 Removing the beam and the electrical box cover and then slide the cover to the left to remove it. Pull down the electrical box.
Page 280 PAC-SH91MK-E/PAR-SA92MW-E/PAR-SL93B-E Pair Number Setting Function Selection of Wireless Remote Controller Function Selection of Wireless Remote Controller Test Run Test Run " OCD869...
Page 281: Function Selection
PAC-SH91MK-E/PAR-SA92MW-E/PAR-SL93B-E Function Selection This setting is available only for Mr. Slim model. CITY MULTI model can be set by dip switch of indoor/outdoor control circuit board. Refer to technical data of CITY MULTI model to set dip switch. Each function can be set according to necessity using the remote controller. The setting of function for each unit can only be done by the remote controller.
Page 282 PAC-SH91MK-E/PAR-SA92MW-E/PAR-SL93B-E Other function selections Now that you know how to change LOSSANY connectivity setting, there are several other settings that can be changed as well. The following table lists the various settings that can be changed through the remote controller and the default settings. Table 3.
Page 283 PAC-SH91MK-E/PAR-SA92MW-E/PAR-SL93B-E 2 Setting the unit numbers Set “00” as the unit number when setting function from Table 4. When setting function from Table 5. - When setting function for an indoor unit in an independent system, set the unit number to 01. - When setting function for a simultaneous-Twin indoor unit system, assign unit numbers from 01 to 02 to each indoor unit.
Page 284 PAC-SH91MK-E/PAR-SA92MW-E/PAR-SL93B-E [Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.) Wired remote Wireless remote controller controller Symptom Remark Beeper sounds/OPERATION INDICATOR lamp blinks Check code (Number of times) Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit) Compressor overcurrent interruption Open/short of outdoor unit thermistors U3,U4...
Page 285: Remote Sensor
Remote Sensor PAC-SE41TS-E Descriptions Figure Enables to pick up the room temperature at the remote position. Applicable Models SLZ-AF09/12/15/18NL PEAD-AA12/18/24/30/36/42NL SEZ-AE09/12/15/18NL PVA-A12/18/24/30/36/42NL PKA-AL12/18NL PKA-AK24/30/36NL PLA-AE12/18/24/30/36/42/48NL Speciﬁ cations External dimensions (mm) 120 (H) x 70 (W) x 15 (D) White gray (Munsell 4.48Y 7.92/0.66) Exterior Material: ABS resin Operating conditions...
Page 286 Remote Sensor PAC-SE41TS-E How to Use / How to Install OCD869...
Page 287: Pac-Sa88Ha-E/Pac-725Ad
Connector Cable for Remote Display PAC-SA88HA-E/PAC-725AD-E Descriptions Figure • This adapter enables control of several units with a multiple remote control display. Applicable Models SLZ-AF09/12/15NL SEZ-AE09/12/15/18NL PEAD-AA09/12/18/24/30/36/42NL PVA-AA12/18/24/30/36/42NL Speciﬁ cations Connecting cable to output status signal of the air condi- Function tioner, and ON/OFF by external (pulse) signal.
Page 288 Connector Cable for Remote Display PAC-SA88HA-E/PAC-725AD-E How to Use / How to Install MULTIPLE REMOTE CONTROL DISPLAY You can control several units with a multiple remote control display, by wir- ing an optional multiple remote controller adapter (PAC-SA88HA-E) with relays and lamps on the market. How to wire (1) Connect the multiple remote controller adapter to the connector CN51 on the indoor controller board.
Page 289: Pac-Se55Ra
Remote On/Off Adapter PAC-SE55RA-E Descriptions Figure • Operation other than ON/OFF (adjustment of temperature, fan speed, and air direction, for example) can be performed even when remote controller operation is prohibited. Applicable Models SLZ-AF09/12/15/18NL PEAD-AA09/12/15/18/24/30/36/42NL SEZ-AD09/12/15/18NL PVA-AA12/18/24/30/36/42NL PKA-AL12/18NL PKA-AK24/30/36NL PLA-AE12/18/24/30/36/42/48NL Speciﬁ...
Page 290 Remote On/Off Adapter PAC-SE55RA-E How to Use / How to Install OCD869...
Page 291: Pac-Sf40Rm
Remote Operation Adapter PAC-SF40RM-E Descriptions Figure Extraction of non-voltage contact output. *Use of optional [Remote Operation Adapter] and "remote display panel" Part to be provided at your site) provides non-voltage con- tact outputs of signals (operation, error) and operation/stop input function.
