USER MANUAL
Spirit Boat Play Centre
WARNING:
which pose a choking hazard to children under 3.
IMPORTANT:
The owner's manual contains safety, assembly, use and maintenance instructions. This product must
be assembled by an adult who has read and understood these instructions. Keep the packaging away
from children and dispose of all packaging before use.
For the installer and your children's safety, it is important to fully read and understand the instructions
and safety hazards before commencing the assembly of the product.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents
inside its carton, may vary from what is listed in this manual. This manual may also be subject to
updates or changes. Updated manuals are available through our website at www.lifespankids.com.au.
The disassembled product may contain small parts
Advertisement
Table of Contents
Related Manuals for LifeSpan Kids Spirit Boat Play Centre
Summary of Contents for LifeSpan Kids Spirit Boat Play Centre
- Page 1 USER MANUAL Spirit Boat Play Centre WARNING: The disassembled product may contain small parts which pose a choking hazard to children under 3. IMPORTANT: The owner’s manual contains safety, assembly, use and maintenance instructions. This product must be assembled by an adult who has read and understood these instructions. Keep the packaging away from children and dispose of all packaging before use.
-
Page 2: Table Of Contents
TABLE OF CONTENTS I. GENERAL SAFETY INSTRUCTIONS 1.1 Danger for Children 1.2 Risk of Injuries 1.3 Risk of Injuries 1.4 Assembly Advice II. SAFETY INSTRUCTIONS III. TOOLS REQUIRED FOR INSTALLATION IV. ASSEMBLY INSTRUCTIONS V. MAINTENANCE VI. WOOD ADVICE VII. WARRANTY... -
Page 3: General Safety Instructions
I. GENERAL SAFETY INSTRUCTIONS NOTE: This product is intended for outdoor domestic use only. DANGER FOR CHILDREN WARNING: No eating while using the product at the same time. • Children do not recognize potential dangers from this product. The unassembled product must be stored out of reach of children and pets. -
Page 4: Assembly Advice
ASSEMBLY ADVICE • The assembly of the product must be done carefully and by an adult. If in any doubt, ask a technically qualified person. • Before you start with the assembly, read the instructions carefully. • Remove all packaging materials and lay down all parts on an open space. This gives you an overview and simplifies the assembly procedure. -
Page 5: Safety Instructions
II. SAFETY INSTRUCTIONS • The safety instructions of the product should always be considered and obeyed. • Using the product may result in permanent injury such as paralysis, or even death. Falling off the product may lead to injuries, particularly to the back, neck or head. •... - Page 6 Consumer Information Sheet for Playground Surfacing Materials The US Consumer Product Safety Commission (CPSC) estimates that about 100 000 playground equipment-related injuries resulting from falls to the ground surface are treated annually in US hospital emergency rooms. Injuries involving this hazard pattern tend to be among the most serious of all playground injuries, and have the potential to be fatal, particularly when the injury is to the head.
-
Page 7: Tools Required For Installation
III. TOOLS REQUIRED FOR INSTALLATION These are the tools that are generally required for assembly of our outdoor products. These tools are not included with the outdoor product purchase. Level 24” Square Tape Measure Phillips Screw Driver Claw Hammer Drill Bits Cordless Drill or Electric Drill Drill Attachments:... - Page 8 1pc. 1pc. 2pcs. 1pc. 1pc. 1pc. 1pc. 1pc. 1pc. 1pc. 1pc. TOOLS REQUIRED FOR INSTALLATION...
- Page 9 1pc. 1pc. 4pcs. 2pcs. 2pcs. 11pcs. 11pcs. 8pcs. 3pcs. 2pcs. 4pcs. 1pc. 1pc. 8pcs. 1pc. 1pc. 1pc. 1pc. 1pc. 1pc. 1pc. 1pc. 3pcs. 1pc. TOOLS REQUIRED FOR INSTALLATION...
- Page 10 1pc. 4pcs. 3pcs. 4pcs. 1pc. M8 x 70 = 31 M8 x 80 = 6 M6 x 30 = 8 M3 x 20 = 4 M3.5 x 30 = 60 M3.5 x 35 = 65 M3.5 x 40 = 48 M3.5 x 50 = 32 M5 x 50 = 16 M5 x 100 = 10...
-
Page 11: Assembly Instructions
IV. ASSEMBLY INSTRUCTIONS Z1 = 1 STEP 1 H = 12pcs. STEP 2 G = 36pcs. ASSEMBLY INSTRUCTIONS... - Page 12 STEP 3 884mm 18mm A = 6pcs. Z = 6pcs. J = 2pcs. STEP 4 884mm 18mm A = 4pcs. Z = 4pcs. J = 2pcs. ASSEMBLY INSTRUCTIONS...
- Page 13 STEP 5 A = 5pcs. Z = 5pcs. J = 6pcs. K = 1pc. G = 8pcs. STEP 6 I = 16pcs. ASSEMBLY INSTRUCTIONS...
- Page 14 STEP 7 A = 6pcs. Z = 6pcs. STEP 8 B = 6pcs. Z = 6pcs. ASSEMBLY INSTRUCTIONS...
- Page 15 STEP 9 A = 4pcs. Z = 4pcs. STEP 10 A = 6pcs. Z = 6pcs. ASSEMBLY INSTRUCTIONS...
- Page 16 STEP 11 F = 61pcs. STEP 12 72.5mm 60mm E = 36pcs. ASSEMBLY INSTRUCTIONS...
- Page 17 STEP 13 73.5mm E = 12pcs. STEP 14 H = 20pcs. ASSEMBLY INSTRUCTIONS...
- Page 18 STEP 15 L = 3pcs. STEP 16 G = 4pcs. F = 4pcs. ASSEMBLY INSTRUCTIONS...
- Page 19 STEP 17 50mm 45mm E = 12pcs. D = 4pcs. K = 2pcs. STEP 18 ASSEMBLY INSTRUCTIONS...
- Page 20 STEP 19 C = 8pcs. Y = 8pcs. STEP 20 ASSEMBLY INSTRUCTIONS...
-
Page 21: Maintenance
V. MAINTENANCE WARNING: Please keep for future reference. We recommend regular maintenance to be conducted at the beginning of each season as well as at regular intervals during the usage session for your play equipment to ensure all main parts/fixings are tightly secured, well-oiled and intact to avoid failure, injury or hazards. -
Page 22: Wood Advice
In the unlikely event you feel that a part has a possible fault in the timber, please contact Lifespan Kids immediately with pictures of the parts so they can be reviewed. Please refer to Page 15 to get in touch with us. -
Page 23: Warranty
VII. WARRANTY AUSTRALIAN CONSUMER LAW All of our products come with a guarantee or warranty from the manufacturer. In addition, they come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. - Page 24 www.l if esp a nkids .c om .a u...
