USER MANUAL
Kingston Play Centre
WARNING: The disassembled product may contain small parts
which pose a choking hazard to children under 3.
IMPORTANT:
This product may contain sharp points and small parts prior to assembly. The owner's manual contains
safety, assembly, use and maintenance instructions. This product must be assembled by an adult who
has read and understood these instructions. Keep the packaging away from children and dispose of all
packaging before use.
For the installer and your children's safety, it is important to fully read and understand the instructions
and safety hazards before commencing the assembly of the product.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents
inside its carton, may vary from what is listed in this manual. This manual may also be subject to
updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.
Find the Digital
Manual Online

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kingston Play Centre and is the answer not in the manual?

Questions and answers

Related Manuals for LifeSpan Kids Kingston Play Centre

Summary of Contents for LifeSpan Kids Kingston Play Centre

  • Page 1 USER MANUAL Kingston Play Centre Find the Digital Manual Online WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: This product may contain sharp points and small parts prior to assembly. The owner’s manual contains safety, assembly, use and maintenance instructions.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS I. GENERAL SAFETY INSTRUCTIONS 1.1 Danger for Children 1.2 Risk of Injuries 1.3 Product Damage 1.4 Assembly Advice II. SAFETY INSTRUCTIONS III. EXPLODED DIAGRAM IV. BOARDS LISTS V. PARTS LIST IV. MAINTENANCE V. WOOD ADVICE VI. CLEANING VII.

  • Page 3: General Safety Instructions

    I. GENERAL SAFETY INSTRUCTIONS NOTE: This product is intended for outdoor domestic use only. - This product must be assembled by an adult - Children must not use the product until properly installed - Small parts. Choking Hazard. - For Outdoor and Domestic Use Only - Age: 3 years and over - Max Users: 5 - Max Fall Height: 2.0m Max User Weight:...

  • Page 4: Product Damage

    1.3 PRODUCT DAMAGE • Do not make alterations to the product. Only use original spare parts. Qualified technicians should only carry out repairs – improper repairs can lead to danger for the user. Use this product only as described in this manual. 1.4 ASSEMBLY ADVICE •...

  • Page 5: Safety Instructions

    II. SAFETY INSTRUCTIONS • The safety instructions of the product should always be considered and obeyed. • Using the product may result in permanent injury such as paralysis, or even death. Falling off the product may lead to injuries, particularly to the back, neck or head. •...
  • Page 6 CONSUMER INFORMATION SHEET FOR PLAYGROUND SURFACING MATERIALS: The US Consumer Product Safety Commission (CPSC) estimates that about 100 000 playground equipment-related injuries resulting from falls to the ground surface are treated annually in US hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.

