USER MANUAL
Montrose
Play Centre
WARNING: The disassembled product may contain small parts
which pose a choking hazard to children under 3.
IMPORTANT:
This product may contain sharp points and small parts prior to assembly. The owner's manual contains
safety, assembly, use and maintenance instructions. This product must be assembled by an adult who
has read and understood these instructions. Keep the packaging away from children and dispose of all
packaging before use.
For the installer and your children's safety, it is important to fully read and understand the instructions
and safety hazards before commencing the assembly of the product.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents
inside its carton, may vary from what is listed in this manual. This manual may also be subject to
updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.
Find the Digital
Manual Online
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LifeSpan Kids Montrose Play Centre
Summary of Contents for LifeSpan Kids Montrose Play Centre
- Page 1 USER MANUAL Montrose Play Centre Find the Digital Manual Online WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: This product may contain sharp points and small parts prior to assembly. The owner’s manual contains safety, assembly, use and maintenance instructions.
-
Page 2: Table Of Contents
TABLE OF CONTENTS I. GENERAL SAFETY INSTRUCTIONS 1.1 Danger for Children 1.2 Risk of Injuries 1.3 Product Damage 1.4 Assembly Advice II. SAFETY INSTRUCTIONS III. EXPLODED DIAGRAM IV. ASSEMBLY INSTRUCTIONS V. MAINTENANCE VI. FREQUENTLY ASKED QUESTIONS VII. WOOD ADVICE VIII. WARRANTY... -
Page 3: General Safety Instructions
I. GENERAL SAFETY INSTRUCTIONS NOTE: This product is intended for outdoor domestic use only. 1.1 DANGER FOR CHILDREN WARNING: No eating while using the product at the same time. • Children do not recognize potential dangers from this product. The unassembled product must be stored out of reach of children and pets. -
Page 4: Assembly Advice
1.3 PRODUCT DAMAGE • Do not make alterations to the product. Only use original spare parts. Qualified technicians should only carry out repairs – improper repairs can lead to danger for the user. Use this product only as described in this manual. 1.4 ASSEMBLY ADVICE •... -
Page 5: Safety Instructions
II. SAFETY INSTRUCTIONS A maximum of 68 kgs. per child is recommended for play activities designed for individual use. A maximum of 54 kgs. per child is recommended for play activities designed for multiple child use. A maximum of 4 children is recommended for this swing set •... - Page 6 Consumer Information Sheet for Playground Surfacing Materials The US Consumer Product Safety Commission (CPSC) estimates that about 100 000 playground equipment-related injuries resulting from falls to the ground surface are treated annually in US hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.
-
Page 7: Exploded Diagram
III. EXPLODED DIAGRAM EXPLODED DIAGRAM... -
Page 8: Assembly Instructions
IV. ASSEMBLY INSTRUCTIONS B O A R D L I S T B1 = 1 2420x134x50mm B2 = 2 2159x76x50mm C1 = 2 2156x86x35mm C2 = 2 2156x86x35mm H25 = 1 D1 = 2 340x60x16mm 1014x134x24mm H3 = 1 D2 = 2 1014x105x16mm 966x134x24mm H4 = 8... - Page 9 F3 = 1 966x86x24mm F4 = 1 966x86x24mm F5 = 2 1580x86x24mm F6 = 2 K22 = 1 966x86x24mm 1284x86x35mm F7 = 2 K23 = 1 606x86x24mm 1284x86x35mm F8 = 1 K30 = 6 966x86x24mm 300x60x35mm F9 = 3 966x60x24mm FA26 = 4 86x76x24mm WP2 = 1...
- Page 10 P A R T S L I S T W10/18 W12/28 A-NUT8 x 6 Washer x 64 Washer x 6 BM615 BM818 N815 B-NUT x 6 B-NUT x 19 NUT x 74 M615 SW21 Bolt x 2 Screw x 12 M625 SW16 Bolt x 2...
- Page 11 (1) L650008 (1) 139008 (1) L651022 (1) L651023 (1) L651024 (6) 650007 Star Bit (S) Star Bit (L) (2) 155003 Allen Wrench (S) Allen Wrench (L) (1) L650050 (1) 155031 (2) 139002 2030mm*966mm (1) L651003 (2) L651015 (2) L651025 (2) T-HY-1 Instructions (6) 139070 (1) 155090...
- Page 12 STEP 1 N815 W10/18 M855 M855 N815 W10/18 ASSEMBLY INSTRUCTIONS...
- Page 13 STEP 2 N815 M855 W10/18 M855 N815 W10/18 ASSEMBLY INSTRUCTIONS...
- Page 14 STEP 3 Note the orientation of the pilot holes N815 M8107 W10/18 M8107 N815 W10/18 ASSEMBLY INSTRUCTIONS...
- Page 15 STEP 4 Note the orientation of the pilot holes N815 W10/18 M8107 M8107 N815 W10/18 ASSEMBLY INSTRUCTIONS...
- Page 16 STEP 5 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 17 STEP 6 SW40 SW28 SW40 SW28 ASSEMBLY INSTRUCTIONS...
- Page 18 STEP 7 SW50 SW50 ASSEMBLY INSTRUCTIONS...
- Page 19 STEP 8 N815 W10/18 M855 M855 N815 W10/18 ASSEMBLY INSTRUCTIONS...