Page 292 Remote Operation Adapter PAC-SF40RM-E How to Use / How to Install OCD869...
Page 293 Remote Operation Adapter PAC-SF40RM-E OCD869...
Page 294 Remote Operation Adapter PAC-SF40RM-E OCD869...
Page 295: External Heater Adapter
External Heater Adapter CN24RELAY-KIT-CM3 Descriptions Figure This product is the special adapter necessary to operate an electric heater with the air conditioner. Applicable Models SEZ-AD09/12/15/18NL CN24RELAY-KIT-CM3 SVZ-AP12/18/24/30/36/48/60NL PEAD-AA09/12/18/24/30/36/42NL PVA-AA12/18/24/30/36/42NL Speciﬁ cations Item Content Coil Voltage 12VDC 0.9W or less Power Consumption 32feet (10meters) Maximum Distance 16 to 22AWG...
Page 296 External Heater Adapter CN24RELAY-KIT-CM3 How to Use / How to Install Field-supplied Wiring (1) Basic wiring Outdoor unit Indoor unit control board Remote control board Relay circuit Adapter control board PUHY, PURY-P-TGMU External output cable 12VDC type CN24 Dip switch SW5-2 “ON/ OFF”...
Page 297 External Heater Adapter CN24RELAY-KIT-CM3 - Return air temperature sensor fault (Error code: 5101) - Indoor unit fan operation error (Error code: 4109) - Transmission error (Error code: 6***, 7***) - When heating mode is prohibited - When demand control or capacity save is set to 0% - During refrigerant recovery mode on PUMY system - For a few minutes when change from thermo OFF to ON or ON to OFF in R2/WR2 system Table.2...
Page 298: Pac-Sj07Sg
Air Outlet Guide PAC-SJ07SG-E (to change air blowing direction) Descriptions Figure A part to change air direction from outdoor unit. Can also be used to prevent short cycles. Applicable Models Air Outlet Guide PUY-AK12/18NL PUZ-AK12/18NL only 1 piece required Speciﬁ cations Color (Munsell) Ivory (3.0Y 7.8/1.1) Exterior...
Page 299 Air Outlet Guide to change air blowing directions PAC-SJ07SG-E How to Use / How to Install Note that two sets of this product are necessary for RP100, RP125, RP140. Accesories Make sure that this package has the following parts as well as the installation sheet: Air outlet Support Support...
Page 300: Installation Method
Air Outlet Guide to change air blowing directions PAC-SJ07SG-E Installation Complete Diagrams 809W × 300D × 630H(mm) Outdoor unit Air outlet guide Installation Method ● Four blowout directions can be selected: Check the orientation of blowout vane, and attach the blowout guide in the direction that matches the situation at local site.
Page 301: Pac-Sg59Sg
Air Outlet Guide PAC-SG59SG-E Descriptions Photo A part to change air direction from outdoor unit. Can also be used to prevent short cycles. Applicable Models PUY-AH24/30NL PUZ-AH24/30NL Speciﬁ cations Ivory (3.0Y 7.8/1.1) Color (Munsell) Exterior Material Air outlet grille: PP resin Weight 1.2kg Air outlet direction...
Page 302 Air Outlet Guide PAC-SG59SG-E How to Use / How to Install 2-fan type outdoor unit Checking provided parts Make sure that this package has the following parts as well as the installation sheet: Support Support Air Discharge guide Attachment screw Spacer (For the upper and lower sides) (For right and left)
Page 303: Pac-Sh96Sg
Air Outlet Guide PAC-SH96SG-E Descriptions Figure A part to change air direction from outdoor unit. Can also be used to prevent short cycles. Applicable Models PUY-AK36/42/48/60NL PUZ-AK36/42/48/60NL SUZ-AK48/60NL PUZ-AK24/30/36/42/48NLHZ SUZ-AK24/30/36/48NLHZ Speciﬁ cations Color (Munsell) Ivory (3.0Y 7.8/1.1) Air outlet guide Exterior Air outlet grille: Alloy hot-dip zinc- Material...