  • Page 7: Exploded Diagram

    III. EXPLODED DIAGRAM...

  • Page 9: Boards Lists

    IV. BOARD LIST ASSEMBLY INSTRUCTIONS...
  • Page 10 ASSEMBLY INSTRUCTIONS...

  • Page 11: Parts List

    V. PARTS LIST W8/15 Washer x 10 W10/18 Washer x 110 W12/28 Washer x 5 BM615 B-NUT x 10 BM818 B-Nut x 10 N815 Nut x 110 AN8 A-NUT8 X4 BM825 B-NUT x 5 M625-Bolt x 10 M845 Bolt x 12 M855 Bolt x 20 M872 Bolt x 4 M896 Bolt x 76...
  • Page 12 ASSEMBLY INSTRUCTIONS...
  • Page 13 Note the orientation of the pilot holes M896 M896 C1 = 1pc C2 = 1pc N815 W10/18 D4 = 1pc F4 = 1pc M896 = 6pcs N815 = 6pcs W10/18 = 6pcs STEP 1 ASSEMBLY INSTRUCTIONS...
  • Page 14 C6 = 1pc F10 = 1pc F17 = 1pc M896 = 8pcs N815 = 8pcs W10/18 = 8pcs SW50 = 3pcs STEP 2 ASSEMBLY INSTRUCTIONS...
  • Page 15 Note the orientation of the pilot holes C1 = 1pc C3 = 1pc C7 = 2pcs D2 = 1pc F2 = 1pc F7 = 2pcs M896 = 16pcs N815 = 16pcs STEP3 W10/18 = 16pcs ASSEMBLY INSTRUCTIONS...
  • Page 16 F16 = 1pc SW50 = 4pcs M896 = 4pcs N815 = 4pcs W10/18 = 4pcs STEP4 ASSEMBLY INSTRUCTIONS...
  • Page 17 D1 = 1pc F1 = 1pc M896 = 8pcs N815 = 8pcs W10/18 = 8pcs STEP 5 ASSEMBLY INSTRUCTIONS...
  • Page 18 D3 = 1pc F3 = 1pc M896 = 8pcs N815 = 8pcs W10/18 = 8pcs STEP 6 ASSEMBLY INSTRUCTIONS...
  • Page 19 C8 = 2pcs F9 = 2pc M896 = 4pcs N815 = 8pcs W10/18 = 8pcs M855 = 4pcs STEP 7 ASSEMBLY INSTRUCTIONS...
  • Page 20 Note the orientation of the pilot holes C4 = 1pc C5 = 1pc D6 = 1pc F6 = 1pc F13 = 1pc M896 = 8pcs N815 = 8pcs W10/18 = 8pcs STEP 8 ASSEMBLY INSTRUCTIONS...
  • Page 21 F5 = 1pc N815 = 8pcs W10/18 = 8pcs M896 = 8pcs STEP 9 ASSEMBLY INSTRUCTIONS...
  • Page 22 F5 = 2pcs D5 = 1pc N815 = 12pcs W10/18 = 12pcs M896 = 6pcs M855 = 6pcs STEP 10 ASSEMBLY INSTRUCTIONS...
  • Page 23 SW50 FA30 FA30 = 10pcs SW50 = 20pcs STEP 11 ASSEMBLY INSTRUCTIONS...
  • Page 24 K1 = 1pc K2 = 2pcs SW60 = 12pcs STEP 12...
  • Page 25 K30 = 8pcs M855 = 8pcs N815 = 8pcs W10/18 = 8pcs M8SW50 = 8pcs STEP 13...
  • Page 26 H8 x 7 H1 = 2pcs H2 = 10pcs H3 = 2pcs H4 = 1pc H5 = 2pcs H6 = 1pcs H7 = 1pc H8 = 7pcs STEP 14 H9 = 1pc...
  • Page 27 SW35 SW35 SW35 SW35 SW35 SW35 = 151pcs STEP 15...
  • Page 28 K7 = 2pcs M855 = 2pcs N815 = 2pcs W10/18 = 2pcs STEP 16...
  • Page 29 H25 = 5pcs 139004 = 5pcs M625 = 10pcs BM615 = 10pcs STEP 17 W8/15 = 10pcs...
  • Page 30 49mm SW35 SW35 H26 = 4pcs H27 = 1pc SW35 = 38pcs STEP 18...
  • Page 31 Note the orientation of the pilot holes BA01 M8125 = 4pcs N815 = 4pcs W10/18 = 4pcs STEP 19 BA01 = 1pc...
  • Page 32 Note the orientation of the pilot holes H14B H14 x 4 SW35 SW35 SW35 H14 = 4pcs H14B = 1pc H15 = 1pc SW35 = 36pcs STEP 20 F15 = 1pc...
  • Page 33 SW40 SW35 T1 = 1pc F25 = 1pc SW35 = 6pcs SW40 = 1pc STEP 21...
  • Page 34 H14 x 7 SW35 SW35 SW35 H14 = 7pcs SW35 = 42pcs STEP 22...
  • Page 35 SW28 SW28 SW16 139001 SW16 H16 = 2pcs H17 - 2pcs 139001 = 1pc SW16 = 8pcs STEP 23 SW28 = 12pcs...
  • Page 36 SW50 70mm SW50 SW50 70mm F8 = 2pcs K4 = 2pcs SW50 = 8pcs STEP 24 M6SW55 = 4pcs...
  • Page 37 H10 x 4 H10 = 4pcs STEP 25 SW35 = 16pcs...
  • Page 38 SW50 SW50 SW50 F21 = 2pcs F19 = 2pcs STEP 26 SW50 = 10pcs...
  • Page 39 SW35 SW35 F20 = 2pcs H24 = 2pcs H28 = 1pc H29 = 1pc H30 = 1pc H31 = 1pc STEP 27 SW35 = 16pcs...