- Page 20 STEP 9 FA26 SW50 SW50 ASSEMBLY INSTRUCTIONS...
- Page 21 STEP 10 W10/18 M855 N815 M6SW55 M6SW55 N815 W10/18 M855 ASSEMBLY INSTRUCTIONS...
- Page 22 STEP 11 SW60 SW60 ASSEMBLY INSTRUCTIONS...
- Page 23 STEP 12 SW35 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 24 STEP 13 SW50 400mm SW50 ASSEMBLY INSTRUCTIONS...
- Page 25 STEP 14 SW35 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 26 STEP 15 SW50 SW50 ASSEMBLY INSTRUCTIONS...
- Page 27 STEP 16 SW35 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 28 STEP 17 M615 BM615 BM615 M633 L651025 x 2 M615 M633 BM615 ASSEMBLY INSTRUCTIONS...
- Page 29 STEP 18 SW50 SW50 ASSEMBLY INSTRUCTIONS...
- Page 30 STEP 19 M845 SW50 W10/18 N815 M845 W10/18 SW50 N815 ASSEMBLY INSTRUCTIONS...
- Page 31 155031 STEP 20 SW16 SW16 SW16 ASSEMBLY INSTRUCTIONS...
- Page 32 STEP 21 N815 W12/28 SWING HANGER-650007 N815 W12/28 Insert the N815 Insert the swing hang- into the beam by hammer er into the beam and fix them with nuts N815 as tightly as possible Fix the AN8 as tightly as possible N815 W12/28 ASSEMBLY INSTRUCTIONS...
- Page 33 STEP 22 L651023 L651022 M845 M845 BM818 M6SW35 BM818 M6SW35 M845 BM818 M6SW35 ASSEMBLY INSTRUCTIONS...
- Page 34 STEP 23 N815 M896 W10/18 M896 W10/18 N815 ASSEMBLY INSTRUCTIONS...
- Page 35 STEP 24 BM818 M845 L651024 L651003 M869 BM818 BM818 M845 M845 M869 BM818 ASSEMBLY INSTRUCTIONS...
- Page 36 STEP 25 N815 N815 M821 M821 Hang the swing L650050 139002 139002 M821 N815 ASSEMBLY INSTRUCTIONS...
- Page 37 STEP 26 SW35 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 38 STEP 27 SW35 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 39 STEP 28 L651015 L651015 BM818 M845 M821 BM818 W10/18 M821 N815 N815 M845 W10/18 M821 N815 W10/18 BM818 M845 ASSEMBLY INSTRUCTIONS...
- Page 40 STEP 29 BM818 M821 SW50 BM818 M821 SW50 ASSEMBLY INSTRUCTIONS...
- Page 41 STEP 30 SW28 SW28 SW28 ASSEMBLY INSTRUCTIONS...
- Page 42 STEP 31 SW35 SW35 SW35 ASSEMBLY INSTRUCTIONS...
- Page 43 STEP 32 139008 139007 SW16 SW16 ASSEMBLY INSTRUCTIONS...
- Page 44 STEP 33 SW50 SW50 Put the slide braces T1 under the floor boards and fix the slide with floor and slide braces together L650001 SW50 ASSEMBLY INSTRUCTIONS...
- Page 45 STEP 34 26mm SW50 SW50 SW50 ASSEMBLY INSTRUCTIONS...
- Page 46 STEP 35 T-HY-1 SW21 15mm DOOR SW21 ASSEMBLY INSTRUCTIONS...
- Page 47 STEP 36 BM615 M6SW35 M625 155003 155003 BM615 M6SW35 M625 M6SW35 M625 BM615 ASSEMBLY INSTRUCTIONS...
- Page 48 STEP 37 L650008 S328 S328 S328 ASSEMBLY INSTRUCTIONS...
- Page 49 STEP 38 SW50 SW50 ASSEMBLY INSTRUCTIONS...
- Page 50 STEP 39 M6SW35 139070 M6SW35 ASSEMBLY INSTRUCTIONS...
-
Page 51: Maintenance
V. MAINTENANCE WARNING: Please keep for future reference. We recommend regular maintenance to be conducted at the beginning of each season as well as at regular intervals during the usage session for your play equipment to ensure all main parts/fixings are tightly secured, well-oiled and intact to avoid failure, injury or hazards. -
Page 52: Frequently Asked Questions
9. The end beam is not straight up and down. Why not? This is normal. Lifespan Kids designs playsets this way to ensure the strongest structure possible. The slight angle adds strength and reduces rocking and twisting. -
Page 53: Wood Advice
VII. WOOD ADVICE Our products are manufactured from premium timber. Great care is taking in selecting, machining, and treating the timber before it is sold to you. 1. Inspect wood parts monthly. The grain of the wood sometimes will lift in dry periods causing splinters to appear. - Page 54 WHEN SHOULD WOOD CRACKS BE A CONCERN? Most of the wood splits will never become large enough to affect the reliability and strength of our products, however, there can be rare cases where splits can occur. This happens when a crack develops past the halfway point from the timber, splitting it into two separate pieces.
-
Page 55: Warranty
If you have purchased this product from the Official Lifespan Kids website, please visit www.lifespankids.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit www.lifespankids.com.au/warranty-form and fill in our Repair/Service Request Form or... - Page 56 www.l i f e s p an k i d s . co m . a u...