Page 304 Air Outlet Guide PAC-SH96SG-E How to Use / How to Install 2-fan type outdoor unit Checking provided parts Make sure that this package has the following parts as well as the installation sheet: Washer Spring washer Air Discharge guide Support Screw(5 15) Checking Installation Space (Unit: mm)
Page 305: Pac-Sj06Ag
Air Protect Guide PAC-SJ06AG-E (for cooling at -15 ) Descriptions Figure Enables operation even when the outside temperature is low. Protect the unit from cold wind. Applicable Models PUY-AK12/18NL PUZ-AK12/18NL only 1 piece required Speciﬁ cations Air Protect Guide Color (Munsell) Ivory (3.0Y 7.8/1.1) Surface treatment Acrylic resin coating...
Page 306 Air Protect Guide for cooling at -15 PAC-SJ06AG-E How to Use / How to Install Accessories Make sure that all the following parts, in addition to this manual, are in this box. Air protect guide Mounting screw 4 Washer Spring washer ×...
Page 307: Pac-Sh63Ag
Air Protect Guide PAC-SH63AG-E Descriptions Photo Enables operation even when the outside temperature is low. Protect the unit from cold wind. Applicable Models PUY-AH24/30NL PUZ-AH24/30NL Speciﬁ cations Color (Munsell) Ivory (3.0Y 7.8/1.1) Acrylic resin coating Surface treatment Exterior Alloy hot-dip zinc-coated carbon steel Material sheet Weight...
Page 308: Checking Parts
Air Protect Guide PAC-SH63AG-E How to Use / How to Install When 2-fan type outdoor unit is used, note that two sets of this product will be necessary. 1 Checking parts OCD869...
Page 309 Air Protect Guide PAC-SH63AG-E 2 Requirements of space for installation 3 Installation procedure OCD869...
Page 310: Pac-Sh95Ag
Air Protect Guide PAC-SH95AG-E Descriptions Photo Enables operation even when the outside temperature is low. Protect the unit from cold wind. Applicable Models PUY-AK36/42/48/60NL PUZ-AK36/42/48/60NL SUZ-AK48/60NL PUZ-AK24/30/36/42/48NLHZ SUZ-AK24/30/36/48NLHZ Speciﬁ cations Ivory (3.0Y 7.8/1.1) Color (Munsell) Surface treatment Acrylic resin coating Exterior Alloy hot-dip zinc-coated carbon steel Material...
Page 311: Installation Procedure
Air Protect Guide PAC-SH95AG-E How to Use / How to Install Checking parts Make sure that all the following parts, in addition to this manual, are in this box: Mounting screw Air Guide Washer Spring washer (5 15) 2 Requirements of space for installation (Unit : mm) (1)One unit installation...
Page 312: Drain Socket
Drain Socket PAC-SJ08DS-E Descriptions Figure Cap the unnecessary holes on the outdoor unit (bottom) and centralize the drainage when using a drain pipe. Applicable Models PUY-AK12/18NL PUZ-AK12/18NL Speciﬁ cations Drain pipe PVC VP-25 or vinyl hose (ID: 25mm) Operating conditions No freezing allowed (Never to be used in cold climates) Dimensions...
Page 313: Pac-Sg61Ds
Drain Socket PAC-SG61DS-E Descriptions Photo Cap the unnecessary holes on the outdoor unit (bottom) and centralize the drainage when using a drain pipe. Applicable Models PUY-AH24/30NL PUZ-AH24/30NL PUY-AK36/42/48/60NL PUZ-AK36/42/48/60NL SUZ-AK48/60NL PUZ-AK24/30/36/42/48NLHZ SUZ-AK24/30/36/48NLHZ Speciﬁ cations Drain pipe PVC VP-25 or vinyl hose (ID: 25mm) No freezing allowed (Never to be used in cold Operating conditions climates)
Page 314 Drain Socket PAC-SG61DS-E How to Use / How to Install 1 Accessory Make sure that the following parts are put in the package. Drain socket 1 pcs Drain cap 5 pcs Insulation part (for liquid pipe) 1 pc Insulation part (for gas pipe) 1 pc Band 8 pcs...