  • Page 40 139008 139007 SW16 139007 = 1pc 139008 = 1pc STEP 28 SW16 = 2pcs...
  • Page 41 SW35 SW35 STEP 29 SW35 = 8pcs...
  • Page 42 SW35 SW50 SW50 SW35 H10 x 4 F12 = 1pc H10 = 4pcs SW50 = 4pcs STEP 30 SW35 = 16pcs...
  • Page 43 SW35 SW50 SW50 SW35 H10 x 3 F14 = 1pc H10 = 3pcs SW35 = 12pcs SW50 = 4pcs STEP 31...
  • Page 44 SW35 SW50 SW50 SW35 H10 x 4 F11 = 1pc H10 = 4pcs SW35 = 16pcs STEP 32 STEP 32 SW50 = 4pcs...
  • Page 45 H11 x 6 H11 x 6 SW35 SW35 SW35 SW35 H11 = 12pcs H12 = 2pcs SW35 = 56pcs STEP 33...
  • Page 46 BM825 W12/28 650012 627001 627001 = 1pc BM825 = 1pc W12/28 = 1pc STEP 34 650012 = 1pc...
  • Page 47 K6 = 2pcs F18 = 2pcs M845 = 2pcs W10/18 = 2pcs N815 = 2pcs SW50 = 2pcs M6SW55 = 4pcs STEP 35 F22 = 1pc...
  • Page 48 M6SW35 Install the handle - 139003 M6SW35 M8SW35 M8SW35 Install the climbing stick - 139011 M8SW35 M8SW35 M8SW35 139003 = 2pcs M6SW35 139011 = 4pcs M6SW35 =4pcs M8SW35 = 8pcs STEP 36...
  • Page 49 N815 W12/28 Swing Hanger-650019 650019 = 4pcs AN8 = 4pcs N815 = 4pcs W12/28 = 4pcs STEP 37 K9B = 1pc...
  • Page 50 M6SW35 M6SW35 M6SW35 Install the climbing stick - 139011 K9A = 1pc M6SW35 = 10pcs STEP 38 139011 = 5pcs...
  • Page 51 139012 x 4 M845 = 10pcs BM818 = 10pcs STEP 39 139012 = 4pcs...
  • Page 52 Hang the swing 139002 = 2pcs M872 = 4pcs W10/18 = 4pcs BM825 = 4pcs STEP 40...
  • Page 53 FP1 = 1pc FP2 = 1pc M8107 = 4pcs W10/18 = 4pcs N815 = 4pcs STEP 41 SW35 = 4pcs...
  • Page 54 SW35 SW35 SW35 SW35 FP3 = 2pcs FP4 = 4pcs SW35 = 36pcs STEP 42...
  • Page 55 Install the handle- 139003 139003 = 4pcs STEP 43 M6SW35= 8pcs...
  • Page 56 SW50 SW50 put T1 under the floor to prevent the screw from falling off Installation Side 650001 650001 = 1pc T1= 2pcs SW50 = 2pcs STEP 44...
  • Page 57 Tie the rople tightly 139031 = 1pc STEP 45...
  • Page 58 139070 139070 = 2pcs M6SW35 = 4pcs STEP 46 MAINTENANCE...

  • Page 59: Maintenance

    VI. MAINTENANCE WARNING: Please keep for future reference. We recommend regular maintenance to be conducted at the beginning of each season as well as at regular intervals during the usage session for your play equipment to ensure all main parts/fixings are tightly secured, well-oiled and intact to avoid failure, injury or hazards.

  • Page 60: Wood Advice

    VII. WOOD ADVICE Our products are manufactured from premium timber. Great care is taking in selecting, machining, and treating the timber before it is sold to you. 1. Inspect wood parts monthly. The grain of the wood sometimes will lift in dry periods causing splinters to appear.
  • Page 61 3. Mould and Mildew Protecting against mould and mildew on your outdoor equipment is an important step in maintaining your backyard. Mould may develop for several reasons, such as certain weather conditions, improper drainage or infrequent usage. Here we’ll share our tips for keeping your outdoor areas free of mould and mildew so that you can enjoy your backyard with peace of mind.

  • Page 62: Cleaning

    VIII. CLEANING Do not use any abrasive cleansers for the cleaning. Use a soft, damp cloth to eliminate dirt and dust. IX. WARRANTY AUSTRALIAN CONSUMER LAW Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with guarantees that cannot be excluded under the Australian Consumer Law.