Page 315: Pac-Sg63Dp
Centralized Drain Pan PAC-SG63DP-E Descriptions Photo A drain pan for the drain water generated from the outdoor unit. Applicable Models PUY-AK12/18NL PUZ-AK12/18NL Speciﬁ cations Drain outlet size R3/4 screw (20A) Color (Munsell) Ivory (3.0Y 7.8/1.1) Acrylic resin coating Exterior Surface treatment Alloy hot-dip zinc-coated carbon steel Material sheet (t1.6)
Page 316: Drain Piping
Centralized Drain Pan PAC-SG63DP-E How to Use / How to Install Installation Method (1) When installing on installation frame 1) The installation frame must have structure and strength that can sufficiently Outdoor unit support the outdoor unit and drain pan. Securely install the outdoor unit and drain pan so that they cannot fall or drop as a result of earthquake, strong wind, etc.
Page 317: Pac-Sg64Dp
Centralized Drain Pan PAC-SG64DP-E Descriptions Photo A drain pan for the drain water generated from the outdoor unit. Applicable Models PUY-AH24/30NL PUZ-AH24/30NL Speciﬁ cations Drain outlet size R3/4 screw (20A) Color (Munsell) Ivory (3.0Y 7.8/1.1) Acrylic resin coating Exterior Surface treatment Alloy hot-dip zinc-coated carbon steel Material sheet (t1.6)
Page 318 Centralized Drain Pan PAC-SG64DP-E How to Use / How to Install Installation Method (1) When installing on installation frame 1) The installation frame must have structure and strength that can sufficiently Outdoor unit support the outdoor unit and drain pan. Securely install the outdoor unit and drain pan so that they cannot fall or drop as a result of earthquake, strong wind, etc.
Page 319: Pac-Sh97Dp
Centralized Drain Pan PAC-SH97DP-E Descriptions Photo A drain pan for the drain water generated from the outdoor unit. Applicable Models PUY-AH24/30NL PUZ-AH24/30NL PUY-AK36/42/48/60NL PUZ-AK36/42/48/60NL SUZ-AK48/60NL PUZ-AK24/30/36/42/48NLHZ SUZ-AK24/30/36/48NLHZ Speciﬁ cations Drain outlet size R3/4 screw (20A) Color (Munsell) Ivory (3.0Y 7.8/1.1) Exterior Acrylic resin coating Surface treatment...
Page 320 Centralized Drain Pan PAC-SH97DP-E How to Use / How to Install Installation Method (1) When installing on installation frame 1) The installation frame must have structure and strength that can sufficiently support the outdoor unit and drain pan. Securely install the outdoor unit and drain pan so that they cannot fall or drop as a result of earthquake, strong wind, etc.
Page 321: Pac-Sj96Ma
M-NET Converter PAC-SJ96MA-E Descriptions A-control Mr. SLIM models can be connected to "M-NET" through optional M-NET converter so that they can be monitored / controlled effectively and meticulously. Applicable Models PUY-AK12/18NL PUZ-AK12/18NL Speciﬁ cations Power Supplied from control board 0.6W (at 5V DC, 12V DC) Power consumption Mounted inside the electrical utility box of outdoor Operating conditions...
Page 322: Parts List
M-NET Converter PAC-SJ96MA-E 2. Parts list Description Figure Q'ty Description Figure Q'ty M-NET board Lead wire (with insulation (5 wires) sheets and for signals length: 280mm supports) Lead wire Mounting plate (3 wires) (M-NET board) for power supply length: 300mm Lead wire Screw (M4×8) (M-NET)
Page 323: Pac-Sj95Ma
M-NET Converter PAC-SJ95MA-E Descriptions A-control Mr. SLIM models can be connected to "M-NET" through optional M-NET converter so that they can be monitored / controlled effectively and meticulously. Applicable Models PUY-AH24/30NL SUZ-AK48/60NL PUZ-AH24/30NL PUZ-AK24/30/36/42/48NLHZ PUY-AK36/42/48/60NL SUZ-AK24/30/36/48NLHZ PUZ-AK36/42/48/60NL Speciﬁ cations Power Supplied from control board 0.6W (at 5V DC, 12V DC) Power consumption...
Page 324: Switch Setting
M-NET Converter PAC-SJ95MA-E 3. Switch setting M-NET address setting Make M-NET setting and refrigerant address setting on only outdoor unit. There is no address settings for outdoor unit and remote controller like City Multi system. The M-NET address setting for taking into centralized control system should be done only to the outdoor unit. The address set number should be 1-50 same as for City Multi indoor unit and make set in order of number for the same group.
Page 325: Pac-Sk52St
Control / Service Tool PAC-SK52ST Descriptions Photo This item is used to display operation and self-diagnosis state. Applicable Models PUY-AK12/18NL PUZ-AK12/18NL PUY-AH24/30NL TO BE CONFIRMED PUZ-AH24/30NL PUY-AK36/42/48/60NL PUZ-AK36/42/48/60NL SUZ-AK48/60NL PUZ-AK24/30/36/42/48NLHZ SUZ-AK24/30/36/48NLHZ Speciﬁ cations 5V DC (supplied from outdoor unit control board) Power Temperature -20 to 60 , Humidity: 90% RH or less (no con-...
Page 326: Base Heater
Base Heater PAC-SK62BH-E Descriptions Figure • This product is designed for prevention of ice on the bottom of the outdoor unit heat exchanger and the clogged drain hole caused by freezing in severe winter. • To drain properly, a drain socket and a concentrated drain pan are not allowed to be used with this product.
Page 327 Base Heater PAC-SK62BH-E How to Use / How to Install 1 Preparation It is easier to mount the base heater before installing the outdoor unit. • Make sure that the main power supply to the unit is OFF. • Do not lose the removed screws. Many screws will be removed to install the base heater. •...
Page 328 Base Heater PAC-SK62BH-E 4 Mounting the base heater <Photo 1> Temporarily place the base heater Base heater Base heater [132mm] [132mm] [132mm] [132mm] the base so that the square hole for the 5-13/64[inch] 5-13/64[inch] motor support on the base comes to the center of the base heater <Photo 1>...
Page 329: Connecting The Lead Wires
Base Heater PAC-SK62BH-E 8 Connecting the lead wires Connect the lead wires according to the following wiring diagram. [ Control board ] BASE HEATER (BU) BLK BLK RED BLK THERMAL PROTECTOR Connector of the base heater Connector of the base heater 9 Securing the lead wires After connecting the lead wires, bundle the lead wires together and secure them...
Page 330: Pac-Sl11Bh
Base Heater PAC-SL11BH-E Descriptions Figure • This product is designed for prevention of ice on the bottom of the outdoor unit heat exchanger and the clogged drain hole caused by freezing in severe winter. • To drain properly, a drain socket and a concentrated drain pan are not allowed to be used with this product.
Page 331 Base Heater PAC-SL11BH-E How to Use / How to Install 1 Preparation It is easier to mount the base heater before installing the outdoor unit. 2 Preparation for mounting the base heater Before mounting the base heater Removal of fan Disconnect the connector of the fan motor OCD869...
Page 332 Base Heater PAC-SL11BH-E 3 Mounting the base heater Fix the base heater with the heater Temporarily place the base heater supports and the screws 4×10 on the base so that the square hole for the motor support on the base comes to the center of the base heater (See photo below.) base heater...
Page 333 Base Heater PAC-SL11BH-E Wiring diagram Connect the lead wires according to the following wiring diagram. [ Control board ] BASE HEATER (BU) BLK BLK BLK BLK THERMAL PROTECTOR 7 Securing the lead wires Bundle the lead Bundle the lead After connecting the lead wires, bundle wires together wires together using the fastener...
Page 334 OCD869...
Page 335 SYSTEM CONTROL T8-1.MAJOR SYSTEM CONTROL System Examples Indoor Unit M Series Indoor Unit S Series P Series Indoor Unit Outdoor Unit M Series and MXZ Series Outdoor S Series and MXZ Series Outdoor P Series Outdoor Indoor unit MAC-334IF-E Indoor unit PAR-40MAA Control PAR-42MAAUB Control Outdoor unit...
Page 336 T8-2.OTHERS For M Series Indoor Units (New A-control Models Only) System Examples Connection Details Control Details Major Optional Parts Required Connect the interface to the air On/Off operation is possible from • MAC-334IF-E Remote On/Off conditioner. Then connect the a remote location. (Interface) Operation MAC-334IF-E...
Page 337 HEAD OFFICE: TOKYO BUILDING, 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8,310, JAPAN ©Copyright 2025 MITSUBISHI ELECTRIC CORPORATION Published: Feb. 2025 No. OCD869 Specifications subject to change without notice Made in Japan...

This manual is also suitable for:

Puz-ak42nl Puz-ak48nl Puz-ak60nl Puy-ak36nl Puy-ak42nl Puy-ak48nl ... Show all
